Product Type	Built-in electric bain-marie
Brand	Vollrath
Model	FC4DH03208I
Use	Holding food hot (does not cook)
Pan compatibility	Gastronorm pans, max depth 6" (15.2 cm)
Power supply	Mains (rated voltage on nameplate)
Control	Rotary thermostat (0 to max)
Indicator light	Power indicator (lights up when heating)
Material	Stainless steel
Preheating	30 minutes at maximum temperature
Holding temperature	Minimum 60 °C (140 °F) for food safety
Cleaning	Daily, damp cloth and soapy water; remove bottom screen
Prohibited products	Steel wool, caustic cleaners, descalers
Electrical safety	Do not immerse, do not use extension cord
Thermal safety	Burn risk: hot surfaces, use gloves
Installation	By qualified personnel, on a flat horizontal surface
Warranty	Vollrath manufacturer warranty (non-domestic use)
Spare parts	Available on Vollrath.com
After-sales service	Contact Vollrath technical services (see manual)

Frequently Asked Questions - FC4DH03208I Vollrath

How to use the FC4DH03208I bain-marie?

Plug the appliance into an outlet matching the indicated voltage. Turn the thermostat to maximum to preheat for 30 minutes. Then place the Gastronorm pans containing already hot food (above 60 °C) and reduce the temperature to maintain heat. Never cook raw food.

What types of pans can I use?

Use only metal Gastronorm pans with a maximum depth of 6 inches (15.2 cm). Plastic pans are prohibited.

How to clean the appliance?

Unplug the appliance and let it cool. Remove the bottom screen of the compartment and wash it with soapy water. Clean the inside and outside with a damp cloth and soapy water, then rinse. Never use steel wool or caustic products.

What are the important safety precautions?

Do not immerse the appliance or use an extension cord. Do not spray liquids on the controls. The appliance becomes very hot – wear gloves. Keep it out of reach of children. Unplug before cleaning or moving.

Can I cook food with this bain-marie?

No, this appliance is designed only for holding already cooked food hot. It does not allow cooking raw food.

What to do if the appliance does not heat enough?

Check that the power supply voltage matches the nameplate. If the problem persists, contact Vollrath technical service – do not attempt to repair yourself.

How to install the built-in bain-marie?

Installation must be carried out by a qualified professional. Place the appliance on a flat horizontal surface and secure it using the provided wing screws. Plug it into a suitable grounded outlet.

Where to find spare parts?

Spare parts are available on the Vollrath.com website. For repairs, contact Vollrath technical services – never send the appliance directly.

What is the minimum holding temperature?

For food safety, keep hot foods at least 60 °C (140 °F). Use a thermometer to check regularly.

Does the warranty cover domestic use?

No, the Vollrath warranty applies only to commercial use. For full details, visit Vollrath.com.

USER MANUAL FC4DH03208I Vollrath

HotDrop-inswithDryWells

ThankyouforpurchasingthisVollrathequipment.Beforeoperatingthe equipment,readandfamiliarizeyourselfwiththefollowingoperating andsafetyinstructions.SAVETHESEINSTRUCTIONSFORFUTURE REFERENCE.Savetheoriginalboxandpackaging.Usethispackaging toshiptheequipmentifrepairsareneeded.

SAFETYPRECAUTIONS

Toensuresafeoperation,readthefollowingstatementsandunderstand theirmeaning.Thismanualcontainssafetyprecautionswhichare explainedbelow.Pleasereadcarefully.

WARNING

Warningisusedtoindicatethepresenceofahazardthatwillorcan causeseverepersonalinjuryordeath.

CAUTION

Cautionisusedtoindicatethepresenceofahazardthatwillorcan causeminorormajorpersonalinjuryifthecautionisignored.

NOTICE: Notice is used to note information that is important but not hazard-related.

Toreduceriskofinjuryordamagetotheequipment:

• This equipment must be installed by a qualified person.
- Useonlygroundedelectricaloutletsthatmatchtheratedvoltageon thenameplate.
NOTICE: Do NOT modify the chordor plug on the drop-in. Modifying any component may damage the drop-in or cause injury, and will void the warranty. Seethespecificationsheet on Vollrath.com forelectrical specifications.
- Donotuseanextensioncordwiththisequipment.Donotplugthis equipmentintoapowerstripormulti-outletpowercord.
- This equipment should only be used in a flat, level position.
- Donotspraythecontrolsortheoutsideofequipmentwithliquidsorcleaningagents.
- Keep the equipment and power cordaway from open flames, electric burners over excessive heat.
- Donotusefoodpansdeeperthan6"(15.2cm).
• Notforusewithplasticpans.
- Donotoperateequipmentifitisdamagedormalfunctioning.
•Donotoperateunattended
- Unplugandallowtheequipmenttocoolbeforecleaningormoving.
- Donotcleanthisequipmentwithsteelwool.

3D rendering of a rectangular industrial enclosure with six rectangular cavities and internal grating (no text or symbols visible)

ItemNo.No.ofWells
FC-4DH-01120-I	One
FC-4DH-01208-I
FC-4DH-01120-T
FC-4DH-01208-T
FC-4DH-02120-I	Two
FC-4DH-02208-I
FC-4DH-02120-T
FC-4DH-02208-T
FC-4DH-03120-I	Three
FC-4DH-03208-I
FC-4DH-03120-T
FC-4DH-03208-T
FC-4DH-04208-I	Four
FC-4DH-04208-T
FC-4DH-05208-I	Five
FC-4DH-05208-T
FC-4DH-06208-I	Six
FC-4DH-06208-T

FUNCTIONANDPURPOSE

This drop-in is intended and designed to hold containers of food at properserving temperatures. Hot food stations are not intended for designed to cook raw food to prepare food. Food must be prepared and placed in food stations at properserving temperatures. This equipment is not intended for household, industrial or laboratory use.

	CAUTION
	BurnHazardDonottouchhotfood,liquidorheatingsurfaceswhile equipmentisheatingoroperating.

NOTICE: Donotusefoodpansdeeperthan6"(15.2cm).

NOTICE: Donotuseplasticpans.

1. Plugelectrical power cord into a outlet that matches herated voltage on the name plate.
2. Turnthetemperature control to the maximum heat setting. Cover the well(s). Preheat for 30 minutes.
3. Placecontainers of hot food, above 140°F (60°C), intopreheated equipment.
4. Reduceheatsettingtoalevelthatwillmaintainasafeholding temperatureandmaintainfoodquality.

NOTICE:Monitorfoodtemperaturecloselyforfoodsafety. The UnitedStatesPublicHealthServicerecommendsthathot foodbeheldataminimumof140°F(60°C)tohelpprevent bacteriagrowth.

1. Use gloves, mittsorpotholderstoprotechands when removing hot food containers.

CLEANING

CAUTION

BurnHazard

Hotsurfacesandfoodcanburnskin.Allowthehotsurfacesto coolbeforehandling.

Tomaintaintheappearanceandincreasetheservicelife,cleanyour equipmentdaily.

NOTICE: Donotusecausticcleaning chemicals, steelwoolor commerciallimeremovalproductstocleantheequipment. Thoroughlyrinseequipmentwithwateraftercleaning.

1. Remove hot food containers. Use gloves, mittsorpotholder to protect hands
2. Turnthetemperaturecontroltothe "0" setting.
3. Unplugthedrop-in.
4. Allowthedrop-intocoolcompletely.
5. Removetheshieldfromthebottomofthewell.
6. Handwashtheshieldinsoapywater.
   7.Drytheshield.
7. Useadampclothorspongedippedinsoapywatertocleanthe insideofthewellandtheoutsideoftheequipment.
8. Useadampclothorspongetothoroughlywipeoffthesoapywater.

TROUBLESHOOTING

ProblemMightbeCausedByCourseofAction
Drop-indoesnotheattothe correcttemperature.	Loworincorrectvoltagetounit.	Verifythatvoltageratingonthedrop-inmatchesthesourcevoltage.If not,havealicensedelectricianinstallpropersourcevoltage.

Thispageintentionallyleftblank.

SERVICEANDREPAIR

ServiceablepartsareavailableonVollrath.com.

To avoid serious injury or damage, never attempt to repair the unit or replace a damaged power cord yourself. Do not send units directly to TheVollrathCompanyLLC.PleasecontactVollrathTechnicalServicesforinstructions.

When contacting Vollrath Technical Services, please be ready with the item number, model number (if applicable), serial number, and proof of purchaseshowingthedatetheunitwaspurchased.

WARRANTYSTATEMENTFORTHEVOLLRATHCO.L.L.C.

This warranty does not apply to products purchased for personal, family or household use, and The Vollrath Company LLC does not offer a written warranty top purchasers for such uses.

The Vollrath Company LLC warrants the products it manufactures or distributes against defects in materials and workmanship as specifically described in our full warranty statement. In all cases, the warranty runs from the date of the end user's original purchase date found on the receipt. Any damages from improper use, abuse, modification or damage resulting from improper packaging during return shipment for warranty repair will not be recovered under warranty.

Forcompletewarrantyinformation,productregistrationandnewproductannouncement,visitwww.vollrath.com.

Outperform every day."

www.vollrath.com

The VollrathCompany, L.L.C.

1236North18thStreet

Sheboygan, WI53081-3201U.S.A.

MainTel:800.624.2051or920.457.4851

MainFax:800.752.5620or920.459.6573

CustomerService:800.628.0830

CanadaCustomerService:800.695.8560

TechnicalServices

[e-mail]

InductionProducts:800.825.6036

CountertopWarmingProducts:800.354.1970

Toasters:1-800-309-2250

AllOtherProducts:800.628.0832

3D rendering of a rectangular industrial or electrical enclosure with multiple recessed grating and internal channels (no text or symbols visible)

Num.d'art.Compartiments
FC-4DH-01120-I	Un
FC-4DH-01208-I
FC-4DH-01120-T
FC-4DH-01208-T
FC-4DH-02120-I	Deux
FC-4DH-02208-I
FC-4DH-02120-T
FC-4DH-02208-T
FC-4DH-03120-I	Trois
FC-4DH-03208-I
FC-4DH-03120-T
FC-4DH-03208-T
FC-4DH-04208-I	Quatre
FC-4DH-04208-T
FC-4DH-05208-I	Cinq
FC-4DH-05208-T
FC-4DH-06208-I	Six
FC-4DH-06208-T

FONCTIONETOBJET
