Product Type	Portable battery (power bank)
Brand	Hama
Model	Fabric 10 00187260
Battery capacity	10000 mAh / 37 Wh
Typical capacity	10250 mAh / 37.93 Wh
Useful capacity	6657 mAh (at 5 V, 2 A)
Battery type	High-density lithium-polymer, 3.7 V
Input (USB-C)	5 V, 3 A
USB-A output	5 V, 2.4 A
USB-C output	5 V, 3 A
Maximum total output	5 V, 3 A
LED indicators	4 LEDs (each LED = 25% capacity)
Function button	On/off, capacity check (single press), power off (double press)
Functionality	Charge optimization (automatic device recognition)
Protection	Against overcharge, deep discharge, short circuit and overheating
Package contents	Power bank, USB-C cable, user manual
Cleaning	Lint-free cloth slightly damp, without harsh detergent
Storage	Recharge at least once every three months, avoid extreme temperatures
Recycling	Do not dispose with household waste, follow WEEE directive
Warranty	Excluded in case of non-compliance with safety instructions

Frequently Asked Questions - Fabric 10 00187260 HAMA

How to recharge the Fabric 10 power bank?

Connect the supplied USB-C cable to the USB-C port (IN 5V/3A) of the power bank and to a suitable USB charger. The charging cycle starts automatically and stops at full capacity. The LEDs indicate the level: each LED = 25%.

What devices can I charge with this battery?

You can charge smartphones, tablets and other USB-compatible devices. The USB-A output delivers 5V/2.4A and the USB-C output 5V/3A. The total current must not exceed 3000 mA.

What do the capacity indicator LEDs mean?

Each LED corresponds to 25% of remaining capacity. When all four LEDs are lit, the battery is fully charged. During charging, the LED for the current level flashes.

How to turn off the power bank?

Press the button twice until the LEDs turn off. The power bank also automatically turns off if no device is connected.

Can I use the power bank while it is recharging?

No, it is not recommended to charge and discharge the power bank simultaneously. This could reduce the charging current and damage the device.

What is the actual available capacity?

The useful capacity is 6657 mAh at 5V/2A. The nominal capacity of 10000 mAh corresponds to the internal battery voltage (3.7V). The difference is due to voltage conversion.

What to do if the power bank stops working?

Check the cable and charger. If the problem persists, do not attempt to repair it yourself. Contact a qualified technician or Hama customer service.

How to maintain and store the portable battery?

Clean with a damp cloth without detergent. Store in a dry place at moderate temperature. Recharge it at least once every three months if not in use.

Can I take this battery on a plane?

Yes, batteries of 10000 mAh (37 Wh) are generally allowed in cabin. However, check your airline's regulations as lithium-ion batteries are subject to restrictions.

How to recycle the power bank at end of life?

Do not dispose of the device with household waste. Take it to an electronic waste collection point or return it to a retailer in accordance with the WEEE directive.

USER MANUAL Fabric 10 00187260 HAMA

Line drawing of a smartphone showing front, back, and side panels (no text or symbols)

OperatingInstructions

Bedienungsanleitung

Moded'emploi

Instruccionesdeuso

Thankyouforchoosinga H amaproduct.

Take your time and read the following instructions and information completely. Please keep these instructions in a safe place for future reference. If you sell the device, please pass these operating instructions onto thenewowner.

1. ExplanationofWarningSymbolsandNotes

Warning

This symbol is used to indicate safety instructions or to draw your attention to specific hazards and risks.

Note

This symbol is used to indicate additional information or important notes.

High-density lithium-polymercells

This product contains high-density lithium-polymer cells. High-density cells were developed mainly forsmartphoneproductioninordertomeetthehighcapacityandperformancedemandsusinga minimum amount of space. This new generation of lithium-polymer cells enables a lightweight and compactdesignalongwitha c comparativelyhighcapacity.

2.PackageContents

• PowerPack"Fabric10",10000mAh
- U SB-Cable
• Theseoperatinginstructions

3. SafetyNotes

• T heproductisintendedforprivate,non-commercialuseonly.
• U setheproductforitsintendedpurposeonly.
- Protect the product from dirt, moisture and overheating, and only use it in a dry environment.
- Do not use the product in the immediate vicinity of heaters or other heat sources or in direct sunlight.
- Keep this product, as all electrical products, out of there each of children!
• D o n otdroptheproductanddonotexposeittoanymajorshocks.
- Do not operate the product outside the power limits given in the specifications.
- Do not open the device or continue to operate it if it becomes damaged.
- D isposeofpackagingmaterialimmediatelyaccordingtolocallyapplicableregulations.
- Since the battery is integrated and cannot be removed, you will need to dispose of the product as a w hole.Dothisincompliancewiththelegalrequirements.
- Do not modify the product in any way. Doing so voids the warranty.
- Do not use the product in areas where the use of electronic devices is not permitted.
- Do not attempt to service or repair the product yourself. Leave any and all service work to qualified experts.
- Do not throw the battery or the product into fire.
- Do not tamper with or damage/heat/disassemble the batteries/rechargeable batteries.

4.Operation

4.1 ChargingthePowerPack

Warning-Battery

• Do not charge the power pack using your PC or the notebook. The charging currents can damagetheUSBportofthePC/notebook.
• O nlyusesuitablechargingdevicesorUSBconnectionsforcharging.
• As a rule, do not charge devices or USB connections that are defective and do not try to repair themyourself.
• Do not overcharge the product or allow the battery to completely discharge.
• A voidstoring, chargingorusingthedeviceinextremetemperaturesandextremelylow atmosphericpressure (forexample,athighaltitudes).

• When stored over a long period of time, batteries should be charged regularly (at least every three months).

• B eginchargingthepowerpackbyconnectingtheincludedUSB-Ccabletothepowerpack's USB-C (IN 5V/3A) port and to a suitable USB charger. Please refer to the operating instructions for theUSBchargerused.

• C hargingbeginsandendsautomatically.
• Charge the Power Pack fully before using it for the first time.

Note-Capacity

• T hecapacityisalwaysshownwhenthePowerPackischarging.
- Each status LED corresponds to 25% of the capacity. When an LED is permanently illuminated, this indicates that this capacity level has already been reached. The Power Pack is charged to at least 75% if three LEDs are illuminated, and the fourth is flashing.
- I fallfourstatusLEDslightup, thefullcapacityisavailable.
- Press the button of the Power Pack to switch it on and to check its current capacity.
• To switch the power pack off, press the button twice until the status LEDs go out.

4.2Chargingterminaldevices

Warning- Connectingterminaldevices

• Before connecting a terminal device, check whether the power output of the charger can supply sufficientpowerforthedevice.
• Ensure that the total power consumption of the connected terminal device does not exceed 3000mA.
• P leaserefertotheinstructionsintheoperatingmanualofyourterminaldevice.
• It is essential that you observe these specifications and the safety instructions regarding the powersupplyofyourdevices.
  • T hepowerpackmustnotbechargedanddischargedatthesametime!
• P leasedonotusetheUSBandUSB-Coutputssimultaneouslyforcharging,asthisreducesthe charging current considerably. As a result, the charging time is greatly increased and the power packmaybeoverloaded.

Warning

• N everconnectthechargingcableofthePowerPacktoboththeinputandtheoutputofthe PowerPackatthesametime.Thiscoulddamagethebattery.
• Do not connect any terminal devices while the Power Pack is charging. This could damage the PowerPackandtheconnecteddevice.
• Connect the included USB-A to USB-C charging cable to the USB port on the power pack (OUT 5V/2.4A) and to the USB-C port on your terminal device (mobile phone, smartphone, etc.).
• The Micro-USBcharging/connecting cable included may not be suitable for the USB connection on your terminal device. In this case, use the USB cable that was included with your terminal device.
• When using the USB-C output (OUT 5V/3A) for charging, please connect a suitable USB-C charging cable to the power pack's USB-C output and to the port of your terminal device.
• Charging begins automatically. The status LEDs show the remaining capacity when the Power Pack ischarging.
• The current battery status of your terminal device will appear on this device.
• Press the button on the power pack twice to stop charging and switch it off. The status LEDs shouldswitchoff.
• The Power Pack will automatically switch off if it is not connected to a terminal device.

Note- O ptimisedcharging

OptimisedchargingmeansthatthePowerPackrecognisestheconnectedterminaldeviceand suppliesitwiththeoptimalcurrenttominimisechargingtime.Pleasenotethatthemaximum poweroutputofthepowerpackis3000mA.

5. Care and Maintenance

Only clean this product with a slightly damp, lint-free cloth and do not use aggressive cleaning agents.

6.WarrantyDisclaimer

Hama GmbH & Co KG assumes no liability and provides no warranty for damage resulting from improper installation/mounting, improper use of the product or from failure to observe the operating instructionsand/orsafetynotes.

7.TechnicalData

USB-Cinput5 V 3 A	---
USB-A o utput5 V 2.4A	---
USB-Coutput5 V 3 A	---
Outputtotal5 V 3 A (max.)	---
Batterytype3.7V/Li-Po
Min.capacity10000mAh/ 3 7 W h
Typ.capacity10250mAh/ 3 7.93Wh
UsableCapacity*6657mAh@ 5 V 2 A	---

* T heusablecapacityisthecapacitythatcanbedrawnfromtheoutputsockets,measuredat5V output voltage and a draw current of 2A.

8. Recycling Information

Noteonenvironmentalprotection:

AftertheimplementationoftheEuropeanDirective2012/19/EUand2006/66/EUinthenationallegalsystem,thefollowingapplies:Electricandelectronicdevicesaswellas batteries must not be disposed of with household waste. Consumers are obliged by law to returnelectricalandelectronicdevicesaswellasbatteriesattheendoftheirservicelives tothepubliccollectingpointssetupforthispurposeorpointofsale.Detailstothisare

defined by the national law of the respective country. This symbol on the product, the instruction manual or the package indicates that a product is subject to these regulations. By recycling, reusing the materials or other forms of utilising old devices/batteries, you are making an important contribution to protecting ourenvironment.
