Evo 2 in 1 2764 - Vacuum Cleaner ARIETE - Free user manual and instructions

Product type	2-in-1 stick vacuum (stick + handheld)
Brand	Ariete
Model	Evo 2 in 1 2764
Use	Household use only
Power supply	Mains (electric cord)
Rated power	600 W (estimated)
Cord length	5 m (estimated)
Container capacity	0.5 L (estimated)
Filter type	Washable filter
Number of filters	1 filter + 1 holder
Usage mode	Electric stick and handheld vacuum
Included accessories	Floor/carpet brush, small brush nozzle, crevice nozzle, cord winder
Floor selector	Yes (hard floors/carpets)
Total weight	4 kg (estimated)
Dimensions (L x W x H)	Not specified
Color	Not specified
Maintenance	Empty the container after each use; wash the filter with clean water; clean the body with a damp cloth
Safety	Turn off before assembly/disassembly; do not immerse; keep away from children; do not vacuum liquids or hot objects
Warranty	Not specified
Repairability	Contact an authorized after-sales service for any defects

Frequently Asked Questions - Evo 2 in 1 2764 ARIETE

How to use the vacuum in stick mode?

Make sure the handheld part (C) is properly assembled on the body (M). Plug in the appliance, press the on/off button (B), and tilt the handle back to clean floors with the brush (L).

How to detach the handheld vacuum?

Lock the handle of the body (M), press the release button (A), and extract the handheld vacuum with its cord.

What accessories are included?

The vacuum comes with a floor/carpet brush (L), a small brush nozzle (G), and a crevice nozzle (H).

How to empty the dust container?

Turn off and unplug the appliance. Extract the handheld vacuum, then press the release button to remove the container (F). Empty it into a trash bin and wash if necessary.

How to clean the filter?

Remove the container, then the filter (D) and its holder (E). Wash the filter only with clean water, without soap. Let it dry completely before reassembling.

Can I vacuum liquids with this appliance?

No, never vacuum flammable or combustible liquids. The appliance is designed only for dry waste.

How to wind the power cord?

After use, wind the cord around the rear housing (N) located on the body of the appliance.

What to do if suction power decreases?

Check that the container is not full and the filter is not clogged. Clean the filter and empty the container if necessary.

Can the vacuum be used by children?

Children aged 8 years and older can use it under adult supervision, after receiving safety instructions. Do not let children play with the appliance.

How to select hard floor or carpet mode?

Use the selector (I) located on the brush to adjust brushing according to floor type: symbols for hard floors and carpets.

USER MANUAL Evo 2 in 1 2764 ARIETE

De' Larghi Appliances St

Line drawing of a vacuum cleaner (no text or symbols)

Scopa elettrica

Stick vacuum cleaner

Fig. 1

Fig. 6 Fig. 7

2.1.3

Fig. 8 Fig. 9

Fig. 2 Fig. 3

Fig. 10 Fig. 11

Fig. 4 Fig. 5

AVVERTENZE IMPORTANTI

LEGGERE QUESTE ISTRUZIONI PRIMA DELL'USO.

The necessary precautions must be taken when using electrical appliances, and these include the following:

Never place the appliance on or close to sources of heat.1.

Never use the appliance in proximity to people or lift to eye level, ear level, etc... 2. as there is a serious risk of accident.

Never leave the appliance exposed to the elements (rain, sun, etc....).3.

Make sure that the power cord does not come into contact with hot surfaces.4.

This appliance is not intended for use by persons with reduced physical, sensory 5. or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

This appliance can be used by children aged 8 years and up if properly monito-6. red or if you have received instructions regarding the appliance safe use and if they understand the dangers involved.

Children shall not play with the appliance.7.

Cleaning and maintenance by the user must not be carried out by children unless 8. they are older than 8 years and are monitored during the operation.

Never insert any items in the openings of the appliance and do not allow items 9. to obstruct air flow.

Keep openings free from dust, fluff, hair, etc.10.

Never use the appliance without the filter.11.

Do not use to clean up hot items or any items that are giving off smoke or which 12. are burning, such as cigarettes, matches or hot ash.

Never pick up flammable or combustible materials (volatile fluids, petrol, kero-13. sene, etc.) or use where there are large amounts of water.

Never use the appliance in closed environments or where there might be fumes 14. from oil-based paints and varnishes or solvents, waterproofing treatments, flammable powders or other toxic or explosive fumes.

Never pick up toxic materials (bleach, ammonia, drain cleaners, petrol, etc.).15.

NEVER PLACE THE APPLIANCE BODY, PLUG OR POWER CORD IN WATER 16. OR OTHER LIQUIDS; ALWAYS WIPE CLEAN WITH A DAMP CLOTH.

1. SWITCH OFF THE APPLIANCE AFTER USE AND BEFORE FITTING OR REMOVING SINGLE PARTS AND BEFORE CLEANING.

Always make sure that your hands are thoroughly dry before using or adjusting 18. the switches on the appliance, or before touching the power plug or power connections.

To unplug the appliance, grip the plug and remove it directly from the power 19. socket. Never pull the power cord to unplug the appliance.

Never use the appliance if the power cord or plug are damaged or if the appli-20. ance itself is faulty; in this case, take it to your nearest Authorised Assistance Centre.

To prevent any risks, if the power cord is damaged, it must be replaced by the 21. manufacturer, its Technical Assistance Service or a similarly qualified person. This appliance is designed for HOME USE ONLY and may not be used for com-22. mercial or industrial purposes.

This appliance conforms to the 2014/35/EU and EMC 2014/30/EU directives.23.

Any changes to this product that have not been expressly authorised by the 24. manufacturer may lead to the user's guarantee being rendered null and void. In the event that you decide to dispose of the appliance, we advise you to make 25. it inoperative by cutting off the power cord. We also recommend that any parts that could be dangerous be rendered harmless, especially for children, who may play with the appliance or its parts.

Packaging must never be left within the reach of children since it is potentially 26. dangerous.

1. To dispose of product correctly according to European Directive 2012/19/EU, please refer to and read the provided leaflet enclosed with the product.

DO NOT THROW AWAY THESE INSTRUCTIONS

APPLIANCE DESCRIPTION (Fig. 1)

A Unlocking buttons

B ON/OFF button

C Removable body / handheld vacuum cleaner

D Filter

E Filter support

F Dust container

G Vacuum cleaner with brush

H Crevice nozzle

I Selector for hard floors / carpets

L Brush for floors / carpets

M Appliance body

N Cord winder

O Button for handle tilting

The product works in two modes:

1 as a standard electric broom through the brush to clean carpets / floors (L) and, by tilting the appliance body (M) backwards, in the normal position for use,
2 as handheld vacuum cleaner, by taking off the removable part (C), suitable for cleaning surfaces and working table through the vacuum cleaner with the brush (G) or the crevice nozzle (H) in case of narrow spaces.

ATTACHMENTS

Brush for floors / carpets (L)

• Suitable for cleaning both of wide spaces and corners hard to reach.
• When cleaning carpets and though floors, never use the brush. The brush is equipped with wheels to facilitate the smoothness on every kind of surfaces. Select the required position of the bristles by pressing the lever at the end of the brush. To lift the brush, press the switch lever marked with the symbol ____ of the carpet.
• For a better cleaning and keeping of the smooth floors, as PVC, parquet or tiles, it is recommended to use the brush. To remove the brush, press the switch lever marked with the symbol smooth floors.

Vacuum cleaner with brush (G) - for handheld vacuum cleaner only

Suitable for cleaning surfaces and working tables, as well as couches and fabrics.

Crevice nozzle (H) - for handheld vacuum cleaner only

Suitable for cleaning corners, crevices or areas hard to reach.

HOW TO OPERATE

• Plug the appliance into a mains power socket.
• With the handheld part (C) properly assembled in the appliance body (M), press the switching on button (B) situated on the removable body (C) and tilt the handle backwards in the standard position of use (Fig. 2).
• Clean the wide surfaces by pushing with the brush (L) forwards.
  This allows the vacuum cleaner to collect the fragments and the dirt on the floor.
• For cleaning the corners and small surfaces, rotate the broom in the opposite direction. The fragments and dirt can be moved to be collected.

ATTENTION: switch the broom off immediately when something remains stuck inside the brush, as some fabric, carpet fringes, etc.

- After cleaning, switch the broom off by pressing the switching off button (B) once more.

Handheld vacuum cleaner

• By holding the handle of the appliance body (M), press the unlocking button (A) and remove the handheld vacuum cleaner complete with power cord (Fig. 3).
• At the end of the dust container (F), apply the required attachment (Fig. 4); press the switching on button (B) to start the appliance by means of the apposite handle (Fig. 5).
• For positioning the handheld vacuum cleaner back into the appliance body (M), remove the

installed attachment first, by removing it outward and then position the end of the dust container (F) in the lower side of the apposite housing in the appliance body (M) and slightly push backward the handheld vacuum cleaner until it clicks into place (Fig. 6).

WARNING: Make sure the handheld vacuum cleaner is properly installed before proceeding with a new use.

CLEANING

• Clean the appliance body (M) and the removable body (C) by using only a damp cloth with mild detergent, if necessary.
  Proceed with care to prevent any kind of liquid from getting into the appliance.
  Never use strong cleaning agents (stain removers, solvents) that may corrode the plastic.

How to empty the dust container (F)

WARNING: Clean the dust container (F) and the filter (D) in due time. The suction power is reduced when the container is full or the filter is obstructed.

• From the back of the appliance, check whether the dust container (F) is full (Fig. 7).
• Remove the handheld vacuum cleaner as previously described.
• Press the unlocking button and remove the complete container (Fig. 8).
• Remove the filter (D) outwards (Fig. 9) and the related support (E) to clean them.

WARNING: Wash the filter (D) only with fresh water without using soap or detergents.

• Empty the dust container (A) into an apposite plastic bag and wash it with water, if necessary.
• Let the components dry and reassemble.

WARNING: Properly assemble the support (E), the filter (D), and the dust container (F) before starting the appliance.

• Reassemble the appliance and store it using the apposite rear cord winder (N) - Fig. 10.
• If necessary, the handle can be tilted back by pressing the apposite button (O), Fig. 11.
