USER MANUAL HG02595 MELINERA

On/off button20 GB/IE Technical data Mains adapter + Halloween LED Projector / Christmas LED Projector: Total power consumption: approx. 5 W Halloween LED Projector / Christmas LED Projector: Operating voltage: 230 V

, 50 Hz Degree of protection: IP44 (Splashproof) Model No. HG02460 (Halloween LED Projector), HG02595 (Christmas LED Projector) TÜV SÜD / GS certified. Mains adapter: Input voltage: 220–240 V

50–60 Hz Output voltage: 12 V , 6 W Protection class: / II Degree of protection: IP44 (Splashproof) Mains adapter (Model No.: JT-DC12V6W-H1-IP44) SGS GS certified. Included items 1 Halloween LED Projector / Christmas LED Projector 1 Mains adapter 1 Ground spike with screw 1 Operating instructions21 GB/IE Safety information

AND INSTRUCTIONS IN A SAFE PLACE

IN CASE YOU NEED TO REFER TO THEM AGAIN IN THE FUTURE! Always keep children away from the product. This product is not a toy and should not be played by children. Children are not able to understand the dangers that can occur when handling this product. This product can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabili- ties or lack of experience and knowledge if they have been given supervision or instruction concerning use of the product in a safe way and understand the hazards involved. Children shall not play with the product. Cleaning and user maintenance shall not be made by children without supervision. Ensure that the product is installed by suitably experienced or qualified persons only. CAUTION! RISK OF OVERHEATING! Do not operate the product inside the packaging. After use, keep the product in the packaging to prevent unwanted damage.22 GB/IE Do not pull the mains cable and make sure it is laid down properly so that no one walks or trips over it. DANGER OF INJURY! Make sure that when the LED projector is removed, the ground spike is also removed so that it is not a hazard (eg tripping). Do not attach any other objects to the product. This product must not be used without properly installed. Avoid the danger of death from electric shock! Before use, ensure that the mains voltage available is the same as the required operat- ing voltage for the product (220–240 V

Before connecting the product to the mains you should always check the lamp body

and the mains adapter

for any damage. Never use the product if you discover that it is damaged in any way. This mains cable of the product is nonreplace- able. Hence if it becomes damaged you must dispose of the entire product. Never open any of the electrical parts or insert any kind of object into them. Protect the mains cable from sharp edges, mechanical loads and hot surfaces. Do not install with sharp fasteners or nails. Always unplug the mains adapter

from the socket before installation, dismantling or cleaning.23 GB/IE Never touch the connection plug

of the product or the product itself with wet hands. If the product is not in use for any length of time (e.g. holidays), disconnect it from the power supply. If you have any questions about the product or are unsure about any of its aspects, please seek the advice of an electrical equipment specialist. Only use the product with the supplied mains adapter

for the type (Model No.: JT-DC12V6W-H1-IP44); all warranty claims will otherwise expire. The illuminants are not replaceable. If the illuminants fail at the end of their lifes, the entire product must be replaced. Please note that the mains adapter continues to draw a small amount of power even if the product is turned off as long as the mains ad

apter is plugged into a power outlet. To switch the product off completely, unplug the mains adapter from the socket. Before use Note: Remove all packaging materials from the product.24 GB/IE Setting up the product Take out locking screw

screwing in anti-clockwise direction (fig. A). Use locking screw

deep into the ground, lawn or flower bed (indoor or outdoor) for it to be stable (Fig. D). Note: For better projection performance, suggest to place the product at least 1 meter away from the projection surface (wall, ceil- ing, etc.). Insert the connection plug

of the LED spot- light into the socket of the mains adapter

Note: Lay the cable so that tripping is avoided. Turn the plug cap

in clockwise direction to fix the connection (fig. C). Insert the mains adapter

into the mains socket. The product is ready to use. Please note that the mains adapter

contin- ues to draw a small amount of power even if the product is switched off as long as the mains adapter

is plugged into a power outlet. To switch the product off completely, unplug the mains adapter

from the socket.25 GB/IE Switching on/off and timer function The on/off button

has below three functions. After inserting the mains adapter, the product lights up: Press once The on/off button

will turn into green light, and timer is activated. The product lights up for 6 hours and will be followed by a subsequent pause of 18 hours. Afterwards, the product will light up again at its designated turn on time for 6 hours followed by a subse- quent pause of 18 hours. Press twice The product is switched off. Press three times The product is switched on permanently.

out of the mains socket.

CAUTION! DANGER OF ELECTRIC

SHOCK! For reasons of electrical safety the product must never be immersed in water.26 GB/IE Do not use any solvents, petrol or similar items. This would damage the product. Clean the product regularly with a dry, lint- free cloth. Use a slightly dampened cloth to remove more stubborn dirt.

Disposal The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities. The Green Dot is not valid for Germany.
