Product Type	External Hard Drive Enclosure
Brand	Tripp Lite
Model	U357-025-UASP
Disk Compatibility	2.5-inch SATA hard drives (HDD) and SSDs, max height 9.5 mm
Host Interface	USB 3.0 SuperSpeed (compatible with USB 2.0 and 1.1)
Max Data Transfer Rate	USB 3.0: 5 Gbps
UASP Protocol	Supported (requires compatible host controller)
Power	Via USB, no external power required
LED Indicator	Blue: power and data access
Power Management	Sleep mode after 30 minutes of inactivity
Max Supported Capacity	Tested up to 3 TB
Operating Temperature	10 to 50 °C
Operating Humidity	10 to 80% RH
Warranty	1 year (limited)
Package Contents	Enclosure, USB 3.0 Type-A to Micro-B cable (0.61 m), HDD/SSD pad, storage sleeve, user manual
OS Compatibility	All USB operating systems
System Requirements	Available USB port (USB 3.0 recommended), UASP host controller for UASP performance

Frequently Asked Questions - U357025UASP Tripp Lite

What types of hard drives are compatible with the U357-025-UASP enclosure?

The enclosure accepts 2.5-inch SATA hard drives (HDD) and SSDs, with a maximum height of 9.5 mm. It is compatible with SATA I (1.5 Gbps), SATA II (3 Gbps) and SATA III (6 Gbps) standards.

Do I need to install a driver to use this enclosure?

No, the enclosure is plug-and-play. No driver or software is required on standard USB operating systems.

How do I install a hard drive in the enclosure?

Slide the cover to expose the tray, connect the drive to the SATA connector by tilting it slightly, then close the cover. Handle the drive carefully to avoid electrostatic discharge.

Does the enclosure support UASP?

Yes, it supports the UASP (USB Attached SCSI Protocol) for faster transfers, provided your computer has a UASP-compatible host controller.

What is the maximum supported hard drive capacity?

The enclosure has been tested with drives up to 3 TB. It may support higher capacities if drives become available.

Does the enclosure need external power?

No, it is powered directly via the USB port. No external power source is required.

How do I format a new drive in this enclosure?

If the drive is not formatted, use your operating system's disk management utility (e.g., Disk Management on Windows, Disk Utility on macOS) to initialize, partition, and format the drive before use.

Does the enclosure have a sleep function?

Yes, after 30 minutes of inactivity, the enclosure automatically enters sleep mode to save power. It wakes up as soon as activity resumes.

What is the warranty for this enclosure?

Tripp Lite offers a one-year limited warranty from the date of purchase, covering defects in materials and workmanship.

Can I use this enclosure with a longer USB cable?

It is recommended to use the included cable (0.61 m) or quality USB 3.0 cables to avoid signal loss. USB 3.0 extension cables (U324 series) are available as an option.

USER MANUAL U357025UASP Tripp Lite

USB 3.0 SuperSpeed to 2.5” SATA Hard Drive Enclosure

Model: U357-025-UASP

Espanol 7 • Français 13 • Pycckn 19

PROTECT YOUR INVESTMENT!

Register your product for quicker service and ultimate peace of mind.

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

www.triplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA www.triplite.com/support

Copyright © 2017 Tripp Lite. All rights reserved.

Package Contents

U357-025-UASP
- USB 3.0 Type-A to Micro-B Cable, M/M, 2 ft.
HDD/SSD Pad
Product Storage Sleeve
- Owner's Manual

Product Features

Supports 2.5" SATA Hard Disk Drives (HDD) and Solid State Drives (SSD)
- Compliant with SATA III (6 Gbps), SATA II (3 Gbps) and SATA I (1.5 Gbps) drives
Supports SATA hard drives up to 3 TB; will support higher capacity drives when available
Supports USB 3.0 data transfer rates up to 5 Gbps
- Backward compatible with USB 2.0 and 1.1
- Features UASP (USB Attached SCSI Protocol) to allow your hard drive to perform significantly faster when connected to a UASP-enabled host controller
- Slim design is perfect for travel; tucks into laptop bag when not in use
- Hibernation mode allows unit to go to sleep after 30 minutes of inactivity; unit wakes up when activity resumes
- Plug-and-play; no external power supply, software or drivers required

System Requirements

• Computer with available USB port (USB 3.0 required to achieve USB 3.0 data transfer rates)
• UASP-enabled host controller required to achieve UASP performance
• 2.5" SATA Hard Disk Drive (HDD) or Solid State Drive (SSD) with 9.5 mm maximum height
• Compatible with all USB-enabled operating systems

Optional Accessories

U324-Series USB 3.0 A/A Extension Cables
U326-Series USB 3.0 Micro-B Cables

Notes:

• HDD/SSD drives are sensitive to static electricity and must be handled properly to avoid the risk of data loss. Always handle your HDD/SSD drive with caution by wearing an anti-static strap (such as Tripp Lite P999-000) or by touching a grounded metal surface to discharge yourself of static electricity prior to touching or handling the drive.
• When disconnecting a connected drive, follow the proper disconnection steps of your operating system to safely disconnect. Removing the drive prior to proper disconnection can result in loss or corruption of data stored on the drive.

• If your SATA drive has not yet been formatted, format it using your computer's disk management utility in order to copy and access files.

• Slide the cover off the unit to expose the hard drive tray and SATA connector.

• Connect the drive by inserting it into the SATA connector. Ensure the drive is kept at a low angle to minimize stress on the connector.
• When the drive is fully inserted, slide the cover back into place to protect the drive from dust and other contaminants.
• Connect the included USB 3.0 Micro-B cable between the unit and computer.
• Your drive is now ready for use. The blue activity LED will flash to indicate data transfer is taking place.

Specifications:

Drive Connection 22-Pin SATA Data + Power

USB Connection USB 3.0 Micro-B

LED Blue: Power and Data Access

Maximum Data Transfer Rate 5 Gbps

Maximum Drive Capacity Tested up to 3 TB

Operating Temperature 50° to 122° F (10° to 50°C)

Operating Humidity 10% to 80% RH

Warranty and Product Registration

1-Year Limited Warranty

TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of one (1) year from the date of initial purchase. TRIPP LITE's obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. To obtain service under this warranty, you must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or an authorized TRIPP LITE service center. Products must be returned to TRIPP LITE or an authorized TRIPP LITE service center with transportation charges prepaid and must be accompanied by a brief description of the problem encountered and proof of date and place of purchase. This warranty does not apply to equipment, which has been damaged by accident, negligence or misapplication or has been altered or modified in any way.

EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTYES, EXPRESS OR IMPLIED, INCLUDING WARRANTYES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any costs, such as lost profits or revenue, loss of equipment, loss of use of equipment, loss of software, loss of data, costs of substitutes, claims by third parties, or otherwise.

Product Registration

Visit www.triplite.com/warranty today to register your new Tripp Lite product. You'll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*

• No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

Warranty and Product Registration

FCC Notice, Class B

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the user's authority to operate this equipment.

WEEE Compliance Information for Tripp Lite Customers and Recyclers (European Union)

Under the Waste Electrical and Electronic Equipment (WEEE) Directive and implementing regulations, when customers buy new electrical and electronic equipment from Tripp Lite they are entitled to:

• Send old equipment for recycling on a one-for-one, like-for-like basis (this varies depending on the country)
• Send the new equipment back for recycling when this ultimately becomes waste

Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life support equipment or to significantly affect its safety or effectiveness is not recommended.

Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.

Manufacturing Excellence.

1111 W. 35th Street, Chicago, IL 60609 USA • www.triplite.com/support

1111 W. 35th Street, Chicago, IL 60609 EE UU www.triplite.com/support

1111 W. 35th Street, Chicago, IL 60609 USA www.triplite.com/support

Manufacturing Excellence.

1111 W. 35th Street, Chicago, IL 60609 USA • www.triplite.com/support

PykoBODCTBO NOIb30BaTeJia

Kopnyc对于我们能击Kor0dNcKa cpa3bemamn USB 3.0 SuperSpeed n2.5" SATA

Modélb: U357-025-UASP

1111 W. 35th Street, Chicago, IL 60609 USA www.triplite.com/support

Oxpanyetca abTOpcknmpaBOM © 2017 Tripp Lite. Iepeneuatka zanpeuaetc.

CopejxHMOe ynaKOBKn

• U357-025-UASP
  Ka6eBcpa3bemamn USB 3.0 Type-A n Micro-B, wTeKeP/wTeKeP, dInHa 0,6 M
• Поставka對於жecTKOrOДиСka(HDD)/ТВердотьного наkonnteя(SSD)
  -Чеклдяхранець.
  -PykoBOdCTBO nOJIb3OBaTeJIA

XapakTepnCTnKn npOdyKTa

• Пдержka 2,5-юшовix кесскOB SATA (HDD) и Тьердотелььхн hakonnteel (SSD)
• CoBmecTmocTb c duckamn SATA III (6Γ6nt/c), SATA II (3Γ6nt/c) n SATA I (1,5Γ6nt/c)
• PoiDJIepKKa JecTKx DNCKOB SATA emKOCTbIO Do 3 TB; noIepeKKa DNCKOB 6oJIbWei emKocTn 6yJeT oBeCneuBaTbcra npu nOABHeHn TaKOBbIX
• Побдержka ckopocteи петачдддддддддддддддддддддддддддддддддддддддддддддддддддддддддддддддддддддддддддддддддддддддддддддддддддд徳с USB 3.0
• 06paTHaRa COBMeCTnMoCTb CnHTepfeycAmu USB 2.0 n 1.1
• Bo3moJHoCTb IcnoIb3OBAHnI npToKoJa UASP (USB Attached SCSI Protocol), 06ecneuBaIoUeIero 3HaunTeIbHo 6oJIeB blicKoE 6bICTpoJeIcTBHe JceTkoI OicKa npi nodkloueHnn K XocT-KOHTrpOpIepy c noIdepXkOu UASP
• I3aHna HnealbHO noXoHT B KaueCTBe DOpOxHOrO yctpoiCTBa, JERKO NomeuaBcB Cymky nIopTaTUBHOrO KOMnbIOTepa B TO BpeM, KOrDa OHO He NcNoB3yeTcA
• Pexim rI6epHaun oBecneuBaet Bo3MOxHocTb nepexoJa yCTpoiCTBa B pexim Cha no nCTeueHm 30 mHyT OTCyTcBnA kTINBHOCTn POJb3OBATeJ; pnB O3O6HOBJeHm AKTNBHOCTn yCTpOJCTBO BO3BpaJaeTcB pa6Ouyn peXIM
• Поклоченье по Тхонори Plug-and-Play — OTCyTCTBNE Heo6xOIMOCTN BO BHeHem Источни Кптаня, пограмном обесneyн Или драьерax

CnCTeMHbIe Tpe6ObaHna

• KomnbpoTep co cbo6oHbIM npotom USB (ДЯ obecneueHnA ckopocTei CTaHapTa USB 3.0 Tpe6yeTcHnUHe nOpta USB 3.0)
• Дя обесенья бICTрODEйCTBЯ,пpeусмOTpeHHOrO CTaHapTom UASP,тpe6yetca xocT-KOHTPoJIneP c noДeprKkoU ASP
  2,5-IOHMOBbIM JecTKn DnCK SATA nnn TBepDoTeNbHbI HaKoNtBb BbcOTou He 60nee 9,5 MM
  CobMeCTUMOcTb CO BCEMN OCHOBHbIMN TINaMNI ONEpaUHOHHbx CNCTeM, npedymatpmbauoumn nCNoB30BaHne pa3beMOB USB

O\Pu\NHaJIbHbIe KOMnJIeKTyIOUcIe

• YdInHntbHbIe Ka6eHn cepuU324 cpa3bEmamn USB 3.0 A/A
• Ka6eHn cepnn U326 c pa3bemamn USB 3.0 Micro-B

yctahOBka

Примочаня:

XecKne/TBepDoTeNbHbIe DnCKn (HDD/SSD) yBCTBnteNbbl K Bo3deJCTBIO CTaTnueckOTo 3neKtpnuecTBa n Tpe6yot NaIeJaCaJeero o6paueHna BO n36eKaHHe notepr DaHHbIX. PpN o6paueHn C XeCTKm/TBepDoTeNbHbIM DnCKOM (HDD/SSD) Heo6xOdImo co6IoudaTb ocTopoXHoCTb: npN nepeBo3Ke 683aTeNbHO cNeUyET HaDeBaTb Hn Hero aHTncTaTnueckn peMeewok (HaNPmEp, Tripp Lite P999-000), a NpePd npNKocHOBeHnEm K Hemy nII B3aTHeM erO B pyKn HaJIeKNT n36aBUTbcr OTHaKOpLeHHoro CTaTnueckOTo 3apra Da NyTeM KacaHn3a3eMleHHo MeTaIIuueckO nobepxHoCTn.
- Пи OTOcoeHHeHn DnCKa BbINONHtE BCE 3TaNbi OTKIOUcHn, yCTaHOBNeHHbIe IJIy NcNoJIb3YeMoI OtnepauOnHoH CNCTeMbI n o6ecneuHBAIOUne 6be3Oanchoe OTcoeHNHeHne. OTcoeHNHeHne DNcKa 6e3 PpeBaPHTeNbHO OTKIOUcHn OTOCTeMbI MoKeT PpNBecTN K NOTepe INI NOBpeXdEHnO XpaHAnxCn Ha HEM DaHHbIX.
- EcIN INCK SATA He OTΦOpMaTHPOBaH, To eTo CNeIyET OTΦOpMaTHPOBaTb C NcIOJIb3OBAHnEM yCTaHOBHeHHo Ha KOMNbIoTepe yTnInTb Disk Management, oBeCneuBaIOSeKoIMPOBaHne foAIOB n IOCTyn K Hm.

1. CdbnHbTe KpbIuKc 6noKa, oTkpBIB IOTOK dJa yCTaHOBKn JecTKoro DnCKa n pa3bem SATA.
   2.ПоdkлioчnteДИСК，ВCTaBиВ erOВ pa3bemSATA.ДЯСbeDEHnK MmHmMyMexaHnueckoHarpy3knHa pa3bem ydePknBaIteДИСКПОДMaIbIMyrIOM.
2. После заBERшеня установки диска надвинбтешу на СBOE MeCTO ДЯ сero 3auntby OT nbINI IN Dpyrnx NCTOCHNKOB 3arpa3HeHnI.
3. Пи пomoши кабеля USB 3.0 Micro-B, Вхаяцero в КOMплкт, coeинite устю сkomпьЮтepam.
   5.ДИСК rOTOB K ИСПОЛьЗОВАHи.МURAнe CBeTOДNOДНOrO INДИКaTOPa CnHERo UcBETA CBnDETeJIbCTByeT O BbIINOLHeHn NepeJaHn DaHHbIX.

TexHnueckne xapaKTepeNCTnKN:
