Product Type	External storage enclosure for 2.5-inch SSD/HDD
Brand	Tripp Lite
Model	U457025G1WPG (USB 3.1 Gen 1)
Connectivity	Built-in USB Type-C (male)
Host Interface	USB 3.1 Gen 1 (5 Gbps), backward compatible with USB 3.0/2.0/1.1
Disk Interface	SATA III (6 Gbps), SATA II, SATA I
Supported Disk Formats	2.5-inch SATA drives (7 mm to 9.5 mm height)
Protection	IP66 rating (water and dust resistant)
Power	USB bus powered (no external power required)
UASP Support	Yes (enhances performance)
Operating Temperature	10 °C to 50 °C
Operating Humidity	10 % to 80 % RH, non-condensing
Dimensions	24 x 94 x 148 mm
Weight (estimated)	About 100 g
Package Contents	Enclosure with built-in cable, mini screwdriver, 10 screws, 10 washers, quick start guide
Warranty	1-year limited warranty
Care and Cleaning	Clean with a soft, dry cloth. Do not use solvents.
Safety	Do not use for life-support devices. Follow installation instructions to ensure sealing.
Spare Parts and Repairability	No spare parts available; in case of failure, contact Tripp Lite support.
General Information	Manufactured in China. WEEE compliant.

Frequently Asked Questions - U457025G1WPG Tripp Lite

What types of hard drives can I use with this enclosure?

This enclosure accepts 2.5-inch SATA SSD/HDD drives with a height of 7 mm to 9.5 mm. It supports SATA I, II, and III interfaces.

What is the maximum transfer speed?

For the U457-025-G1-WPG model, the maximum speed is 5 Gbps (USB 3.1 Gen 1). To achieve these speeds, your computer must have a compatible USB 3.1 Gen 1 port.

Is the enclosure really waterproof?

Yes, it is IP66 certified, making it fully protected against dust and water jets. Ensure the screws are tightened properly to maintain the seal.

How do I install a hard drive in this enclosure?

Remove the back cover, connect the drive to the SATA connector, replace the cover, and secure the 10 screws with the provided washers using the screwdriver. Then plug the USB-C cable into your computer.

Does this enclosure require an external power supply?

No, it operates solely on USB bus power. No external power supply is needed.

Does the enclosure support UASP protocol?

Yes, it is UASP (USB Attached SCSI Protocol) compatible, which improves performance compared to the standard BOT protocol. Your host controller must also support UASP.

What is the length of the built-in USB cable?

The cable is relatively short (about 20 cm), designed for direct connection to a computer or hub. It is not removable.

Does this enclosure work with Windows, Mac, or Linux?

Yes, it is compatible with common operating systems such as Windows, macOS, and Linux. No additional drivers are required.

What is the warranty on this product?

Tripp Lite offers a 1-year limited warranty from the date of purchase. For any claims, contact Tripp Lite support with proof of purchase.

What should I do if the enclosure is not recognized by the computer?

First, check that the drive is properly installed and the screws are tight. Try a different USB port or cable. If the problem persists, the drive may be defective or the enclosure may be faulty; contact customer support.

USER MANUAL U457025G1WPG Tripp Lite

USB-C 3.1 SATA SSD/HDD Water-Resistant Enclosure with Built-In Cable for 2.5-Inch Drives

Models: U457-025-G1-WPG (USB 3.1 Gen 1, 5 Gbps), U457-025-G2-WPB (USB 3.1 Gen 2, 10 Gbps)

Español 5 • Français 9 • Русский 13

WARRANTY REGISTRATION

Register your product today and be automatically entered to win an ISOBAR surge protector in our monthly drawing!

tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

Copyright © 2019 Tripp Lite. All rights reserved.

Product Features

• Converts any 2.5 in. internal SATA SSD (solid state drive) or HDD (hard disk drive) into an external hard drive for storing data
• Designed for 2.5 in. SATA drive heights between 7 mm and 9.5 mm
  • Supports SATA III (6 Gbps), II (3 Gbps) and I (1.5 Gbps) drives
• Backward compatible with USB 3.0, 2.0 and 1.1 devices
  • Water-resistant and dust-tight to comply with IP66 standards
  • UASP-compatible for enhanced performance
• Bus-powered plug-and-play operation with no software or external power required

Package Contents

• U457-025-G1-WPG (SuperSpeed USB 3.1 Gen 1, 5 Gbps) or U457-025-G2-WPB (SuperSpeed USB 3.1 Gen 2, 10 Gbps)
• Mini Screwdriver
• Screws (x10)
• Washers (x10)
• Quick Start Guide

System Requirements

• USB 3.1 Gen 1 (5 Gbps) port required to achieve maximum speeds for U457-025-G1-WPG
• USB 3.1 Gen 2 (10 Gbps) port required to achieve maximum speeds for U457-025-G2-WPB
• UASP-enabled host controller required to achieve UASP performance
  • 2.5 in. SATA HDD or SSD with maximum height of 9.5 mm

Installation

1 Remove the back cover (side with the screw holes) of the SSD/HDD enclosure.
2 Connect your 2.5 in. SATA SSD/HDD to the SATA connector.
3 Once the SATA SSD/HDD is securely in place, replace the back cover, ensuring the screw holes line up with one another.
4 Using the included screwdriver, screws and washers, fasten the 10 screws and washers securely to the enclosure.

Note: In order to comply with IP66 standards, screws need to be properly tightened to the enclosure.

5 Connect the built-in USB 3.1 Type-C cable to an available USB port on your computer.

Specifications

Drive Connection 22-Pin SATA	Data + Power
USB Connection USB Type-C (Male)
Maximum Data Transfer Rate	10 Gbps (U457-025-G2-WPB)
	5 Gbps (U457-025-G1-WPG)
SSD/HDD Supported 2.5 in. SATA I/II/III HDD/SSD
Operating Temperature 50° to	122°F (10° to 50°C)
Relative Humidity 10% to 80% RH, Non-Condensing
Dimensions 0.94 x 3.7 x 5.8 in. (24 x 94 x 148 mm)

Warranty and Product Registration

1-Year Limited Warranty

TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of one (1) year from the date of initial purchase. TRIPP LITE's obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. To obtain service under this warranty, you must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or an authorized TRIPP LITE service center. Products must be returned to TRIPP LITE or an authorized TRIPP LITE service center with transportation charges prepaid and must be accompanied by a brief description of the problem encountered and proof of date and place of purchase. This warranty does not apply to equipment, which has been damaged by accident, negligence or misapplication or has been altered or modified in any way. EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any costs, such as lost profits or revenue, loss of equipment, loss of use of equipment, loss of software, loss of data, costs of substitutes, claims by third parties, or otherwise.

Product Registration

Visit tripplite.com/warranty today to register your new Tripp Lite product. You'll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*

* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

WARNING

Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life support equipment or to significantly affect its safety or effectiveness is not recommended.

WEEE Compliance Information for Tripp Lite Customers and Recyclers (European Union)

Under the Waste Electrical and Electronic Equipment (WEEE) Directive and implementing regulations, when customers buy new electrical and electronic equipment from Tripp Lite they are entitled to:

• Send old equipment for recycling on a one-for-one, like-for-like basis (this varies depending on the country)
• Send the new equipment back for recycling when this ultimately becomes waste

Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.
