Product Type	USB 3.1 Enclosure for M.2 NGFF SATA SSD
Model	U457-1M2-SATAG2
Brand	Tripp Lite
Connectivity	USB 3.1 Gen 2 Type-C (10 Gbps), backward compatible with USB 3.0/2.0/1.1
Drive Interface	M.2 NGFF SATA (B key or B+M key)
Supported Drive Form Factors	2230, 2242, 2260, 2280
Max USB Speed	10 Gbps
Max SATA Speed	6 Gbps
Power Source	USB bus-powered (no external power required)
Enclosure Material	Aluminum
Dimensions (Approx.)	108 x 34 x 12 mm
Weight (Approx.)	50 g
LED Indicator	Blue (read/write/transfer)
Operating Temperature	10° to 50 °C
Operating Humidity	10 to 80 % RH
Warranty	1 year limited
Package Contents	Enclosure, USB 3.1 Type-C cable, mounting hardware, mini screwdriver, manual
System Requirements	Computer with USB Type-C port; USB 3.1 Gen 2 port recommended for max speed
Special Features	UASP support (up to 70% faster), plug and play, no driver required
Maintenance	Clean with a dry, soft cloth; avoid moisture
Safety	Handle SSD with antistatic precautions; disconnect using the system's safe removal option

Frequently Asked Questions - U4571M2SATAG2 Tripp Lite

What types of M.2 SSDs are compatible?

The enclosure supports M.2 NGFF SATA SSDs with B key or B+M key connector, in form factors 2230, 2242, 2260, and 2280. It is not compatible with M.2 PCIe NVMe SSDs.

What is the maximum transfer speed?

Using a USB 3.1 Gen 2 port (10 Gbps), the theoretical maximum speed is 10 Gbps. The SATA III speed of the SSD can reach 6 Gbps. With UASP support, performance can be up to 70% faster than the BOT protocol.

Does the enclosure require external power?

No, power is supplied via the computer's USB port. No battery or AC adapter is needed.

How do I install an M.2 SSD into the enclosure?

Remove the two screws from the enclosure tray, slide the tray outward. Place the SSD into the M.2 connector aligning the notch, then secure it with the provided screw in the mounting hole corresponding to its length. Replace the tray and screw it back.

Is the enclosure compatible with my computer?

It requires a USB Type-C port. For maximum speeds, a USB 3.1 Gen 2 (10 Gbps) port is recommended, but it is backward compatible with USB 3.0, 2.0, and 1.1.

How do I format a new SSD?

Use your operating system's disk management utility. Initialize the disk and create a volume (NTFS, exFAT, etc.) before copying files to it.

What should I do if the enclosure is not recognized?

Check that the USB cable is properly connected, try a different USB port or cable. Ensure the SSD is correctly installed and formatted. On some systems, a reboot may be necessary.

How do I safely disconnect the enclosure?

Use the 'Safely Remove Hardware' option (Windows) or 'Eject' (macOS) before unplugging the USB cable. Removing without ejection may result in data loss.

What is the product warranty?

Tripp Lite offers a one-year limited warranty against defects in materials and workmanship from the date of purchase.

Can I use this enclosure with a PCIe NVMe SSD?

No, this enclosure only supports M.2 NGFF SATA SSDs (B key or B+M key). It is not compatible with PCIe NVMe SSDs (M key).

USER MANUAL U4571M2SATAG2 Tripp Lite

Register your product for quicker service and ultimate peace of mind.

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

www.triplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA www.triplite.com/support

Copyright © 2017 Tripp Lite. All rights reserved.

Package Contents

U457-1M2-SATAG2
- USB 3.1 Gen 2 (10 Gbps) Type-C Cable (M/M)
- Mounting Hardware
- Mini Screwdriver
- Owner's Manual

Product Features

• Quickly transfer files to and from your computer by adding the speed of an M.2 NGFF SATA SSD
• Slim design with aluminum enclosure is durable and perfect for travel, tucking into your laptop bag when not in use
  Supports 2230, 2242, 2260 and 2280 M.2 drive types
  Supports USB 3.1 Gen 2 data transfer rates up to 10 Gbps; backward compatible with USB 3.0, 2.0 and 1.1
  Supports SATA III data transfer rates up to 6 Gbps
  UASP Compatible for up to 70% faster performance

Product Features

• Plug and play; no software or drivers required
• No external power required

System Requirements

• Computer with an available USB Type-C port; a USB 3.1 Gen 2 (10 Gbps) port is required to achieve maximum speeds
• M.2 NGFF SATA Drive with a B-Key or B + M Key connector; not compatible with M.2 NGFF PCIe SSDs
  Supports 2230, 2242, 2260 and 2280 M.2 drive types

Optional Accessories

• U420-003-G2 USB 3.1 Gen 2 (10 Gbps) Cable, USB Type-C (M/M) - 3 ft.
• U428-003-G2 USB 3.1 Gen 2 (10 Gbps) Cable, USB Type-C to USB-A (M/M) - 3 ft.

Installation

Notes:

• HDD/SSD drives are sensitive to static electricity and must be handled properly so as not to risk data loss. Always handle your HDD/SSD drive with caution by wearing an anti-static strap (Such as Tripp Lite P999-000) when transporting it, or by touching a grounded metal surface to discharge yourself of static electricity prior to picking up the drive.
• When disconnecting the connected drive, be sure to go through the proper disconnection steps of your operating system to safely disconnect. Removing the drive prior to proper disconnection can result in loss or corruption of data stored on the drive.
• Using the included screwdriver, remove the 2 drive tray screws located on both sides of the USB port.
• Remove the front plate and slide out the internal drive tray.
• Place your SSD next to the M.2 SSD connector, matching up the drive mounting holes. Position the included nut underneath a drive mounting hole that matches the length of your SSD.

Installation

1. Slide the M.2 connector on the SSD drive into the M.2 receptacle on the drive tray.

Note: The connector on the M.2 SSD is keyed so the drive will only fit one way.

1. Hold down the drive toward the drive mounting hole. Using the included screwdriver, drive the screw through the mounting holes on your SSD drive and into the drive mounting hole. Your M.2 drive is now installed.
2. Replace the 2 drive tray screws on the front of the enclosure located on both sides of the USB port.
3. Connect the included USB 3.1 Gen2 Cable between the USB port on the U457-1M2-SATAG2 and the USB port on your computer.
4. If your drive has not been formatted yet, you will first need to format it using your computer's Disk Management Utility in order to copy and access files.
5. Your enclosure is now ready to use. The blue LED light will blink to indicate reading, writing and transferring of data.

Specifications

Drive Connection M.2	NGFF SATA (B-Key)
USB Connection USB	Type-C
LEDs Blue: Read, Write and Transfer Data
Maximum Data Transfer Rate	10 Gbps
Supported SSDs 2230, 2242, 2260, 2280
Operating Temperature	50° to 122°F (10° to 50°C)
Operating Humidity 10% to 80% RH

Warranty and Product Registration

1-Year Limited Warranty

TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of one (1) year from the date of initial purchase. TRIPP LITE's obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. To obtain service under this warranty, you must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or an authorized TRIPP LITE service center. Products must be returned to TRIPP LITE or an authorized TRIPP LITE service center with transportation charges prepaid and must be accompanied by a brief description of the problem encountered and proof of date and place of purchase. This warranty does not apply to equipment, which has been damaged by accident, negligence or misapplication or has been altered or modified in any way.

Warranty and Product Registration

EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH

DAMAGE. Specifically, TRIPP LITE is not liable for any costs, such as lost profits or revenue, loss of equipment, loss of use of equipment, loss of software, loss of data, costs of substitutes, claims by third parties, or otherwise.

Product Registration

Visit www.triplite.com/warranty today to register your new

Tripp Lite product. You'll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*

• No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

FCC Notice, Class A

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which

Warranty and Product Registration

case the user will be required to correct the interference at his own expense. The user must use shielded cables and connectors with this equipment. Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the user's authority to operate this equipment.

WEEE Compliance Information for Tripp Lite Customers and Recyclers (European Union)

Under the Waste Electrical and Electronic Equipment (WEEE) Directive and implementing regulations, when customers buy new electrical and electronic equipment from Tripp Lite they are entitled to:

• Send old equipment for recycling on a one-for-one, like-for-like basis (this varies depending on the country)
• Send the new equipment back for recycling when this ultimately becomes waste

Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life support equipment or to significantly affect its safety or effectiveness is not recommended.

Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.

1111 W. 35th Street, Chicago, IL 60609 USA www.triplite.com/support

1111 W. 35th Street, Chicago, IL 60609 EE UU www.triplite.com/support

1111 W. 35th Street, Chicago, IL 60609 EE UU www.triplite.com/support

16

Manufacturing Excellence.

1111 W. 35th Street, Chicago, IL 60609 USA www.triplite.com/support

1111 W. 35th Street, Chicago, IL 60609 USA www.triplite.com/support

24

PyKOBODCTBO N0JIb30BaTeJIa

Kopnyc pa3bemamn USB 3.1 Gen 2

(10 Γ6πT/c)

n M.2 NGFF SATA SSD B-Key

Mодenvb:U457-1M2-SATAG2

1111 W. 35th Street, Chicago, IL 60609 USA

www.triplite.com/support

OxpaHЯETcA bTOpCKnM npaBOM © 2017 Tripp Lite.

Iepeneuataka 3anpeuaetcra.

Copexnmoe ynaKOBKn

U457-1M2-SATAG2
- Ka6eNb c pa3bemamn USB 3.1 Gen 2 (10Γ6nt/c) Type-C (wTekep/wTekep)
- MohtaxHbIe npncnoc6JeHna
MHHN-OTBepTka
PykoB0dCTBO nOlb30BaTeJia

XapakTepnCTnKn npOnyKta

• Быстры перацoc phаиов на КOMпьтep / cКOMпьтepa 6лагоря ВсOKоскopoctHomy M.2 NGFF SATA SSD
  -ИЗЯшая KOHCTpyKця саIOMMHHeBbIM KOpnycom OTINuHaETcRdoJIROBeUHOCtBu INIealbHO IOxOДNT B KaueCTBe IopoxHOrO yCTpoIcTBa,JeRKO NOMEuaCb B cyMky ДЯ NOpTaTINBHorO KOMNbIOTepa B TO BpeM, KOrDa OHO He IcNoIb3YeTcR
  -Подержka дисьтuna 2230,2242,2260 n 2280 M.2
• Повдержka Иntepфса USB 3.1 Gen 2 co ckopoctamn пераши даньх до 10 ГиT/c; образная COBmectUMOCTb с Иntepфсamn USB 3.0, 2.0 n 1.1
• Пордержka Иntерфейca SATA III co ckopoстмп поедачданных до 6 ГиТ/c
• Cobmectnmoctb c UASP, o6ecneuBaIOuaЯ NOBbiueHne 6bICTpoIeICTBna Ha BENUHy do 70%

XapakTepnCTnKn npOdyKta

• Поклоченье поTekhoлоги Plug-and-play 6e3 Heo6xOДIMOCtN ИСПОЛБ3OBaHЯ КAKOrO-JIb60 nporpaMM nJI npaIBepOB
  OTcYCTBHe Heo6xOIMOCn BO BHeUHem NCTouHnKe nHTaHn

1111 W. 35th Street, Chicago, IL 60609 USA www.triplite.com/support

32

16-12-187 93-369E_revA
