USER MANUAL ProCube2 Hähnel

01. AA battery charge plate

05. Interchangable charge

01. Left charge bank

02. mAh charge indicators

03. Right charge bank

Identify battery and plate Remove plate

Push to release Insert plate

Power USB power ProCUBE2 Accessory Wireless charger available seperately Pt No: 1000 580.0 DC 12VFor CAN

Left bank (4s increments) Right bank (4s increments) Li-Ion Charge AA x 4 mAh Charge Li-Ion x 1 Li-Ion x 2 Li-Ion full 15min = 300mAh = 150 photos* 400mAh = 200 photos* 600mAh = 300 photos* Power Li-Ion charge mAh charge AA battery chargeEN

• Top up charge. The ‘mAh’ reading on the LCD display shows how much capacity (mAh) has been added during charging. It does not show what capacity is in the battery already. 15 minutes charge = 300 mAh = 150 photos* (*approximate - this is dependent on camera & amp; usage)

• Only use the Charger to charge the specified batteries

• Do not allow charger to get wet or get exposed to moisture

• Keep the Charger out of reach of children

• Once charging is completed, unplug the charger from power source

• Never apply excessive force when connecting or disconnecting a battery or contact plate.

• Keep all contacts clean.

• Do not force down any of the contacts.

• Do not short-circuit the contacts.

• Never store the battery connected to the charger for an extensive period of time.

• Do not expose to excessive heat or naked flame.

• Do not dismantle or carry out any alteration to the product.

• Use only rechargeable Li-ion/Ni-MH/Ni-Cd batteries. Oridinary non-rechargeable batteries must not be used otherwise there is a danger to batteries and charger

• Do not short circuit, solder or dismantle batteries or charger

• Do not incinerate batteries, danger of explosion

• Do not dispose of batteries in domestic waste. Return batteries to special collection point or point of sale This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety (IEC/EN 60335-1/A2: 2006) Children should be supervised to ensure that they do not play with the appliance (IEC/EN 60335-1/A2: 2006) Connection to the supply mains is to be in accordance with the national wiring rules. Only use the Charger to charge the digital camera Li-ion batteries, not for non-rechargeable batteries or non-Li-ion batteries.DE Warnung:
