USER MANUAL JIS300 BLACK & DECKER

Parts Identification

A. Pusher
B. Juicer Lid
C. Rotary Sieve
D. Juice Collector
E. Pulp Container
F. Control Knob
G. Release Button
H. Motor unit
I. Juice Jug
J. Ice Shaver
K. Ice Shaver Lid

Intended use

Your BLACK+DECKER™ Juicer has been designed for juicing fruits and vegetables. This product is intended for household use only.

Read this entire manual carefully before using the appliance.

Safety instructions

Warning! When using

mains-powered appliances, basic safety precautions, including the

following, should always be followed to reduce the risk of fire, electric shock and personal injury.

• The intended use is described in this manual. The use of any accessory or attachment or the performance of any operation with this appliance other than those recommended in this instruction manual may present a risk of personal injury.
• Retain this manual for future reference.

Using your appliance

• Always take care when using the appliance.
• Never pull the power supply cord to disconnect the plug from the socket. Keep the power supply cord away from heat, oil and sharp edges.
• Do not place the appliance on or near heat sources or in a heated oven.
• Do not use the appliance outdoors.
• Always protect the motor unit from water or excessive humidity.
• If the power supply cord is damaged during use, disconnect the appliance from the power supply immediately. Do not touch the power supply cord before

disconnecting from the power supply.

• Disconnect the appliance from the power supply when not in use, before fitting or removing parts and before cleaning.
• Never let the appliance operate unattended.
• Never reach into the feeding tube with your fingers or an object while the appliance is running. Only the pusher is to be used for this purpose.
• Only unlock the clamp after you have switched the appliance off and any moving parts have stopped.
• Do not touch the small cutting blades in the base of the filter.
• Keep any loose clothing or long hair away from the feeding tube and any moving parts.
• Allow moving parts to come to a stop before removing any cover.
• Do not immerse the appliance, cord set or plug in liquids.
• Unit must be attended in use
  Take care when handling the sharp cutting blades when emptying the bowl and during cleaning

Safety of others

• This appliance is not intended for use by persons (including children) with reduced physical sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.

After use

• Remove the plug from the socket before leaving the appliance unattended and before changing, cleaning or inspecting any parts of the appliance.
• When not in use, the appliance should be stored in a dry place. Children should not have access to stored appliances.

Inspection and repairs

• Before use, check the appliance for damaged or defective parts. Check for breakage of parts, damage to switches and any other conditions that may affect its operation.
• Switch off the appliance and disconnect from supply before changing accessories or approaching parts that move in use.
• Do not use the appliance if any part is damaged or defective.
• Do not use the appliance if the rotary sieve is damaged.
• Have any damaged or defective parts repaired or replaced by an authorised repair agent.
• Before use, check the power supply cord for signs of damage, ageing and wear.
• Do not use the appliance if the power supply cord or mains plug is damaged or defective.

• If the power supply cord or mains plug is damaged or defective it must be repaired by an authorised repair agent in order to avoid a hazard. Do not cut the power supply cord and do not attempt to repair it yourself.

• Never attempt to remove or replace any parts other than those specified in this manual.

Electrical safety

Before use, check that the mains voltage corresponds to the voltage on the rating plate.

This appliance is double insulated in accordance with EN 60335-2-14; therefore no earth

wire is required

• To avoid the risk of electric shock, do not immerse the cord, plug or motor unit in water or other liquid.
• Check that the supply voltage shown on the rating plate of the appliance matches that of your electrical system. Any connection error will invalidate the guarantee.

Labels on appliance

The following warning symbols are found on the appliance:

Warning! Allow moving parts to come to a stop before approaching.

Assembly

1. Wash all detachable parts (see chapter 'Maintenance and cleaning').
2. Place the pulp container (E) onto the appliance.
3. Place the juice collector (D) onto the appliance.
4. Put the rotary sieve (C) in the juice collector and lower it into position. Make sure the rotary sieve is fitted securely onto the driving shaft ('click').

Warning! Always check the rotary sieve before use. If you detect any cracks or damage, do not use the

appliance and contact the nearest service centre or take the appliance to your dealer.

1. Fit the lid (B) by lowering it into position. Press down firmly until it locks into place. (the lid can only be removed by sliding the release button (G) to the unlock position)
2. Fit the juice jug (I). Push firmly until it clicks into place.
3. Fit the ice shaving (J) by lowering it into position.
4. Fit the ice shaver lid (K) and lock it into position by turning it anti-clockwise.

Use

Juicing

1. Fully assemble the appliance (including the ice shaver) the appliance will not run unless both lids are securely locked in position.
2. Place the appliance on a flat, stable surface and connect it to the electrical supply.
3. Select the juicing function by turning the control knob (F) anti-clockwise.
4. Remove the pusher (A) and add the ingredients, using the pusher to guide the ingredients onto the blades.

5. While you are preparing juice, you can empty the pulp container by switching the appliance off and carefully removing the pulp container. Note: Reassemble the empty pulp container before you continue juicing.

6. When juicing is completed, return the control knob (F) to the O (off) position.

The appliance should be disconnected from the mains supply before removing the jug.

The Juicer should not be run for longer than 2 Minutes. After each 2 Minutes use, the Juicer should be allowed to cool for at least 2 minutes.

The appliance has a safety feature which prevents overheating. If the device gets too hot it will automatically shut off. The appliance should be left for 15 minutes to fully cool before re-starting.

Ice shaving

1. Fully assemble the appliance the appliance will not run unless both lids are securely locked in position.
2. Place the appliance on a flat, stable surface and connect it to the electrical supply.
3. Put ice into the ice shaver (J) and fit the ice shaver lid (K) securely.
4. Select the Ice shaver function by turning the control knob (F) clockwise.
5. When ice shaving is completed, return the control knob (F) to the O (off) position.

The appliance should be disconnected from the mains supply before removing the jug.

The appliance should not be run for longer than 2 Minutes. After each 2 Minutes use, the appliance should be allowed to cool for at least 1 minute.

Useful advice

• Wash the fruit carefully before stoning.
• Use fresh fruit and vegetables, as they contain more juice. Pineapples, celery stalks, apples, cucumbers, carrots, spinach, melons, tomatoes, oranges and grapes are particularly suitable for processing in the juice extractor.
• You do not need to remove the peels or skins. You only need to peel fruit with thick skin: citrus fruit, pineapple (remove the centre stalk).
• Fruits that contain starch, such as bananas, papayas, avocados, figs, strawberries and mangoes are not suitable for processing in the juice extractor. Use a food processor, blender or stick blender to process these fruits.
• The juicer is not suitable for processing very hard and/or fibrous/starchy fruits or vegetables such as sugar cane.
• Choose fresh, ripe fruit and vegetables, they will yield more juice.
• Drink the juice immediately after you have extracted it. If it is exposed to air for some time, the juice will lose its taste and nutritional value.
• To extract the maximum amount of juice, always press the pusher down slowly.

Maintenance & cleaning

• Switch the appliance off, remove the plug from the wall socket and wait until the rotary sieve has stopped rotating before cleaning, changing accessories or approaching parts that move during use.

• The appliance is easier to clean if you do so immediately after use.

• Do not use abrasive cleaning agents, scourers, acetone, alcohol etc. to clean the appliance.
• All detachable parts, should be washed by hand.

Warning! Care must be taken when washing the rotary sieve. Do not touch the small cutting blades in the base of the filter.

• Clean these parts with a cleaning brush in warm water with some washing-up liquid and rinse them under the tap.

• Remove the dirty parts from the motor unit. Disassemble the appliance in the following order:

• Remove the pulp container,

• Remove the pusher,
• Open the clamp & remove the lid,
• Remove the juice collector together with the rotary sieve.
• Clean the motor base with a damp cloth.
• Never immerse the motor unit in water nor rinse it under the tap.

Technical Data

JIS300

Voltage 220 - 240 Volts

Supply 50-60 Hz

Power consumption (Juicing) 280W

Power Consumption (Ice shaving) 25W

Weight 3.7 kg

Protecting the environment

Separate collection. This product must not be disposed of with normal household waste.

Should you find one day that your Black+Decker product needs replacement, or if it is of no further use to you, do not dispose of it with other household waste. Make this product available for separate collection.

• Black+Decker provides a facility for recycling Black+Decker products once they have reached the end of their working life. This service is provided free of charge. To take advantage of this service please return your product to any authorised repair agent who will collect them on our behalf.
• You can check the location of your nearest authorised repair agent by contacting your local Black+Decker office at the address indicated in this manual. Alternatively, a list of authorized Black+Decker repair agents and full details of our after-sales service and contact are available on the Internet at: www.2helpU.com.

Warranty

Black+Decker is confident of the quality of its products and offers an outstanding warranty.

This warranty statement is in addition to and in no way prejudices your statutory rights.

The warranty is valid within the territories of the Member States of the European Union and the European Free Trade Area.

If a Black+Decker product becomes defective due to faulty materials, workmanship or lack of conformity, within 24 months from the date of purchase, Black+Decker warranty to replace defective parts, repair products subjected to fair wear and tear or replace such products to ensure minimum inconvenience to the customer unless:

The product has been used for trade, professional or hire purposes;
The product has been subjected to misuse or neglect;
The product has sustained damage through foreign objects, substances or accidents;
Repairs have been attempted by persons other than authorised repair agents or Black+Decker service staff.

To claim on the warranty, you will need to submit proof of purchase to the seller or an authorised repair agent. You can check the location of your nearest authorised repair agent by contacting your local Black+Decker office at the address indicated in this manual.

Alternatively, a list of authorised Black+Decker repair agents and full details of our after-sales service and contacts are available on the Internet at: www.2helpU.com.

Identification des pieces

J 24 Jx
J
J
J
J
J
J
J
J

110 no yolil pccjy. 5naiio 2

gai jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia jia

：g>gA

1000 100000000000000000000000000000000000000000000000000000000000000000

aaii aai i 5g gaaia

J 1 J 1 J 1 J 1 J 1 J 1 J 1 J 1 J 1 J 1 J 1 J 1 J 1 J 1 J 1 J 1 J 1 J 1 J 1 J 1 J 1 J 1 J 1 J 1 J 1 J 1 J 1 J 1 J 1 J 1 J 1 J 1 J 1 J 1 J

JL 8g
LolJ L JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI JI J1
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.

i 1

Jaaalalal 1j

2.0gJl oJL JwC Si c 1y j
oCL g0gJl y aall hll wol
.0

LwJyW LjJgJ 11 JIi j

1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

$$ \cdot \downarrow \downarrow \downarrow \downarrow \downarrow \downarrow \downarrow \downarrow \downarrow \downarrow \downarrow \downarrow \downarrow \downarrow \downarrow \downarrow \downarrow \downarrow $$

$$ . \dot {a} \dot {a} \dot {j} \dot {j} j j - $$

$$ . {l h } j l g {l, \dot {l} } \dot {l} $$

$$ . \dot {a} _ {j} | g _ {i} | \dot {a} _ {i} | g _ {j} | \dots $$

aeho plssiwl yol 10g aibii .

gab gll

A

JIS300

العربية Εξ-ΕΩ·العربية Εξ-ΩΩ

العربية Εη/Ω·العربية Εη/Ω

العربية Εη/Ω·(العربية)

العربية Εη/Ω·(العربية)

العربية Εη/Ω·(العربية)

العربية Εη/Ω·(العربية)

Laae Jie 1y jie 11

aalal aalal alal alal alal

1

J 1

aaiilg aiall

J 100000000000000000000000000000000000000000000000000000

11 100000000000000000000000000000000000000

1gL 1Jg

Lg jgj1 aagl > 5j doLcl p :

Lg<LLJ LJI JI J I J I J I J I J I J I J I J I J I J

jglg 1c oogggl lal

Jc oogoo aIJI Jrnnnclao 1

2gjagjj 1s jgjgj

= 0. - 11

）JALALJIgJALSLJ1.1 （"aJALJgJHJ

（）ylllyggygLg2

jLg（）JGLgSLcg

4
1
1
1
1
1
1
1

P

gJ 45j J1 j aall jLgJ Lla J a J 1c J 1 gJ J 1

plic 1jLs o jlg 1n jz jy . Jlabsl aig .olssw .g21

L

gJ 1 gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ g

aIbI Jn no aIg jIg IlaIpa 1JgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJgJ

g j 1j g 1j 1j 1j 1j

aI aJI JgJgJpIiJ 1

aill jJlui w g Cai ci 2 . aieo cui J5g Jq no x! aiil g

gJ 1 gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ gJ

Names & Addresses for Black & Decker Service Concessionaries

ALGERIA: Sarl Outillage Corporation, DW, B&D Pet, HHD, 08, Rue Med Boudiaf (ex TELLA Achen) Cheraga, Alger, Tel: [phone], Fax: [phone], Email: [e-mail];
nefissa. [e-mail]; [e-mail]. AZERBAJAN: Kontakt - NN LLC, HHD, M.Qashqay 43, Baku Azerbaijan Az1000, Tel: [phone], Mob: [phone], Fax: [phone], [e-mail]. BAHRAIN: Alfouz Services Co. WLL, Tubli, DW, B&D PET, HHD, P.O. Box 26562, Tubli, Manama, Tel: [phone], Fax: [phone], Email: [e-mail]. EGYPT: Anasia Egypt for Trading S.A.E. (Mentreade), HHD, P.O. Box 2443, 9, Mostafa Refaat Street, Sheraton Heliopolis 11361, Cairo, Tel: [phone], Fax: [phone], Email: [e-mail]; [e-mail]. ETHIOPIA: Seif Tewfik Sherif, DW, B&D PET, HHD, Arada Sub City, Kebele 01/02, Global Insurance Bldg, 2nd Flr, Room 43, P.O. Box 2525, Addis Ababa, Tel: [phone], Fax: [phone], Email: [e-mail]; [e-mail]; [e-mail]. IRAQ: Financial Links, B&D PET, HHD, Kazzaz Building Arasat Al-Hindia, Block No: 629, Street: 31, Building No: 1, Baghdad, Iraq, Tel: 00964-(0)780-195-2223/ [phone], Email: [e-mail]. JORDAN: Bashiti Hardware (Palestine), B&D pet, HHD,"93 King Abdullah, 2nd St., Opp ELBA House, P.O. Box 3005, Amman 11953, Tel: [phone], ext.11, Fax: [phone], Email: [e-mail]; [e-mail];
[e-mail]. KENYA: Zylog Enterprises Ltd. (T/A Leading Concepts), HHD, IPS Building,Kaunda Street, P.O. Box 40877-00100, Nairobi, Tel: [phone], Fax: [phone], Email: [e-mail]; [e-mail]; [e-mail]. LEBANON: Aces Service Centre (Est. F.A.Ketaneh SA), HHD, P.O. Box 90-102, Nahr El Mot, Seaside Highway, Pharaon Building, Beirut, Tel: [phone]/ + 961-(1)-262626, Fax: [phone], Email: [e-mail]; [e-mail]; [e-mail]; [e-mail]. LIBYA: North Africa Trading (El Ghoul Brothers), DW, B&D Pet, HHD, P.O. Box 348, 7 October Street 11, Benghazi, Tel: [phone], Fax: [phone], Email: [e-mail]; CC: [e-mail]; [e-mail]. North Africa Trading ( El Ghoul Brothers), DW, B&D Pet, HHD, AlBarniq Dewalt Center, Mokhazin-elsukar St., ElFallah, Tripoli, Tel: [phone], Fax: [phone], Email: [e-mail]; cc: ([e-mail]; [e-mail]. Homeworld Co., HHD, Senidal St. Amr Ibn Elaaas Road, Benghazi, Libya, P.O. Box 18182, Salmany, Tel: [phone], ext. 103, Fax: [phone], ext. 108, Email: [e-mail]. MAURITIUS: J.M. Goupille & Co.Ltd. The Brandhouse Ltd., HHD, Rogers Industrial Park 1, Riche Terre, Mauritius, Tel: [phone], Fax: [phone], Email: claims service [e-mail]; [e-mail]; [e-mail]; [e-mail], [e-mail]; Cc.
[e-mail]; [e-mail]; [e-mail]. MOROCCO: UATS, HHD, "No. 37, Lotissement KADIRIA, km 10 Route, Eljadida, LISASSFA, Casablanca, Morocco, Tel: [phone], Fax: [phone], Email: [e-mail]; [e-mail]. OMAN: Oman Marketing & Service Co.(Omasco), Wattayah/ Muscat, HHD, B&D PET, P.O. Box 2734, Behind Honda Showroom, Wattayah, Oman, Tel: [phone], Fax: [phone], Email: [e-mail]; Cc. [e-mail], damodaran [e-mail]; [e-mail]. Oman Marketing & Service Co.(Omasco), Sohar, HHD, B&D PET, Al Ohi, Sohar, Oman, Tel: [phone], Fax: [phone], Email: [e-mail]. Oman Marketing & Service Co.(Omasco), Salalah, HHD, B&D PET, Sanaya, Salalah, Oman, Tel: [phone], Fax: [phone], Email: [e-mail]. Omar Mohammed Ali Bawain Trading Co., Salalah, Al-Awqadain, PC 217, P.O.Box 112, Salalah, Sultanate of Oman, Tel: [phone], Fax: [phone], Email: [e-mail]. PAKISTAN: Ammar Service & Spares, B&D PET, HHD, Office No 6068, 6th Floor Central Plaza, Behind Gul Plaza Marston Road, Karachi, Tel: [phone], Fax: [phone], Email: [e-mail]. QATAR: Al MUTFah Service Centre, Doha, HHD, B&D PET, Al Wakrah, Road, P.O. Box 875, Doha, Qatar, Tel: [phone], Fax: [phone], Email: [e-mail]; [e-mail]. SAUDI ARABIA: Fawaz Ebrahim Al Zayani Trading Est., Dammam, DW, B&D PET, HHD, P.O. Box 76026, AI Raka: 31952, Tel: [phone], Fax: [phone], Email: [e-mail]; ([e-mail]); Website: www.fawazalzayanigroup.com. Fawaz Ebrahim Al Zayani Trading Est., Makkah, DW, B&D PET, HHD, 4753-Wali Alashed, Makkah, 9130-24353 Tel: [phone], Fax: [phone], Email: [e-mail]. Banaja Trading Co. Ltd., Riyadh, HHD, P.O. Box 566, Riyadh-11421, Tel: [phone], Fax: [phone], Email: [e-mail]. Banaja Trading Co. Ltd., Jeddah, HHD P.O. Box 366,Jeddah-21411Tel:[phone],Fax: [phone] Email: [e-mail]; [e-mail]. SOUTH AFRICA: Benray Tool Wholesalers C.C., B&D PET, HHD, 460 Koeberg Road, Cape Town South Africa Tel: [phone] Fax: [phone] Email: [e-mail]. Stanley Black & Decker-RSA,BED,PET,HHD 199 Winze Drive Stormill Ext 9 Roodepoort Tel:[phone]Fax:[phone]Email: [e-mail]; [e-mail]; [e-mail]. SRI LANKA: Delmege Forsyth & Co. Ltd., DW,B&D Pet,HHD,Delmege Forsyth & Co.Ltd,Lifestyle Cluster, 101,Vinayankara Mawatha Colombo 10,Sri LankaTel:[phone]/+94-11-2 Email:[e-mail]; [e-mail] cc: [e-mail]. TUNISIA:Societe Tunisienne De Maintenance (STM), B&D Pet, HHD,Rue De La Physique.Nouvelle Zone Industrielle Ben Arous 2013 Ben Arous,TUNISIA.Tel:[phone],Fax:[phone] Email: [e-mail]. UAE: (Abu Dhabi) Galaxy Equipment Trading Abu Dhabi DW,B&D PETHHD,Madinath Zayed Baada Zaid), Abu Dhabi P.C. 58910Tel:[phone]Fax:[phone]Email: [e-mail]; [e-mail] Light House Electrical,Abu Dhabi,DW,B&D PET,HHD,P.O.Box 120,Abu Dhabi,Tel:[phone]Fax:[phone]Email: [e-mail] House Electrical,Musaffah,DW,B&D PET,HHD,P.O.Box 120,Abu Dhabi,Tel:[phone],Fax: [phone] Email:[e-mail].(Al Ain) Zillion Equipment and Spare Parts Trading LLC.Al AinDW,B&D PET,HHD,P.O.Box 19740Opp.Bin Sadal/ Trimix Redymix SanaiyaAl Ain Tel:[phone]Fax:[phone]Email: [e-mail] BLACK & DECKER (OVERSEAS)GmbH,DubaiDW,B&D PET,HHD,P.O.Box 5420DubaiTel:[phone]/8127406,Fax: [phone] Email: [e-mail].(Ras Al Khaimah) Mc Coy Middle East LLC,Ras Al Khaimah,DW,B&D PET,HHD,P.O.Box 10584,Ras Al KhaimahTel:[phone]Fax: [phone],Email:[e-mail].(Sharjah) Mc Coy Middle East LLC Sharjah DW,B&D PET,HHD,P.O.Box 25793SharjahTel:[phone]Fax:[phone]Email:[e-mail]; [e-mail]: Anisuma Investment & Service Ltd.(Jacky's Electronics), HHD,J.R Complies,Ware house No.5 Plot No.101. 3rd Industrial Area,Jinja Rd,KampalaTel:00256-414237106Mob:[phone] Email
[e-mail]. YEMEN: Middle East Trading Co. (METCO) DW, B&D Pet, HHD, 5th Flr. Hayel Saeed Anam Bldg. Al-Mugamma St. Taiz, Yemen, Tel: [phone], Fax: [phone], Email: [e-mail]; [e-mail]. Middle East Trading Co. (METCO) DW, B&D Pet, HHD, Mualla Dakka, Aden, Tel: [phone], Fax: [phone], [e-mail]; [e-mail]. Middle East Trading Co. (METCO), DW, B&D Pet, HHD, Hayel st., Sana'a, Yemen, Tel: [phone], Fax: [phone], Email: [e-mail]; [e-mail].

WARRANTY REGISTRATION CARD

YOUR NAME

YOUR ADDRESS

POSTCODE

DATE OF PURCHASE

DEALER'S NAME & ADDRESS/
