USER MANUAL SKMK 1000 A2 SILVERCREST

White coffee maker with clear glass and dark liquid, no visible text or symbols

KAFFEEMASCHINE SKMK 1000 A2 COFFEE MACHINE SKMK 1000 A2 MACHINE À CAFÉ SKMK 1000 A2

HOYER Handel GmbH

Tasköprüstraße 3

DE-22761 Hamburg

GERMANY

09/2019 ID: SKMK 1000 A2_19_V1.2

Labeled diagram of a coffee maker with numbered parts for identification

Inhalt

1. Overview 15
2. Intended purpose 16
3. Safety information 16
4. Items supplied 19
5. How to use 19
6. Before using for the first time 19
7. Operation 19

7.1 Anti-drip 20
7.2 Opening and closing the lid.... 20
7.3 Filling volumes.... 20
7.4 Brewing coffee 20

1. Cleaning 21

8.1 Dishwasher 21
8.2 After every use 21
8.3 Descaling.... 21

1. Storage 22

2. Disposal 22

3. Trouble-shooting 23
4. Technical specifications 23
5. Warranty of the HOYER Handel GmbH 24

1. Overview

1 Handle of the permanent filter
2 Permanent filter
3 Handle of the filter holder
4 Filter holder
5 Anti-drip valve
6 Water tank
7 Lever for opening the lid
8 Pot
9 Hot plate
10 On/off switch
11 Power cable with mains plug
12 Lid of the pot
13 Water level indicator: minimum 2, maximum 10 MAX cups
14 Cover
15 Cover handle

Thank you for your trust!

Congratulations on the purchase of your new coffee machine.

For safe handling of the device and in order to get to know the entire range of features:

• Thoroughly read these user instructions prior to initial use.
• Above all, observe the safety information!
• The device should only be used as described in this copy of the user instructions.
• Keep this copy of the user instructions for reference.
• If you pass the device on to someone else, please include this copy of the user instructions. The user instructions are a part of the product.

We hope you enjoy using your new coffee machine!

Symbols on your device

The symbol indicates that materials marked in this way will not change the taste or smell of food.

2. Intended purpose

The coffee machine is intended exclusively for the production of filter coffee. The device is designed for private, domestic use. The device must only be used indoors. This device must not be used for commercial purposes.

Foreseeable misuse

WARNING! Risk of material damage!

- Never put fluids other than fresh drinking water into the water tank 6!

3. Safety information

Warnings

If necessary, the following warnings are used in this copy of the user instructions:

DANGER! High risk: failure to observe this warning may result in injury to life and limb.

WARNING! Moderate risk: failure to observe this warning may result in injury or serious material damage.

CAUTION: low risk: failure to observe this warning may result in minor injury or material damage.

NOTE: circumstances and specifics that must be observed when handling the device.

Instructions for safe operation

- This device can be used by children from the age of 8 and people with restricted physical, sensory or intellectual abilities or people without adequate experience and/or understanding, if they are supervised or instructed on how to use this device safely and if they are aware of the resulting dangers.

- Children must not play with the device.

- Cleaning and user maintenance must not be performed by children unless they are older than 8 years and supervised.

- Children under the age of 8 must be kept away from the device and the power cable.

- This device is equally intended for use in the home and in applications similar to the home, such as for example...

... in kitchens for staff in shops, offices and other commercial settings;

... on agricultural properties;

... by customers in hotels, motels and other residential facilities; ... in bed-and-breakfast establishments.

- This device is not intended to be operated using an external timer or a separate remote control system.

- Fill the device only to the maximum filling level, as boiling water may otherwise spray out.

- The coffee machine, the power cable and the mains plug must not be immersed in water or other liquids.

- If the power cable of this device should become damaged, it must be replaced by the manufacturer, the manufacturer's customer service department or a similarly qualified specialist in order to avoid any hazards.

- Please take note of the chapter on cleaning (see "Cleaning" on page 21).

- Make sure that no liquid overflows onto the device plug connection.

- Remember that the surface of the hot plate remains hot after use.

DANGER for children

- Packing materials are not children's toys. Children should not be allowed to play with the plastic bags. There is a risk of suffocation.

DANGER to and from pets and livestock

Electrical devices can represent a danger to pets and livestock. In addition, animals can also cause damage to the device. For this reason you should keep animals away from electrical devices at all times.

DANGER! Risk of electric shock due to moisture

• Protect the device from moisture, water drops and water splashes: failure to observe this instruction may result in an electrical shock hazard.
• If liquids get into the device, remove the mains plug immediately. Have the device checked before reusing.

DANGER! Risk of electric shock

• Do not use the device if the device or the power cable has any visible damage, or if the device has previously been dropped.
• Only connect the mains plug to a properly installed and easily accessible grounded wall socket whose voltage corresponds to the specifications on the rating plate. The wall socket must still be easily accessible after the device is plugged in.
• Ensure that the power cable cannot be damaged by sharp edges or hot spots. Do not wrap the power cable around the device.

• The device is not fully disconnected from the power supply, even after it is switched off. In order to fully disconnect it, pull out the mains plug.

• When using the device, ensure that the power cable cannot be trapped or crushed.

• When removing the mains plug from the wall socket, always pull on the plug and never the cable.
• Disconnect the mains plug from the wall socket ...
  ... if there is a fault,
  ... when you are not using the coffee machine,
  ... prior to cleaning the coffee machine, and
  ... during thunderstorms.

- In order to avoid any hazards, do not make modifications to the device.

DANGER! Risk of injury through scalding

During the brewing process, hot steam escapes upwards through the cover. The cover becomes hot. Never touch it or put your hands or other body parts in the steam.
- Fill the coffee machine only to the maximum filling level (10 MAX), as hot water may otherwise spray out.
- Do not bend over the coffee machine when you open the holder and the contents are still hot. There is a danger of being scalded by escaping steam.

WARNING! Risk of material damage

The device is fitted with non-slip silicon feet. Because furniture can be coated with a wide variety of varnishes and plastics, and treated with various care products, the possibility cannot be excluded that some of these substances have components that may attack and soften the silicon feet. If necessary, place a non-slip mat under the device.
- Never put fluids other than fresh drinking water into the coffee machine!
- Place the device on a stable, level surface.
- Do not use any astringent or abrasive cleaning agents.

4. Items supplied

1 coffee machine
1 pot 8
1 filter holder 4
1 permanent filter 2
1 coffee spoon
1 copy of the user instructions

5. How to use

DANGER! Risk of electric shock!

- Only connect the device to an easily accessible wall socket with earthing contacts whose voltage corresponds to the specifications on the rating plate. The wall socket must still be easily accessible after connection.

• Remove all packing materials.
• Check to ensure that all parts are present and undamaged.
• Place the device on a dry, level, non-slip surface.

6. Before using for the first time

Clean all parts before using for the first time (see "Cleaning" on page 21).

1. Fill the water tank 6 with clear water up to the 8 cup marking twice and start the brewing process (see "Operation" on page 19).
2. This process should be repeated once.
3. Wait until the coffee machine has cooled down. Then it is safe to use the device.

7. Operation

DANGER! Risk of injury through scalding!

• During the brewing process, hot steam escapes upwards through the cover 14. The cover 14 becomes hot. Never touch it or put your hands or other body parts in the steam.
• Fill the coffee machine only to the maximum filling level (10 MAX), as hot water may otherwise spray out.

WARNING! Risk of material damage!

• Fill in water at least up to the 2 marking on the water level indicator 13. Otherwise the device may overheat.
• Never put fluids other than fresh drinking water into the coffee machine.

7.1 Anti-drip

The filter holder 4 has an anti-drip valve 5. This ensures that no coffee drips out of the filter when you remove the pot 8.

In order to ensure that the anti-drip valve 5 opens during the brewing process, it is important that the filter holder 4 is inserted correctly and the pot 8 with its lid 12 closed is positioned completely in the coffee machine. The fitted lid 12 of the pot 8 opens the anti-drip valve 5. Otherwise the filter can overflow.

7.2 Opening and closing the lid

In order that the appliance can work correctly, it is important that the pot 8 is placed in the coffee machine and that the lid 12 is closed.

7.3 Filling volumes

Always fill the water tank 6 at least up to the marking for 2 cups (2). Do not fill with water above the 10 MAX marking in the water tank.

7.4 Brewing coffee

1. Open the lid 14 of the water tank 6.
2. Only fill fresh, cold tap water into the water tank 6. Hot or carbonated water can result in malfunctions.
   Fill the water tank 6 with water up to the desired marking (maximum 10 cups: 10 MAX).
3. Close the lid 14 of the water tank 6.
4. Hold the filter holder 4 by its handle 3 and lower it into the the coffee machine.
5. Fold down the handle 3 of the filter holder 4.
6. Place the permanent filter 2 into the filter holder 4.
7. Place ground coffee powder into the permanent filter 2. For medium-strength

coffee, put one coffee spoon (around 7 - 8 g) of ground coffee powder per cup into the filter. Use ground coffee powder for filter coffee. If you grind the coffee yourself, grind it to a medium grinding degree.

NOTE: you can also use a paper filter. In this case, the permanent filter 2 must not be inserted, however. Place a paper filter (size 1x4) with folded sides directly into the filter holder 4. When it is folded, the paper filter fits better in the filter holder 4 and the seams are prevented from tearing.

1. Close the cover 14.
2. It is very important that the pot 8 has a closed lid 12 when it is placed on the hot plate 9.
3. Press the button ⏻ 10. The button lights up. The brewing process will start after a short time.
4. After the end of the brewing process, the hot plate 9 remains active for approx. 40 minutes, and the button ⏻ 10 flashes approx. every 2 seconds. The hot plate 9 then switches itself off and the ⏻ 10 button goes out.

NOTE: by pressing the ⏻ 10 button, you can cancel the brewing process and switch off the hot plate 9 sooner at any time.

8. Cleaning

DANGER! Risk of electric shock!

• Pull out the mains plug 11 from the wall socket before cleaning the coffee machine.
• The coffee machine and the power cable with mains plug 11 must not be immersed in water or other liquids.

DANGER! Risk of injury through scalding!

- The coffee machine becomes very hot during operation. Allow it to cool down before cleaning.

WARNING! Risk of material damage!

- Do not use any astringent or abrasive cleaning agents.

NOTE: in order to start the brewing process with clear water or a descaling solution, the filling of the water tank 6 must not exceed the 8 cup marking. Otherwise the pot 8 may overflow.

8.1 Dishwasher

The coffee spoon and the filter holder 4 can be cleaned in the dishwasher.

8.2 After every use

Clean the device after every use, if possible.

1. Pull the mains plug 11 out of the wall socket.
2. Open the cover 14.
3. Only for the permanent filter 2: open the handle 1 of the permanent filter, remove the permanent filter and rinse it out under running water.

4. Fold up the handle 3 of the filter holder 4 and remove the filter holder.

5. Only for paper filters: dispose of the used paper filter.

6. Rinse out the filter holder 4 with warm water.
7. Rinse the pot 8 and its lid 12 with clear water. Only in the case of stubborn residues should you use a little mild detergent and a soft rinsing brush. Then rinse all parts thoroughly with clear water.
8. Wipe down the coffee machine and the power cable 11 with a damp cloth when required. Dry with a dry cloth.
9. Allow all parts to dry completely before you put them away or use the device again.

8.3 Descaling

Time intervals for descaling

The intervals for descaling are dependent on the hardness of the water, and how often you use the device. Where the hardness of the water is medium or high, we recommend descaling monthly.

If using tap water, you can find out the hardness of the water in the area where you live by inquiring at your local waterworks.

After some time, the boiling process will result in limescale being deposited in parts of the coffee machine (depending on the hardness of the water used). You should remove this at regular intervals, because otherwise the power consumption of the device will increase.

1. Turn off the coffee machine and allow it to cool down completely.
2. Place the descaling agent into the water tank 6. Use a liquid, environmentally friendly descaling agent based on citric acid, and follow the instructions of the manufacturer.
3. Fill the water tank 6 to the 8 cup marking.

4. Close the cover 14 of the water tank 6.

5. It is very important that the pot 8 has a closed lid 12 when it is placed on the hot plate 9.

6. Press the button ⏻ 10. The LED ring around the button lights up. The brewing process will start after a short time.

7. Allow approximately half of the descaling agent to run through the machine, and then switch off the device by pressing the button 10.
8. Leave the descaling agent to work for approx. 30 minutes.
9. Switch the coffee machine on by pressing the button ⏻ 10 and allow the rest of the descaling agent to run through.
10. At the end of the brewing process, switch the coffee machine off by pressing the button ⚫10.
11. Empty the pot 8 and rinse it with water.
12. Fill the water tank 6 with clear water up to the 8 cup marking a further two times and start the brewing process.

9. Storage

DANGER for children!

- Keep the device out of the reach of children.

1. Clean the permanent filter 2 and rinse out the filter holder 4 and the pot 8.
2. Leave the cleaned coffee machine and the cleaned accessories to dry before you assemble them and put them away.

10. Disposal

This product is subject to the provisions of European Directive 2012/19/EC. The symbol showing a wheelie bin crossed through indicates that the product requires separate refuse collection in the European Union. This applies to the product and all accessories marked with this symbol. Products identified with this symbol may not be discarded with normal household waste, but must be taken to a collection point for recycling electric and electronic appliances.

This recycling symbol marks e.g. an object or parts of the material as valuable for recycling. Recycling helps to reduce the consumption of raw materials and protect the envi

Packaging

When disposing of the packaging, make sure you comply with the environmental regulations applicable in your country.

11. Trouble-shooting

If your device fails to function as required, please try this checklist first. Perhaps there is only a minor problem, and you can solve it yourself.

DANGER! Risk of electric shock!

- Do not attempt to repair the device yourself under any circumstances.

Fault	Possible causes /Actions
No function	Has the device been connected to the power supply?Check the connection.
The quality of the coffee brewed is becoming worse.	The coffee machine needs to be descaled.
The brewing process takes longer for the same volume.
The cover 14 cannot be closed.	Is the filter holder 4 correctly inserted and is the handle 3 folded down?
The filter overflows during the brewing process.	Is the lid 12 correctly placed on the pot 8?Is the filter holder 4 correctly inserted?

12. Technical specifications

Model: SKMK 1000 A2
Mains voltage: 2	20 – 240 V ~ 50 - 60 Hz
Protection class: I
Power rating: 1,000 W

Symbols used

	Protective earth connection
	Geprüfte Sicherheit (certified safety). Devices must comply with the generally acknowledged rules of technology and the German Product Safety Act (Produkt-sicherheitsgesetz - ProdSG).
	With the CE marking, HOYER Handel GmbH declares the conformity with EU guidelines.
	This symbol reminds you to dispose of the packaging in an environmentally friendly manner.
PAP	Recyclable materials: cardboard (except corrugated cardboard)
	The symbol identifies parts that can be cleaned in the dishwasher.

Subject to technical modifications.

13. Warranty of the HOYER Handel GmbH

Dear Customer,

your device is provided with a 3 year warranty starting with the purchase date. In the event of product defects, you are entitled to statutory rights against the vendor. These statutory rights are not restricted by our warranty presented in the following.

Warranty conditions

The warranty period starts with the purchase date. Please keep the original purchase receipt in a safe place. This document is required to verify the purchase.

If within three years from the purchase date of this product a material or factory defect occurs, the product will be repaired or replaced by us – at our discretion – free of charge to you, or the purchase price will be refunded. This warranty implies that within the period of three years the defective device and the purchase receipt are presented, including a brief written description of the defect and the time it occurred.

If the defect is covered by our warranty, the repaired or a new product will be returned to you. No new warranty period starts with a repair or replacement of the product.

Warranty period and statutory claims for defects

The warranty period is not extended when the warranty has been claimed. This also applies to replaced and repaired parts. Any damages and defects already existing at the time of purchase must be reported immediately upon unpacking. Repairs arising after the expiration of the warranty period are subject to a charge.

Warranty coverage

The device was produced carefully according to strict quality guidelines and tested diligently prior to delivery. The warranty applies to material or factory defects.

Excluded from the warranty are wear parts subject to normal wear and damages to fragile parts, e.g. switches, batteries, lamps or other parts manufactured from glass.

This warranty expires if the product is damaged, not used as intended or not serviced. For the proper operation of the product, all instructions listed in the operating instructions must be observed carefully. Any form of use and handling that is advised against in the operating instructions or warned against must always be avoided.

The product is only intended for private and not for commercial use. In the case of incorrect and improper treatment, use of force and interventions not performed by our authorised Service Centre, the warranty shall cease.

Handling in case of a warranty claim

In order to ensure prompt processing of your matter, please observe the following notes:

- Please keep the article number

IAN: 329281_1904 and the purchase receipt as a purchase verification for all inquiries.

- The article number can be found on the rating plate, an engraving, the title page of your instructions (in the bottom left), or as a label on the rear or underside of the device.

- If faulty operation or other defects occur, first contact the Service Centre listed in the following by telephone or email.

- Then, you are able to send a product reported as defective free of charge to the service address specified to you, including the purchase receipt and the information on the defect and when it occurred.

At www.lidl-service.com you can download this and many other manuals, product videos and installation software.

PDF ONLINE www.lidl-service.com

This QR code takes you directly to the Lidl Service website (www.lidl-service.com), where you can enter the article number (IAN)

329281_1904 to open your user instructions.

Service Centre

GB Service Great Britain

Tel.: [phone]

E-Mail: [e-mail]

IE Service Ireland

Tel.: [phone]

(0,08 EUR/Min., (peak))

(0,06 EUR/Min., (off peak))

E-Mail: [e-mail]

MT Service Malta

Tel.: [phone]

E-Mail: [e-mail]

CY Service Cyprus

Tel.: [phone]

E-Mail: [e-mail]

IAN: 329281_1904

Supplier

Please note that the following address is no service address. First contact the aforementioned Service Centre.

HOYER Handel GmbH

Tasköprüstraße 3

DE-22761 Hamburg

GERMANY

Sommaire
