USER MANUAL Vapore Stiro 2600 Di4

PROBLEMA CAUSA POSSÍVEL SOLUÇÃO

Este produto está em conformidade com a Diretiva Europeia 2012/19/UE quanto a dispo- sitivos elétricos e eletrónicos, conhecida como REEE (Resíduos de Equipamentos Elétricos e Eletrónicos), que disponibiliza o enquadramento legal dentro da União Europeia para a eliminação e reutilização de resíduos eletrónicos e elétricos. Não eliminar este produto no caixote do lixo, dirigir-se antes ao centro de recolha de resíduos elétricos e eletrónicos da área de residência. Esperamos que fique satisfeito com este produto.15 WE WOULD LIKE TO THANKS YOUR FOR CHOOSING DI4, WE WISH THE PRODUCT PERFORMS TO YOUR SATISFACTION AND PLEASURE. WARNING PLEASE READ THE INSTRUCTIONS FOR USE CAREFULLY PRIOR TO USING THE PRODUCT. STORE THESE IN A SAFE PLACE FOR FUTURE REFERENCE. DESCRIPTION A-Spray button B-Shot of steam button C-Steam regulator D- Cover for filling opening E- Output water spray F- Self-cleaning button* G-Temperature Control H-Temperature indicator light I-Level mark for maximum filling J-Power cord K-Soleplate *Depends of the model you can find the special button Self-cleaning or you can find this function in the control of the steam. SAFETY INSTRUCTIONS This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards invol- ved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without su- pervision. If the supply cord is damaged it must be replaced by the ma- nufacturer, its service agent or similarly qualified persons in ENGLISH16 order to avoid a hazard. The iron must not be left unattended while it is connected to the supply mains. The plug must be removed from the socket-outlet before the water reservoir is filled with water. The iron must be used and rested on a flat, stable surface When placing the iron on its stand, ensure that the surface on which the stand is placed is stable. The iron is not to be used if it has been dropped, if there are visible signs of damage or if it is leaking. Keep the iron and its cord out of reach of children less than 8 years of age when it is energized or cooling down. CAUTION Hot surfaces. Surfaces are liable to get hot during use. IMPORTANT WARNINGS This appliance is designed for home use and should never be used for commercial or industrial use under any circumstances. Any incorrect use or improper handling of the product shall render the warranty null and void. Prior to plugging in the product, check that your mains voltage is the same as the one indicated on the product label. If you use one adaptor make sure it can reach 16 A and is provided with earth socket The mains connection cable must not be tangled or wrapped around the product during use.17 Do not use the device, or connect and disconnect to t supply mains with the hands and / or feet wet. Do not pull on the connection cord in order to unplug it or use it as a handle Do not direct steam at people and animals. Do not place the appliance under the tap to fill the water tank, or immerse it in water or other liquids. Unplug the product immediately from the mains in the event of any breakdown or damage and contact an official technical support service. In order to prevent any risk of danger, do not open the device. Only qualified technical personnel from the brand´s Official technical support service may carry out repairs or procedures on the device. Only an official technical support service centre may carry out repairs on this product. Proceed according to maintenance and cleaning section of this manual for cleaning B&B TRENDS SL. disclaims all liability for damages that may occur to people, animals or objects, for the non-observance of these warnings.

BEFORE THE FIRST USE

Before using the steam iron, please ensure you read the user manual and understand all parts and features of the Steam Station. Be sure to remove any packaging material and labels before using for the first time. In the first use they can break off odors or fumes that sent quickly. Do not spray for the first time on clothes and there may be traces of dirt on the soleplate

Always check whether a label with ironing instructions is attached to an article to be ironed. Follow these instructions in all cases. Turn the temperature control dial round to set the appropriate temperature indicated in ironing ins- tructions or in fabric label. Marking Material, for example

• (1 dot) Acetate, elastane, polyamida, polypropylene

• • (2 dots) Cupro, polyester, silk, triacetate, viscose, wool

• •• (3 dots) Cotton, linen Insert the main plug into the wall socket. The indicator light will turn on. When the indicator light goes out you may start ironing.18

Unplug the iron before filling the water tank. Open the cover for filling. Slowly pour water through the water inlet. Do not fill higher than mark on the water tank, in order to avoid spilling out of water. NOTE: Your steam iron is designed to use tap water, however, if the water is very hard, it is advisable to use distilled water. The water tank should be emptied after each use. SPRAYING As long as there is enough water in the water tank, you may use the spray button at any temperature setting during steam or dry ironing. Press the spray button several times to activate the pump while you are ironing. STEAM IRONING Set the temperature control dial to the desired position in accordance with the manufacturer’s label. Set the variable steam control to the desired position. CAUTION: Avoid coming in contact with ejected steam. DRY IRONING The steam iron can be used on the dry setting with or without water in the water tank, it is best to avoid having the water tank full while dry ironing. Turn the variable steam control to the minimum position. Select the setting on the temperature control dial best suited for the fabric to be ironed. CAUTION: If the steam iron has been used for a long time, it is hot and there is no water. Do not refill it with water until the steam iron cools down.

The shot of steam feature provides additional steam for removing stubborn wrinkles. Turn off the variable steam control to the min position Press the powerful steam button to release the burst of steam. NOTE: To prevent water leakage from the soleplate, do not keep the powerful steam button in conti- nuously and wait almost 5 seconds between pressures. VERTICAL IRONING By pressing the shot-steam button at intervals you can also iron vertically (curtains, hung garments, etc.) NOTE: To prevent water leakage from the soleplate, do not keep the powerful steam button in conti- nuously and wait almost 5 seconds between pressures.19

WHEN YOU FINISHED IRONING

Set the temperature dial to the minimum position. Remove the main plug from the wall socket. Stand the iron on heel rest.

MANITENCE AND CLEANING

It is recommended to the self-cleaning every two weeks if the water in the area is hard or semi-hard if frequent use of the device is made Before cleaning the steam iron ensure it is unplugged from the power supply and has completely cooled down. Do not use abrasive cleaners. To clean exterior surfaces, use a damp soft cloth and wipe dry. Do not use any chemical solvents, as these will damage the surface. Cleaning the soleplate; do not use scouring pads or harsh cleaners on the soleplate as these will da- mage the surface. To remove burnt residue, iron over a damp cloth while iron is still hot. To clean the soleplate, simply wipe with soft damp cloth and wipe dry. SELF-CLEANING Fill the half of the water reservoir. Set the temperature control to its maximum position. Insert the main plug into the wall socket. Allow the iron to heat up until the indicator light goes out. Unplug the steam iron. Holding the iron horizontally over the sink and press the button of self-clean, in case if not have this button change the steam control to the maximum position. Boiling water and steam will be ejected from the holes in soleplate with impurities washed out Move the iron over an old (preferably) piece of cloth. This ensures that the soleplate will be dry during sto- rage. ANTI-CALC SYSTEM A special resin filter inside the water reservoir softens the water and prevents scale build-up in the plate. The resin filter is permanent and does not need replacing. Please note: Use tap water only. Distilled and/demineralized water makes the “Zero-Calc”, anti-calc system ineffective by altering its physicochemical characteristics. Do not use chemical additives, scented substances or decalcifies. Failure to comply with the abo- ve-mentioned regulations leads to the loss of guarantee. ANTI-DRIP SYSTEM With the anti-drip system, you can perfectly iron even the most delicate fabrics. Always iron these fabrics at low temperatures. The plate may cool down to the point where no more steam comes out, but rather drops of boiling water that can leave marks or stains. In these cases, the Anti-drip system automatically activates to prevent vaporization, so that you can iron the most delicate fabrics without risk of spoiling or staining them.20 TROUBLESHOOTING PROBLEM POSSIBLE CAUSE Solution SOLEPLATE IS NOT HEATING EVEN THOUGH

ON. Connection problem Check main power supply cable, plug and outlet. Temperature control is in MIN position Select adequate temperature

PRODUCE STEAM Not enough water in tank Fill water tank Steam control is selected in non- steam position. Set steam control between positions of minimum steam and maximum steam (see“iron chart”). Selected temperature is lower than that specified to use with steam. Select a higher temperature SPRAY FUNCTION DOES NOT WORK Not enough water in tank Fill water tank (see “getting started”, no 2).

PROBLÈME CAUSE POSSIBLE SOLUTION

Consumers should contact a technical service centre authorised by B&B TRENDS, SL. for repair of the product as any tampering thereof by persons not authorised by B&B TRENDS, SL., as well as misuse or inappropriate use, will lead to the cancellation of this warranty. The warranty must be fully completed and delivered along with the receipt or delivery docket for the effective exercise of rights under this warranty. Claims must take place within three years from delivery of the product according to the provisions of the warranty, and the consumer must inform the sales vendor of the lack of conformity, provided that such claim is made within the statutory period of warranty This warranty should be retained by the user as well as the invoice, receipt or the delivery docket to facilitate the exercise of these rights. For technical service and after-sales care outside the Spanish territory, please submit your query to the point of sale where you purchased the item or by contacting B&B TRENDS, SL.
