USER MANUAL Betty BA 829 ADE

Digital kitchen scale with black and white bands, displaying a digital display showing 'CO2' (no text or symbols on the device itself)

Inhaltsverzeichnis

Warning symbols including no heart, warning triangle, hazard symbol, and document with a 'F' mark

Statutory instructions on battery disposal

Batteries must not be disposed of as household waste. The law requires that you, as consumer, return the waste batteries either to public collection points in your town or village or to any outlet selling batteries of the same kind. Note:

fies are marked as follows:

Li = Battery contains Lithium

AI = Battery contains Alkali

Mn = Battery contains Manganese

CR 2032 (LI); AA (Al, Mn); AAA (Al, Mn)

Disposal of old electrical and electronic equipment

This symbol on the product or on its packaging indicates that this product shall not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. For more detailed information about recycling contact your local city office, your household waste disposal service or the shop where you purchased the product.

With kind regards

ADE (GmbH & Co.)

Guarantee card - 3 years warranty for the body analysing scale

- Sender

- Reason for complaint

- Date of purchase

Please return this guarantee card together with the receipt to your retailer.

ACTIVITY LEVEL

BODY FAT

BODY WATER

Model Betty / BA 829 Instruction Manual

Digital kitchen glass with black and white casing, showing a digital display on top (no visible text or symbols)

Directory

1. How does the body analyser work? Page 2
2. Conditions to use Page 2
3. Commissioning Page 3
4. Weighing function (weight measurement only).....Page 4
5. Programming / enter of personal data ...... Page 4
6. Body Analysis.....Page 5
7. Error Messages Page 7
8. Technical Data Page 7
9. Warranty Page 7

Thank you for your decision to purchase this high quality body analyser scale. Please read this instruction manual prior to the start up and keep this user instruction careful to have this information on hand whenever needed.

1. How does the body analyser work?

Through this new revolutionary scale, you will be able to get information about your body composition with reference to your weight, body fat %, body water % and BMI (body mass index). First of all you have to enter once your personal data like gender (male / female), body height and age under your selected personal memory location. Afterwards a measurement is as simple as on a normal bathroom scale. You have only to push your personal memory location, step on the scale and within a few seconds your measured values will be indicated. The analysis is based on the measurement of the body's electrical resistance. A low, safe electrical signal passes freely through fluids contained in lean tissue, such as muscle and blood, but meets resistance passing through fat tissue. The body analyser accurately measures the resistance and with reference to your personal data use it to calculate elements of body composition.

2. Conditions to use

If possible, the measurement should be done undressed but always barefoot.

By nature, a body is subject of fluctuations (for example: loss of water after taking exercise or after a sauna visit, after a meal, etc.). To enable comparable readings it is important to take the measurements as possible always under the same conditions.

In order to ensure that the results of analysis are accurate and consistent, please keep the measurement conditions constant always at the same daytime. In the morning, directly after you've woken up, your body will be dehydrated and also the majority of fluid will be stored in the central trunk area. This means that the resistance is relatively high because of the poor conductivity in the body. By intensify moving during the day progresses the fluid becomes more evenly distributed through the limbs and increasing the accuracy of the readings. To get a realistic result it is important to take your readings at the same time and under the same conditions every day. The easiest way to stick the rule, measure always in the morning, 15 minutes after you've got up, either before or after you've gone to the bathroom.

In spite of a very low electrical signal, this body analyzer is not suitable for persons with heart pacemaker or other electronic medical implants! There is no risk for persons with none electronic implant for instance a titanium plate in the knee. However, metal conducts the electric current extremely well and therefore the scale implicates the body fat value "beautified" – means the actual body fat value is higher as indicated. However, tendencies may be determined as well. Due to menstrual cycle and hormonal changes women experience greater changes in their hydration level. Retaining fluid may cause the weight to fluctuate day-to-day. This will also affect the body fat percentage readings. If the hydration level is high the body

8. Error Messages

“LO” = Batteries are used up - Please replace the batteries with the intended type (4 x AAA).

“O_Ld” = Overload - The weight exceeds the maximum capacity of 180 kg. Please immediately remove the critical load to avoid load cell damage.

"Err" = Incorrect weighing / measuring process - For example, the scale is placed unstable, you do not remain stationary on the weighing platform or if body fat is less than 3% or higher than 55%.

9. Technical Data

Capacity x graduation: max. 180 kg x 100 g

Display resolution: body fat: 0.1%

Display resolution: body water: 0.1%

Display resolution: BMI (Body Mass Index)

Personal memory loc.: 12 positions

Age: 10 – 99 years

Body height: 100 – 220 cm

Dimensions: 330 mm x 330 mm x 21,5 mm

Batteries: 4 x AAA (included)

Subject to technical modifications

10. Warranty

ADE warrants for a period of 3 years from the date of purchase that it will remedy any defects due to faulty material or workmanship free of charge by repair or replacement. When purchasing, please have the warranty coupon signed and stamped by the dealer. When making a guarantee claim, please return the weighing scale together with the guarantee card including the reason of complaint to your dealer.

CE-Conformity. This device features radio interference suppression in compliance with valid EC Regulation 2004/108

Note: The displayed value may be adversely affected under extreme electromagnetic influences, e.g. when using a radio unit in the immediate vicinity of the device. Once the interference has been rectified, the product can once again be used for its intended purpose. The device may have to be switched on again.

The body fat content is shown as the amount of stored fat as a percentage of total body weight. There is no generally accepted set value as this varies significantly according to gender (due to the different build) and age. Body fat is vital for basic body functions. It's protecting organs, cushioning joints, regulating body temperature, storing vitamins and serves the body as energy storage. As essential for women a minimum body fat proportion between 10% and 13% and for men between 10% and 13% is requested - with the exception of competitive athletes.

Body fat is not a clear indicator for health. Too high body weight and a too high body fat proportion are linked to the incidence of many civilization diseases such as diabetes, cardiovascular diseases, etc. Lack of movement and improper nutrition are often the prime course for these diseases. There is a obvious direct relationship between overweight and lack of movement.

A significant part of the human body consists of body water. This body water is differently distributed throughout the whole body. Lean muscle tissue contains approx. 75% body water, blood approx. 83% body water, body fat approx. 25% body water and bones have a water content of about 22%.

The average total body water percentage range for healthy men is between 50 – 65%. The equivalent value for women is approximately 45 – 60% due to the higher body fat content. About two third of the total body water is stored in the cells and is therefore called intra cellular. The other third of the total body water is extra cellular body water.

Women
AGE	Body Fat				Body Water
	slim	normal	slightlyoverweight	overweight	normal
10-16	<18%	18-28%	29-35%	>35%	57-67%
17-39	<20%	20-32%	33-38%	>36%	47-57%
40-55	<23%	23-35%	36-41%	>41%	42-52%
56-85	<24%	24-36%	37-42%	>42%	37-47%
Me ^(CCDA)
AGE	Body Fat				Body Water
	slim	normal	slightlyoverweight	overweight	normal
10-16	<10%	10-18%	19-23%	>23%	58-72%
17-39	<12%	12-20%	21-25%	>25%	53-67%
40-55	<13%	13-21%	22-26%	>26%	47-61%
56-85	<14%	14-22%	23-27%	>27%	42-56%

fat percentage is slightly less – a less hydration level means the body fat percentage is slightly higher.

There is no healthy risk for pregnancy. The body analyzer is absolutely safe for the mother and her unborn baby. However, due to the changes in water content in the mother's body, the readings should not be interpreted as completely accurate.

ADE Germany takes no responsibility for any damages or losses caused by the use of this body analyzer scale or for Third Party claims. This product is exclusively intended for private use. This product is not designed for commercial or professional use in hospitals or other medical facilities.

3. Commissioning

Safety guidelines:

Persons (including children) with reduced physical, sensory, or mental capabilities or lack of experience and knowledge do not intend the appliance for use, unless a person responsible for their safety has given them supervision or instruction concerning use of the appliance.

- Children should be supervised to ensure that they do not play with the appliance.

Warning symbols including no heart, warning sign, falling object, warning triangle, and warning sign with a document.

Not suitable for persons with electronic implants (heart pacemaker, etc.).

Place the scale on a plane and firm surface (tiles, hardwood flooring, etc.) to avoid a wrong measurement on carpeted floor.

Always stay in the centre of the scale to prevent the scales tipping to the side.

Attention - Hazard of slips! Do not stand on the scale with wet feet or on a slippery surface of the weighing platform.

Please care that no heavy object may fall on the scale. The glass surface is breakable.

Clean the scale only by using a slightly damp cloth. Do not use solvents or abrasive cleaning agents. Do not submerge the scale under water.

Preparation: Open the battery cover at the bottom side of the scale and insert the supplied batteries. Please ensure the correct polarity of the batteries (+/-).

There is a little switch button at the bottom side of the scale KG / LB / ST for country specific settings with the option to switch from kg = kilogram to lb = pound or st = stone. Please pay attention to use the scale under consideration of your country specific unit of weight.

4. Weighing function (weight measurement only)

1. Switch-on the scale by using the tap-on-function. For this, tap with your foot shortly on the centre of the scale. The display indicates the signal "0.0 kg". Now the scale is ready to use.
2. Step on the centre of the scale. Remain stationary on the weighing platform and do not you hold tight. After a few seconds, your weight will be indicated.
3. After weighing, step off the scale. The scale will automatically switch-off after a few seconds.

5. Programming / Enter of personal data

Before first time use your personal data like gender (female or male), body height, age and fitness level (A1 = no sport, A2 = occasional sport, A3 = regular sport, A4 = daily sport, A5 = athlete) must be programmed and saved under selected locations 1 - 12 (up to 12 persons). The enter keys are located at the head front of the scale. To enter your personal data please utilise the buttons: ▼(minus button), ▲(plus button), SET (save button) and follow the particular points:

1. Place the scale on a table. Switch-on the scale by using the tap-on-function. For this, tap with your hand shortly on the centre of the scale. The display will indicate the signal "0.0 kg". To select your personal location (01-12) press the SET-button and select your personal location by using the ▲ or ▼ button. Press the SET-button to save the reading.

01

1. After you've selected your personal location (e.g. 03) the symbol for gender starts to flash. To select the requested gender ( ♣ female or ♦ male), press the ▲ or ▼ button. After the selection of your gender press the SET-button to save the reading.

Age	30	170cm
	A	1 03

1. After you've selected your gender (e.g. female) the symbol for body height starts to flash (default 170cm). To enter your height press the ▲ or ▼ button. After the selection for your height press the SET-button to save the reading.

Age	30	170cm
		A 1 03

1. After you've selected your body height the symbol for age starts to flash (default Age 30). To enter your press the ▲ or ▼ button. After the selection of your age press the SET-button to save the reading.

Age 30	170cm
	A 1 03

1. After you selected your age the symbol for fitness level starts to flash (default A1). To enter your fitness level (A1-A5), press the ▲ or ▼ button. After the selection of your fitness level, press the SET-button to save the reading.

Age	30	170cm
	A	1 03

A few seconds after completion of the input, the scale automatically power-off.

To enter personal data of further persons or to change already stored data please repeat the steps listed below.

6. Body Analysis

An analysis is only possible in bare feet. Your personal data must be entered first (please see page 4-5).

1. Switch-on the scale by using the tap-on-function. For this, tap with your foot shortly on the centre of the scale. The display indicates the signal ,8888" and a few seconds later "0.0 kg". To select your personal location (01–12), press the ▲ or ▼ button.
2. At the first time measurement, the display indicates the under this location stored data and a few seconds later 0.0^ kg. When you once used the scale, the display indicates at first the under this location stored data and afterwards the readings of your last measurement. This function allows you to follow the changes between your measurements.
3. As soon as "0.0 kg" appears on the display, the scale is prepared for the measurement.
4. Carefully in bare feet step on the stainless steel strips on the right and left side of the weighing platform and remain stationary while the measurement is now taking place.
5. At first, your weight will be indicated. Shortly after, while the analysis is taking place the signal “↑” start to move. After completion of the measurement, the display indicates as follows: weight, body fat, body water, and BMI (body mass index).

EXAMPLE:

F 23.8% W 57.3%
kg 56.4	23.4BMI	F = Body Fat %W = Body Water %BMI = Body Mass Index

Normal BMI range for men:

Normal BMI range for women:

Normal BMI for elder persons:

between 20 and 25

between 19 and 24

up to 26
