Brand	Korona
Model	10233
Product type	Drip coffee maker
Maximum capacity	12 cups
Water reservoir	With level indicator
Filter type	Reusable permanent filter and paper filter
Automatic shut-off function	Yes, after 40 minutes
Keep warm	Yes, via heating plate
Anti-drip system	Yes
Power supply	Mains (estimated 220-240 V, 50/60 Hz)
Power	1000 W (estimated)
Material	Plastic, glass (carafe)
Cleaning	Washable with water, descaling recommended
Safety	Automatic shut-off, caution hot surfaces
Warranty	2 years
After-sales service	KORONA Service, Germany
Country of origin	Germany (brand)
Number of manual pages	48 pages

Frequently Asked Questions - 10233 KORONA

How to use the Korona 10233 coffee maker?

Open the lid, fill the water reservoir to the desired level (max 12 cups), place a paper filter or the permanent filter, add ground coffee, close the lid, place the carafe on the heating plate, then press the on/off button. The automatic shut-off activates after 40 minutes.

What type of filter to use?

You can use a disposable paper filter or the provided reusable permanent filter. Never use both simultaneously.

How to clean the machine?

Unplug the appliance and let it cool down. Remove the filter and carafe. Wash the removable parts with warm soapy water. Wipe the exterior with a damp cloth. Never immerse the appliance in water.

How to descale the machine?

Use a mild descaling agent suitable for coffee machines. Follow the manufacturer's instructions. After descaling, rinse the appliance by running two cycles of clear water.

What to do if the machine does not turn on?

Check that the appliance is plugged in and the power outlet works. Make sure the carafe is correctly placed on the heating plate, as the safety system prevents operation without the carafe.

How many cups can you prepare?

The maximum capacity is 12 cups. The water reservoir is graduated to indicate the desired number of cups. Do not exceed the max level.

How to stop the machine before the end of the cycle?

Press the on/off button to interrupt brewing. You can also remove the carafe to activate the anti-drip system; replace it within 30 seconds to resume brewing.

Is the automatic shut-off adjustable?

No, the automatic shut-off is set to 40 minutes after the end of brewing. It cannot be modified.

Can I use the carafe on a heating plate?

Yes, the glass carafe is designed to be kept warm on the appliance's heating plate. Do not remove it unnecessarily to maintain temperature.

Where to find spare parts or after-sales service?

Contact KORONA after-sales service at the address: KORONA Service, Am Steinbach 9, 59872 Meschede-Enste, Germany. Phone: [phone], Email: [e-mail], Website: www.korona-electric.de

USER MANUAL 10233 KORONA

Before use, please read these instructions carefully and keep them in a safe place for future reference. When passing on the appliance to a third party, make sure to include these instructions for use.

attempt to heat any other liquids in it. This appliance is only intended for private household use!

Safety:

This symbol warns of hot surfaces. Risk of burns!
This symbol identifies electric shock hazards!
! General Safety Instructions

caused by incorrect use.

sure your local voltage matches the technical data of the appliance. Otherwise the appliance may overheat and get damaged.

Caution! Danger of electric shock!

other liquid.

An electric appliance is not a toy!

and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall

supervised.

before cleaning.

surfaces to avoid any damage to the appliance.

cause anyone to trip when in use. Do not allow the cord to hang over sharp edges.

Do not use the appliance,

Have it checked and, if necessary, repaired by a qualified modifications to or repair the appliance yourself.

Special Safety Instructions

1 5

Warning! To avoid the possibility of injury/damage to the appliance, electric shock and risk of burns.

be high during operation. Therefore, do not touch the

use the handle. Danger of serious burns!

during operation, hot steam evaporates. Danger of serious burns!

water from spilling. Danger of serious burns!

cool down before cleaning.

Product Description

1. Appliance lid
2. Water tank with water level indicator
3. Hot plate
4. Carafe
5. Filter holder + permanent filter
6. Water outlet

Before First Use

appliance is complete.

and Care.

and connect it to a properly installed wall socket.

times without coffee. After that your coffee maker is ready for operation.

Note: After each rinse cycle, the appliance has to be switched off for approx. 5 minutes, in order to cool down.

Warning: Plastic bags are a danger to toddlers and babies, therefore keep them away to avoid suffocation.

Operation

Brewing Coffee

Using a Paper Filter

• hot water could evaporate - Danger of serious burns!

• Place the appliance on an even and heat resistant surface and connect it to a properly installed wall socket.

• Open the appliance lid (1) and fill the water tank (2) with cold, fresh tap water. The markings on the water tank (2) indicate the required water level to brew the desired

cups).

1. Insert a standard paper filter 1 × 4 into the filter holder (6).

it slightly down.

Note: When using a paper filter, remove the permanent filter from the filter holder before inserting the paper filter.

1. For each cup of coffee, use one leveled measuring spoon (9) of grounded coffee. For stronger or milder coffee,
2. Close the appliance lid (1) and place the carafe (5) into

placed into the appliance

The integrated indicator light indicates that the appliance is in operation. The brewing process can be interrupted

unit is switched on again the appliance will continue with the brewing process.

Note: If you wish to have a cup of coffee before the brewing cycle is completed, remove the carafe (5) from the appliance. Due to the automatic drip stop, dripping will automatically cease. Put the carafe (5) back within 30 seconds, dripping process will automatically resume.

1. After the brewing cycle is completed (no more water is dripping through the filter), the carafe (5) can be removed. When serving coffee do not remove the lid in order to preserve the proper serving temperature.

the coffee hot, by returning the carafe (5) to the hotplate (4) after serving. The hotplate (4) will automatically cycle on and off to maintain the ideal serving temperature as long as the coffee maker is switched on.

within 40 minutes and the indicator light will go OFF as well.

warm function is also deactivated.

Using the permanent filter

When using the permanent filter, do not insert a paper filter!

Instead of inserting a paper filter into the filter holder (6) you can insert the permanent filter (6) into the filter holder. Add your grounded coffee and follow steps 5 - 9.

After use, remove the grounded coffee and clean the permanent filter (6) as described under Cleaning and Care.

! Note: If you wish to prepare more than one pot of coffee, the appliance has to be switched off for approx. 5 minutes, in order to cool down.

Always disconnect the appliance from the mains if you are not using it!

Cleaning and Care

Before cleaning, always switch off the appliance and disconnect it from the mains. Let it completely cool down.

Shock!

Before cleaning always remove the paper filter resp. the permanent filter!

Clean the body of the appliance with a moistened soft cloth.

All detachable parts can be cleaned in warm water using some dishwashing detergent, rinse them afterwards and dry them thoroughly.

DESCALING

Depending on the water quality and usage, calcification can occur. Therefore, to keep your coffee maker operating efficiently, you should descale it on a regular basis.

limescale built up in the appliance.

To remove limescale, use a common gentle descaler, which is suitable for your appliance. Follow the manufacturer's instructions.

After descending, always rinse your appliance as described under Before First Use.

Note: Descaler mixtures should not be poured down enamel coated sinks.

Storage

Disconnect the appliance from the mains and let it completely cool down.

Keep the appliance away from children and store it in a clean and dry place.

Disposal Instructions

Waste electrical devices marked with this sign must not be disposed of with your household waste, but are to be collected separately. Therefore, please return this device at the end of its life cycle to special collection points for disposal or your local dealer.

Such boxes are recyclable waste, i.e. they are reusable or recyclable.

Technical Data:

Technical data subject to change!

CE

Guarantee:

This product is guaranteed against defects in materials and workmanship for a period of 2 years.

instructions

This guarantee does not affect your statutory right, nor any legal right you may have as a costumer under applicable national legislation governing the purchase of goods.

guaranteed period, the customer must provide evidence of the date of purchase (receipt).

The guarantee is to be asserted against

KORONA electric GmbH, Sundern/Germany.

Service Address:

KORONA Service, Am Steinbach 9, 59872 Meschede,

Germany

Telephone Hotline: [phone]

Mail: [e-mail]

web: www.korona-electric.de

within 2 years after the date of purchase. In case of guarantee the customer is given the right to get the appliance repaired at our own or at an authorized shop. Further rights (due to guarantee case) are not given to the customer.
