USER MANUAL ME21M706BAG SAMSUNG

Microwave Oven User manual ME21M706BA* / ME21R706BA* ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 1 2019-06-19 3:19:022 English Contents ContentsContents Important safety instructions 3 Setting up your new microwave oven 10 Checking the parts 10 Setting up your microwave oven 11 Installing the metal shelf 11 Learning about the control panel 11 Setting the time 12 Using my setting feature 12 Using your microwave oven 13 Using the stop/clear button 13 Using the child lock 13 Using the kitchen timer 14 Using the microwave +30 sec. feature 14 Using the more/less feature 14 Using the eco mode 14 Turntable on/off feature 15 Turning on the light 15 Turning on the vent 15 Using the keep warm feature 16 Using the auto defrost button 16 Using the 1 pound defrost button 17 Using the sensor cooking buttons 18 Using the microwave setting cooking times & power levels 20 Power levels 20 One-stage cooking 21 Multi-stage cooking (maximum of 2 stages) 21 Using the t choice button 22 Using the kids meals button 23 Using the snacks button 24 Using the soften/melt button 25 Cookware guide 26 Recommended cooking utensils 26 Limited use items 26 Not recommended 26 Testing utensils 26 Cooking guide 27 Cooking techniques 27 General cooking recommendations 28 Guide for cooking eggs in your microwave 28 Guide for cooking vegetables in your microwave 28 Cleaning and maintaining your microwave oven 29 Cleaning the exterior 29 Cleaning under your microwave oven 29 Cleaning the control panel 29 Cleaning the door and door seals 29 Cleaning the interior 29 Cleaning the turntable and roller rings 29 Storing and repairing your microwave oven 30 Replacing the cooktop/night light 30 Replacing the oven light 31 Cleaning the grease lter 31 Replacing the charcoal lter 32 Troubleshooting 33 Check points 33 Information codes 37

SAVE THESE INSTRUCTIONS

Important safety instructions Congratulations on your new Samsung microwave oven. This manual contains important information on the installation, use and care of your appliance. Please take time to read this manual to take full advantage of your microwave oven’s many benets and features.

WHAT YOU NEED TO KNOW

ABOUT SAFETY INSTRUCTIONS

Warnings and Important Safety Instructions in this manual do not cover all possible conditions and situations that may occur. It is your responsibility to use common sense, caution, and care when installing, maintaining, and operating your microwave oven.

PRECAUTIONS TO AVOID

POSSIBLE EXPOSURE TO

EXCESSIVE MICROWAVE ENERGY

A. Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. B. Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on the sealing surface. C. Do not operate the oven if it is damaged. It is particularly important that the oven door close properly and that there is no damage to the:

2. Hinges and latches, (broken or loosened),

3. Door seals and sealing surface.

D. The oven should not be adjusted or repaired by anyone except properly qualied service personnel.

IMPORTANT SAFETY SYMBOLS

AND PRECAUTIONS What the icons and signs in this user manual mean: WARNING Hazards or unsafe practices that may result in severe personal injury or death. CAUTION Hazards or unsafe practices that may result in minor personal injury or property damage. CAUTION To reduce the risk of re, explosion, electric shock, or personal injury when using your microwave oven, follow these basic safety precautions. Do NOT attempt. Unplug the power plug from the wall socket. Do NOT disassemble. Make sure the machine is grounded to prevent electric shock. Do NOT touch. Call the service center for help. Follow directions explicitly. Note These warning signs are here to prevent injury to you and others. Please follow them explicitly. After reading this section, keep it in a safe place for future reference. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 3 2019-06-19 3:19:034 English Important safety instructions Important safety instructions

SAVE THESE INSTRUCTIONS

9. This appliance should be repaired or serviced only by qualied service

personnel. Contact the nearest authorized service facility for examination, repair, or adjustment.

10. Do not cover or block any openings on the appliance.

11. Do not tamper with or make any adjustments or repairs to the door.

12. Do not store this appliance outdoors. Do not use this product near water, for

example, near a kitchen sink, in a wet basement, near a swimming pool, or similar locations.

13. Do not immerse the cord or plug in water.

14. Keep the cord away from heated surfaces. (including the back of the oven).

15. Do not let the cord hang over the edge of a table or counter.

16. When cleaning surfaces of the door and oven that come together when the

door closes, use only mild, nonabrasive soaps, or detergents applied with a sponge or soft cloth. Unplug the plug before cleaning.

17. To reduce the risk of re in the oven cavity:

a. Do not overcook food. Carefully attend the appliance when paper, plastic, or other combustible materials are placed inside the oven to facilitate cooking. b. Remove wire twist-ties from paper or plastic bags before placing the bags in the oven. c. If materials inside the oven ignite, keep the oven door closed, turn the oven off, and disconnect the power cord, or shut off the power at the fuse or circuit breaker panel. If the door is opened, the re may spread. d. Do not use the cavity for storage purposes. Do not leave paper products, cooking utensils, or food in the cavity when not in use.

18. Liquids, such as water, milk, coffee, or tea can be overheated beyond the

boiling point without appearing to be boiling. Visible bubbling or boiling when the container is removed from the microwave oven is not always present. THIS COULD RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN THE CONTAINER IS DISTURBED OR A SPOON OR OTHER UTENSIL IS INSERTED INTO THE LIQUID. To reduce the risk of injury: a. Do not overheat liquid. b. Stir liquid both before and halfway through heating it. c. Do not use straight-sided containers with narrow necks. CALIFORNIA PROPOSITION 65 WARNING WARNING Cancer and Reproductive Harm - www.P65Warnings.ca.gov WARNING To reduce risk of burns, electric shock, re, personal injury or exposure to excessive microwave energy:

1. Read all safety instructions before using the appliance.

2. Read and follow the specic PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO

EXCESSIVE MICROWAVE ENERGY on page 3.

3. This appliance must be grounded. Connect only to properly grounded outlets.

See Important Grounding instructions on page 5 of this manual.

4. Install or locate this appliance only in accordance with the provided

installation instructions.

5. Some products such as whole eggs and sealed containers (for example, closed

glass jars) can explode if heated rapidly. Never heat them in a microwave oven.

6. Use this appliance only for its intended use as described in the manual. Do not

put corrosive chemicals or vapors in or on this appliance. This type of oven is specically designed to heat, cook, or dry food. It is not designed for industrial or laboratory use.

7. As with any appliance, close supervision is necessary when it is used by

children. Keep children away from the door when opening or closing it as they may bump themselves on the door or catch their ngers in the door.

8. Do not operate this appliance if it has a damaged cord or plug, if it is not

working properly, or if it has been damaged or dropped. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 4 2019-06-19 3:19:03English 5 Important safety instructions

SAVE THESE INSTRUCTIONS

WARNING Improper use of the grounding plug can result in a risk of electric shock.

• Plug into a grounded, 3 pronged outlet. Do not remove the third (grounding) prong. Do not use an adaptor or otherwise thwart the safety function of the grounding plug.

• Consult a qualied electrician or service person if you do not understand the grounding instructions or if you are not sure if the appliance is properly grounded.

• We do not recommend using an extension cord with this appliance. If the power-supply cord is too short, have a qualied electrician or serviceman install an outlet near the appliance. However, if it is necessary to use an extension cord, read and follow the “Use of Extension Cords” section below.

USE OF EXTENSION CORDS

A short power-supply cord is provided to reduce the risk of your becoming entangled in or tripping over a longer cord. Longer cord sets or extension cords are available and you can use them if you exercise care. If you use a long cord or an extension cord:

1. The marked electrical rating of the cord set or extension cord should be at

least as great as the electrical rating of the appliance.

2. The extension cord must be a grounding-type 3-wire cord and it must be

plugged into a 3-slot outlet.

3. The longer cord should be arranged so that it will not drape over the

counter top or tabletop where it can be pulled on by children or tripped over accidentally. If you use an extension cord, the interior light may icker and the speed of the blower may vary when the microwave oven is on. Cooking times may be longer too. d. After heating, allow the container to stand in the microwave oven for a short time before removing the container. e. Use extreme care when inserting a spoon or other utensil into the container.

19. Oversized foods or oversized metal utensils should not inserted into the

microwave oven as they may cause a re or risk of electric shock.

20. Do not clean the microwave with a metal scouring pad. A piece of metal could

come off the pad, contact electrical parts, and cause an electric shock.

21. Do not put paper products into the oven when you are operating it in the

22. Do not store any materials, other than manufacturer’s recommended

accessories, in this oven when not in use.

23. Do not cover the racks or any other part of the oven with metal foil. This will

cause the oven to overheat. CAUTION

1. Clean Ventilating Hoods Frequently - Grease should not be allowed to

accumulate on the hood of the lter.

2. When aming foods under the hood, turn the fan on.

3. Use care when cleaning the vent-hood lter. Corrosive cleaning agents, such

as lye-based oven cleaner, may damage the lter. GROUNDING INSTRUCTIONS This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electrical current. This appliance is equipped with a cord that includes a grounding wire and a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 5 2019-06-19 3:19:036 English Important safety instructions Important safety instructions

SAVE THESE INSTRUCTIONS

This appliance must be properly grounded. Read and follow the specic “Grounding instructions” found in the beginning of this section. Do not ground the appliance to a gas pipe, plastic water pipe, or telephone line.

• This may result in electric shock, re, an explosion, or problems with the product.

• Never plug the power cord into a socket that is not grounded correctly and make sure that it is grounded in accordance with local and national codes. Do not cut or remove the third (ground) prong from the power cord under any circumstances. The microwave requires a separate branch circuit single grounded outlet of at least 15A and max of 20A. Do not install this appliance in a humid, oily, or dusty location, or in a location exposed to direct sunlight or water (rain drops).

• This may result in electric shock or re. Plug the power plug into the wall socket rmly. Do not use a damaged power plug, damaged power cord, or loose wall socket.

• This may result in electric shock or re. Do not mount over a sink. Do not pull or excessively bend the power cord. Do not twist or tie the power cord. Do not hook the power cord over a metal object, place a heavy object on the power cord, insert the power cord between objects, or push the power cord into the space behind the appliance.

• This may result in electric shock or re. Do not pull the power cord when you unplug the oven.

• Unplug the oven by pulling the plug only.

• Failing to do so may result in electric shock or re. If the power plug or power cord is damaged, contact your nearest service center for a replacement or repair. CRITICAL INSTALLATION WARNINGS This appliance must be installed by a qualied technician or service company.

• Failing to have a qualied technician install the oven may result in electric shock, re, an explosion, problems with the product, or injury. Unpack the oven, remove all packaging material and examine the oven for any damage such as dents on the interior or exterior of the oven, broken door latches, cracks in the door, or a door that is not lined up correctly. If there is any damage, do not operate the oven and notify your dealer immediately. Make sure to install your oven in a location with adequate space. Remove all foreign substances such as dust or water from the power plug terminals and contact points using a dry cloth on a regular basis.

• Unplug the power plug and clean it with a dry cloth.

• Failing to do so may result in electric shock or re. Plug the power cord into a properly grounded 3 pronged outlet. Your oven should be the only appliance connected to this circuit.

• Sharing a wall socket with other appliances, using a power strip, or extending the power cord may result in electric shock or re.

• Do not use an electric transformer. It may result in electric shock or re.

• Ensure that the voltage, frequency and current provided match the product’s specications. Failing to do so may result in electric shock or re. Keep all packaging materials out of the reach of children. Children may use them for play. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 6 2019-06-19 3:19:03English 7 Important safety instructions

SAVE THESE INSTRUCTIONS

In the event of a grease re on the surface units below the microwave oven, smother the aming pan on the surface unit by covering the pan completely with a lid, a cookie sheet, or a at tray. Never leave surface units beneath your microwave oven unattended at high heat settings. Boil overs cause smoking and greasy spillovers that may ignite and spread if the vent fan is operating. To minimize automatic fan operation, use adequate sized cookware and use high heat on surface units only when necessary. If materials inside the microwave oven should ignite, keep the oven door closed, turn the oven off and disconnect the power cord, or shut off power at the fuse or circuit breaker panel. If the door is opened, the re may spread.

• Always observe safety precautions when using your microwave oven. Never try to repair the oven on your own. There is dangerous voltage inside. If the oven needs to be repaired, contact an authorized service center near you. Do not attempt to repair, disassemble, or modify the appliance yourself.

• Because a high voltage current enters the product chassis during operation, opening the chassis can result in electric shock or re.

• You may be exposed to electromagnetic waves.

• If your microwave oven requires repair, contact your nearest Samsung service center. If any foreign substance such as water enters the microwave, unplug it, and then contact your nearest service center.

• Failing to do so may result in electric shock or re. INSTALLATION CAUTIONS Position the oven so that the plug is easily accessible.

• Failing to do so may result in electric shock or re due to electric leakage. Unplug the oven when it is not being used for long periods of time or during a thunder/lightning storm.

• Failing to do so may result in electric shock or re.

CRITICAL USAGE WARNINGS

If the microwave appliance is ooded, please contact your nearest Samsung service center. Failing to do so may result in electric shock or re. Read and follow the specic “Precautions to Avoid Possible Exposure to Excessive Microwave Energy”, found in the beginning of this Safety Information Section. If the microwave generates a strange noise, a burning smell or smoke, unplug it immediately and contact your nearest Samsung service center.

• Failing to do so may result in electric shock or re. In the event of a gas leak (propane gas, LP gas, etc.), ventilate the room immediately. Do not touch the microwave, power cord, or plug.

• Do not use a ventilating fan.

• A spark may result in an explosion or re. Take care that the door or any of the other parts do not come into contact with your body while the microwave is cooking or just after cooking.

• Failing to do so may result in burns. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 7 2019-06-19 3:19:038 English Important safety instructions Important safety instructions

SAVE THESE INSTRUCTIONS

USAGE CAUTIONS If the surface of the microwave is cracked, turn it off.

• Failing to do so may result in electric shock. Dishes and containers can become hot. Handle with care. Hot foods and steam can cause burns. Carefully remove container coverings, directing steam away from your hands and face. Remove lids from baby food before heating. After heating baby food, stir well to distribute the heat evenly. Always test the temperature by tasting before feeding the baby. The glass jar or surface of the food may appear to be cooler than the food in the interior, which can be so hot that it will burn the infant’s mouth. Make sure all cookware used in your microwave oven is suitable for microwaving. Use microwavable cookware in strict compliance with such manufacturer’s recommendations. Do not stand on top of the microwave or place objects (such as laundry, oven covers, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance.

• Items, such as a cloth, may get caught in the door.

• This may result in electric shock, re, problems with the product, or injury. Do not operate the appliance with wet hands.

• This may result in electric shock. Do not spray volatile material such as insecticide onto the surface of the appliance.

• As well as being harmful to humans, it may also result in electric shock, re or problems with the product. Do not place the appliance over a fragile object such as a sink or glass object.

• This may result in damage to the sink or glass object. Do not touch the power plug with wet hands.

• This may result in electric shock. Do not turn the appliance off by unplugging the power plug while the appliance is in operation.

• Plugging the power plug into the wall socket again may cause a spark and result in electric shock or re. Keep all packaging materials well out of the reach of children. Packaging materials can be dangerous to children.

• If a child places a bag over its head, the child can suffocate. Do not let children or any person with reduced physical, sensory or mental capabilities use this appliance unsupervised. Make sure that the appliance is out of the reach of children.

• Failing to do so may result in electric shock, burns, or injury. Do not touch the inside of the appliance immediately after cooking. The inside of the appliance will be hot.

• The heat on the inside of your microwave oven can cause burns. Do not put aluminum foil (except as specically directed in this manual), metal objects (such as containers, forks, etc.), or containers with golden or silver rims into the microwave.

• These objects can cause sparks or a re. Do not use or place ammable sprays or objects near the microwave oven.

• Heat from the microwave can cause ammable sprays to explode or burn.

• Failing to do so may result in electric shock or injury. Do not tamper with or make any adjustments or repairs to the door. Under no circumstances should you remove the outer cabinet. Do not store or use your microwave oven outdoors. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 8 2019-06-19 3:19:03English 9 Important safety instructions

SAVE THESE INSTRUCTIONS

CRITICAL CLEANING INSTRUCTIONS Do not clean the appliance by spraying water directly onto it. Do not use benzene, thinner, or alcohol to clean the appliance.

• This may result in discoloration, deformation, damage, electric shock, or re. Before cleaning or performing maintenance, unplug the appliance from the wall socket. Then, remove food waste from the door and cooking compartment.

• Failing to do so may result in electric shock or re. Take care not to hurt yourself when cleaning the appliance. (external/internal)

• You may hurt yourself on the sharp edges of the appliance. Do not clean the appliance with a steam cleaner.

• This may result in corrosion. Keep the inside of your microwave oven clean. Food particles or spattered oils stuck to the oven walls or oor can cause paint damage and reduce the efciency of the oven. Do not put your face or body close to the appliance while it is cooking or when opening the door just after cooking.

• Take care that children do not come too close to the appliance.

• Failing to do so may result in children burning themselves. Do not place food or heavy objects over the door.

• When you open the door, the food or object may fall and this may result in burns or injury. Do not abruptly cool the door, the inside of the appliance, or the dish by pouring water over it during or just after cooking.

• This may result in damage to the appliance. The steam or water spray may result in burns or injury. Do not cook without the glass tray in place on the oven oor. Food will not cook properly without the tray. Do not defrost frozen beverages in narrow-necked bottles. The containers can break. Do not scratch the glass of your microwave oven door with a sharp object.

• This may result in the glass being damaged or broken. Do not store anything directly on top of the appliance when it is in operation. Do not use sealed containers. Remove seals and lids before use. Sealed containers can explode due to buildup of pressure even after the oven has been turned off. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 9 2019-06-19 3:19:0310 English Setting up your new microwave oven Setting up your new microwave oven

• Hardware kit (Screws & Brackets) Manuals (User & Installation) Templates (Top & Wall) NOTE If you need an accessory marked with an * (asterisk), please contact the Samsung Call Center using the phone number listed on the last page of this manual or visit our on-line parts web site at www.samsungparts.com. Setting up your new microwave oven Be sure to follow these instructions closely so that your new microwave oven works properly. Checking the parts Carefully unpack your microwave oven, and make sure you’ve received all the parts shown below. If your microwave oven was damaged during shipping, or if you do not have all the parts, contact the Samsung Call Center. (Refer to the WARRANTY AND SERVICE INFORMATION on page 38.) Microwave oven

1. Open the door by pulling the handle on

the right side of the door.

2. Wipe the inside of your microwave

oven with a damp cloth. indentation pre-assembled roller ring

3. Install the pre-assembled ring into

the indentation at the center of the microwave oven. glass tray

4. Place the glass tray securely in the

center of the pre-assembled roller ring. Installing the metal shelf When you need to use the Metal Shelf, place it on the plastic hooks inside your oven and make sure it is positioned properly to avoid electrical arcing that can damage your oven. CAUTION Make sure the shelf is positioned properly inside the microwave to prevent damage to the oven from arcing. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 11 2019-06-19 3:19:0412 English Setting up your new microwave oven Setting up your new microwave oven The functions, options, and corresponding numeric buttons are listed in the table below. No. Function Description Options 1 Display Weight Weight options are pounds and kilograms. 1 Lbs. 2 Kg. 2 12 HR/24 HR The clock can display in either the 12 HR or 24 HR time mode. 1 12 HR 2 24 HR 3 Sound Sound can be turned On and Off. 1 Sound ON 2 Sound OFF 4 Remind End Signal The Remind End Signal can be turned On and Off. 1 ON 2 OFF 5 Daylight Savings Time Adjustment The time can be advanced one hour for DST without resetting the clock. 1 ON (to advance one hour) 2 OFF (to go back one hour) 6 Demo Mode The Demo Mode can be turned On and Off. 1 ON 2 OFF 7 Filter Remind The Filter Remind function can be turned On and Off. 1 ON 2 OFF 8 Word Scroll Speed There are three speeds, Slow, Normal, and Fast. The default is Normal speed. 1 Slow speed 2 Normal speed 3 Fast speed 9 Clock The clock can be adjusted. Press the numeric buttons to enter the current time. (First 2 digits are for hours, last 2 digits are for minutes.) Setting the time Your microwave oven is equipped with a built-in clock. Set the clock when rst installing your microwave oven and after a power failure. The time is displayed whenever the microwave oven is not being used.

current time. You need to press at least three numbers to set the clock. For example, if the current time is 5:00, press 5, 0, 0. The display will show 5 : 00.

5. Press the OK button.

Using my setting feature You can customize your new microwave oven to suit your preferences. To customize:

2. Press one of the numeric buttons to

select a function you want to customize.

3. Press the OK button.

4. Press one of the numeric buttons to

ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 12 2019-06-19 3:19:04English 13 Using your microwave oven Using your microwave oven Using the stop/clear button The STOP/CLEAR button allows you to clear instructions you have entered. It also allows you to pause your microwave oven’s cooking cycle, so that you can check the food.

• To pause the oven during cooking, press the STOP/CLEAR button once. To restart, press the START button.

• To stop cooking, erase instructions, and return the oven display to the time of day, press the STOP/CLEAR button twice.

• To clear instructions you have just entered, press the STOP/CLEAR button once, and then re-enter the instructions.

• To cancel a timer setting, press the STOP/CLEAR button once. Using the child lock The Child Lock function allows you to lock all buttons except Eco Mode so that the microwave oven cannot be operated by children accidentally. The oven can be locked at any time. Activating / Deactivating If you want to activate or deactivate the child lock function, press the START button for 3 seconds. The display will show ‘CHILD LOCK ON’ or ‘CHILD LOCK OFF’ when the oven is locked or unlocked, and then redisplay the time. NOTE If you change your mind while adjusting a setting, press the STOP/CLEAR button to cancel, and then adjust the setting again. NOTE If there is a power interruption, you will need to reset these options. NOTE If the clock is set for standard time, the Daylight Savings Time Adjustment function allows you to change the time easily without needing to reset the clock. Daylight Saving Time begins for most of the United States at 2 a.m. on the rst Sunday of April and reverts to Standard time at 2 a.m. on the last Sunday of October. Filter Reminder If the Filter Remind function is ON, the microwave will remind you to clean or replace the grease lter every four months. When it is time to clean or replace the grease lter, the microwave displays the “Filter” message to remind you to clean or replace the grease lter. To remove the message, press the number 0 when the microwave is in standby mode. If you don`t want to receive this message, set the Filter Remind function off in Options. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 13 2019-06-19 3:19:0514 English Using your microwave oven Using your microwave oven Using the more/less feature The More or Less feature allows you to adjust the pre-set cooking time. It works with 1 and 2 stage cooking, regular microwave cooking, and Keep Warm.

Use the More or Less feature only after cooking has begun.

1. To ADD more time to a cooking

Each time you press the More button ( ), the cooking time will be increased by 10 seconds.

2. To REDUCE the time of a cooking

procedure, press the Less button ( ). Each time you press the Less button ( ), the cooking time will be decreased by 10 seconds. Using the eco mode Eco Mode reduces standby power usage. When you press the Eco Mode button once, the display will go out and the microwave shifts to a mode which minimizes power usage. To cancel the Eco Mode, press the Eco Mode button once again, or press any other button. Using the kitchen timer Your microwave has a built-in timer function - the Kitchen Timer. Use the Kitchen Timer for timing up to 99 minutes, 99 seconds.

you want the timer to run. (Max time 99 minutes, 99 seconds.)

3. Press the OK button.

4. The display counts down, and then

beeps when the time has elapsed.

5. To cancel the timer setting : Press the

STOP/CLEAR button once. Using the microwave +30 sec. feature This feature offers a convenient way to heat food in set time increments at the High power level (100 % power).

1. Press the +30 sec button for each

additional 30 seconds you want the food to be cooked for. (For example, press the button twice to cook for one minute.)

2. Press the START button.

NOTE When the oven is operating, if you press the +30 sec button, the cooking time will be increased by 30 seconds. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 14 2019-06-19 3:19:05English 15 Using your microwave oven Turning on the vent The vent fan removes steam and other vapors that result from cooking on the rangetop below. Press the Vent button once for boost fan speed, twice for high fan speed, three times for medium fan speed, and four times for low fan speed. Press the Vent button 5 times to turn the fan off. NOTE The exhaust fan’s speed will decrease when the oven’s cooking function is activated. NOTE The Vent Fan protects the microwave from excess heat. It automatically turns on if it senses too much heat. If you have turned the fan on, you may nd that you cannot turn it off. The fan will automatically turn off when the internal parts are cool. It may stay on for 30 minutes or more after the cooktop and microwave controls are turned off. Turntable on/off feature For best cooking results, leave the turntable on. However, for large dishes it can be turned off. Press the Turntable On/Off button to turn the turntable on or off. NOTE You can use this feature in the following modes: Microwave and Keep Warm If the turntable does not rotate for an extended period of time, food may burn. CAUTION The turntable may become too hot to touch. Use pot holders to handle the turntable during and after cooking. Turning on the light Press the Light button to turn the cooktop lamp on or off. Press the button once for high, twice for low, and three times to turn the cooktop lamp off. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 15 2019-06-19 3:19:0616 English Using your microwave oven Using your microwave oven Below are the amounts of food we recommend you apply the Keep Warm function to by Food Type. Food Type Recommended Quantity Liquid 1-2 cups Dry 5-10 oz. Using the auto defrost button To thaw frozen foods, enter the weight of the food, and the microwave automatically sets the defrosting time, power level, and standing time. Press the START button to start defrosting.

enter the weight of the food. (0.1-6.0 lbs. See the table at the beginning of the next page.)

3. Press the START button.

4. The oven will beep and the display will

read TURN THE FOOD OVER during the defrosting process. Open the oven door, and turn the food over. If you do not turn the food over when TURN THE FOOD OVER is displayed, the microwave will continue until the end of cooking time. Using the keep warm feature You can keep cooked food warm in your microwave oven for up to 99 minutes and 99 seconds.

2. Enter the warm hold time by pressing

the numeric buttons. If you don`t set the time, your oven will maintain the Warm Hold function for 99 minutes.

• Keep Warm operates for up to 99 minutes and 99 seconds.

• The Vent Fan protects the microwave from excess heat. It automatically turns on if it senses the overheating. If you have turned the fan on, you may nd that you cannot turn it off. The fan will automatically turn off when the internal parts are cool. NOTE

• Food that is cooked covered should also be covered during Keep Warm.

• Pastry items (pies, turnovers, etc.) should be uncovered during Keep Warm.

• Complete meals kept warm on a dinner plate can be covered during Keep Warm. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 16 2019-06-19 3:19:07English 17 Using your microwave oven Using the 1 pound defrost button To thaw 1.0 lbs of frozen food, press this button, and the microwave automatically sets the defrosting time, power level, and standing time.

3. The oven will beep and the display will

read TURN THE FOOD OVER during the defrosting process. Open the oven door, and turn the food over. Press the START button to resume the defrosting process.

4. If you do not turn the food over when

TURN THE FOOD OVER is displayed, press the START button to continue the defrosting process. The microwave will not continue until you press START. Follow the instructions below when defrosting different types of food. Food Amount Procedure Roast Beef, Pork 2.5-6.0 lbs. Start with the food placed fat side down. After each stage, turn the food over and shield any warm portions with narrow strips of aluminum foil. Let stand, covered for 10-20 minutes. Steaks, Chops, Fish 0.5-3.0 lbs. After each stage, rearrange the food. If there are any warm or thawed portions of food, shield them with narrow, at pieces of aluminum foil. Remove any pieces of food that are nearly defrosted. Let stand, covered for 5-10 minutes. Ground Meat 0.5-3.0 lbs. After each stage, remove any pieces of food that are nearly defrosted. Let stand, covered with foil for 5-10 minutes. Whole Chicken 2.5-6.0 lbs. Before freezing the poultry, remove the giblets. When you defrost the poultry, start defrosting with the breast side down. After the rst stage, turn the chicken over and shield any warm portions with narrow strips of aluminum foil. After the second stage, again shield any warm portions with narrow strips of aluminum foil. Let stand, covered for 30- 60 minutes in the refrigerator. Chicken Pieces 0.5-3.0 lbs. After each stage, rearrange or remove any pieces of food that are nearly defrosted. Let stand for 10-20 minutes. NOTE Check the food when you hear the oven signal. After the nal stage, small sections may still be icy; let them stand to continue the thawing process. The food is not defrosted until all ice crystals have melted. Shielding roasts and pieces of steak using small pieces of foil prevents the edges from being cooked before the center of the food has defrosted. Use narrow, at, smooth strips of aluminum foil to cover edges and thinner sections of the food. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 17 2019-06-19 3:19:0718 English Using your microwave oven Using your microwave oven Category Cook No. Food Amount Directions Popcorn 1 Popcorn 3.0-3.5 oz. 1 package Cook only one microwave popcorn bag at a time. Be careful when removing the heated bag from the oven and opening it. Let the microwave oven cool for at least 5 minutes before using it again. Potato 1 Potato 1-6 potatoes. Pierce each potato several times with a fork. Place on the turntable in a spoke-like fashion. After cooking, let the potatoes stand for 3-5 minutes. Let the microwave oven cool for at least 5 minutes before using it again. Pizza 1 Pizza 1-4 slices Place 1-4 pizza slices on a microwave-safe plate with the wide ends of the slices towards the outside edge of the plate. Do not let the slices overlap. Do not cover. Let the microwave oven cool for at least 5 minutes before using it again. Using the sensor cooking buttons The Sensor Cooking buttons let you cook favorite foods using preset power levels and times at the touch of a button. If the food is not thoroughly cooked or reheated when you use the auto cook feature, complete the cooking process by selecting a power level and cooking the food for an additional amount of time.

1. Put the food on the tray.

2. Press the category button that

corresponds to the food you want to cook.

3. Select the Cook Number designated for

that food. To select, press the Up/Down buttons or the appropriate numeric buttons. For example, to reheat a casserole, after selecting Reheat, select

1. See the tables on this page and the

following page for details.

4. Press the START button. The microwave

oven will automatically operate for the preprogrammed time. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 18 2019-06-19 3:19:08English 19 Using your microwave oven Category Cook No. Food Amount Directions Reheat 1 Casserole 1-4 servings Cover the plate with a lid or vented plastic wrap. If the food is not as hot as you would like after using the “Sensor Cooking Reheat” function, continue heating using additional time and power. Stir the food once before serving. Contents: Casserole, refrigerated foods. 2 Dinner plate 1-4 servings Use only precooked, refrigerated foods. Cover the plate with vented plastic wrap or waxed paper tucked under the plate. If the food is not as hot as you would like after using the “Sensor Cooking Reheat” function, continue heating using additional time and power. Contents: 3-4 oz. meat, poultry or sh (up to 6 oz. with bone) ½ cup starch (potatoes, pasta, rice, etc.) ½ cup vegetables (about 3-4 oz.) 3 Pasta 1-4 servings Cover the plate with a lid or vented plastic wrap. If the food is not as hot as you would like after using the “Sensor Cooking Reheat” function, continue heating using additional time and power. Stir the food once before serving. Contents: Pasta: canned spaghetti and ravioli Category Cook No. Food Amount Directions Cook 1 Beverage 8 oz. Use a measuring cup or mug and do not cover. Place the beverage in the microwave oven. After heating, stir well. Let the oven cool for at least 5 minutes before using it again. 2 Chicken Breasts 8-24 oz. Place the chicken breasts on a microwave safe plate and cover with vented plastic wrap. Cook to an internal temperature of 170 °F. Let stand for 5 minutes. 3 Frozen Breakfast 4-8 oz. Follow the package instructions for covering and letting stand. Use this button for frozen sandwiches, breakfast entrees, pancakes, wafes, etc. Let the microwave oven cool for at least 5 minutes before using it again. 4 Frozen Dinner 8-14 oz. Remove the food from its wrapping and follow the instructions on the box for covering and letting stand. Let the microwave oven cool for at least 5 minutes before using it again. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 19 2019-06-19 3:19:0820 English Using your microwave oven Using your microwave oven Using the microwave setting cooking times & power levels Your microwave oven allows you to set two different cooking stages, each with its own time length and power level. The power level lets you control the heating intensity from Warm (1) to High (10). Power levels The 10 power levels allow you to choose the optimal power level for your cooking needs. No. Power Level Description No. Power Level Description 1 10 Warm 6 60 Simmer 2 20 Low 7 70 Medium high 3 30 Defrost 8 80 Reheat 4 40 Medium low 9 90 Sauté 5 50 Medium 10 100 High Category Cook No. Food Amount Directions Veggies 1 Fresh Vegetables (Fresh Veggies) 1-4 cups Place the fresh vegetables in a microwave-safe ceramic, glass, or plastic dish and add 2-4 tbs. of water. Cover with a lid or vented plastic wrap. Stir before letting stand. Let the microwave oven cool for at least 5 minutes before using it again. 2 Frozen Vegetables (Frozen Veggies) 1-4 servings Place the frozen vegetables in a microwave-safe ceramic, glass, or plastic dish and add 2-4 tbs. of water. Cover with a lid or vented plastic wrap to cook. Stir before letting stand for 3-5 minutes. Let the microwave oven cool for at least 5 minutes before using it again. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 20 2019-06-19 3:19:08English 21 Using your microwave oven Multi-stage cooking (maximum of 2 stages) Your oven allows you to set two different cooking stages, each with its own time length and power level. The power level lets you control the heating intensity from Warm to High.

1. Follow steps 1, 2, and 3 from the “One-stage cooking” section.

2. Press the OK button to move to the second stage.

3. Follow steps 1, 2, 3, and 4 from the “One-stage cooking” section.

One-stage cooking For simple one-stage cooking, you only need to set the cooking time. The power level is automatically set to High. If you want to set the power level to any other level, press OK after entering the cooking time, and then use the numeric buttons to set the level.

cooking time. You can enter a time from one second to 99 minutes and 99 seconds. To select a time greater than one minute, enter the seconds too. (For example, to set a cooking time of 20 minutes, enter 2, 0, 0, 0.) If you do not need to set the power level, just press the START button. The microwave will automatically operate at the High power level. If you want to change the power level, go to Step 3.

2. If you want to set the power level to

a level other than High, press the OK button.

3. Press the Up/Down buttons or numeric

buttons that correspond to the power level you want to use.

4. Press the START button. If you want to

add to or reduce the cooking time, use the Up/Down buttons. You can adjust the cooking time while the microwave oven is operating. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 21 2019-06-19 3:19:0822 English Using your microwave oven Using your microwave oven Menu / Item No. / Amount Instructions 3 Brown rice 1 1 serving Place 0.5 cups brown rice + 1 cup water for 2 servings or 1 cup brown rice + 2 cups water for 4 servings in a microwave safe bowl. Stir well before and uff with a fork afterwards. Let stand 5 minutes before serving. 2 2 servings 4 Oatmeal 1 1 package Follow the package directions for the recommended amount of water needed. Stir well before and afterwards. 2 2 packages 5 Quinoa 1 1 serving Follow the package directions for the recommended amount of water needed. When the microwave beeps, stir well, and then restart the microwave. 2 2 servings

Bone in chicken pieces 1 2 servings Brush the chicken pieces with oil and seasonings. Arrange chicken pieces in dish with meatiest portions toward the outside edge of dish, and then cover with wax paper. Place the dish on the center of the turntable. 2 4 servings

Fresh sh llet 1 1 serving Put the llets (cod, pollack, etc.) in a dish, and then cover with plastic wrap. Place the dish on the center of the turntable. 2 2 servings

Fresh salmon llet 1 1 serving Put the salmon llets in a dish, and then cover with plastic wrap. Place the dish on the center of the turntable. 2 2 servings 9 Fresh prawns 1 2 servings Put the prawns in a dish, and then cover with plastic wrap. Place the dish on the center of the turntable. 2 4 servings Using the t choice button

buttons to select the amount. (Refer to the Fit Choice table for the serving size.)

5. Press the START button to begin

cooking. Fit Choice table Menu / Item No. / Amount Instructions 1 Spinach 1 1 serving Wash and clean the spinach. Place the spinach in a microwave safe bowl. Add 1-4 tablespoons of water (1 Tbsp per serving). Cover during cooking and stir afterwards. 2 2 servings 3 3 servings 4 4 servings 2 Squash 1 1-2 lbs. Slice the squash in half and remove the seeds. Place the squash cut side down in a microwave safe dish and cover with the plastic wrap. If needed, add a ¼ cup of water. 2 2-3 lbs. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 22 2019-06-19 3:19:08English 23 Using your microwave oven Using the kids meals button

buttons to select the amount. (Refer to the Kids Meals table for the serving size.)

5. Press the START button to begin

cooking. Kids Meals table Menu / Item No. / Amount Instructions

Chicken nuggets (frozen) 1 1 serving Place a paper towel on a plate and arrange the nuggets in a spoke- like fashion on the paper towel. Do not cover. Let stand for 1 minute after heating. NOTE Refer to the package directions for the serving size and the amount of food. 2 2 servings Menu / Item No. / Amount Instructions

French fries (frozen) 1 1 serving Place two paper towels on a microwave-safe plate and arrange the French fries on the towels without letting them overlap. Blot the fries with additional paper towels after removing from the oven. Let stand for 1 minute. NOTE Refer to the directions on the packaging for the serving size and the amount of food. 2 2 servings

Frozen sandwiches (in crisping sleeve) 9-oz package size 1 1 sandwich Place the frozen sandwich in a susceptor “crisping sleeve” (which is in the package) and place on a microwave-safe plate. Remove from the “crisping sleeve”. Let stand for 2 minutes after heating. 2 2 sandwiches 4 Hot dogs 1 2 hot dogs Pierce the hot dogs and place them on a plate. When the oven beeps, add the buns and restart the oven. Let stand for 1 minute after heating. NOTE For the best texture, the buns should be added to the hot dogs when the oven beeps. 2 4 hot dogs ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 23 2019-06-19 3:19:0924 English Using your microwave oven Using your microwave oven Snacks table Menu / Item No. / Amount Instructions

Cheese sticks (frozen) 1 5-6 pcs (1 Srv.) Place the cheese sticks on a plate in a spoke-like fashion. Do not cover. Let stand for 1 to 2 minutes after heating. 2 7-10 pcs (2 Srvs.)

Chicken wings 1 5-6 oz. (1 Srv.) Use precooked, refrigerated chicken wings. Place the chicken wings around the plate in a spoke-like fashion and cover with wax paper. Let stand for 1 to 2 minutes. 2 7-8 oz. (2 Srvs.) 3 Nachos 1 1 serving Place the nachos on a plate without letting them overlap. Sprinkle cheese evenly over them. Contents: 2 cups tortilla chips ⅓ cup grated cheese 4 Potato skins 1 1 cooked potato Cut the cooked potato into 4 even wedges. Scoop or cut out the potato esh, leaving about a ¼ in. of skin. Place the skins in a spoke- like fashion around the plate. Sprinkle with bacon, onions and cheese. Do not cover. Let stand 1 to 2 minutes.

2 cooked potatoes Using the snacks button

buttons to select the serving size. You can cook only 1 serving for Nachos. (Refer to the Snacks table for the serving size.)

5. Press the START button to begin

cooking. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 24 2019-06-19 3:19:09English 25 Using your microwave oven Soften/Melt table Menu / Item No. / Amount Instructions 1 Melt butter 1 1 stick Remove the wrapping and cut the butter in half vertically. Place the butter in a dish and cover with wax paper. Stir well after nishing and let stand for 1-2 minutes. 2 2 sticks

1 cup chips or 1 square Place the chocolate chips or squares in a microwave-safe container. When the oven beeps, stir the chocolate and restart the oven. Stir and let stand for 1 minute. 3 Soften butter 1 1 stick (¼ lbs.) Remove wrapping and cut butter in half vertically. Place butter in dish, cover with wax paper.

Soften cream cheese 1 1 package (8 oz.) Unwrap the cream cheese and place on a microwave-safe container. Cut in half vertically. Let stand for 2 minutes. Using the soften/melt button

buttons to select the amount. You can cook only 1 serving using the Melt Chocolate, Soften Butter, and Soften Cream Cheese options. (Refer to the Soften/Melt table for the serving size.)

• Glass jars and bottles — Regular glass is too thin to be used in a microwave and can shatter.

• Paper bags — These are a re hazard, except for popcorn bags that are designed for microwave use.

• Styrofoam plates and cups — These can melt and leave an unhealthy residue on food.

• Plastic storage and food containers — Containers such as margarine tubs can melt in the microwave. Testing utensils If you are not sure whether a dish is microwave-safe or not, you can perform this test:

1. Fill a 1 cup glass measuring cup with

water and put it inside your oven, next to the dish you want to test.

2. Set the microwave to 1 minute using

the numeric buttons, and then press the START button. This will heat the glass and dish for one minute at High power. When the microwave stops, the water should be warm and the dish you are testing should be cool. If the dish is warm, then it is absorbing microwave energy and is not acceptable for use in the microwave. Cookware guide To cook food in your microwave oven, microwaves must be able to penetrate the food without being reected or absorbed by the cookware holding the food. Consequently, it is important to choose cookware that both allows microwaves to penetrate food and is microwave-safe. The following lists contain various types of cookware and indicate if and how the cookware should be used in a microwave oven. Recommended cooking utensils

• Glass and glass-ceramic bowls and dishes — Use for heating or cooking.

• Microwavable plastic wrap — Use to cover. Leave a small opening for steam to escape and avoid placing it directly on the food.

• Wax paper — Use as a cover to prevent spattering.

• Paper towels and napkins — Use for short-term heating and covering. They absorb excess moisture and prevent spattering. Do not use recycled paper towels, which may contain metal and can catch re.

• Paper plates and cups — Use for short-term heating at low temperatures. Do not use recycled paper, which may contain metal and can catch re.

• Thermometers — Use only those labeled “Microwave Safe” and follow all directions. Check the food in several places. Conventional thermometers may be used once the food has been removed from the oven. Limited use items

• Aluminum foil — Use narrow strips of foil to prevent overcooking of exposed areas. Using too much foil can damage your oven, so be careful.

• Ceramic, porcelain, and stoneware — Use these if they are labeled “Microwave Safe”. If they are not labeled, test them to make sure they can be used safely. Never use dishes with metallic trim.

• Plastic — Use only if labeled “Microwave Safe”. Other plastics can melt.

• Straw, wicker, and wood — Use only for short-term heating, as they are ammable. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 26 2019-06-19 3:19:10English 27 Cooking guide Standing Food cooked in the microwave builds up internal heat and continues to cook for a few minutes after the oven stops. Let food stand to complete cooking, especially food such as roasts and whole vegetables. Roasts need this time to complete cooking in the center without overcooking the outer areas. All liquids, such as soup or hot chocolate, should be shaken or stirred when cooking is complete. Let liquids stand a moment before serving. When heating baby food, stir well and test the temperature before serving. Adding Moisture Microwave energy is attracted to water molecules. Food that is uneven in moisture content should be covered or allowed to stand so that the heat disperses evenly. Add a small amount of water to dry food to help it cook. Venting After covering a dish with plastic wrap, vent the plastic wrap by turning back one corner so excess steam can escape. Cooking guide Microwave energy actually penetrates food and is attracted to and absorbed by the water, fat, and sugar molecules in the food. The microwaves cause the molecules in the food to move rapidly. The rapid movement of these molecules creates friction and the resulting heat cooks the food. Cooking techniques Stirring Stir foods such as casseroles and vegetables while cooking to distribute heat evenly. Food at the outside of the dish absorbs more energy and heats more quickly, so stir from the outside to the center. The oven will turn off when you open the door to stir your food. Arrangement Arrange unevenly shaped foods, such as chicken pieces or chops, with the thicker, meatier parts toward the outside of the turntable where they will receive more microwave energy. To prevent overcooking, place thin or delicate parts toward the center of the turntable. Shielding Shield food with narrow strips of aluminum foil to prevent overcooking. Areas that need shielding include poultry wing-tips, the ends of poultry legs, and the corners of square baking dishes. Use only small amounts of aluminum foil. Larger amounts can damage your oven. Turning Turn foods over midway through cooking to expose all parts to microwave energy. This is especially important with large items such as roasts. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 27 2019-06-19 3:19:1028 English Cooking guide Cooking guide Guide for cooking vegetables in your microwave

• Vegetables should be washed just before cooking. Often, no extra water is needed. If you are cooking dense vegetables such as cubed potatoes, carrots, or green beans, add about ¼ cup water.

• Small vegetables (sliced carrots, peas, lima beans, etc.) will cook faster than larger ones.

• Whole vegetables, such as potatoes, acorn squash, or corn on the cob, should be arranged in a circle on the turntable before cooking. They will cook more evenly if turned over after half the cooking time.

• Always place vegetables like asparagus and broccoli with the stem ends pointing towards the edge of the dish and the tips toward the center.

• When cooking cut vegetables, always cover the dish with a lid or vented microwavable plastic wrap.

• Whole, unpeeled vegetables such as potatoes, squash, eggplant, etc., should have their skin pricked in several spots before cooking to prevent them from bursting.

• For more even cooking, stir or rearrange whole vegetables halfway through the cooking time.

• Generally, the denser the food, the longer the standing time. (Standing time refers to the time necessary for dense, large foods and vegetables to nish cooking after they come out of the oven.) A baked potato can stand on the counter for ve minutes before cooking is completed, while a dish of peas can be served immediately. General cooking recommendations

• Dense foods, such as potatoes, take longer to heat than lighter foods. Food with a delicate texture should be heated at a low power level to prevent it from becoming tough.

• Altitude and the type of cookware you are using can affect cooking time. When trying a new recipe, use the minimum cooking time and check the food occasionally to prevent overcooking.

• Food with a non-porous skin such as potatoes or hot dogs should be pierced to prevent bursting.

• Frying with oil or fat is not recommended. Fat and oil can suddenly boil over and cause severe burns.

• Some ingredients heat faster than others. For example, the jelly inside a jelly doughnut will be hotter than the dough. Keep this in mind to avoid burns.

• Home canning in the microwave oven is not recommended because all harmful bacteria may not be destroyed by the microwave heating process.

• Although microwaves do not heat the cookware, the heat from the food is often transferred to the cookware. Always use pot holders when removing food from the microwave and instruct children to do the same.

• Making candy in the microwave is not recommended as candy can heat to very high temperatures. Keep this in mind to avoid injury. Guide for cooking eggs in your microwave

• Never cook eggs in the shell and never warm hard-cooked eggs in the shell. They can explode.

• Always pierce whole eggs to keep them from bursting.

• Cook eggs just until set. They become tough if overcooked. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 28 2019-06-19 3:19:10English 29 Cleaning and maintaining your microwave oven Cleaning the door and door seals Always ensure that the door seals are clean and that the door closes properly. Take particular care when cleaning the door seals to ensure that no particles accumulate and prevent the door from closing correctly. Wash the glass door with very mild soap and water. Be sure to use a soft cloth to avoid scratching. NOTE If steam accumulates inside or outside the oven door, wipe with a soft cloth. Steam can accumulate when you operate the oven when humidity is high and in no way indicates microwave leakage. Cleaning the interior CAUTION To avoid injury, ensure that the microwave oven has cooled down before cleaning it. CAUTION Remove the glass tray from the oven when cleaning the oven or tray. To prevent the tray from breaking, handle it with care and do not put it in water immediately after cooking. Wash the tray carefully in warm sudsy water or in the dishwasher. Cleaning the turntable and roller rings Clean the roller rings periodically and wash the turntable as required. The turntable can be washed safely in your dishwasher. Cleaning and maintaining your microwave oven Keeping your microwave oven clean improves its performance, wards off unnecessary repairs, and lengthens its life. Cleaning the exterior It’s best to clean spills on the outside of your microwave oven as they occur. Use a soft cloth and warm, soapy water. Rinse and dry. CAUTION Do not get water into the vents. Never use abrasive products or chemical solvents such as ammonia or alcohol as they can damage the appearance of your microwave. WARNING Unplug the microwave plug before cleaning. Cleaning under your microwave oven Regularly clean grease and dust from the bottom of your microwave using a solution of warm water and detergent. Cleaning the control panel Wipe with a damp cloth and dry thoroughly. Do not use cleaning sprays, large amounts of soap and water, abrasives, or sharp objects on the panel as it is easily damaged. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 29 2019-06-19 3:19:1030 English Cleaning and maintaining your microwave oven Cleaning and maintaining your microwave oven Replacing the cooktop/night light When replacing the cooktop/night light, make sure that you are wearing gloves to avoid injury from the heat of the lamp. Lamp

1. Unplug the oven or turn off the power

at the main power supply.

2. Remove the screw from the light cover

and lower the cover.

3. Disconnect the wire connectors.

4. Remove the screw securing the LED

5. Replace the LED lamp board.

NOTE To purchase a new LED lamp board, visit an authorized Samsung service center or call 1-800-SAMSUNG (726-7864). Storing and repairing your microwave oven If you need to store your microwave oven for a short or extended period of time, choose a dust-free, dry location. Dust and dampness may adversely affect the functionality of the microwave parts. WARNING Do not repair, replace, or service any part of your microwave oven yourself. Allow only a qualied service technician to perform repairs. If the oven is faulty and needs servicing, or you are in doubt about its condition, unplug the oven from the power outlet and contact your nearest service center. Do not use the oven if the microwave oven is damaged, in particular, if the door or door seals are damaged or the door does not close properly. This can be caused by a broken hinge, a worn out seal or distorted/bent casing. Do not remove the oven from its casing. This microwave oven is for home use only and is not intended for commercial use. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 30 2019-06-19 3:19:11English 31 Cleaning and maintaining your microwave oven Cleaning the grease lter Your microwave oven has reusable grease lter. The grease lter should be removed and cleaned at least once a month or as required. To order a new grease lter, contact Samsung Parts at 1-800-627-4368 or your Samsung dealer. You can also order online at www.samsungparts.com. WARNING To avoid the risk of personal injury or property damage, do not operate the oven hood without the lter in place. Push

1. To remove the lter, push the front

of the grease lter case where it says “PUSH”. Pull out

2. Pull the lter case out of the microwave

oven. Replacing the oven light When replacing the oven light, make sure that you are wearing gloves to avoid injury from the heat of the lamp.

1. Unplug the oven or turn off the power

at the main power supply.

3. Remove the vent cover mounting

5. Remove the charcoal lter, if present.

6. Remove the screw securing the lamp

7. Remove the lamp by pulling it out

8. Replace the lamp with a 50 watt

10. Replace the vent grille and re-insert the

11. Plug the oven in or turn on the power

at the main power supply. Reset the clock. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 31 2019-06-19 3:19:1132 English Cleaning and maintaining your microwave oven Cleaning and maintaining your microwave oven Widen Remove

3. Remove the lter from the lter case

by widening the case, as shown below. Then, soak the grease lter in hot water mixed with a mild detergent. Rinse well and shake to dry. If necessary, brush the lter lightly to remove embedded dirt. When the lter is dry, put it back in the lter case. WARNING Do not use ammonia or put the grease lter in the microwave oven to dry. The aluminum will darken. Push

4. To re-insert the lter into the

microwave oven, slide the lter case into the frame slot, and then push it inside. Replacing the charcoal lter If your oven is vented to the inside, the charcoal lter should be replaced every 6 to 12 months and more often if necessary. The charcoal lter cannot be cleaned. To order a new charcoal lter, contact the Samsung Parts at 1-800-627-4368 or your Samsung dealer. You can also order online at www.samsungparts.com The lter angle The lter angle

1. Unplug the oven or turn off the power

at the main power supply.

3. Remove the vent grille mounting

6. Slide a new charcoal lter into place.

The lter should rest at the angle shown.

7. Replace the vent grille and 2 screws,

and then close the door. Plug the oven in or turn on the power at the main power supply. Reset the clock. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 32 2019-06-19 3:19:12English 33 Troubleshooting Troubleshooting Check points If you encounter a problem with your oven, rst check the tables starting below and try the recommendations. If a problem persists, or if an information code keeps appearing on the display, contact a local Samsung service center. Problem Cause Action General The buttons cannot be pressed properly. Foreign matter may be caught between the buttons. Remove the foreign matter and try again. For touch models: Moisture is on the exterior. Wipe the moisture from the exterior. The Child Lock is activated. Deactivate the Child Lock. The time is not displayed. Power is not supplied. Make sure power is supplied. Conrm the microwave is plugged in. Check your fuses or circuit breakers. The Eco (power-saving) function is set. Turn off the Eco function. The oven does not work. Power is not supplied. Make sure power is supplied. Conrm the microwave is plugged in. Check your fuses or circuit breakers. The door is open. Close the door and try again. The door open safety mechanisms are covered by foreign matter. Remove the foreign matter and try again. Problem Cause Action The oven stops while in operation. The user has opened the door to turn food over. After turning over the food, press the START button again to start operation. The power turns off during operation. The oven has been cooking for an extended period of time. After the oven has cooked for an extended period of time, let the oven cool. The cooling fan is not working. Listen for the sound of the cooling fan. Trying to operate the oven without food inside. Put food in the oven. There is not enough ventilation space around the oven. There are intake/exhaust outlets on the front and rear of the oven for ventilation. Check the installation guide and make sure that the microwave is far enough away from walls and cabinets for proper ventilation. Several appliances or devices are plugged into the same outlet. Unplug all other appliances or devices from the outlet. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 33 2019-06-19 3:19:1234 English Troubleshooting Troubleshooting Problem Cause Action There is no power to the oven. Power is not supplied. Make sure power is supplied. Conrm the microwave is plugged in. Check your fuses or circuit breakers. There is a popping sound during operation, and the oven doesn't work. Cooking food in a sealed container or using a container with a a tight lid. Do not cook food in sealed containers or in containers with tight lids. Expanding steam from the cooking food can cause the containers to burst or the lids to pop off. The oven exterior gets too hot during operation. There is not enough ventilation space around the oven. There are intake/exhaust outlets on the front and rear of the oven for ventilation. Check the installation guide and make sure that the microwave is far enough away from walls and cabinets for proper ventilation. Objects are on top of the oven. Remove all objects on the top of the oven. The door cannot be opened properly. Food residue is stuck between the door and oven interior. Clean the oven the door. Problem Cause Action The oven does not heat. The oven may not work if too much food is being cooked or improper cookware is being used. To test the oven, put one cup of water in a microwave-safe container, put the container in the oven, and then run the microwave for 1-2 minutes to check whether the water is heated. If the water is heated, reduce the amount of food and start the function again. Use a cooking container with a at bottom. Heating is weak or slow. The oven may not work if too much food is being cooked or improper cookware is being used. To test the oven, put one cup of water in a microwave-safe container, put the container in the oven, and then run the microwave for 1-2 minutes to check whether the water is heated. If the water is heated, reduce the amount of food and start the function again. Use a cooking container with a at bottom. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 34 2019-06-19 3:19:12English 35 Troubleshooting Problem Cause Action The warm function does not work. The oven may not work if too much food is being warmed or improper cookware is being used. To test the oven, put one cup of water in a microwave-safe container, put the container in the oven, and then run the microwave for 1-2 minutes to check whether the water is heated. If the water is heated, reduce the amount of food and start the function again. Use a cooking container with a at bottom. The thaw function does not work. The oven may not work if too much food is being thawed or improper cookware is being used. To test the oven, put one cup of water in a microwave-safe container, put the container in the oven, and then run the microwave for 1-2 minutes to check whether the water is heated. If the water is heated, reduce the amount of food and start the function again. Use a cooking container with a at bottom. Problem Cause Action The interior light is dim or does not turn on. The door has been left open for a long time. The interior light may automatically turn off when the Eco function operates. Close and reopen the door or press the STOP/CLEAR button. The interior light is covered by foreign matter. Clean the inside of the oven and check again. A beeping sound occurs during cooking. If the Auto Cook function is being used, this beeping sound means it's time to turn over the food. After turning over the food, press the START button again to restart operation. The oven is not level. The oven is installed on an uneven surface. Make sure the oven is installed on at, stable surface. There are sparks during cooking. Metal containers are used during cooking or thawing. Do not use metal containers. When power is connected, the oven immediately starts to work. The door is not properly closed. Close the door and check again. There is electricity coming from the oven. The power source or power outlet is not properly grounded. Make sure the power source and power outlet are properly grounded. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 35 2019-06-19 3:19:1236 English Troubleshooting Troubleshooting Problem Cause Action There is water dripping. Water or steam may be generated by the cooking or defrosting process, depending on the food. This is not an oven malfunction. Let the oven cool and then wipe with a dry dish towel. There is steam coming through a crack in the door. Water or steam may be generated by the cooking or defrosting process, depending on the food. This is not an oven malfunction. Let the oven cool and then wipe with a dry dish towel. There is water left in the oven. Water or steam may be generated by the cooking or defrosting process, depending on the food. This is not an oven malfunction. Let the oven cool and then wipe with a dry dish towel. The brightness inside the oven varies. Changes in brightness reect changes in power output. Power output changes depending on the functions in use. Power output changes during cooking are not malfunctions. Cooking is nished, but the cooling fan is still running. To ventilate the oven, the cooling fan continues to run for about 3 minutes after cooking is complete. This is not an oven malfunction. Problem Cause Action Pressing the START button operates the oven. This happens when the oven is not operating. The microwave oven is designed to start operating when you press the START button if it was not operating. Turntable While turning, the turntable comes out of place or stops turning. There is no roller ring, or the roller ring is not properly in place. Install the roller ring properly and then try again. The turn table drags while turning. The roller ring is not properly in place, there is too much food, or the container is too large and touches the inside of the microwave. Install the roller ring properly. Adjust the amount of food. Do not use containers that are too large. The turn table rattles while turning and is noisy. Food residue is stuck to the bottom of the oven. Remove any food residue stuck to the bottom of the oven. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 36 2019-06-19 3:19:12English 37 Appendix Information codes If the microwave oven fails to operate, you may see an information code on the display. Check the table below for the code, and then follow the directions. Code Description Action C-10 The GAS sensor is open. Unplug the power cord of the oven, and then contact a local Samsung service center. The GAS sensor is shorted. C-F0 The microwave has sensed an internal communications failure. Unplug the power cord of the oven, and then contact a local Samsung service center. C-F2 A touch button has malfunctioned. Press STOP/CLEAR, and then try the button again. Appendix Specications Model ME21M706BA*/AA ME21R706BA*/AA ME21M706BA*/AC ME21R706BA*/AC Oven Cavity 2.1 cu ft Controls 10 power level, including Defrost Timer 99 minutes, 99 seconds Power Source 120 VAC, 60 Hz Power Consumption 1700 Watt Microwave 1500 Watt Microwave Microwave Power Output 1000 Watts 950 Watts Cook Top Light LED lamp (2 EA) Oven Light 50 Watt halogen lamp Oven Cavity Dimensions (inches) 22 /” (W) x 10 /” (H) x 14 /” (D) Outside Dimensions (inches) 29 /” (W) x 17 /” (H) x 16 /” (D) Shipping Dimensions (inches) 33 /” (W) x 20 /” (H) x 19 /” (D) Net/Shipping Weight 60 lbs. / 67.2 lbs. (27.2 kg / 29.4 kg) ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 37 2019-06-19 3:19:1238 English Warranty Warranty During the applicable warranty period, a product will be repaired, replaced, or the purchase price refunded, at the sole option of SAMSUNG. SAMSUNG may use new or reconditioned parts in repairing a product, or replace the product with a new or reconditioned product. Replacement parts and products are warranted for the remaining portion of the original product’s warranty or ninety (90) days, whichever is longer. All replaced parts and products are the property of SAMSUNG and you must return them to SAMSUNG. This limited warranty covers manufacturing defects in materials or workmanship encountered in normal household, noncommercial use of this product and shall not cover the following: damage that occurs in shipment, delivery, installation, and uses for which this product was not intended; damage caused by unauthorized modication or alteration of the product; product where the original factory serial numbers have been removed, defaced, changed in any way, or cannot be readily determined; cosmetic damage including scratches, dents, chips, and other damage to the product’s nishes; damage caused by abuse, misuse, overheating due to overcooking, glass tray or turntable, pest infestations, accident, re, oods, or other acts of nature or God; damage caused by use of equipment, utilities, services, parts, supplies, accessories, applications, installations, repairs, external wiring or connectors not supplied or authorized by SAMSUNG; damage caused by incorrect electrical line current, voltage, uctuations and surges; damage caused by failure to operate and maintain the product according to instructions; in-home instruction on how to use your product; service to correct installation not in accordance with electrical or plumbing codes or correction of household electrical or plumbing (i.e., house wiring, fuses, or water inlet hoses); and reduced magnetron power output related to normal aging. The cost of repair or replacement under these excluded circumstances shall be the customer’s responsibility. Visits by an authorized servicer to explain product functions, maintenance or installation are not covered by this limited warranty. Please contact SAMSUNG at the number below for assistance with any of these issues. Warranty (USA) Samsung over-the-range (otr) microwave oven LIMITED WARRANTY TO ORIGINAL PURCHASER WITH PROOF OF PURCHASE This SAMSUNG brand product, as supplied and distributed by SAMSUNG ELECTRONICS AMERICA, INC. (SAMSUNG) and delivered new, in the original carton to the original consumer purchaser, is warranted by SAMSUNG against manufacturing defects in materials or workmanship for the limited warranty period, starting from the date of original purchase, of: One (1) Year Parts and Labor Ten (10) Years Magnetron Part (Part Only) This limited warranty is valid only on products purchased and used in the United States that have been installed, operated, and maintained according to the instructions attached to or furnished with the product. To receive warranty service, the purchaser must contact SAMSUNG at the address or phone number provided below for problem determination and service procedures. Warranty service can only be performed by a SAMSUNG authorized service center. The original dated bill of sale must be presented upon request as proof of purchase to SAMSUNG or SAMSUNG’s authorized service center to receive warranty service. SAMSUNG will provide in-home service within the contiguous United States during the warranty period at no charge, subject to availability of SAMSUNG authorized servicers within the customer’s geographic area. If in-home service is not available, SAMSUNG may elect, at its option, to provide transportation of the product to and from an authorized service center. If the product is located in an area where service by a SAMSUNG authorized servicer is not available, you may be responsible for a trip charge or required to bring the product to a SAMSUNG authorized service center for service. To receive in-home service, product must be unobstructed and accessible to the service agent. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 38 2019-06-19 3:19:12English 39 Warranty Samsung will charge a repair fee for replacing an accessory or repairing cosmetic damage if the damage to the unit and/or damage to or loss of the accessory was caused by the customer. Items this covers include:

• Dented, scratched, or broken door, handle, out-panel, or control panel

• Broken or lost tray, guide roller, coupler, lter, or wire rack Parts that SAMSUNG has determined can be replaced by the user may be sent to the customer for installation. In SAMSUNG’s discretion, an authorized servicer can be dispatched to perform such installation.

EXCLUSION OF IMPLIED WARRANTIES

IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW. Some states do not allow limitations on how long an implied warranty lasts, so the above limitations or exclusions may not apply to you. This warranty gives you specic rights, and you may also have other rights, which vary from state to state.

LIMITATION OF REMEDIES

YOUR SOLE AND EXCLUSIVE REMEDY IS PRODUCT REPAIR, PRODUCT REPLACEMENT, OR REFUND OF THE PURCHASE PRICE AT SAMSUNG’S OPTION, AS PROVIDED IN THIS LIMITED WARRANTY. SAMSUNG SHALL NOT BE LIABLE FOR SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT LIMITED TO TIME WAY FROM WORK, HOTELS AND/OR RESTAURANT MEALS, REMODELING EXPENSES, LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Some states do not allow exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you. This warranty gives you specic rights, and you may also have other rights, which vary from state to state. SAMSUNG does not warrant uninterrupted or error-free operation of the product. No warranty or guarantee given by any other person, rm, or corporation with respect to this product shall be binding on SAMSUNG. To obtain warranty service, please contact SAMSUNG at: Samsung Electronics America, Inc. 85 Challenger Road Ridgeeld Park, NJ 07660 1-800-SAMSUNG (726-7864) and www.samsung.com/us/support ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 39 2019-06-19 3:19:1340 English Warranty In-home service will be provided during the warranty labor period subject to availability within the contiguous United States. In-home service is not available in all areas. To receive in-home service, the product must be unobstructed and accessible to service personnel. If during in-home service repair can not be completed, it may be necessary to remove, repair and return the product. If in- home service is unavailable, SAMSUNG may elect, at our option, to provide for transportation of our choice to and from a SAMSUNG authorized service center. Otherwise, transportation to and from the SAMSUNG authorized service center is the responsibility of the purchaser. This limited warranty covers manufacturing defects in materials and workmanship encountered in normal, noncommercial use of this product and shall not apply to the following, including, but not limited to: damage which occurs in shipment; delivery and installation; applications and uses for which this product was not intended; altered product or serial numbers; cosmetic damage or exterior nish; accidents, abuse, neglect, re, water, lightning or other acts of nature; use of products, equipment, systems, utilities, services, parts, supplies, accessories, applications, installations, repairs, external wiring or connectors not supplied or authorized by SAMSUNG which damage this product or result in service problems; incorrect electrical line voltage, uctuations and surges; customer adjustments and failure to follow operating instructions, cleaning, maintenance and environmental instructions that are covered and prescribed in the instruction book; problems caused by pest infestations, and overheating or overcooking by user; glass tray or turntable; reduced magnetron power output related to normal aging. SAMSUNG does not warrant uninterrupted or error-free operation of the product. Warranty (CANADA) Samsung over-the-range (otr) microwave oven Limited warranty to original purchaser This SAMSUNG brand product, as supplied and distributed by Samsung Electronics Canada, Inc. (SAMSUNG) and delivered new, in the original carton to the original consumer purchaser, is warranted by SAMSUNG against manufacturing defects in materials and workmanship for a limited warranty period of: ONE (1) YEAR PARTS AND LABOR, FIVE (5) YEARS PARTS WARRANTY FOR MAGNETRON Samsung will charge a repair fee for replacing an accessory or repairing a cosmetic defect if the damage to the unit and/or damage to or loss of the accessory was caused by the customer. Items this stipulation covers include:

• A Dented, Scratched, or Broken Door, Handle, Out-Panel, or Control Panel

• A Broken or missing Tray, Guide Roller, Coupler, Filter, or Wire Rack User Replaceable Parts may be sent to the customer for unit repair. If necessary, a Service Engineer can be dispatched to perform service. This limited warranty begins on the original date of purchase, and is valid only on products purchased and used in the United States. To receive warranty service, the purchaser must contact SAMSUNG for problem determination and service procedures. Warranty service can only be performed by a SAMSUNG authorized service center. The original dated bill of sale must be presented upon request as proof of purchase to SAMSUNG or SAMSUNG’s authorized service center. SAMSUNG will repair this product or replace it if cannot repair it, at our option and at no charge as stipulated herein, with new or reconditioned parts or products if found to be defective during the limited warranty period specied above. All replaced parts and products become the property of SAMSUNG and must be returned to SAMSUNG. Replacement parts and products assume the remaining original warranty, or ninety (90) days, whichever is longer. ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 40 2019-06-19 3:19:13English 41 Warranty THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE LISTED AND DESCRIBED ABOVE, AND NO WARRANTIES WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, SHALL APPLY AFTER THE EXPRESS WARRANTY PERIODS STATED ABOVE, AND NO OTHER EXPRESS WARRANTY OR GUARANTY GIVEN BY ANY PERSON, FIRM OR CORPORATION WITH RESPECT TO THIS PRODUCT SHALL BE BINDING ON SAMSUNG. SAMSUNG SHALL NOT BE LIABLE FOR LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, OR ANY OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. NOR SHALL RECOVERY OF ANY KIND AGAINST SAMSUNG BE GREATER IN AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT SOLD BY SAMSUNG AND CAUSING THE ALLEGED DAMAGE. WITHOUT LIMITING THE FOREGOING, PURCHASER ASSUMES ALL RISK AND LIABILITY FOR LOSS, DAMAGE OR INJURY TO PURCHASER AND PURCHASER’S PROPERTY AND TO OTHERS AND THEIR PROPERTY ARISING OUT OF THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT SOLD BY SAMSUNG NOT CAUSED DIRECTLY BY THE NEGLIGENCE OF SAMSUNG. THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF THIS PRODUCT, IS NONTRANSFERABLE AND STATES YOUR EXCLUSIVE REMEDY. Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you. This warranty gives you specic legal rights, and you may also have other rights which vary from state to state. To obtain warranty service, please contact SAMSUNG at: 1-800-SAMSUNG (726-7864) or www.samsung.com/ca/support (English) www.samsung.com/ca_fr/support (French) ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 41 2019-06-19 3:19:1342 English Memo ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 42 2019-06-19 3:19:13English 43 Memo ME21M706BA_ME21R706BA_AA_EN+MES+CFR.indb 43 2019-06-19 3:19:13Please be advised that the Samsung warranty does NOT cover service calls to explain product operation, correct improper installation, or perform normal cleaning or maintenance. QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT U.S.A Consumer Electronics 1-800-SAMSUNG (726-7864) www.samsung.com/us/support CANADA 1-800-SAMSUNG (726-7864) www.samsung.com/ca/support (English) www.samsung.com/ca_fr/support (French) ME21M706BA* / ME21R706BA* Scan the QR code* or visit www.samsung.com/spsn to view our helpful How-to Videos and Live Shows

STOP/CLEAR (DETENER/
