USER MANUAL IAN 286719 MELINERA

Assembly, operating and safety instructions

NL BE

SOLAR-LASERSCHIJNWERPER

Intended use.. Page 20
Parts description.. Page 20
Technical Data . Page 21
Scope of delivery.. Page 21

General safety instructions.. Page 22

Product-specific safety instructions . Page 23
Safety instructions for batteries / rechargeable batteries ....Page 23

Function

Before first use.. Page 25

Charging the rechargeable battery.. Page 25
Installing the product.. Page 26

Start-up Page 27

Cleaning and care/storage

Replacing rechargeable battery . Page 28

Troubleshooting

Disposal

Warranty

Solar laser spotlight

Introduction

We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the product as described and for the specified applications. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.

Intended use

This product is intended for lighting effects on trees, lawns, house walls, etc. in an outdoor environment. The product is intended for private use only and is not intended for commercial use or for use in other applications.

Not suitable for household room illumination.

- Parts description

Solar cell unit Lamp head Joint screw Pole

Ground spike
Main unit
Battery
compartment

8 Rechargeable battery 9 Switch

Technical Data

Operating voltage: 3.2 V (direct current)

Rechargeable battery: 1 × 3.2 ~V = - (direct current) Li-1on battery, 600 mAh, 14500

Solar cell: 1 × polycrystalline, 5 ~V, 75 ~mA

Protection type: IP44 (splash-proof)

Laser class: 2

Laser wavelength: 650-670 nm

Laser output power: < 1mW

- Scope of delivery

Check immediately after unpacking that the parts are complete and that the product is in proper condition.

1 Solar laser spotlight
1 Ground spike
1 Pole
1 Rechargeable battery 3.2 V (direct current), 600 mAh, 14500 (assembled in lamp)
1 Instructions for assembly and use

General safety instructions

Before using the product, please familiarise yourself with all of the safety information and instructions for use! When passing this product on to others, please also include all the documents!

his product may be used by children age 8 years and up, as well as by persons with reduced physical, sensory or mental capacities, or lacking experience and/

or knowledge, so long as they are supervised or instructed in the safe use of the product and understand the associated risks. Children should not be allowed to play with the product. Cleaning and user maintenance should not be performed by children without supervision.

• Never leave children unsupervised with the packaging material. The packaging material represents a danger of suffocation. Children frequently underestimate the dangers.
• Keep children out of the area you are working in during assembly or whilst changing batteries. Screws are included. These may prove life-threatening if swallowed or inhaled.
  Do not use this product if you notice any damage!
  The illuminant is not replaceable.
  If the illuminant fails at the end of its life, the entire product must be replaced.

Danger from laser radiation

This product features a Class 2 laser.
Never direct the laser beam at persons or animals.
- Never look directly into the laser beam. Even a weak laser beam can cause eye damage.
- Never point the laser beam at reflective surfaces or materials. Even a reflected laser beam can cause eye damage.

Any adjustment intensifying the laser beam is prohibited. Risk of injury!
We assume no liability for damages arising from manipulating the laser product and for failure to observe the safety notices.
This product may be used by children age 8 years and up, as well as by persons with reduced physical, sensory or mental capacities, or lacking experience and knowledge, so long as they are supervised or instructed in the safe use of the product and understand the associated risks. Do not allow children to play with the product. Cleaning and user maintenance should not be performed by children without supervision.
Do not use this product if you notice any damage.
- Keep away from open flames!
Do not modify the product.

CAUTION! EXPLOSION HAZARD! Do not use.

the product in locations with a fire hazard or explosion hazard, for example near flammable liquids or gasses.

- Product-specific safety instructions

WARNING! RISK OF INJURY! Make sure that when the mainunit 6 is removed that the ground spike 5 is also removed so it cannot pose any risk (e.g. stumbling over them).

Safety instructions for batteries / rechargeable batteries

DANGER TO LIFE! Keep batteries / rechargeable batteries out of reach of children. If accidentally swallowed seek immediate medical attention.

DANGER OF EXPLOSION! Never recharge non

rechargeable batteries. Do not short-circuit batteries / rechargeable batteries and/or open them.

Overheating, fire or bursting can be the result.

Never throw batteries / rechargeable batteries into fire or water.

Do not exert mechanical loads to batteries / rechargeable batteries.

Risk of leakage of batteries / rechargeable batteries

Avoid extreme environmental conditions and temperatures, which could affect batteries / rechargeable batteries, e.g. radiators / direct sunlight.

Avoid contact with the skin, eyes and mucous membranes. In the event of contact with battery acid, thoroughly flush the affected area with plenty of clean water and seek immediate medical attention.

WEAR PROTECTIVE GLOVES! Leaked or dam-

aged batteries / rechargeable batteries can cause burns on contact with the skin. Wear suitable protec

tive gloves at all times if such an event occurs.

In the event of a leakage of batteries / rechargeable batteries, immediately remove it from the product to prevent damage.

Only use the same type of batteries / rechargeable batteries. Do not mix used and new batteries / rechargeable batteries.

Remove the batteries / rechargeable batteries if the product will not be used for a longer period.

Risk of damage of the product

Only use the specified type of battery / rechargeable battery!

Insert batteries / rechargeable batteries according to polarity marks (+) and (-) on the battery / rechargeable battery and the product.

Clean the contacts on the battery / rechargeable battery and in the battery / rechargeable battery compartment before inserting!
Remove exhausted batteries / rechargeable batteries from the product immediately.

- Function

The solar cell unit 1 converts energy from sunlight into electricity. It charges the rechargeable battery inside the battery compartment 7 through the cable. The rechargeable battery store electricity supplied by the solar cell unit 1. Fully charged rechargeable battery provide power for about 3-5 hours of light. In summer, completely drained rechargeable battery take about 2 to 4 days to fully recharge in good sunlight. The rechargeable battery must be charged prior to initial use (see "Charging the rechargeable battery").

Before first use

Note: Remove all packaging materials from the product.

- Charging the rechargeable battery

Note: The rechargeable battery inside the product is charged at delivery. However, it may have lost charge during transport from the manufacturer to the retail location. Therefore charge the rechargeable battery prior to use.

Set the switch to the R'' or FLASH'' position (see Fig. D).

Note: In constant sunlight (depending on the season) the drained rechargeable battery should take two to ten days to charge.

Replace the rechargeable battery 8 if the light output does not improve after charging (Fig. B + C).

- Installing the product

Install the product in accordance with Fig. A

1. Place the main unit 6 on to the pole 4
2. Insert ground spike 5 into the pole 4 with the tip facing downwards.
3. Turn the joint screw 3 counter-clockwise to adjust the angle of the lamp head 2 as well as the angle of the solar cell unit 1.
4. Tighten the joint screw 3 after adjusting the angle.

For optimal results, place the product in a location where the solar cell unit 1 is exposed to direct sunlight for as long as possible.
To adjust the angle of incidence, loosen the joint screw to position the solar cell unit 1 correctly.
Then tighten the joint screw 3.
Do not place the product under shrubs, trees, awnings, etc. This will reduce the incidence of sunlight (see Fig. F).
Position the product so the solar cell unit 1 is not covered or shaded.
Make sure the solar cell unit 1 is not impacted by other light sources, e.g. yard- or street lighting, or the light will not switch on at twilight.

Note: Push the assembled product far enough into the ground (grass, flower bed) to be stable. Make sure it is firmly placed (see Fig. E).

Note: Do not use force during assembly or setup, e.g. hammer blows. This damages the product.

- Start-up (see Fig. D)

The switch 9 features the following functions:

• Position „OFF“: Product is off.

-Position, R^ : The solar cell unit 1 charges the rechargeable battery 8 in sunlight. The product automatically switches on continuous light or off once the solar cell unit 1 detects dusk or dawn.

-Position, FLASH": The solar cell unit 1 charges the rechargeable battery 8 in sunlight. The product automatically switches on flash light or off once the solar cell unit 1 detects dusk or dawn.

- Cleaning and care/ storage

Never use caustic cleaners.
First switch off the product.
Regularly clean the product with a dry, lint-free cloth. Use a slightly moist cloth to remove any stubborn dirt.

Note: Be sure the solar cell unit 1 is always clean to achieve good charging.

Cold temperatures have a negative impact on the battery operating time. When not using the product for extended periods, e.g. in winter,

it should be cleaned and stored in a dry, warm location. Be sure the switch 9 is set to the "OFF" position during storage.

- Replacing rechargeable battery

Set the switch to the "OFF" position (see Fig. D).
Remove the solar cell unit 1 by loosening the 4 screws on the underside of the battery compartment 7. The battery compartment 7 is located inside the solar cell unit 1.
Remove the old rechargeable battery and insert a new rechargeable battery in the battery compartment noting correct polarity (see Fig. B-C).
Then install all components in the reverse order. Be careful not to damage the cable.

- Troubleshooting

Note: This product has delicate electronic components. This means that if it is placed near an object that transmits radio signals, it could cause interference. If you notice that the product is malfunctioning, remove any sources of interference from the area of the product.

Note: Electrostatic discharges may cause product to malfunction. In the event of such malfunctions, remove the rechargeable battery briefly and reinsert it.

Problem Cause Solution
The light will not switch on although the product has been in sunlight all day.	- The product is not switched on.	- Switch the product on (refer to chapter „Start-up").
Problem Cause Solution
Limited battery power.	-Therechargeable battery 8 is drained or the so-lar cell unit 1 is dirty.	-Replengethe rechargeable battery. - Switch the product on (refer to chapter „Start-up“).
The light does not come on or only stays on briefly.	-Artificiallight sources, e.g. street lights, are interfering with the product.	- Keep away the pro- duct from artificial light sources, e.g. street lights. - Place the product in a location where other light sources will not interfere with it.

Disposal

The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities. The Green Dot is not valid for Germany.

Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1-7: plastics / 20-22: paper and fibreboard / 80-98: composite materials.

The product and packaging materials are recyclable, dispose of it separately for better waste treatment. The Triman logo is valid in France only.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.

Faulty or used batteries / rechargeable batteries must be recycled in accordance with Directive 2006/66/EC and its amendments. Please return the batteries / rechargeable batteries and / or the product to the available collection points.

Environmental damage through incorrect disposal of the batteries / rechargeable batteries!

Batteries / rechargeable batteries may not be disposed of with the usual domestic waste. They may contain toxic heavy metals and are subject to hazardous waste treatment rules and regulations. The chemical symbols for heavy metals are as follows: Cd = cadmium, Hg = mercury, Pb = lead. That is why you should dispose of used batteries / rechargeable batteries at a local collection point.

Warranty

The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of product defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.

The warranty for this product is 3 years from the date of purchase. Should this product show any fault in materials or manufacture within

3 years from the date of purchase, we will repair or replace it - at our choice - free of charge to you.

The warranty period begins on the date of purchase. Please keep the original sales receipt in a safe location. This document is required as your proof of purchase. This warranty becomes void if the product has been damaged, or used or maintained improperly.

The warranty applies to defects in material or manufacture. This warranty does not cover product parts subject to normal wear, thus possibly considered consumables (e.g. batteries) or for damage to fragile parts, e.g. switches, rechargeable batteries or glass parts.
