| Product type | Built-in dishwasher |
| Brand | Telefunken |
| Model | TFGS45SI10A+++ |
| Capacity | 10 place settings |
| Height | 820 - 870 mm (adjustable) |
| Width | 450 mm |
| Depth | 570 mm |
| Net weight | 32 kg |
| Power supply | 220-240 V ~ 50 Hz, 10 A |
| Total power | 1900 W |
| Annual energy consumption | 188 kWh (standard cycle) |
| Annual water consumption | 2520 L (standard cycle) |
| Energy class | A+++ |
| Drying class | A |
| Noise level | 44 dB(A) |
| Programs | Pre-wash, Auto, Intensive, Duo Wash, Quick 30 min, Eco, Super 50 min, Hygiene 70°C |
| Functions | Delayed start, Half load, Extra quick, Extra silent, Interior light, Child lock |
| Safety | Aquastop (depending on model), child safety, automatic stop when opened |
| Water pressure | 0.03 - 1 MPa (0.3 - 10 bar) |
| Maintenance | Regular cleaning of filters and spray arms |
Frequently Asked Questions - TFGS45SI10A+++ TELEFUNKEN
How to adjust the water hardness on my Telefunken dishwasher?
To adjust the water hardness, press and hold the Program Selection button, then press the On/Off button. Release the button when 'SL' disappears. Use the '+' and '-' buttons to adjust the level (from L1 to L6) according to your water hardness. Confirm with On/Off.
What to do if the dishwasher displays error code F5?
Error code F5 indicates insufficient water supply. Check that the water inlet tap is fully open and there is no water cut. Close the tap, unscrew the inlet hose and clean the filter. If the error persists, contact customer service.
How to clean the dishwasher filters?
Turn the filter assembly counterclockwise to remove it. Separate the micro filter, coarse filter and metal filter. Wash them under running water. Replace the coarse filter into the micro filter, then insert the whole assembly into the metal filter, aligning the marks. Never operate the appliance without the filter.
Why does my dishes remain damp at the end of the cycle?
This may be due to a program without drying, too low a rinse aid setting, or dishes removed too early. Make sure to use a program with drying and check the rinse aid dispenser (position 3 recommended). Leave the door ajar after the cycle to improve drying.
How to activate the child lock?
To activate the child lock, press the '+' and '-' buttons simultaneously for 3 seconds. 'CL' is displayed for 2 seconds. To deactivate, repeat the same operation. This prevents children from changing settings or starting the appliance.
Which detergent to use for my dishwasher?
Use a specific household dishwasher detergent (powder, gel or tablet). Follow the indicated dosages: 25 cm³ for heavily soiled dishes, 15 cm³ for normal. Combined detergents can be used but may require an appropriate adjustment of water hardness and rinse aid.
How to fill the salt reservoir?
Remove the lower basket, unscrew the salt reservoir cap counterclockwise. Fill with special dishwasher regenerating salt (about 1 kg). On first use, add water up to the brim. Screw the cap back on. The salt indicator lights up when the level is low.
What to do if the dishwasher does not drain?
Check that the drain hose is not kinked or blocked. Clean the internal filters. If error code F2 appears, turn off the machine and activate the program cancel command. If the problem persists, contact customer service.
How to use the half-load function?
Press the Half Load button (½) to select the desired basket: upper indicator on = upper basket only wash, lower indicator = lower basket, both = full wash with reduced load. Make sure no dishes are in the unselected basket.
What is the procedure for a delayed start?
Select a program, then press the Start/Pause button. Use the '+' and '-' buttons on the display to set the delayed start time (e.g. 3 hours). Press Start/Pause again to activate the delay. The countdown begins and the program starts at the selected time.
