USER MANUAL PCPW 3007 FA ProfiCare

Thank you for choosing our product. We hope you enjoy using the appliance.

Symbols in these Instruction Manual

Important information for your safety is specially marked. It is essential to comply with these instructions in order to avoid accidents and prevent damage to the appliance:

WARNING:

This warns you of dangers to your health and indicates possible injury risks.

CAUTION:

This refers to possible hazards to the appliance or other objects.

NOTE: This highlights tips and information.

Contents

Overview of the Components....3

General Notes......35

Special Safety Instructions for this Appliance....35

Handling of Batteries 36

Inserting the Batteries 36

Overview of the Components....36

Technical Data 36

Information about the Analysis Scale ....36

Use....37

Weighing Function....37

Saving Personal Data 37

Measurement and Analysis....37

Assessment of the Results....38

Body Fat 38

The Importance of Water for our Health 38

Body Fat Percentage Guidelines (Approx. Figures)......38

Benchmarks for Body Water Level and

Muscle Mass Level in Percent (Approx. Figures)......38

Benchmarks for Bone Weight

in Kilogram (Approx. Figures) 38

BMR (Basal Metabolic Rate/Energy Expenditure) ...... 38

Reference Values of the Daily Intake of

Kilocalories without Physical Activities.... 39

BMI (Body Mass Index)....39

Reference Values for the BMI 39

Visceral Fat Percentage Guidelines (Approx. Figures) ... 39

Display Error Messages....39

Cleaning 39

Disposal 39

Disposal of Batteries 39

Meaning of the "Dustbin" Symbol....39

General Notes

Read the operating instructions carefully before putting the appliance into operation and keep the instructions including the warranty, the receipt and, if possible, the box with the internal packing. If you give this appliance to other people, please also pass on the operating instructions.

• The appliance is designed exclusively for private and not for commercial use.
• Only use the appliance for the intended purpose.
• Do not use a damaged appliance.
• Keep away from heat, direct sunlight, damp (never immerse in liquids) and sharp edges.
• Do not try to repair the appliance on your own. Always contact an authorized technician.
  • Children should be supervised at all times in order to ensure that they do not play with the appliance.
• In order to ensure your children's safety, please keep all packaging (plastic bags, boxes, polystyrene etc.) out of their reach.

WARNING:

Do not allow small children to play with the foil. There is a danger of suffocation!

Special Safety Instructions for this Appliance

WARNING:

If the weighing surface is damp or if there are water drops on it, first wipe it dry, as there is a risk of slipping.

CAUTION:

• Handle the balance with care, as it is a precise measuring instrument. Do not drop it or jump on it.
• Do not load the appliance with more than 180 kg (396.8 lb, 28: 3½ st:lb) to avoid damaging the appliance.

- If the scales are carried or not going to be used, please store them only in a horizontal position.

- The body fat analysis scale is not suitable for the following persons:

• Children under 6 years and adults over 100 years
• Persons with symptoms of fever, oedema, or osteoporosis
• Persons undergoing treatment for dialysis
• Persons who use a pacemaker
• Persons who take cardiovascular medication
• Pregnant women
• Sportspersons who perform over 5 hours of intensive sporting activities each day
• Persons with a heartbeat lower than 60 beats / minute
• Persons with considerable anatomic deviations of the legs in relation to total body size (length of the legs considerably shortened or lengthened).

Handling of Batteries

Do not charge!

Do not disassemble!

Insert correctly!

Do not short circuit!

Danger of explosion! Do not expose batteries to intense heat, such as sunlight, fire or similar.

Inserting the Batteries

(Batteries not included)

1. Open the battery compartment on the underside.
2. Insert 3 batteries of type AAA / R03. Please ensure that the polarity is correct (see the loor of the battery compartment)!
3. Close the battery compartment again.
4. If the message "Lappears on the display, replace the batteries.

Overview of the Components

1 Display
2 button
3 button
4 button

5 Contact surfaces

Underside (not shown)

Battery compartment

Display Indications	Meaning
P0 - P9 User memory space
	Male
	Female
cm (ft:in) Body height
age Age
kg (lb / st:lb) Body weight
fat Body fat display
	Muscle mass display

Display Indications	Meaning
TBW Body water display
	Bone weight display
	Percentage - body fat / body water / muscle mass
[W50Z]	Basal metabolic rate of the daily energy requirement in kilocalories (BMR)
BMI Body Mass Index
	Visceral fat display (organ fat)

Technical Data

Model: PC-PW 3007 FA
Power supply:....3 Batteries 1.5 V Type "AAA" / "R03"
Net weight of appliance:......approx. 1.7 kg
Memory capacity: 10
Mass alignment:....from 80 to 220 cm (2'7 1/2" - 7'2 1/2" ft:in)
Age: from 6 to 100 years
Minimum weight:....from 5.0 kg (11.0 lb / 0: 11 st:lb)
Maximum weight: 180 kg (396.8 lb/28: 3½ st/lb)
Weight measurement unit: .... 100g (0.2lb/¼st:lb) increments
Body fat measurement unit: 0.1%
Body fluid graduation: 0.1%
Recommended operating environment:
Temperature: 0°C-40°C/32°F-104°F
Relative air humidity: ....../<85%
Body fat measuring range: 5% - 85%
Body water measuring range: 7% - 75%
Muscle mass measuring range: 13% - 82%
Bone weight measuring range: 0.5 kg - 8 kg

The right to make technical and design modifications in the course of continuous product development remains reserved.

This appliance has been tested according to all relevant current CE guidelines, such as electromagnetic compatibility and low voltage directives, and has been constructed in accordance with the latest safety regulations.

Information about the Analysis Scale

WARNING:

Do not use the scales if you use a pacemaker or another medical implant with electronic components. The function of the implant may be impaired by the measurement.

The main principle of this appliance is based on the measurement of the electric impedance within the human body. In order to determine the actual body data, the appliance leads a weak, unnoticeable electric signal through your body.

The signal is generally safe! However, please read our special safety instructions!

The method of measurement is referred to as “bioelectric impedance analysis” (BIA), a factor which is based on the relationship between body weight and associated body water percentages as well as on other biological data (age, gender, body weight).

Use

i NOTE:

• The buttons are sensor touch buttons. Touch the buttons lightly with a finger to execute the function.
• The scales are factory set with the units "kg" and "cm".

To change the settings to "lb" or "st:lb" as well as "ft:in", proceed as follows:

1. Turn on the scales by light pressure with the foot onto the weighing surface.
2. Press the ▼ or button repeatedly until the desired weight unit is displayed. The unit for the height also automatically changes.

Weighing Function

1. Place the scale on a hard, flat surface (avoid carpets). An uneven floor contributes to inaccurate measurements.
2. Stand on the scales with both feet. The appliance switches on automatically.
3. Distribute your weight equally and wait for the scale to determine your weight.
4. The digits on the display will flash before your exact weight will be shown.

- In order to extend the battery life, the appliance will automatically turn off 15 seconds after you have stepped off the scale.

- If there is no weight determination while "0.0" is shown, the scale will shut off automatically after 15 seconds.

Saving Personal Data

i NOTE:

• The scale has default values that you can change, as described below.
• Carry out the following steps in sequence and within a few seconds. Otherwise, the appliance will automatically cancel input mode.

• Holding one of the buttons (▲/▼) pressed for approx. 2 seconds selects fast mode.

• Press the button ●The memory location selected last flashes on the display (for example P0). Confirm the setting by pressing ●or select another memory space by pressing the ▲/▼ button. Then press ●to go to the next setting.

• The symbol for "male" or "female" will flash. Confirm the setting by pressing Ⓞ or use the ▲/▼ button to choose

the symbol for your gender. Then press to go to the next setting.

1. The height setting will flash. Select your height by pressing ▲ or ▼ button. Confirm your entry by pressing Ⓞ.

2. The setting age will flash. Select your age by pressing ▲ or ▼button. Confirm your entry by pressing ⚙

3. The short display “--” will terminate the entry mode for this memory location. Then you will see the memory location, the symbol of the gender and the weight “0.0 kg” (0.0 lb / 0: 00 st:lb) in the display.

You now have the following options:

• Press the button repeatedly to display the settings again or to change them.
• You can set further preset locations. Proceed as described above.
• You can immediately start measuring.

Measurement and Analysis

Record your personal data in the memory.

i NOTE:

• The analysis scale will only work correctly when you are standing on the contact surfaces barefoot and with slightly moistened foot soles, if possible. Completely dry foot soles can lead to unsatisfactory results as they have a conductivity that is too low.
• If necessary wipe the contact surfaces to improve results.
• Due to the significant fluctuation of body fat, it is difficult to attain a standard value. Therefore, to obtain consistent data, always measure at the same time of day.

• Amongst other things, our body consists of body fat, body water, muscle mass and bone weight. The obtained values may differ due to individual water retention within these main components. This is normal and highly dependent on nutrition and lifestyle.

• Press the ⬤ button. Use the ▲/▼ button to select the stored position at which your data is saved. The location flashes for approx. 3 seconds. Then you will see the memory location, the symbol of the gender and the weight "0.0 kg" (0.0 lb / 0: 00 st:lb) in the display.

• Stand on the contact surfaces (5) of the scales with both feet.
• Firstly your weight will flash on the display. The analysis starts after the display has stopped flashing. You'll see a treadmill "cod" in the display during the analysis. Remain on the scales until the last display (💡) has appeared.
  The following results are displayed one after the other:
• The weight in the previously selected unit (kg / lb / st:lb)
• The body fat proportion in % (fat)
• The proportion of body fluid % (TBW)
• The proportion of muscle mass in % (♀)

• The bone weight in kg (♂)

• The basal metabolic rate of the daily energy requirement in KCAL

• The Body Mass Index (BMI)
• The visceral fat ( Ⓜ)

Assessment of the Results

There are heavy persons with a well-balanced percentage between fat and muscle mass, and there are seemingly slim persons with significantly high body fat values. Fat is a factor that puts serious strain on the body, in particular the cardiovascular system. Therefore, controlling both values (fat and weight) is a prerequisite for health and fitness.

Body Fat

Body fat is an important component of the body. From protecting the joints as a vitamin repository to regulating the body temperature, fat plays a vital role in the body. Thus the goal is not to radically reduce the proportion of body fat, but rather to achieve and maintain a healthy balance between muscle and fat.

The Importance of Water for our Health

Approximately fifty-five to sixty percent of the human body consist of water, depending on age and gender in varying amounts.

Water has to fulfill several tasks within the body:

• It is the building block of our cells. That means that all the cells in our body, whether skin cells, gland cells, muscle cells, brain cells or others, are functional only if they contain enough water.
  • It is a solvent for important substances in our body.
• It is a means of conveyance for nutrients, the body's own substances and metabolic products.

Reference values for your fitness profile can be seen in the benchmark table. It shows the dependency of body fat data on age and gender. Always pay attention to your body's water balance, which, as well as the fat level, undergoes strong fluctuations throughout the day. Therefore, to obtain consistent data, always measure at the same time of day.

The calculated results of the body fat and water level should only be considered as reference values. They are not recommended to be used for medical purposes. Please always consult a doctor if you have questions about a medical treatment or a diet in order to achieve a normal body weight.

Body Fat Percentage Guidelines (Approx. Figures)

Age (Years)	Women Men
	Underweight	Normal Overweight Obese	Underweight	Normal Overweight Obese
6-39<21	21~33	33~39	>39<88~19	19~25>25
40-59	<23	23~35	35~40	>40	<11	11~22	22~28	>28
60-100	<24	24~36	2>42	<13	13~25	25~30>30

Benchmarks for Body Water Level and Muscle Mass Level in Percent (Approx. Figures)

Age (Years)	Women				Men
	Body Water			Muscle mass	Body Water			Muscle mass
	Low	Normal	High		Low	Normal	High
6-15	<57	57-67	>67	>34	<5858-72	>72		>40
16-30	<47	47-57	>57		<53	53-67	>67
31-60	<42	42-52	>52		<47	47-61	>61
61-100	<37	37-47	>47		<42	42-56	>56

Benchmarks for Bone Weight in Kilogram (Approx. Figures)

	Women			Men
Body weight	<45	45-60	>60	<60	60-75	>75
Bone weight	-2,6	-3,2	-8	-3,4	-3,8	-8

BMR (Basal Metabolic Rate / Energy Expenditure)

The Basal Metabolic Rate (BMR) characterizes the energy expenditure. The energy expenditure is used to describe the amount of energy in KCAL that the body requires per day during complete rest, at an indifference temperature (28 - 30 °C)

and on an empty stomach for the maintenance of its function (e.g. while sleeping).

Reference Values of the Daily Intake of Kilocalories without Physical Activities

Age(Years)	Women Men
	Weight (kg)	KCAL Weight (kg) KCAL
6-1750	1265 60 1620
18-2955	1298 65 1560
30-4960	1416 70 1680
50-6960	1302 70 1561
70-10050	1035 65 1397

BMI (Body Mass Index)

The Body Mass Index (BMI) refers the body weight to the square of the body height.

BMI = Weight in kg: (body height in m x body height in m)

Example:

A woman weighs 55 kg and is 1.68 m tall. Her BMI is calculated as follows:

55 kg : (1.68 m x 1.68 m) ≈ 19.5 kg / m ^2 Normal weight

The value "square of the body height" is in no relation to the body surface. The BMI is merely a rough reference value, as it neither considers the build and gender, nor the individual composition of the body mass from the fat and muscle tissue of a human.

Reference Values for the BMI

BMI	Underweight	Normal Overweight Obese
	<18.5 18.5	-27 30 - 39 >40

Please note that the interpretation of the BMI indicates excess weight with very muscular bodies (bodybuilder). The reason for this is that the far above-average muscle mass is not considered in the BMI formula.

Visceral Fat Percentage Guidelines (Approx. Figures)

Visceral fat	Normal	Somewhat too high	Too high
	<9	10-14	>15

Display Error Messages

i NOTE:

If an error message appears on the display, wait until the appliance is turned off. Turn it on again to restart the operation. If the error display has not disappeared, take the batteries out of the battery compartment for 10 seconds.

Display Indications	Meaning
	Self test (after inserting the batteries) for perfect functioning of the display
Lo	Battery is low
Err2	The percentage of body fat content lies above or below the limits of the measuring scale
Err	The weight lies above the allowed maximum weight.

Cleaning

CAUTION:

• Do not immerse the balance in water: the electronic components can be damaged.
  • Do not use a wire brush or any abrasive items.
  • Do not use any acidic or abrasive detergents.

• Clean the appliance with a slightly moist cloth. Make sure that no humidity or waters seeps into the appliance!
  • Use a commercially sold detergent or soap for cleaning.

• Dry the appliance well after cleaning with a dry and soft cloth.

Disposal

Disposal of Batteries

Your appliance contains batteries. If these batteries are spent, follow the instructions below:

CAUTION:

Batteries / rechargeable batteries must not be disposed of with household waste!

• The batteries must be removed from the appliance.
• Take spent batteries to the appropriate collection point or to a dealer.
- Your town or local authority can provide information about public collection points.

Meaning of the "Dustbin" Symbol

Protect our environment: do not dispose of electrical equipment in the domestic waste.

Please return any electrical equipment that you will no longer use to the collection points provided for their disposal.

This helps avoid the potential effects of incorrect disposal on the environment and human health.

This will contribute to the recycling and other forms of reutilisation of electrical and electronic equipment.

Information concerning where the equipment can be disposed of can be obtained from your local authority.

Instrukcja obsługi

CTC Clatronic Sp. zo.o.

Ul. Brzeska 1

45 - 960 Opole

Usuwanie

Usuwanie baterii
