Lumix SR24105 - Camera PANASONIC - Free user manual and instructions

Product type	Interchangeable lens for digital camera
Brand	Panasonic
Model	Lumix SR24105
Mount	L-Mount (Leica)
Focal length	24-105 mm
Maximum aperture	f/4
Minimum aperture	f/22
Optical construction	16 elements in 13 groups, including 2 ED lenses and 3 aspherical lenses
Field of view	84° to 23° (diagonal)
Image stabilization	Built-in (Power O.I.S.)
Minimum focus distance	0.30 m (wide-angle) / 0.45 m (telephoto)
Maximum magnification ratio	0.23x (at 105 mm)
Filter diameter	77 mm
Dimensions (Diameter x Length)	84 x 118 mm
Weight	680 g (without lens hood or caps)
Power supply	None (lens has no self-power)
Key features	Silent autofocus, smooth zoom, aperture ring, AF/MF switch, optical stabilization
Care and cleaning	Clean lenses with a soft, dry cloth; use a blower to remove dust; store in a dry place
Safety	Do not expose to rain or excessive humidity; avoid shocks; use the lens hood to protect the front lens
Spare parts and repairability	Lens hood (supplied), front and rear caps, case; repair by Panasonic authorized service center
General information	Standard zoom lens for full-frame, compatible with Panasonic Lumix S and Leica SL cameras

Frequently Asked Questions - Lumix SR24105 PANASONIC

How do I mount the Lumix SR24105 lens on my camera body?

Align the red dot on the lens with the corresponding mark on the camera mount, then turn the lens clockwise until you hear a click. Make sure the lens is securely locked.

What is the maximum aperture of this lens?

The maximum aperture is f/4 throughout the entire focal range, providing consistent brightness.

Can I use this lens with an adapter on a camera from another brand?

The lens uses the L-Mount (Leica). It is compatible with Panasonic Lumix S and Leica SL cameras. For other mounts, an adapter may exist but could limit automatic functions.

How do I activate image stabilization?

The Power O.I.S. stabilization is enabled by default on the compatible camera body. Check the camera menu to enable or disable it if needed.

What is the recommended lens hood and how do I attach it?

The supplied lens hood is the HV-FX131 model. Attach it by aligning the mark on the hood with the one on the lens, then turn it clockwise until it clicks.

How do I clean the lenses without scratching them?

Use a blower to remove dust, then a soft, dry microfiber cloth. For stains, slightly dampen the cloth with lens cleaner. Avoid circular motions.

What is the minimum focus distance?

The minimum distance is 0.30 m at wide-angle (24 mm) and 0.45 m at telephoto (105 mm).

Is the lens dust and splash resistant?

Yes, the lens is designed with weather seals to resist dust and splashes, offering better durability outdoors.

Can I use filters with this lens?

Yes, the filter diameter is 77 mm. You can screw in standard UV, polarizing, or ND filters.

How do I switch to manual focus?

Slide the AF/MF switch on the lens to the MF position. Then turn the focus ring to adjust sharpness manually.

USER MANUAL Lumix SR24105 PANASONIC

Operating Instructions

If you have any questions, visit:

USA : http://shop.panasonic.com/support

Canada: www.panasonic.ca/english/support

Register online at http://shop.panasonic.com/support (U.S. customers only)

保證書別添付

DVQX1714ZA

F0119YTO

取叢説明書

徴ル力×用交换レNs
