KG2000 - Grinder BLACK & DECKER - Free user manual and instructions
Find the device manual for free KG2000 BLACK & DECKER in PDF.
📄
Document temporarily unavailable
The manual is currently being transferred to our new server. It will be accessible again in a few hours. Thank you for your patience.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Angle Grinder |
| Brand | Black & Decker |
| Model | KG2000 |
| Power | 2,000 W |
| Supply Voltage | 230 V |
| No-load Speed | 6,500 rpm (estimated) |
| Disc Diameter | 230 mm (max) |
| Disc Bore | 22 mm |
| Max. abrasive disc thickness | 6 mm |
| Max. cutting disc thickness | 3.5 mm |
| Shaft dimension | M14 |
| Weight | 7 kg |
| Sound pressure level (LpA) | 94.5 dB(A) (uncertainty 3 dB) |
| Sound power level (LWA) | 105.5 dB(A) (uncertainty 3 dB) |
| Vibrations (surface grinding) | 4.8 m/s² (uncertainty 1.5 m/s²) |
| Double insulation | Yes |
| Main functions | Grinding, cutting, sanding, brushing, polishing |
| Safety equipment | Protective guard, side handle, spindle lock, lock switch |
| Maintenance | Regular cleaning of ventilation slots, storage in a dry place |
| Warranty | 2 years |
Frequently Asked Questions - KG2000 BLACK & DECKER
How to install the protective guard on the KG2000 angle grinder?
To install the protective guard, place the tool on a table with the spindle facing up. Position the protective guard on the tool by aligning the holes of the adjustment plate with the screw holes. Insert and tighten the provided screws. Ensure the guard is securely attached before use. Never use the tool without the protective guard.
What types of discs can I use with the KG2000?
The KG2000 accepts grinding discs up to 6 mm thick and cutting discs up to 3.5 mm. The maximum disc diameter is 230 mm with a bore of 22 mm. Use only discs recommended for this tool and observe the rated speeds.
How to change the disc on the KG2000 angle grinder?
Unplug the tool. Press the spindle lock to lock the shaft. Use the two-pin wrench to loosen the outer flange. Remove the outer flange and the used disc. Place the new disc on the inner flange, then replace the outer flange. Tighten firmly with the wrench while holding the spindle lock.
What are the essential safety precautions during use?
Always wear safety glasses and hearing protection. Use the side handle for better control. Ensure the work area is clean and well lit. Do not wear loose clothing or jewelry. Keep the cord away from the rotating accessory. Do not force the tool and let it operate at its normal speed.
Can the KG2000 angle grinder be used for sanding?
Yes, the KG2000 can be used for sanding with appropriate accessories. Use a suitable sanding pad and sandpaper of the correct size. Do not exceed the pad dimensions to avoid risk of laceration or kickback.
How to maintain the KG2000?
Before any maintenance, unplug the tool. Clean the ventilation slots regularly with a soft brush or dry cloth. Wipe the motor housing with a damp cloth. Do not use abrasive products or solvents. Periodically check the condition of the power cord and have it replaced by a professional if damaged.
What to do if the disc jams during cutting?
Stop the tool immediately and hold it still until the disc comes to a complete stop. Do not attempt to remove the disc while it is rotating. Identify the cause of the jam (excessive pressure, material, etc.) and correct the problem before resuming. Restart the tool away from the workpiece, then re-enter the cut carefully.
How to reduce the risk of kickback?
Maintain a firm grip on the tool and use the side handle. Position your body to resist potential kickback. Avoid sharp angles and edges that can pinch the disc. Do not use saw blades or cutting chains. Work with moderate pressure and support large workpieces.
What is the motor power of the KG2000 and can it cut concrete?
The motor develops 2,000 W of power, allowing it to cut and grind metal and concrete with appropriate discs (diamond discs for concrete). Make sure to use the protective guard suitable for the cutting operation.
How to know if an accessory is compatible with the KG2000?
Check that the rated speed of the accessory is at least equal to the maximum speed of the tool. The diameter must not exceed 230 mm and the bore must be 22 mm. Use only accessories recommended by the manufacturer. An unsuitable accessory may break and cause serious injury.
