Technical Features	Production capacity: 12 kg of ice per day, 2.2-liter water tank, ice production cycle from 6 to 15 minutes.
Usage	Ideal for parties, barbecues, and events, easy to use with an intuitive control panel.
Maintenance and Repair	Regular cleaning recommended, descaling every 3 to 6 months depending on usage, spare parts available.
Safety	Equipped with an overheating protection system, automatic shut-off when the water tank is empty.
General Information	Dimensions: 30 x 25 x 35 cm, weight: 10 kg, 2-year warranty, power consumption: 150 W.

Frequently Asked Questions - IM540 Duronic

Why is my Duronic IM540 ice machine not producing ice?

Make sure the machine is properly plugged in and the water tank is filled. Also check that the lid is properly closed.

How long does it take for the Duronic IM540 ice machine to produce ice?

The machine can take about 6 to 15 minutes to produce the first ice cubes, depending on ambient temperature and water quantity.

How do I clean my Duronic IM540 ice machine?

Unplug the machine, empty the water tank, and clean the interior surfaces with a soft cloth and soapy water. Rinse thoroughly and let dry.

Does the Duronic IM540 ice machine make noise during operation?

A slight noise is normal during operation, but if the noise is excessive, check that the machine is on a flat and stable surface.

Can I use tap water in my Duronic IM540 ice machine?

Yes, you can use tap water, but for better taste, filtered water is recommended.

What should I do if the full tank indicator lights up?

This means the tank is full. Remove the ice or empty the tank before continuing to produce ice.

Can the Duronic IM540 ice machine produce different types of ice?

The Duronic IM540 is designed to produce ice cubes of specific shape and size, but you cannot change the type of ice produced.

What should I do if the Duronic IM540 ice machine does not turn on?

Check if the machine is properly plugged in and if the outlet is working. If the problem persists, contact customer service.

USER MANUAL IM540 Duronic

Creative Consumer Products

White DURONIC water purifier with open lid and internal components (no visible text or symbols)

IM540 - Ice Cream Maker

DURONIC

Contents

English Manual 5

1. Read all of the instructions carefully before use.
2. Unplug the machine before fitting, removing, or cleaning parts.
3. Children should not use this machine unsupervised. Do not let the cord hang down where a child could grab it.
4. Do not operate any appliance with a damaged cord or plug, or after the appliance malfunctions, is dropped, or has been damaged in any manner.
5. To protect against the risk of fire, electric shock, or personal injury, do not place the cord, plug, or unit in water or other liquids.
6. Never use an unauthorized attachment.
7. Avoid contact with moving parts. Keep hands, hair, clothing, spatulas and other utensils away during operation to reduce the risk of injury to persons and/or damage to the machine.
8. Do not use outdoors.
9. Never leave the machine on unattended.
10. Do not let children play with this machine.
11. Only use the machine for its intended domestic use.
12. Always make sure everything is thoroughly clean before making ice cream or sorbet.
13. Never freeze ice cream that has been fully or partially defrosted.
14. Any ice cream or sorbet containing raw ingredients should be consumed within one week. Ice cream tastes best when fresh.
15. Ice cream or sorbet that contains raw or partially cooked eggs should not be given to young children, pregnant women, the elderly or people who are generally unwell.
16. To prevent freezer burn, always ensure that hands are protected when handling the inner bowl, especially when first removed from the freezer.
17. If the freezing solution appears to be leaking from the inner bowl, discontinue use. The freezing solution is non toxic.
18. Do not place the machine on hot surfaces such as stoves, hotplates or near open gas flames.
19. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
20. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
21. Children should be supervised to ensure that they do not play with the appliance.

DURONIC

Information

This product must not be disposed together with the domestic waste. This product has to be disposed at an authorized place for recycling of electrical and electronic appliances.

Before plugging in:

Make sure your electricity supply is the same as the electrical rating specified on the underside of the power unit.

Before using item for the first time:

1. Remove all of the packaging.
2. Wash the parts: see 'cleaning".
3. Eight hours in advance, place the inner bowl into a freezer.
4. Prepare the ice cream or sorbet mix (see recipe ideas).
   Allow the mix to cool in the refrigerator.

How To Use

Key:

• Power Unit
  • Lid
• Paddle
• Inner Bowl
• Outer Bowl

• On/Off Knob

• Fit the power unit into the lid, It will click into place.

Diagram of a car interior with labeled parts, showing front and rear views with numbered annotations.

1. Fit the paddle into the power unit.

Diagram of a device with a handle and internal components, showing a mechanical assembly (no text or symbols)

1. Lower the assembled lid/power uniVpaddle onto the bowl and It will click into place.

2. Take the inner bowl from the freezer and put it into the outer bowl.

Technical diagram of a two-part container with labeled parts ④ and ⑤

1. Insert the plug into outlet.

Line drawing of a device with a top component and bottom casing (no text or symbols)

Line drawing of a cylindrical device with a lid and label (⑥), no text or symbols present.

1. Now you can switch the ice cream maker on using the on/off knob switch on. The machine is turned on immediately.

THE MACHINE MUST BE SWITCHED ON BEFORE ADDING THE ICE CREAM OR SORBET RECIPE TO PREVENT THE MIX FROM IMMEDIATELY FREEZING ON THE INSIDE OF THE INNER BOWL.

1. Use the chute and pour the ice cream or sorbet mix into the inner bowl. When pouring mixture into the bowl, always stop at least 5 cm (2 inch) from the top, as the mixture will increase in volume during freezing.

DURONIC

1. Allow the mixture to chum until frozen or the desired consistency is reached. This can take up to 15 to 30 minutes, but most recipes will be ready in less time.

2. Do not stop and start the machine during the freezing process, as the mixture may freeze in contact with the bowl and prevent movement of the paddle.
   • To avoid overheating the motor, the direction of rotation will change if the mixture becomes too thick. If the direction of rotation continues to change, stop the machine when the mixture is ready.

3. In the unlikely event of the motor overheating, a safety cut out will operate causing the motor to stop. If this happens, unplug the machine and allow the power unit to cool.

4. For the best result of ice cream, the paddle will contact with the inside of the inner bowl when the paddle moves.

5. 'Mien the setting time is over, the machine is stopped automatically, unplug the machine and remove the power uniVlid. The ice cream is ready to serve.

The ice cream produced should be a soft spoonable type. This can be transferred to a separate container for storage in the freezer or if you wish to firm the ice cream before eating.

Important

• Do not use metal utensils to remove mix from the bowl.
• Do not remove the inner bowl from the freezer until ready to make ice cream.

We suggest that you keep the inner bowl in the freezer so that it is ready for use. Place in a plastic bag before freezing. Freeze the inner bowl in the upright position. Always make sure the inner bowl is thoroughly dry before placing in the freezer.

Do not puncture or heat the inner bowl.

The inner bowl should be placed in a freezer that is operating at a temperature of -18°C (-0.40°Fahrenheit) or below for 8 hours before use.

For best results always refrigerate the ingredients before making ice cream. The addition of alcohol to recipes inhibits the freezing process.

Cleaning

• Always switch off, unplug and dismantle before cleaning.
- Never put the power unit in water or let the cord or plug get wet.
- Do not wash parts in the dishwasher.
- Do not clean with scouring powders, steel wool pads, or other abrasive materials.

Inner Bowl

Allow the inner bowl to reach room temperature before attempting to clean. Take out the inner bowl and wash the inside of the bowl, then dry thoroughly. Do not immerse in water.

Paddle

Remove the paddle from the power unit. Wash then dry thoroughly.

Power Unit

Wipe with a damp cloth, then dry.

Outer Bowl

Wash then dry thoroughly.

Lid

Wash the lid then dry thoroughly.

Recipes

BANANA ICE CREAM

Ingredients

Large ripe banana 1

Skimmed milk 200ml

Heavy cream 100ml

Confectioner's sugar 50g

Mash the bananas until smooth. Mix in the milk, heavy cream and sugar. Pour the mixture into the freezer bowl with the paddle running. Allow to freeze until the desired consistency is achieved.

RASPBERRY FROZEN YOGHURT

Ingredients

Fresh raspberries 200g

Confectioner's sugar 100g

Natural yoghurt 200ml

Mash the raspberries or puree them. For a smooth result remove the pips by sieving. Add the sugar and natural yoghurt and mix together. Pour the mixture into the freezer bowl with the paddle running. Allow to freeze until the desired consistency is achieved.

CHOCOLATE MINT ICE CREAM

Ingredients

Skimmed milk 200ml

Confectioner's sugar 50g

Heavy cream 200g

Peppermint extract 1/2 tsp

Grated chocolate 50g

Place the milk and sugar into a saucepan. Place over a low heat and stir until the sugar has dissolve, then leave until cold. Stir the cream and peppermint essence into cooled milk. Pour the mixture into freezer bowl with the paddle running. When the mixture starts to freeze add the grated chocolate down the chute. Allow to freeze until the desired consistency is achieved.

CUSTARD BASED VANILLA ICE CREAM

Ingredients

Egg yolks 2

Confectioner's sugar 50g

Skimmed milk 200ml

Heavy cream 200ml

Vanilla extract 1/2 tsp

Place the egg yolks and sugar in a glass bowl and beat together. In a saucepan slowly bring the milk to boiling point, then pour onto the egg mixture beating together. Return the mixture to the pan and stir constantly until the mixture thickens and forms a film over the back of the spoon. Do not let it boil or the mixture will separate. Remove from heat and leave until cold. Stir in the cream and vanilla extract. Pour the mixture into the freezer bowl with the paddle running. Allow to freeze until the desired consistency is achieved.

LEMON SORBET

Ingredients

Granulated sugar 175g

Water 175ml

Orange juice 3 tbsp

Lemon juice 100ml

Egg white From 1 medium egg

Place the sugar and water in a saucepan. Stir over a low heat until the sugar has dissolved. Bring the mixture to the boil and allow to boil for 1 minute.

Remove from heat and allow to cool. Add the orange and lemon juice. VWhisk the egg white until almost stiff and then stir into the lemon mixture. Pour the mixture into the freezer bowl with the paddle running. Allow to freeze until the desired consistency is achieved.

STRAWBERRY ICE CREAM

Ingredients

Fresh strawberries 250g

Confectioner's sugar 100g

Heavy cream 100ml

Lemon juice 2 tbsp

Puree the strawberries until smooth, add the remaining ingredients. Pour the mixture into the freezer bowl with the paddle running. Allow the mixture to freeze until the desired consistency is achieved.

DURONIC

Warranty

1 Year Guarantee from Shine-Mart Ltd, Trademark owners of Duronic Products.

NOTE: THESE STATEMENTS DO NOT AFFECT YOUR STATUTORY RIGHTS AS A CONSUMER

This product has been manufactured under the strictest or quality control procedures, and using the highest quality of materials, to ensure excellent performance and reliability. It will give very good and long lasting service, provided it is properly used and maintained. The product is guaranteed for 1 years from the date of original purchase. If any defect arises due to a faulty materials or poor workmanship, the faulty product must be returned to the original place of purchase. Refund or replacement is at the discretion of that company.

Duronic Products are offered with a 1 year guarantee under the following conditions:

1. The product must be returned to the retailer with original proof of purchase.
2. The product must be installed and used in accordance with the instructions contained in this operating manual.
3. It must be used only for domestic purposes.
4. It does not cover wear and tear, malicious damage, misuse, neglect, inexpert repairs or consumable parts.
5. Shine-Mart Ltd has no responsibilities for accidental or consequential loss or damage.
6. Shine-Mart Ltd are not liable to carry out any type of servicing work, under the guarantee
7. Valid in the UK only

This product is tted with CE:1363 plug and fuse Imported by Shine-Mart Ltd, RM3 8SB

Information on waste Disposal for Consumers of

Electrical & Electronic Equipment.

This mark on a product and/or accompanying documents indicates that when it

is to be disposed of, it must be treated as Waste

Electrical & Electronic Equipment, (WEEE).

Any WEEE marked products must not be mixed with general household waste, but kept separate for the treatment, recovery and recycling of the materials used.

For proper treatment, recovery and recycling; please take all WEEE marked

waste to your Local Authority Civic waste site,

where it will be accepted free of charge.

If customers dispose of Waste Electrical & Electronic Equipment correctly, they will be helping to save valuable resources and preventing any potential negative effects upon human health and the environment, of any hazardous materials that the waste may contain.
