Technical Specifications	Dacor DRF36C500SR refrigerator, 36-inch capacity, stainless steel finish, air circulation cooling system.
Total Capacity	Approximately 20 cubic feet.
Dimensions	Width: 91.4 cm, Height: 182.9 cm, Depth: 76.2 cm.
Energy Consumption	Energy class not specified, but designed to be energy efficient.
Usage	Household refrigerator, ideal for families, with compartments for fruits, vegetables, and meats.
Care and Maintenance	Regular cleaning of surfaces, checking door seals, defrosting if necessary.
Safety	Door lock system, high temperature alarm.
General Information	2-year limited warranty, after-sales service available, professional installation recommended.

Frequently Asked Questions - DRF36C500SR Dacor

The Dacor DRF36C500SR refrigerator is not cooling properly. What should I do?

Check that the thermostat is set to the correct temperature. Make sure the door seals are in good condition and close properly. Clean the condenser coils and check if the fan is working.

There is water at the bottom of the refrigerator. What is the cause?

This may be due to a clogged drain. Check the drain hole at the bottom of the refrigerator and clean it if necessary. Also ensure that the refrigerator is level.

The refrigerator is making noise. Is this normal?

Some level of noise is normal. However, if you hear loud or unusual noises, check if items inside are properly arranged and not blocking the fan. If the noise persists, contact technical service.

The interior lights do not turn on. What should I do?

Check if the bulb is burnt out and replace it if necessary. Also make sure the door is properly closed. If the problem persists, it could be an electrical issue requiring professional assistance.

How do I adjust the temperature of the refrigerator and freezer?

To adjust the temperature, use the digital control panel. Press the temperature buttons to set the desired levels. The recommended temperature for the refrigerator is 4 °C and for the freezer, -18 °C.

The water dispenser is not working. What should I do?

Check that the refrigerator is properly connected to the water supply. Make sure the water filter is not clogged and replace it if necessary. Also check that the refrigerator door is properly closed.

How do I clean the water filter of the Dacor DRF36C500SR refrigerator?

To clean or replace the water filter, open the filter compartment, remove the old filter and insert the new one. Follow the manual instructions for correct installation. Remember to replace the filter every 6 months.

The Dacor DRF36C500SR refrigerator has an unpleasant odor. How do I eliminate it?

Empty the refrigerator and clean the shelves with a vinegar and water solution. Also check the expiration dates of food. Place a bowl of baking soda inside to absorb odors.

How do I update the refrigerator software?

To update the software, consult the user manual for specific instructions. Generally, you will need a Wi-Fi connection and access the settings menu to check for updates.

USER MANUAL DRF36C500SR Dacor

User Manual Refrigerator DRF36C500** Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 1 2022-04-28 10:55:27English2 Contents Contents Important Information 4 Before You Begin 4 Safety information 5 What you need to know about the safety instructions 5 Important safety symbols and precautions: 6 State of California Proposition 65 Warning 6 Important safety precautions 6 Severe warning signs for transportation and site 8 Critical installation warnings 8 Installation cautions 10 Critical usage warnings 10 Usage cautions 12 Cleaning cautions 13 Critical disposal warnings 14 Installation 15 Refrigerator at a glance 15 Step-by-step installation 18 Operations 36 Control panel 36 Setting the desired temperature or function 38 Turning on or off the AutoFill Pitcher 39 Turning on or off the ice maker 39 Changing the temperature scale 40 Turning on or off the Peak Demand function 40 Activating or deactivating the Sabbath mode 40 Activating or deactivating the Cooling Off mode 41 Resetting or dismissing the water lter replacement alarm 41 SmartThings 42 SMART GRID Function (Demand Response) 45 Special features 48 Maintenance 55 Handling and care 55 Cleaning 58 Replacement 59 Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 2 2022-04-28 10:55:28English 3 Contents Troubleshooting 62 General 62 Do you hear abnormal sounds from the refrigerator? 66 SmartThings 68 Smart Grid (applicable models only) 69 Warranty 70 United States - Warranty 70 CANADA – Warranty 74 Regulatory Notice 79 FCC Notice 79 IC Notice 80 Open Source Announcement 81 Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 3 2022-04-28 10:55:28Important Information Before You Begin Installer

• Leave these Use and Care instructions with the appliance. Consumer

• Please read this Use and Care Manual completely before using your refrigerator. Save it for future reference. Retain your sales receipt or canceled check. Proof of original purchase date is required for warranty service. Have the complete model and serial number identication for your appliance ready. These numbers are found on the label located inside of the refrigerator wall. Record these numbers below for easy access. Model Number Serial Number Date of Purchase English4 Important Information Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 4 2022-04-28 10:55:28English 5 Safety information Safety information Before using your new Dacor Refrigerator, please read this manual thoroughly to ensure that you know how to operate the features and functions that your new appliance offers safely and efciently. What you need to know about the safety instructions

• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.

• Because the following instructions cover various models, the characteristics of your refrigerator may differ slightly from the refrigerator described in this manual.

• If you have any question, nd help and information online at www.Dacor.com.

• Refrigerant squirting out of the pipes could ignite or cause an eye injury. When refrigerant leaks from the pipe, avoid any naked ames and move anything ammable away from the product and ventilate the room immediately. - Failing to do so may result in re or explosion.

• Improper use of the grounding plug can result in a risk of electric shock. If it is necessary to use an extension cord, use only a 3-wire extension cord that has a 3-blade grounding plug and a 3-slot receptacle that will accept the plug on the appliance. The marked rating of the extension cord should be AC 115-120 V, 10 A, or more. If a grounding adapter is used, make sure the receptacle box is fully grounded. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 5 2022-04-28 10:55:28Safety information English6 Safety information Important safety symbols and precautions: Please follow all safety instructions in this manual. This manual uses the following safety symbols. WARNING Hazards or unsafe practices that may result in severe personal injury, property damage, and/or death. CAUTION Hazards or unsafe practices that may result in severe personal injury and/or property damage. NOTE Useful information that helps users understand or benet from the refrigerator. These warning signs are here to prevent injury to you and others. Please follow them carefully. After reading this section, keep it in a safe place for future reference. State of California Proposition 65 Warning WARNING Cancer and Reproductive Harm - www.P65Warnings.ca.gov. Important safety precautions Warning; Risk of re / ammable materials WARNING

• R-600a is used as a refrigerant. This product contains ammable gas (Refrigerant R-600a), contact your local authority in regard to safe disposal of this product.

• In order to avoid the creation of a ammable gas-air mixture if a leak in the refrigerating circuit occurs, the size of the room in which the appliance may be sited depends on the amount of refrigerant used. The room must be 35.3 ft³ in size for every 8 g of R-600a refrigerant inside the appliance.

• The installation location should not be exposed to direct sunlight and not placed near any electric appliance or heat source, e.g. stove, oven or hob, radiator, etc. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 6 2022-04-28 10:55:28English 7 Safety information

• If you use two products side by side, for safety reason, be sure to use certied products in explosive gas atmospheres.

• Never start up an appliance showing any signs of damage. If in doubt, consult your dealer.

• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualied persons in order to avoid a hazard.

• The socket must be easily accessible so that the appliance can be quickly disconnected from the supply in an emergency. It must be outside the area of the rear of the appliance.

• Do not store explosive substances such as aerosol cans with a ammable propellant in this appliance.

• New hose-sets supplied with the appliance are to be used and that old hose-sets should not be reused.

• When positioning the appliance, ensure the supply cord is not trapped or damaged.

• Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance. WARNING

• Fill with potable water only.

• Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.

• Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.

• Do not damage the refrigerant circuit.

• Do not use electrical appliances inside the food storage compartments of The appliance, unless they are of the type recommended by the manufacturer.

• Connect to potable water supply only. WARNING

• Risk of child entrapment. Before you throw away your old refrigerator or freezer: - Take off the doors. - Leave the shelves in place so that children may not easily climb inside. This appliance is intended to be used in household and similar applications such

• staff kitchen areas in shops, ofces and other working environments;

• farm houses and by clients in hotels, motels and other residential type environments;

• bed and breakfast type environments;

• catering and similar non-retail applications. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 7 2022-04-28 10:55:28Safety information English8 Safety information Severe warning signs for transportation and site WARNING

• When transporting and installing the appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged. - Refrigerant leaking from the pipe work could ignite or cause an eye injury. If a leak is detected, avoid any naked ames or potential sources of ignition and air the room in which the appliance is standing for several minutes. - This appliance contains a small amount of isobutane refrigerant (R-600a), a natural gas with high environmental compatibility that is, however, also ammable. Critical installation warnings WARNING

• Do not install the refrigerator in a damp location or place where it may come in contact with water. - Deteriorated insulation on electrical parts may cause an electric shock or re.

• Do not place this refrigerator in direct sunlight or expose it to the heat from stoves, room heaters, or other appliances.

• Do not plug several appliances and the refrigerator into the same multiple power strip. The refrigerator should always be plugged into its own individual electrical outlet which has a voltage rating that matches the voltage listed on the refrigerator’s rating plate. - This provides the best performance and also prevents overloading of house wiring circuits, which could overheat the wires and cause a re hazard.

• If the wall socket is loose, do not insert the power plug. - There is a risk of electric shock or re.

• Do not use a power cord that has cracks or abrasion damage along its length or at either end.

• Do not bend the power cord excessively or place heavy objects on it.

• Do not pull or excessively bend the power cord.

• Do not twist or tie the power cord.

• Do not hook the power cord over a metal object, place a heavy object on the power cord, insert the power cord between objects, or push the power cord into the space behind the appliance.

• When moving the refrigerator, be careful not to roll over or damage the power cord. - This may result in an electric shock or re.

• Never unplug your refrigerator by pulling on the power cord. Always grip the plug rmly and pull straight out from the outlet. - Damage to the cord may cause a short-circuit, re, and/or electric shock.

• Do not install this appliance near a heater or ammable material.

• Do not install this appliance in a location where gas may leak. - This may result in an electric shock or re.

• This refrigerator must be properly located and installed in accordance with the instructions in this manual before you use it. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 8 2022-04-28 10:55:28English 9 Safety information

• Connect the power plug in the proper position with the cord hanging down. - If you connect the power plug upside down, the wire can get cut off and cause a re or electric shock.

• Make sure that the power plug is not crushed or damaged by the back of the refrigerator.

• The appliance must be positioned so that the plug is accessible after installation. - Failing to do so may result in an electric shock or re due to electric leakage.

• Do not install this appliance in a humid, oily or dusty location, or in a location exposed to direct sunlight or to water (rain drops). - Deteriorated insulation on electrical parts may cause an electric shock or re.

• If large amounts of dust or water enter the refrigerator, disconnect the power plug and contact a Dacor service center. - Otherwise there is a risk of re.

• Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance. - This may result in an electric shock, re, problems with the product, or injury.

• You need to remove all the protective plastic lm before you initially plug the product in.

• Children should be supervised to ensure that they do not play with the snap rings used for door adjustment or the water tube clips. - There is risk of death by suffocation if a child swallows a snap ring or water tube clip. Keep the snap rings and water tube clips out of children's reach.

• The refrigerator must be safely grounded. - Always make sure that you have grounded the refrigerator before attempting to investigate or repair any part of the appliance. Power leakages can cause severe electric shock.

• Never use gas pipes, telephone lines, or other potential lightning attractors as an electrical ground. - You must ground the refrigerator to prevent any power leakages or electric shocks caused by current leakage from the refrigerator. - Current leakage may result in an electric shock, re, explosion, or problems with the product.

• Plug the power plug into the wall socket rmly. Do not use a damaged power plug, damaged power cord, or loose wall socket. - This may result in an electric shock or re.

• Only a qualied technician or service company should be allowed to change the fuse in the refrigerator. - Failing to do so may result in an electric shock or personal injury. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 9 2022-04-28 10:55:28Safety information English10 Safety information Installation cautions CAUTION

• Allow sufcient space around the refrigerator and install it on a at surface. - Keep the ventilation space in the appliance enclosure or mounting structure clear of obstructions.

• After you have installed the refrigerator and turned it on, allow the appliance to stand for 2 hours before loading it with food.

• It is strongly recommended you have a qualied technician or service company install the refrigerator. - Failing to do so may result in an electric shock, re, explosion, problems with the product, or injury.

• Overloading one door may make the refrigerator fall, causing physical injury. Critical usage warnings WARNING

• Do not insert the power plug into a wall socket with wet hands. - This may result in an electric shock.

• Do not store articles on the top of the appliance. - When you open or close the door, the articles may fall and cause personal injury and/or material damage.

• Do not insert hands, feet, or metal objects (such as chopsticks, etc.) into the bottom or the back of the refrigerator. - This may result in an electric shock or injury. - Any sharp edges may cause a personal injury.

• Do not touch the inside walls of the freezer or products stored in the freezer with wet hands. - This may cause frostbite.

• Do not put a container lled with water on the refrigerator. - If spilled, there is a risk of re or electric shock.

• Do not keep volatile or ammable objects or substances (benzene, thinner, propane gas, alcohol, ether, LP gas, and other such products) in the refrigerator. - This refrigerator is for storing food only. - This may result in re or explosion.

• Children should be supervised to ensure that they do not play with the appliance. - Keep ngers out of "pinch point" areas. Clearances between the doors and cabinet are necessarily small. Be careful when you open the doors if children are in the area.

• Do not let children hang on the door or door bins. A serious injury may occur.

• Do not let children go inside the refrigerator. They could become trapped.

• Do not insert your hands into the area under the appliance. - Any sharp edges may cause personal injury. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 10 2022-04-28 10:55:28English 11 Safety information

• Do not store pharmaceutical products, scientic materials, or temperature sensitive products in the refrigerator. - Products that require strict temperature controls must not be stored in the refrigerator.

• Do not place or use electrical appliances inside the refrigerator/freezer, unless they are of a type recommended by the manufacturer.

• If you smell smoke, pull out the power plug immediately, and then contact a Dacor service center.

• If large amounts of dust or water enter the refrigerator, disconnect the power plug and contact your Dacor service center. - Otherwise there is a risk of re.

• Do not let children step on a drawer. - The drawer may break and cause them to slip.

• Do not leave the doors of the refrigerator open while the refrigerator is unattended and do not let children enter the refrigerator.

• Do not allow babies or children to go into a drawer. - It can cause death from suffocation by entrapment or personal injury.

• Do not overll the refrigerator with food. - When you open the door, an item may fall out and cause personal injury or material damage.

• Do not spray volatile material such as insecticide onto the surface of the appliance. - As well as being harmful to humans, it may also result in an electric shock, re, or problems with the product.

• Never put ngers or any objects into the water dispenser outlet, ice chute, or ice maker bucket. - It may cause a personal injury or material damage.

• Do not use or place any substances sensitive to temperature such as ammable sprays, ammable objects, dry ice, medicine, or chemicals near or inside the refrigerator.

• Do not use a hair dryer to dry the inside of the refrigerator. Do not place a lighted candle in the refrigerator to remove bad odors. - This may result in an electric shock or re.

• Fill the water tank and ice cube trays with potable water only (tap water, mineral water, or puried water). - Do not ll the tank with tea, juice, or a sports drink. They can damage the refrigerator.

• Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance. This may result in an electric shock, re, problems with the product, or injury. Do not put a container lled with water on the appliance. - If spilled, there is a risk of re or electric shock.

• Never stare directly at the UV LED lamp for long periods of time. - This may result in eye strain due to the ultraviolet rays.

• Do not put a fridge shelf into the refrigerator upside down. The shelf stopper will not work. - The glass shelf could fall and cause personal injury.

• If a gas leak is detected, avoid any naked ames or potential sources of ignition, and air the room in which the appliance is standing for several minutes. - Do not touch the appliance or power cord. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 11 2022-04-28 10:55:28Safety information English12 Safety information - Do not use a ventilating fan. - A spark may result in an explosion or re.

• Use only the LED Lamps provided by the manufacturer or its service agents.

• Bottles should be stored tightly together so that they do not fall over or out.

• This product is intended only for the storage of food in a domestic environment.

• Do not attempt to repair, disassemble, or modify the refrigerator yourself. - Unauthorized modications can cause safety problems. To reverse an unauthorized modication, we will charge the full cost of parts and labor.

• Do not use any fuse (such as cooper, steel wire, etc.) other than a standard fuse.

• If your refrigerator needs to be repaired or reinstalled, contact your nearest Dacor service center. - Failing to do so may result in an electric shock, re, problems with the product, or injury.

• If the interior or exterior LED lamp has gone out, contact your nearest Dacor service center.

• If the refrigerator emits a burning smell or smoke, unplug the refrigerator immediately and contact a Dacor service center. - Failing to do so may result in an electric or re hazards.

• Pull the power plug out of the socket before changing the interior lamps of the refrigerator. - Otherwise, there is a risk of electric shock.

• If you experience difculty changing a non-LED light, contact a Dacor service center.

• If the product is equipped with LED lamps, do not disassemble the Lamp Covers and LED lamps yourself. - Contact a Dacor service center.

• Plug the power plug into the wall socket rmly.

• Do not use a damaged power plug, damaged power cord, or loose wall socket. - This may result in an electric shock or re. Usage cautions CAUTION

• Do not re-freeze frozen foods that have thawed completely.

• Use only the ice maker provided with the refrigerator.

• To get the best performance from the product: - Do not place food too close to the vents at the rear of the refrigerator as this can obstruct free air circulation in the refrigerator compartment. - Wrap food up properly or place it in airtight containers before putting it into the refrigerator. - Please observe maximum storage times and expiration dates of frozen goods.

• Do not put glass containers or bottles or carbonated beverages into the freezer. - The container may freeze and break, and this may result in injury.

• Service Warranty and Modication. - Any changes or modications performed by a 3rd party on this nished appliance are not covered under Dacor warranty service, nor is Dacor responsible for safety issues that result from 3rd party modications. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 12 2022-04-28 10:55:28English 13 Safety information

• Do not block the air vents inside the refrigerator. - If the air vents are blocked, especially with a plastic bag, the refrigerator can be over cooled. If a cooling period lasts too long, the water lter may break and cause water leakage.

• If the refrigerator is disconnected from the power supply, you should wait for at least ve minutes before plugging it back in.

• If large amounts of water enter the refrigerator, pull out the power plug and contact a Dacor service center.

• Do not strike or apply excessive force to any glass surface. - Broken glass may result in a personal injury and/or property damage.

• Fill the water tank and ice cube trays with potable water only (tap water, mineral water, or puried water). - Do not ll the tank with tea, juice, or a sports drink. They can damage the refrigerator.

• If the refrigerator is ooded, shut off the power to the refrigerator and contact your nearest Dacor service center. - There is a risk of electric shock or re.

• Do not keep vegetable oil in your refrigerator’s door bins. The oil can solidify, making it foul-tasting and difcult to use. In addition, the open container can leak and the leaked oil can cause the door bin to crack. After opening an oil container, it is best to keep the container in a cool and shaded place such as a cupboard or pantry. - Examples of vegetable oil: olive oil, corn oil, grape-seed oil, etc. Cleaning cautions CAUTION

• Do not spray water directly on the inside or outside of the refrigerator. - There is a risk of re or electric shock.

• Do not use a hair dryer to dry the inside of the refrigerator.

• Do not place a lighted candle in the refrigerator to remove bad odors. - This may result in an electric shock or re.

• Do not spray cleaning products directly on the display. - Printed letters on the display may come off.

• If any foreign substance such as water has entered the appliance, unplug the power plug and contact your nearest Dacor service center. - Failing to do so may result in an electric shock or re.

• Use a clean, dry cloth to remove any foreign matter or dust from the power plug blades. Do not use a wet or damp cloth when cleaning the plug. - Otherwise, there is a risk of re or electric shock.

• Do not clean the appliance by spraying water directly onto it.

• Do not use benzene, thinner, or Clorox (bleach) to clean the refrigerator. - They may damage the surface of the appliance and may cause a re.

• Never put ngers or any objects into the dispenser outlet. - This can cause a personal injury or material damage.

• Before cleaning or performing maintenance, unplug the appliance from the wall socket. - Failing to do so may result in an electric shock or re. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 13 2022-04-28 10:55:28Safety information English14 Safety information

• Use a clean sponge or soft cloth and a mild detergent in warm water to clean the refrigerator.

• Do not use abrasive or harsh cleansers such as window sprays, scouring cleansers, ammable uids, muriatic acid, cleaning waxes, concentrated detergents, bleaches, or cleansers containing petroleum products on exterior surfaces (doors and cabinet), plastic parts, door and interior liners, and gaskets. - These can scratch or damage the material.

• Do not clean glass shelves or covers with warm water when they are cold. Glass shelves and covers may break if exposed to sudden temperature changes or impacts such as bumping or dropping. Critical disposal warnings WARNING

• Children trapped inside a refrigerator can hurt themselves or suffocate to death.

• Please dispose of the packaging material from this product in an environmentally friendly manner.

• Ensure that none of the pipes on the back of the refrigerator are damaged prior to disposal.

• This product contains R-600a, a ammable gas, which is used as the refrigerant. Contact your local authorities regarding safe disposal of this product.

• When disposing of this refrigerator, remove the door/door seals and door latch so that small children or animals cannot become trapped inside. Children should be supervised to ensure that they do not play with the appliance. - If trapped inside, the child could be injured or suffocate to death.

• Cyclopentane is used in the insulation. The gases in the insulation material require a special disposal procedure. Please contact your local authorities in regard to the environmentally safe disposal of this product.

• Keep all packaging materials well out of the reach of children, as packaging materials can be dangerous to children. - If a child places a bag over his or her head, the child could suffocate. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 14 2022-04-28 10:55:29English 15 Installation Installation Follow these instructions carefully to ensure a proper installation of this refrigerator and to prevent accidents before using it. WARNING

• Use the refrigerator only for its intended purpose as described in this manual.

• Any servicing must be performed by a qualied technician.

• Dispose of the product packaging material in compliance with the local regulations.

• To prevent electric shock, unplug the power plug before servicing or replacing parts. Refrigerator at a glance NOTE The actual image and provided component parts of the refrigerator may differ, depending on the model and the country.

• For energy efciency, keep all shelves, drawers, and baskets in their original positions.

• When closing the door, make sure the vertical hinged section is in the correct position to avoid scratching the other door.

• If the vertical hinged section is reversed, put it back into the correct position, and then close the door.

• Moisture may form at times on the vertical hinged section.

• If you close a door forcefully, the other door may open.

• If the internal or external LED lamp is out of order, contact a local Dacor service center. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 16 2022-04-28 10:55:29English 17 Installation Door bins Your refrigerator ships with door bins of different types and sizes. If the door bins for your refrigerator were packaged separately, use the gure below to help you position the bins properly. NOTE The actual refrigerator and provided component parts of your refrigerator may differ from the illustrations in this manual, depending on the model and the country. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 17 2022-04-28 10:55:29Installation English18 Installation Step-by-step installation STEP 1 Select a site The site must:

• Have a solid level surface without carpeting or ooring that may obstruct ventilation

• Be out of direct sunlight

• Have adequate room for opening and closing the door

• Be away from any heat source

• Provide room for maintenance and servicing

• Have a temperature range between 50 °F (10 °C) and 110 °F (43 °C) Clearance See the following gures and tables for installation space requirements.

/2" (723 mm) Width “B” 35

/8" (912 mm) Height “C” 68

more than 2" (50 mm) recommended 02 125° 03 58" (1472 mm)

/8" (47 mm) 07 43" (1093 mm) NOTE The measurements in the tables may differ slightly from the actual measurements, depending on the measuring and rounding method. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 19 2022-04-28 10:55:29Installation English20 Installation STEP 2 Flooring If the refrigerator cannot pass through the entrance due to its size, see Door removal for entrance. NOTE To prevent oor damage, make sure the front leveling legs are in the upright position.

• The surface you install the refrigerator on must support a fully loaded refrigerator.

• To protect the oor, put a large piece of cardboard along the path to the refrigerator's nal installation location.

• Once the refrigerator is in its nal position, do not move it unless necessary to protect the oor. If you have to move the refrigerator, place thick paper or cloth such as old carpets along the path of movement. STEP 3 Door removal for entrance If the refrigerator cannot pass through the entrance to your home or kitchen due to its size, follow these instructions to remove and then re-install the refrigerator's doors. If you do not need to remove the doors, go to page 28 to continue the installation procedure. WARNING Unplug the power cord of the refrigerator before removing the doors. Tools required (not provided) Phillips screwdriver Flat-head screwdriver Socket wrench

1. With the doors closed, use a Phillips

screwdriver to remove the screws (x3) from the top cover. Pull up and remove the top cover with the connectors.

2. Disconnect the two wire connectors on

the left door. CAUTION

• Do not remove both doors simultaneously. Make sure to remove one door at a time. Otherwise, any of the doors may fall and cause physical injury.

• Make sure the refrigerator is off before disconnecting the connectors.

3. Disconnect the water tube from the

coupler on the left door as shown.

4. Gently draw up the clamp in several

steps. To prevent nger injuries, do not apply a sudden force to the clamp. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 21 2022-04-28 10:55:30Installation English22 Installation

5. Pull the clamp to remove.

6. Open the door 90 degrees. While

holding the door, pull up and remove the top hinge. Be careful not to damage the connector wires when you remove the hinge.

7. Gently pull up the door vertically to

remove. Do not apply excessive force to the door. The door may fall, causing physical injury.

8. Lay the door down on a at surface.

9. Repeat steps 1-8 for the other door,

except for step 3. There is no water tube on the right side door. - Step 2 does not apply to the models without the Reveal door. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 22 2022-04-28 10:55:31English 23 Installation Detach the freezer doors CAUTION

• Be sure to remove the fridge doors before removing the freezer doors.

• Use caution when disconnecting the bottom connectors.

1. Open the freezer door.

2. Use a Phillips screwdriver to remove the

screw holding the cover (A). - This step only applies to the right side freezer door.

3. Disconnect the wire connectors.

- This step only applies to the right side freezer door.

4. Locate the hinge shaft. While holding

the door with one hand, use a at-head screwdriver or Allen wrench to press the shaft down. Make sure to hold the door to prevent the door from falling. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 23 2022-04-28 10:55:31Installation English24 Installation

5. To prevent contact with the middle

hinge, slightly tilt the door to the front, and then lift it up to remove.

6. Repeat steps 1-5 for the other door,

except for steps 2 and 3. To reattach the freezer doors CAUTION

• After re-attaching the doors, make sure all the electrical connectors are properly connected.

• The freezer doors must be re-attached before the fridge doors.

• Be careful not to damage or step on the wires during this process.

1. Insert the freezer door into the bottom

hinge while pushing the freezer door in the direction of the arrow. CAUTION

• Be careful not to damage or step on the wires during this process. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 24 2022-04-28 10:55:31English 25 Installation

2. While pressing the hinge shaft down,

position the door so that the hinge shaft is below the shaft hole in the middle hinge. Release the hinge shaft so that it enters the shaft hole.

3. With the door open, connect the bottom

connectors in the direction of the arrows. - This step only applies to the right side freezer door.

4. Attach the cover using a Phillips

screwdriver. Be careful not to damage or step on the connectors. - This step only applies to the right side freezer door.

5. Repeat steps 1-2 for the other door.

Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 25 2022-04-28 10:55:31Installation English26 Installation To reattach the fridge doors

1. While holding the door open by more

than 90 degrees, insert the shaft on the middle hinge into the hole on the bottom of the door.

2. Put the top hinge into position on the

top of the refrigerator, and then insert the hinge shaft into the top hole of the door. Make sure the wires from the door pass through the hole in the hinge shaft.

3. Insert the clamp in the direction of the

4. Push back the clamp as shown.

Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 26 2022-04-28 10:55:32English 27 Installation

5. Connect the wire connectors.

• Make sure the wire connectors are connected properly. Otherwise, the refrigerator may not operate properly.

6. Connect the water tube.

• To prevent water leaks, make sure the red clips tighten the coupler properly.

• Keep the clips out of children’s reach.

7. Repeat steps 1-5 for the other door.

- Step 5 does not apply to the models without the Reveal door.

8. Attach the top cover with the front side

rst, and then press down on its back to get it into position. Then, tighten the screws (x3). Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 27 2022-04-28 10:55:32Installation English28 Installation STEP 4 Leveling the refrigerator CAUTION

• When installed, the refrigerator must be leveled on a at, solid oor. Not leveling the refrigerator can cause damage to the refrigerator or physical injury.

• Leveling must be performed with the refrigerator empty. Make sure no food items are inside the refrigerator.

• For safety reasons, adjust the front a little higher than the rear. Level the refrigerator using the special screws (levelers) on the front legs. Use a at-head screwdriver to turn the levelers.

• To adjust the height of the left side: Insert a at-head screwdriver into the leveler of the left side front leg. Turn the leveler clockwise to raise the left side or turn it counterclockwise to lower.

• To adjust the height of the right side: Insert a at-head screwdriver into the leveler of the right side front leg. Turn the leveler clockwise to raise the right side or turn it counterclockwise to lower. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 28 2022-04-28 10:55:32English 29 Installation STEP 5 Adjust the door height Adjusting the height with the height lever (applicable models only)

• Before aligning the door height, make sure the refrigerator is level. Use the leveling legs for this purpose.

• You can use the height lever at the bottom of the right-side door of the fridge. Open the right-side door of the freezer with both fridge doors closed and use the lever to adjust the door height.

• Turn the height lever (A) until the two doors are aligned at the top. Turn the lever toward UP (as marked) to raise the right-side door and turn it toward DOWN (as marked) to lower the door.

• Lift the fridge door slightly to make alignment easier. The maximum adjustable height is 3 mm. - The lever will not turn past the maximum limit. It may make a noise it if is turned too far. - Excessive height may interfere with the upper hinge cover of the fridge door.

• If you align the door height with the door bins empty and then store items in the bins, the heights may differ again. If this happens, follow the steps above to realign the doors. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 29 2022-04-28 10:55:33Installation English30 Installation Adjusting the height with the snap rings For the models with the height lever on the right-side door of the fridge, use the snaps rings only if you cannot align the doors with the height lever. NOTE The height of a door can be adjusted using the provided snap rings, which come in 4 different sizes (1 mm, 1.5 mm, 2 mm, and

1. Check the height difference between the

doors, and then lift up and hold the door with the lower height.

between the door grommet (B) and the hinge as shown. CAUTION

• Insert only one snap ring. If you insert two or more snap rings, the rings may slip out or make a rubbing noise.

• Keep the snap rings out of children’s reach and keep them for future use.

• Do not raise the door too much. The door can contact and damage the top cover. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 30 2022-04-28 10:55:33English 31 Installation Adjusting the freezer door height (applicable models only)

• Before aligning the door height, make sure the refrigerator is level. Use the leveling legs for this purpose.

• You can adjust the height of both freezer doors using the lever located at the bottom hinge.

• Open the door, lift it a little, and then turn the lever left or right to adjust the height. Adjusting the gap between the fridge doors and the main body of the refrigerator (applicable models only)

• You can adjust the gap between both fridge doors and the main body of the refrigerator using the adjustment bolt located at the bottom of the fridge compartment.

• Lift the door gasket and located the adjustment bolt underneath the gasket. Use the 4 mm Allen wrench to adjust the gap. CAUTION Make sure you rmly attach the gasket. Otherwise, cold air from the refrigerator may leak. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 31 2022-04-28 10:55:33Installation English32 Installation STEP 6 Connect the water dispenser line A water dispenser with a lter is one of the helpful features on your new refrigerator. To help promote better health, the water lter removes unwanted particles from your water. However, it does not sterilize or destroy microorganisms. You may need to purchase a water purifying system to do that. The water line also connects to the ice maker. For the ice maker to operate properly, water pressure must be between 30-125 psi (206-861 kPa). If the refrigerator is installed in an area with low water pressure (below 30 psi / 206 kPa), you can install a booster pump to compensate for the low pressure. After you have connected the water line, check if the water dispenser works properly. Press the water dispenser lever until the water runs from the water outlet. NOTE

• Water line installation kits are available at extra cost from your retailer. We recommend using a water line installation kit that contains copper tubing and a

1. Shut off the main water source.

2. Insert the pipe clamp (B) and the shutoff

valve (C) into the cold water line (A).

3. Connect the water line installation kit

(A) to the shutoff valve (B). Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 32 2022-04-28 10:55:33English 33 Installation Connect the water supply line to the refrigerator There are several items you must purchase to complete this connection. You may nd these items sold as a kit at your local hardware store. Copper Tubing

/4" (6 mm) plastic tubing Molded end (Bulb)

A. Refrigerator B. Household water supply line C. Water Line: must be kept straight. 01 Compression Nut (

/4" (6 mm)) (Assembled) 02 Ferrule (Not supplied) 03 Copper tubing (Not supplied) 04 Plastic Tubing (Assembled) 05 Compression Fitting (Assembled) 06 Molded end (Bulb) 07 Compression nut (B) (

/4" (6 mm)) (Not supplied) 08 Plastic Tubing (A) (Not supplied) NOTE If you have to relocate the refrigerator after connecting the water line (C), make sure the joined section of the water line is straight. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 33 2022-04-28 10:55:34Installation English34 Installation CAUTION Do not mount the water lter on any part of the refrigerator. This may damage the refrigerator.

1. Connect the household water line to the assembled compression tting.

- If you are using copper tubing, slip the compression nut (B) (not supplied) and ferrule (not supplied) on the copper tubing (not supplied) as shown. - If you are using plastic tubing (A), insert the molded end (Bulb) of the plastic tubing (A) into the compression tting. CAUTION

• If you use plastic tubing (A), do not use it without the molded end (Bulb).

• Leaving the water line disconnected may cause the water valve to produce a buzzing sound over time. If this is the case, make sure that the ice making function is turned "OFF" and do not attempt to use the water dispenser.

2. Tighten the compression nut (B) onto the compression tting. Do not over-tighten the

compression nut (B).

3. Turn the water on and check for any leakage. If you nd water drops or leakage in

the connection areas, turn off the main water supply. Check the connections and, if necessary, tighten.

4. Flush 3 gallons (11.5 L) of water through the lter before drinking or using the water

from the refrigerator. (Flush approximately 5-6 minutes.) To ush, press a large glass or cup against the water dispenser lever. Fill the glass, empty it, and then repeat.

5. After you turn on the refrigerator, let the ice maker make ice for 1 to 2 days. Over that

period of time, throw out the rst 1 or 2 buckets of ice the ice maker makes to ensure all impurities have been removed from the water line. NOTE Only connect the water line to a potable water source.

• If you have to repair or disassemble the water line, cut off

/4" (6 mm) of the plastic tubing to make sure you get a snug, leak-free connection.

• You can test the water line quickly using a paper cup. Under normal conditions, the water dispenser can ll a 5

/4 oz. (170 cc) cup in about 10 seconds. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 34 2022-04-28 10:55:34English 35 Installation STEP 7 Initial settings By completing the following steps, the refrigerator should be fully functioning.

1. Plug the power cord into the wall socket to turn the refrigerator on.

2. Open the door, and check if the interior light lights up.

3. Set the temperature to the coldest setting, and wait for about an hour. Then, the freezer

will be slightly chilled, and the motor should be running smoothly.

4. Wait until the refrigerator reaches the set temperature. Now the refrigerator is ready

for use. STEP 8 Final check When installation is complete, conrm that:

• The refrigerator is plugged into an electrical outlet and grounded properly.

• The refrigerator is installed on a at, level surface with a reasonable clearance from walls and cabinets.

• The refrigerator is level and is sitting rmly on the oor.

• The door opens and closes freely, and the interior light turns on automatically when you open the door. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 35 2022-04-28 10:55:34English36 Operations Operations Control panel

• Displays the current or desired temperature of the fridge.

• indicates that the Power Cool function is on. 02 Peak Demand indicator

• Displays the status of the Peak Demand function.

• For more information on the Peak Demand function, see the SMART GRID Function (Demand Response) section. 03 Freezer indicator

• Displays the current or desired temperature of the freezer.

• indicates that the Power Freeze function is on. 04 Network connection indicator

• This icon indicates that the refrigerator is connected to a network. If the Wi-Fi icon ashes, we recommend connecting your refrigerator with the SmartThings app. You can control and monitor your refrigerator on the SmartThings app. For more information, see the SmartThings section. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 36 2022-04-28 10:55:34English 37 Operations 05 AutoFill Pitcher indicator The AutoFill Pitcher has 2 indicators (AutoFill Pitcher On / Off) to indicate its operating status.

• When the AutoFill operates, the corresponding indicator (AutoFill Pitcher On) turns on.

• When the AutoFill is turned off, the corresponding indicator (AutoFill Pitcher Off) turns on.

• To enable AutoFill Pitcher, you must turn on the AutoFill Pitcher. 06 Ice Maker indicator The ice maker has 2 indicators (Ice Maker On / Off) to indicate its operating status.

• When the ice maker operates, the corresponding indicator (Ice Maker On) turns on.

• When the ice maker is turned off, the corresponding indicator (Ice Maker Off) turns on.

• To enable ice making, you must turn the ice maker on. 07 Water Filter indicator

• indicates that the water lter needs to be replaced.

• When you see the icon, you can replace the water lter and reset the water lter replace alarm, or dismiss the alarm and change the lter later. (For more information, see the "Resetting or dismissing the water lter replacement alarm" section on page 41. 08 Buttons

• When the display is off, tap any button to wake up the display.

• Tap to select the desired item on the main panel and to conrm any setting changes.

• Tap or to change the settings of the selected item on the main panel. NOTE

• If the door is left open for 5 minutes, the internal light will blink for 5 minutes and turn off to alert deaf and hard of hearing users that a door is open. Note that this function is normal. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 37 2022-04-28 10:55:35Operations English38 Operations Setting the desired temperature or function Select the fridge or freezer and set the desired temperature or function of your choice.

1. Tap any button ( , , or ) to wake up the display.

- This step may not apply to some models.

2. Tap until the fridge or freezer indicator blinks.

- The selected compartment’s indicator blinks.

3. Tap or to select the desired temperature or function.

- Refer to the table for available selection for each compartment. Fridge

• Power Cool speeds up the cooling process at maximum fan speed. The fridge keeps running at full speed for two and a half hours and then returns to the previous temperature. Freezer

• Power Freeze speeds up the freezing process at maximum fan speed.

• The freezer keeps running at full speed for 50 hours and then returns to the previous temperature. To freeze large amounts of food, activate Power Freeze for at least 20 hours before putting food in the freezer. NOTE When you use this function, the energy consumption of the refrigerator will increase. Remember to turn it off when you do not need it and return the freezer to your original temperature setting.

4. Wait for 5 seconds or tap to conrm your selection.

- The selected compartment’s indicator stops blinking. NOTE

• Using Power Cool or Power Freeze increases power consumption.

• When you change the temperature on the panel, the panel displays the actual temperature inside the refrigerator until the temperature matches the temperature you set. Then, the panel displays the new set temperature. Note that it will take time for the refrigerator to reach the new temperature. This is normal. During this time, you do not need to set the temperature again.

• To ensure optimal performance, we recommend setting the temperature to 0 °F (-18 °C) for the freezer, and 37 °F (3 °C) for the fridge. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 38 2022-04-28 10:55:35English 39 Operations

• The temperature in the refrigerator may rise if you open the door frequently or put a large amount of food into the refrigerator. If this happens, the temperature display blinks until the refrigerator returns to the specied temperature settings. If the blinking continues for an extended time, contact a local Dacor service center for technical assistance.

• While the temperature display is blinking, an alarm may occur. To stop the alarm, tap any button on the display. Turning on or off the AutoFill Pitcher You can turn on or off the AutoFill Pitcher in fridge.

1. Tap any button ( , , or ) to wake up the display.

- This step may not apply to some models.

2. Tap until the AutoFill Pitcher indicator blinks.

3. Tap or to turn on or off the AutoFill Pitcher.

- Tap to turn it on. - Tap to turn it off.

4. Wait for 5 seconds or tap to conrm your selection.

- The AutoFill Pitcher indicator stops blinking. Turning on or off the ice maker You can turn on or off the auto ice maker in the freezer.

1. Tap any button ( , , or ) to wake up the display.

- This step may not apply to some models.

2. Tap until the Ice Maker indicator blinks.

3. Tap or to turn on or off the ice maker.

- Tap to turn it on. - Tap to turn it off.

4. Wait for 5 seconds or tap to conrm your selection.

- The Ice Maker indicator stops blinking. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 39 2022-04-28 10:55:35Operations English40 Operations Changing the temperature scale You can switch the temperature scale between Fahrenheit and Celsius.

1. Tap any button ( , , or ) to wake up the display.

- This step may not apply to some models.

2. Tap until the °F and °C symbols on the fridge or freezer blink.

3. Tap or to select the desired temperature scale.

- Tap to select Fahrenheit. - Tap to select Celsius.

4. Wait for 5 seconds or tap to conrm your selection.

- The °F and °C symbols stop blinking. Turning on or off the Peak Demand function You can turn on or off the Peak Demand function. For more information on the Peak Demand function, see the SMART GRID Function (Demand Response) section. To activate or deactivate the Peak Demand function, tap and hold for 3 seconds. When the function is enabled, the Peak Demand indicator ( ) turns on with a chime. Activating or deactivating the Sabbath mode The Sabbath mode stays active for 85 hours once it is activated. After that, it will be deactivated automatically.

• To activate or deactivate the Sabbath Mode, tap and hold and simultaneously for 6 seconds. Then, when the display blinks, tap . - When the refrigerator is in the Sabbath mode, the buttons, display, and internal lights do not function. The refrigerator and freezer, however, continue to cool. NOTE

• If the refrigerator powers off and restarts (for example, if there is a power failure), the Sabbath mode remains active. To end Sabbath Mode, you must deactivate it as instructed above. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 40 2022-04-28 10:55:36English 41 Operations Activating or deactivating the Cooling Off mode The Cooling Off mode (also called the Shop mode) is designed for retailers to display refrigerators on a retail oor. In the Cooling Off mode, the refrigerator’s fan motor and lights operate normally, but the compressors do not run, so neither the refrigerator nor the freezer becomes cold.

• To activate or deactivate the Cooling Off mode, tap and hold and simultaneously for 6 seconds. Then, when the display blinks, press . - When the Cooling Off mode is on, the refrigerator chime sounds, and the refrigerator shows “0” on the fridge indicator and “FF” on the freezer indicator. Resetting or dismissing the water lter replacement alarm The water lter replacement icon ( ) blinks to alert the user that it is time to replace the water lter. You can replace the water lter immediately and reset the water lter replacement alarm, or dismiss the alarm if you want to change the water lter later.

1. Tap any button ( , , or ) to wake up the display.

- This step may not apply to some models.

2. Tap until the Water Filter indicator blinks.

3. Tap or to select Reset or Later.

- If you have changed the water lter, tap to reset the water lter replacement alarm. - If you want to change the water lter later and dismiss the alarm, tap .

4. Wait for 5 seconds or tap to conrm your selection.

- The Water Filter indicator stops blinking. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 41 2022-04-28 10:55:36Operations English42 Operations SmartThings Installation Visit the Google Play Store, Galaxy Apps, or Apple App Store and search for “SmartThings”. Download and install the SmartThings app provided by Samsung Electronics to your smart device. NOTE

• The supporting software version of the SmartThings app is subject to change according to the OS supporting policy the manufacturer provides. In addition, as for the SmartThings app or the functions that the app supports, the new application update policy on the existing OS version can be suspended due to usability or security reasons.

• The SmartThings app is subject to change without notice to improve usability or performance. As the mobile phone OS version is updated every year, the SmartThings is also updated continually according to the latest OS. If you have enquiries regarding the items mentioned above, please contact us on [e-mail].

• For improved performance, the SmartThings app is subject to change without notice or discontinued support according to the manufacturer’s policy. In addition, further updates on the app or the function in the app may stop due to usability and security reasons, even if updates are currently supported on your OS.

• Recommended encryption systems include WPA/TKIP and WPA2/AES. Any newer or non-standard Wi-Fi authentication protocols are not supported.

• Wireless networks may be affected by the surrounding wireless communication environment.

• If your Internet service provider has registered the MAC address of your PC or modem for identication, your Dacor Smart Refrigerator may fail to connect to the Internet. If this happens, contact your Internet service provider for technical assistance.

• The rewall settings of your network system may prevent your Dacor Smart Refrigerator from accessing the Internet. Contact your Internet service provider for technical assistance. If this symptom continues, contact a local Dacor service center or retailer.

• To congure the wireless access point (AP) settings, see the user manual of the AP (router).

• Dacor Smart Refrigerators support both Wi-Fi 2.4 GHz with IEEE 802.11 b/g/n and Soft- AP protocols. (IEEE 802.11 n is recommended.)

• Unauthorized Wi-Fi wireless routers may fail to connect to applicable Dacor Smart Refrigerators. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 42 2022-04-28 10:55:36English 43 Operations Samsung account You are required to register your Samsung account to use the app. If you don’t have a Samsung account, follow the app’s onscreen instructions to create a free Samsung account. Getting started Turn on the device you want to connect, open the SmartThings app on your phone, and then follow the instructions below. If a pop-up appears saying that a new device has been found, tap ADD NOW. If a pop-up doesn't appear, tap the + button, and then select the device you want to connect from the list of available devices. If your device isn't in the list of available devices, tap Supported Devices, select the device type (Refrigerator), and then select the specic device model. Follow the instructions in the app to set up your device. Once setup is complete, your refrigerator will appear as a "card" on your Devices screen. Refrigerator app Integrated control You can monitor and control your refrigerator at home and on the go.

• Tap the refrigerator icon on the SmartThings Dashboard or tap the Devices icon at the bottom of the Dashboard, and then tap the refrigerator "card" to open the Refrigerator page.

• Check the operation status or notications related to your refrigerator, and then change options or settings if necessary. NOTE Some options or settings of the refrigerator may not be available for remote control. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 43 2022-04-28 10:55:36Operations English44 Operations Category Item Description Monitoring Fridge temperature Displays the desired temperature setting of the fridge. Freezer temperature Displays the desired temperature setting of the freezer. Energy monitoring Checks the accumulated power consumption of the refrigerator for the last 180 days. Functions Ice making You can turn the ice making function on or off. Power Cool You can turn Power Cool on or off, and check the current settings. Power Freeze You can turn Power Freeze on or off, and check the current settings. Fridge temperature You can set the desired temperature of the fridge. Freezer temperature You can set the desired temperature of the freezer. AutoFill Pitcher You can turn the AutoFill Pitcher function on or off. Sabbath Mode You can activate and deactivate the Sabbath mode. Alarms Abnormally high temperature This alarm is triggered when the fridge or the freezer has abnormally high temperatures. Door opening This alarm is triggered if the fridge door or the freezer drawer is open for a specic time. AutoFill Pitcher overowing If the AutoFill Pitcher function senses an overow, it triggers this alarm to let you know the status of the overow. Water lter replacement This alarm reminds you that the water lter must be replaced. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 44 2022-04-28 10:55:36English 45 Operations SMART GRID Function (Demand Response) When the refrigerator operates in SMART GRID (Demand Response) mode, the Energy Management Refrigerator function can control energy usage or delay the operation of some functions to save money when energy prices or demand are the highest. NOTE

• You can deactivate the SMART GRID (Demand Response) function at any time using the Peak Demand Off function.

• To use the SMART GRID (Demand Response) function, you need a separate contract with your electric utility company. In addition, to use the Smart Grid (Demand Response) function, you must register for the service with your electric company. The company must have an EMS (Energy Management System) that supports SEP (Smart Energy prole). Using the SMART GRID (Demand Response) Function This feature monitors energy prices and demand information from your utility company and sends notications to the refrigerator to run high energy consuming tasks during off- peak times when electricity costs and demand are lower. If the refrigerator receives a control signal from the utility company, the refrigerator will display the DAL ~ TALR levels on the refrigerator display and control the power consumption according to the level. [Exception condition] The DAL and TALR control signals from a utility company work as long as product performance is maintained. If the refrigerator receives the SMART GRID (Demand Response) signal (DAL or TALR), the refrigerator will operate in Delay Appliance Load (DAL) or Temporary Appliance Load Reduction (TALR) mode.

• Delay Appliance Load (DAL): The refrigerator responds to a DAL signal by providing a moderate load reduction for the duration of the delay period. This function controls functions that consume a lot of energy such as adjusting the Cooling system, running the defrost cycle, and making ice. - When the refrigerator operates in DAL mode, “L3” is displayed on the refrigerator display. - DAL mode is automatically deactivated after it lasts for the amount of time stipulated by the DAL signal (max. 4.5 hours) or when the Peak Demand Off key is pressed.

• Temporary Appliance Load Reduction (TALR): The refrigerator responds to a TALR signal by aggressively reducing the load for a short time period. This function reduces energy consumption by stopping the compressor and controlling the functions that consume a lot of energy such as the defrost cycle and making ice. - When the refrigerator operates in TALR mode, “L4” is displayed on the refrigerator display. - TALR mode is automatically deactivated after it lasts for the received duration (max. 15 minutes), or when the Peak Demand Off key is pressed. The mode is immediately deactivated and the refrigerator returns to the normal state when the door is opened or closed, or the dispenser is used. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 45 2022-04-28 10:55:36Operations English46 Operations Peak Demand Off (Override mode) When you want the refrigerator to ignore the SMART GRID (Demand Response) signal from the utility company, you can activate Peak Demand Off (Override mode). When you activate Peak Demand Off (Override mode), the refrigerator ignores the SMART GRID (Demand Response) signal and is not controlled by the utility company. Activating and deactivating Peak Demand Off (Override mode)

1. Tap and hold for 3 seconds.

2. Then the Peak Demand Off (Override mode) icon ( ) turns on.

3. If the refrigerator receives a SMART GRID (Demand Response) signal from the utility

company, ’Or’ is displayed in the freezer temperature display.

4. To deactivate Peak Demand Off (Override mode), tap and hold for 3 seconds.

5. Then the Peak Demand Off (Override mode) icon ( ) turns off.

• Alternatively, you can activate or deactivate Peak Demand Off (Override mode) using the SmartThings app and the Energy Management function. See the Using the Energy Management Function section. Using the Energy Management Function The Energy Management function enables you to control and monitor your Energy Management refrigerator using the SmartThings app for your convenience. NOTE

• To use the Energy Management refrigerator functions, you have to install the corresponding app rst.

1. Operational Status

- You can check the DR and Peak Demand status.

2. Energy Consumption Reporting

- Shows the accumulated power consumption. Power consumption data is updated every 10 minutes. NOTE The energy consumption report may differ from the power consumption specications of the product depending on the operating environment and the stored food.

3. Delay Defrost Capability

- The Delay Defrost Capability function saves energy by delaying the defrost operation to a time specied by the user. You can congure the time. and this function will save energy during the specied period in a 24 hour cycle. If the time is not set, the function works with the default time settings. The default time settings are below: - 6 am to 10 am: 1st. November ~ 30th. April - 3 pm to 7 pm: 1st. May ~ 31th. October To change the time setting for the Delay Defrost Capability You can change the time setting for the Delay Defrost Capability on the app. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 46 2022-04-28 10:55:36English 47 Operations Provision for Open Access to the Connected Product Requirements

1. SGIP Open Standards (Smart Energy Prole 2.0 - http://www.csep.org/)

- Energy Consumption Reporting - Demand Response

- Operational Status, User Settings & Messages - ICE Maker Status: GET /icemaker/status/vs/0 - Door Open Alarm: GET /doors/vs/0 - DR Status: GET /drlc/vs/0 - Delay Defrost Capability - Set Schedule of the Defrost Delay: POST /defrost/reservation/vs/0?op=add - Get Schedule of the Defrost Delay : GET /defrost/reservation/vs/0 - Delete Schedule of the Defrost Delay: POST /defrost/reservation/vs/0?op=remove - Defrost Delay On/OFF: POST /defrost/delay/vs/0 Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 47 2022-04-28 10:55:36Operations English48 Operations Special features Beverage Center B A A. Fridge door handle B. Beverage Center handle The left fridge door has two handles on the bottom. To use the autoll pitcher, drink cold or puried water, press handle (B) to open the Beverage Center. Water pitcher (AutoFill Pitcher) Cold, puried water is always ready in the AutoFill Pitcher. You can put tea or fruits in the infuser to enjoy the various infused water you like.

then pull up to open the lid.

2. Put tea leaves or fruit to your taste into

the infuser. NOTE If you want to keep the infused water in its initial concentration, turn the AutoFill Pitcher function off.

3. Enable the AutoFill Pitcher function on

the control panel. Open the Reveal door, and then mount the water pitcher onto the holder. Push it straight in as shown in the gure. CAUTION Make sure the water pitcher ts in the water pitcher holder.

4. Close the door. The water pitcher will

start to ll with chilled water a short time later.

5. To drink tea, open the Reveal door, and

then detach the water pitcher. Pull it straight out. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 49 2022-04-28 10:55:37Operations English50 Operations CAUTION

• We recommend consuming fruit infused water within 24 hours. After that, the infused water can spoil over time.

• You must clean the water pitcher after you have consumed the infused water. Also clean the water pitcher if you haven't used it for a long time.

• To prevent the water pitcher from tipping over or leaking, make sure the water pitcher ts in the water pitcher holder.

• To prevent the water pitcher from spilling over or leaking, make sure the infuser holder is properly inserted. NOTE

• If the front side (specically marked area) of the water pitcher has too much moisture, the water pitcher may not fully ll. Remove the moisture, and then try again.

• AutoFill Pitcher function will stop supplying water to the water pitcher if the water pitcher does not ll after a certain amount of time. If this happens, check if the water line is properly connected. Remove and reinsert the water pitcher, and then try again. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 50 2022-04-28 10:55:37English 51 Operations NOTE

• Wipe around the water pitcher holder if the water pitcher overows or leaks.

• Water drops off if the rubber cap is opened.

• An alert message appears on the control panel if there is a leak. In case of a leak, open the rubber cap so that the leaked water drains. If the alert message does not disappear after draining, there might be a system failure. Contact your local Dacor service center. NOTE

• You must clean the water pitcher after you have consumed the infused water. You must also clean the water pitcher if you have not used it for a long time or left the full pitcher for more than three days.

• If the infuser is not properly cleaned, the scent of the tea or fruits you previously used in the infuser may remain. If you are not going to use the infuser, separate it from the pitcher and store it safely.

• If you have not used the water lter for a long time, pour away the rst two pitchers of water. Then, clean the water pitcher thoroughly and use it. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 51 2022-04-28 10:55:38Operations English52 Operations Water dispenser To dispense chilled water, open the Beverage Center and press the dispenser lever. NOTE

• The dispenser will stop dispensing if you keep pushing the dispenser lever for about 1 minute. To dispense more water, release and push the lever again.

• Make sure the glass is in line with the dispenser to prevent the dispensed water from spilling out.

• If you do not use the water dispenser for 2-3 days, the dispensed water may have an abnormal smell or taste. This is not a system failure. Discard the rst 1-2 glasses of water. Water clouding Water supplied to the refrigerator ows through a core alkaline lter. During this ltering process, the water pressure of the water increases and the water becomes saturated with oxygen and nitrogen. This causes the water to look misty or cloudy temporarily when dispensed. This is normal and the water will look clear after a few seconds. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 52 2022-04-28 10:55:38English 53 Operations Auto Ice maker The refrigerator has a built-in ice maker that automatically dispenses ice.

• The overall design and/or accessories may differ with the model.

• This product has two types of ice makers.

• Keep the scoop inside the scoop tray. Ice making After you have installed your refrigerator and plugged it in, follow these instructions to ensure proper ice making and to keep the ice bucket full of ice. For rst-time use

• Let the ice maker make ice for 1-2 days.

• Discard the rst 1-2 buckets of ice to remove impurities in the water supply system. Diagnosis

• The overall design and/or accessories may differ with the model.

• If ice does not dispense, rst check the status of ice maker using the Test button on the bottom of the ice maker.

• Press the Test button on the back of the ice maker. You will hear a chime (ding- dong) when you press the button. You will hear another chime if the ice maker is operating properly. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 53 2022-04-28 10:55:38Operations English54 Operations

• Ice accumulating on one side of the tray is normal. Arrange the ice evenly in the tray to store more ice. CAUTION

• Leaving the water line disconnected may cause the water valve to produce a buzzing sound over time. If this is the case, make sure to turn the ice making function off.

• If the ice making chime rings repeatedly, contact the waterline installer or a local Dacor service center.

• Do not put food in the ice bucket. The frozen food may damage the ice maker, especially when you open or close the door.

• When the refrigerator recovers power after a power failure, the ice bucket may contain a mix of melted and jammed ice cubes, which can prevent the ice maker from working properly. To prevent this, make sure to empty the ice bucket before using the refrigerator.

• Do not put ngers or any objects into the ice maker. This can cause physical injury or property damage.

• Due to sublimation, ice stored in the freezer for a long time gets smaller and then forms large ice chunks. Therefore, if it will be a long time before you use ice, turn the ice maker off as follows.

• Use the new hose-sets supplied with the appliance only. Do not re-use an old hose set. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 54 2022-04-28 10:55:38English 55 Maintenance Maintenance Handling and care Ice bucket If you do not dispense ice for an extended period, ice may form clumps inside the bucket. If this happens, remove and empty the ice bucket. CAUTION

• To prevent injury, make sure to clean up any ice or water that has fallen on the oor.

• To prevent accidents or injury, do not let children play with the water dispenser or the ice maker.

• Use only the provided ice bucket. Third-party ice buckets may cause a system failure. NOTE

• The water pressure required for ice making is between 30-125 psi (206-861 kPa).

• Noise from the ice maker as it produces ice during the ice making process is normal. AutoFill Pitcher (applicable models only)

1. Grasp a handle groove of the lid, and

then pull up to remove.

2. Grasp both sides of the infuser holder,

and then lift to remove. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 55 2022-04-28 10:55:38Maintenance English56 Maintenance

3. While slightly twisting the infuser, pull

it out of the sealed mouth.

4. Clean the infuser with neutral agents

and running water. Rinse and dry well.

5. Reassemble the AutoFill Pitcher in the

reverse order of disassembly. CAUTION The water pitcher and lid are not microwave and dishwasher safe. They can melt or deform if exposed to heat (including hot water). Door bins

• To remove the door bin, hold the front sides of the bin, and then gently lift up to remove.

• To reinsert, insert the door bin slightly above its nal location making sure that the back of the bin is against the door. Hold the rear of the door bin with both hands, and then press down so that it ts snugly. CAUTION

• Do not remove a bin that is lled with food. Empty the bin beforehand.

• Use caution when opening the door if the bottom bin contains larger bottles, which may fall over.

• Do not allow children to play with the bins. Sharp corners of the bin may cause injury. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 56 2022-04-28 10:55:39English 57 Maintenance Fridge shelves The appearance of the shelves differs by model.

• To remove a shelf, fully open the corresponding door. Hold the front of the shelf, and then gently lift up and pull out. NOTE Do not lift up the shelf fully when removing or reinserting the shelf. The rear wall of the fridge room can be dented.

• To reinsert, hold the shelf at an angle so the front is higher than the back, and then insert the top hook into the top shelf notch. Then, lower the shelf and insert the bottom shelf hook into the bottom shelf notch. CAUTION

• The tempered glass shelves are heavy. Use caution when removing them.

• The shelf must be inserted correctly. Do not insert upside down.

• Glass containers may scratch the surface of glass shelves. Fridge drawers Gently lift up the front of the drawer and slide out.

• We recommend that you remove the door bins before removing the drawer. This is to prevent damage to the door bins.

• To reinsert, insert the drawer into the frame rails and then slide inward. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 57 2022-04-28 10:55:40Maintenance English58 Maintenance Cleaning Interior and exterior WARNING

• Do not use benzene, thinner, home/car detergent, or Clorox™ to clean the refrigerator. They may damage the surface of the refrigerator and cause a re.

• Do not spray water onto the refrigerator. This may cause electric shock. Regularly use a dry cloth to remove all foreign substances such as dust or water from the power plug terminals and contact points.

1. Unplug the power cord.

2. Use a moistened, soft, lint-free cloth or paper towel to clean the refrigerator’s interior

3. When done, use a dry cloth or paper towel to dry well.

4. Plug in the power cord.

Dispenser nozzle (applicable models only)

1. Hold the end of the dispenser nozzle (A).

2. While turning the dispenser nozzle (A)

left, pull it down to remove it from the dispenser.

3. Clean the dispenser nozzle thoroughly,

and then assemble it back. CAUTION

• Fully insert the dispenser nozzle, so it is back to its original position.

• Do not use a sponge with rough textures for cleaning the dispenser nozzle. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 58 2022-04-28 10:55:40English 59 Maintenance Rubber seals If the rubber seals of a door become dirty, the door may not close properly and reducing refrigerator performance and efciency. Use a mild detergent and damp cloth to clean the rubber seals. Then, dry well with a cloth. Rear panel To keep cords and exposed parts of the rear panel free of dirt, vacuum the panel once or twice a year. CAUTION Do not remove the rear panel cover. Electric shock may occur. Replacement Water lter WARNING

• Do not use third-party water lters. Use only Dacor-provided or -approved lters.

• Unapproved lters may leak and damage the refrigerator, causing electric shock. Dacor is not responsible for any damage that may occur from use of third-party water lters. The water lter replacement icon ( ) blinks to let you know it is time to replace the water lter. Before replacing the lter, make sure the water supply line is shut off.

1. Shut off the water supply line.

2. Open the lter cartridge cover.

Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 59 2022-04-28 10:55:40Maintenance English60 Maintenance

3. Turn the knob of the lter cartridge

counterclockwise 90 degrees (

4. Pull out to remove the cartridge.

- If the water lter is severely contaminated, the cartridge may not be easy to remove. If that is the case, use force to remove the cartridge. - To prevent water leaks from the lter opening, pull the cartridge straight out while removing it.

5. Insert a new lter cartridge. Use only

Dacor-provided or approved lters.

7. Close the lter cartridge cover.

8. Reset the water lter replacement

alarm. (For detailed instructions, see the "Resetting or dismissing the water lter replacement alarm" section on page 41.)

9. When you are done replacing the lter,

open the water valve and run water through the dispenser for about 7 minutes. This is to remove impurities and air from the water line. NOTE

• A newly installed lter may cause the water dispenser to spurt water briey. This is because air has entered the waterline.

• The replacement process may cause the water dispenser to drip for a short period of time. If it drips, simply wipe up any water on the oor with a dry towel. Ordering a new lter To purchase a new water lter, contact a local service agent. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 60 2022-04-28 10:55:41English 61 Maintenance LED Lamps To replace the lamps of the refrigerator, contact a local service agent. WARNING

• The lamps are not user-serviceable. Do not attempt to replace a lamp yourself. This can cause electric shock. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 61 2022-04-28 10:55:41English62 Troubleshooting Troubleshooting Before calling for service, review the checkpoints below. Any service calls regarding normal situations (No Defect Cases) will be charged to users. General Temperature Symptom Possible causes Solution Fridge/freezer does not operate. Fridge/freezer temperature is warm.

• Power cord is not plugged in properly.

• Properly plug in the power cord.

• Temperature control is not set correctly.

• Set the temperature lower.

• Refrigerator is located near a heat source or direct sunlight.

• Keep the refrigerator away from direct sunlight or a heat source.

• Not enough clearance between refrigerator and nearby walls or cabinets.

• Make sure there is a gap of at least 2.5 inches (5 cm) between the refrigerator back and sides and any nearby walls or cabinets.

• The refrigerator is overloaded. Food is blocking the refrigerator vents.

• Do not overload the refrigerator. Do not allow food to block vents. Fridge/freezer is over-cooling.

• Temperature control is not set correctly.

• Set the temperature higher. Interior wall is hot.

• Refrigerator has heat-proof piping in the interior wall.

• To prevent condensation from forming, the refrigerator has heat-proof piping in the front corners. If the ambient temperature rises, this equipment may not work effectively. This is not a system failure. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 62 2022-04-28 10:55:41English 63 Troubleshooting Odors Symptom Possible causes Solution Refrigerator has odors.

• Clean the refrigerator and remove any spoiled food.

• Food with strong odors.

• Make sure strong smelling food is wrapped airtight. Frost Symptom Possible causes Solution Frost around the vents.

• Food is blocking the vents.

• Make sure no food blocks the refrigerator vents. Frost on interior walls.

• Door is not closed properly.

• Make sure food does not block the door. Clean the door gasket. Condensation Symptom Possible causes Solution Condensation forms on the interior walls.

• If door is left open, moisture enters the refrigerator.

• Remove the moisture and do not leave a door open for extended periods of time.

• Food with high moisture content.

• Make sure food is wrapped airtight. Water/ice Symptom Possible causes Solution Water ow is weaker than normal.

• Water pressure is too low.

• Make sure the water pressure is between 30- 125 psi (206-861 kPa) Ice maker makes a buzzing sound.

• The ice maker function is activated, but the water supply to the refrigerator has not been connected.

• Turn off the Ice Maker. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 63 2022-04-28 10:55:41Troubleshooting English64 Troubleshooting Symptom Possible causes Solution Ice maker does not make ice.

• Ice maker has just been installed.

• You must wait for 12 hours for the refrigerator to make ice.

• Freezer temperature is too high.

• Set the freezer temperature below 0 °F (-18 °C) or -4 °F (-20 °C) in warm ambient air.

• Ice maker is off. • Turn on the ice maker. Ice does not dispense.

• Ice may jam if the ice dispenser is not used for a long time (approx. 3 weeks).

• If you won't be using the refrigerator for a long time, empty the ice bucket and turn off the ice maker.

• Ice bucket is not properly inserted.

• Make sure the ice bucket is properly inserted.

• Water line is not connected properly or water supply is not on.

• Check the water installation conditions. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 64 2022-04-28 10:55:41English 65 Troubleshooting Symptom Possible causes Solution Water does not dispense.

• Water line is not connected properly or water supply is not on.

• Check the water installation conditions.

• A third-party water lter was installed.

• Use only Dacor-provided or approved lters.

• Unapproved lters may leak and damage the refrigerator.

• The water lter replacement icon blinks and then stays turned on.

• Replace the water lter. Then, reset the water lter replacement alarm. (For detailed instructions, see the "Resetting or dismissing the water lter replacement alarm" section on page 41.) Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 65 2022-04-28 10:55:42Troubleshooting English66 Troubleshooting Do you hear abnormal sounds from the refrigerator? Before calling for service, review the checkpoints below. Any service calls related to normal sounds will be charged to the user. These sounds are normal.

• When starting or ending an operation, the refrigerator may make sounds similar to a car engine ignition. As the operation stabilizes, the sounds will decrease. Clicking! or Chirping!Buzzing!

• While the fan is operating, these sounds may occur. When the refrigerator reaches the set temperature, the fan sound will stop. SSSRRR!Whir! Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 66 2022-04-28 10:55:42English 67 Troubleshooting

• During a defrost cycle, water may drip on the defrost heater, causing sizzling sounds. HiSS!

• As the refrigerator cools or freezes, refrigerant gas moves through sealed pipes, causing bubbling sounds. Bubbling!

• As the refrigerator temperature increases or decreases, plastic parts contract and expand, creating knocking noises. These noises occur during the defrosting cycle or when electronic parts are working. Cracking!

• For ice maker models: When the water valve opens to ll the ice maker, you may hear a buzzing sound.

• Due to pressure equalizing when you open and close the refrigerator door, you may hear a whooshing sound. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 67 2022-04-28 10:55:43Troubleshooting English68 Troubleshooting SmartThings Symptom Action Could not nd "SmartThings" in the app market.

• The supporting software version of the SmartThings app is subject to change according to the OS supporting policy the manufacturer provides. In addition, as for the SmartThings app or the functions that the app supports, the new application update policy on the existing OS version can be suspended due to usability or security reasons. The SmartThings app fails to operate.

• The SmartThings app is available for applicable models only.

• The old Dacor Smart Refrigerator app cannot connect with Dacor Smart Home models. The SmartThings app is installed but is not connected to my refrigerator.

• You must log into your Samsung account to use the app.

• Make sure that your router is operating normally.

• If the Wi-Fi icon on the refrigerator’s display is off, this indicates that no network connection has been established yet. In this case, use the SmartThings app to connect and register your refrigerator to the access point (AP) of your house. Could not log into the app.

• You must log into your Samsung account to use the app.

• If you don’t have a Samsung account, follow the app’s onscreen instructions to create one. An error message appears when I try to register my refrigerator.

• Easy Connection may fail due to the distance from your access point (AP) or electrical interference from the surrounding environment. Wait a moment and try again. The SmartThings app is successfully connected to my refrigerator but does not run.

• Exit and restart the SmartThings app, or disconnect and reconnect the router.

• Power off the refrigerator, and then power it on again after 1 minute. The Wi-Fi icon is blinking. ( )

• Connect your refrigerator with the SmartThings app before use. When the connection is made successfully, the indicator stops blinking. - If you fail to make connection or don’t want to use the app, press and hold the button for 10 seconds. The indicator stops blinking with "O FF" shown on the temperature display. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 68 2022-04-28 10:55:43English 69 Troubleshooting Smart Grid (applicable models only) Symptom Action What Do I Need to use the Energy Management and Smart Grid functions? To use the Smart Grid (Demand Response) and Energy Management functions on your refrigerator, you need the following: Devices

• A wireless access point (router)

• A Samsung Energy Management-supported refrigerator

• A smartphone Registration

• Connect your refrigerator to your home Wi-Fi network.

• Register for the EMS service with your electric company. Your electric company must have an EMS (Energy Management System) supporting SEP (Smart Energy prole). App

• Download the SmartThings app from the Google Play Store, Apple App Store, or Samsung Galaxy Apps.

• Install and run the SmartThings app on your smartphone. Why isn’t the Energy Management function working normally?

• Make sure that your home router is operating normally with proper Internet service and connection.

• Make sure that the refrigerator is connected to the AP (router). Checkpoints

• Connect your smartphone to the router (AP, Access Point), and then check if you can browse the Internet on the smartphone. Why isn’t the Delay Defrost Capability working normally?

• Make sure that your home router is operating normally with proper Internet service and connection. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 69 2022-04-28 10:55:43English70 Warranty Customer Service Before you request help or schedule service:

1. Try the Solutions offered in the Problem—Solution table in the “Troubleshooting” section.

2. Become familiar with the warranty terms and conditions of your product.

3. If none of these tips or suggestions resolves your problem, visit dacor.com or call our

Customer Service center at [phone] (United States), [phone] (Canada) United States - Warranty CERTIFICATE OF WARRANTY ON DACOR REFRIGERATOR - UNITED STATES:

FULL TWO-YEAR WARRANTY

This warranty covers any defects in materials or workmanship in the Dacor-branded new appliance purchased from a Dacor Authorized Dealer or other seller authorized by Dacor. This full warranty runs for two years starting from the date of original retail purchase receipt or closing date for new construction, whichever period is longer. Dacor will repair or replace your product. LIMITED WARRANTY After the Full Warranty period has ended, this product is warranted against defects in materials or workmanship reported to us during the applicable warranty periods as follows: Years 3–6 of your ownership – Parts and Labor on Sealed System For the third through sixth years of your ownership, we will pay for factory specied parts and repair labor costs to correct defects in materials or workmanship in the sealed refrigeration system (the compressor, evaporator, condenser, dryer and connecting tubing). Years 7-12 of your ownership – Parts only on the Sealed System For the seventh through twelfth years of your ownership, we will pay for factory-specied parts only to correct defects in the sealed refrigeration system. Years 13-15 of your ownership – Parts only on the Compressor For the thirteenth through fteenth years of your ownership, we will pay for factory-specied parts only to correct defects in the compressor. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 70 2022-04-28 10:55:43English 71 Cosmetic Defects. In addition, for 60 days from the date of purchase, your product is warranted to be free from cosmetic defects in material and workmanship (such as scratches of stainless steel, paint/porcelain blemishes, chip, dents, or other damage to the nish). Color variations are excluded, and display, oor-model, “as-is” or refurbished products are specically excluded. COVERAGE LIMITATIONS Service will be provided by a Dacor designated service company during regular business hours. Please note service providers are independent entities and are not agents of Dacor. The owner must provide proof-of-purchase or a closing statement for new construction upon request. All Dacor products must be accessible for service. Warranty will be null and void on product that has altered, defaced, or missing serial numbers and tags. Warranty is null and void if non-CSA approved product is transported from the U.S.A. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 71 2022-04-28 10:55:43Warranty English72

• Due to differences in painted parts, kitchen lighting, product placement, and other factors; this warranty does not apply to color variation.

• Service calls to educate the customer on proper use and care of the product.

• Service fees for travel to islands and remote areas, which include but are not limited to, ferries, toll roads, or other travel expenses.

• Consequential or incidental damage, including but not limited to: food or medicine loss, time away from work, or restaurant meals.

• Commercial, business, or rental use, or any application other than residential consumer use.

• Failure of the product caused by improper product installation.

• Replacement of house fuses, fuse boxes, or resetting of circuit breakers.

• Damage caused by accident, re, ood, power interruption, power surges, or acts of God.

• Liability or responsibility for damage to surrounding property including cabinetry, oors, ceilings and other structures or objects.

• Breakage, discoloration or damage to glass, metal surfaces, plastic components, trim, paint, or other cosmetic nish caused by improper usage, care, abuse, or neglect.

• Except as noted above, consumable parts such as lters and light bulbs are not covered and are the responsibility of the purchaser. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 72 2022-04-28 10:55:43English 73 THE REMEDIES PROVIDED IN THE ABOVE EXPRESS WARRANTIES ARE THE SOLE AND EXCLUSIVE REMEDIES. THEREFORE, NO OTHER EXPRESS WARRANTIES ARE MADE, AND OUTSIDE THE FIFTY STATES OF THE UNITED STATES AND CANADA, ALL IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR USE OR PURPOSE, ARE LIMITED IN DURATION TO ONE YEAR FROM THE DATE OF ORIGINAL PURCHASE. IN NO EVENT SHALL DACOR BE LIABLE FOR INCIDENTAL EXPENSE OR CONSEQUENTIAL DAMAGES. IN THE EVENT DACOR PREVAILS IN ANY LAWSUIT, DACOR SHALL BE ENTITLED TO REIMBURSEMENT OF ALL COSTS AND EXPENSES, INCLUDING ATTORNEY’S FEES, FROM THE DACOR CUSTOMER. NO WARRANTIES, EXPRESS OR IMPLIED, ARE MADE TO ANY BUYER FOR RESALE. Some states do not allow limitations on how long an implied warranty lasts, or do not allow the exclusion or limitation of inconsequential damages, therefore the above limitations or exclusions may not apply to you. This warranty gives you specic legal rights, and you may also have other rights that vary from state-to-state. Warrantor: Samsung Electronics America, Ridgeeld Park, NJ, 07660 Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 73 2022-04-28 10:55:43Warranty English74 CANADA – Warranty CERTIFICATE OF WARRANTY ON DACOR REFRIGERATOR - CANADA: This Limited Warranty covers only those Products supplied and distributed in Canada by us and delivered new, in the original carton or packaging, to the original consumer purchaser that are purchased from an authorized reseller or distributor, except as otherwise stated herein. Except where prohibited by applicable provincial law, only the original consumer purchaser of the Product has any rights under this Limited Warranty and this Limited Warranty may not be transferred or assigned. Any additional statements such as dealer advertising or presentation, whether oral or written, that make additional warranties or modications to this Limited Warranty do not constitute warranties by us and should not be relied upon.

1. WHAT IS COVERED AND FOR HOW LONG

We warrant to the original purchaser (“Purchaser”) that your Dacor Refrigerator purchased from an authorized reseller or distributor in Canada (the “Products”) is free from defects in material and workmanship encountered in normal use for the warranty period identied below, effective as of the date of purchase or closing date for new construction, whichever period is longer. Dacor Product or Part Warranty Period and Warranty Coverage Refrigerator Two (2) Years: Parts and Labour Refrigerator Sealed System (compressor, evaporator, condenser, dryer and connecting tubing) Six (6) Years: Parts and Labour Refrigerator Sealed System (compressor, evaporator, condenser, dryer and connecting tubing) Twelve (12) Years: Parts Only Refrigerator Compressor Fifteen (15) Years: Parts Only Cosmetic Defects. For sixty (60) days from the date of purchase, the Product is warranted to be free from cosmetic defects in material and workmanship (such as scratches of stainless steel, paint/porcelain blemishes, chip, dents, or other damage to the nish). Color variations are excluded, and display, oor-model, “as-is” or refurbished products are specically excluded. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 74 2022-04-28 10:55:43English 75

2. COVERAGE LIMITATIONS

If the Product fails to operate according to the Product’s specications during the applicable warranty period and the failure is due to improper workmanship or defective material, we will repair or replace, at our sole option, and without charge to the Purchaser, the Product or any defective component part of the Product. We may, at our sole option, use rebuilt, reconditioned, or new parts or components when repairing any Product. If the same model Product or part is not available for replacement, we may, at our sole option, replace the Product or part with any rebuilt, refurbished, reconditioned or new Product or part of similar utility and value to the Product or part being replaced. We expressly reserve the exclusive right, at our sole option, and in lieu of any service, repair or replacement of a Product under this Limited Warranty, to offer the Purchaser a partial refund of the original purchase price paid by the Purchaser for that Product (a “Partial Refund”). The amount of any Partial Refund to be offered shall be determined in our discretion based on the fair market value of the Product given its age and condition. If Purchaser accepts that offer of a Partial Refund, the Purchaser shall be deemed to have released us from any claim or liability whatsoever under this Limited Warranty or under any other applicable express or implied warranty or condition in respect of that Product. All repaired parts or replaced Products will be warranted for a period equal to the remainder of the original Limited Warranty on the original Product or for 90 days, whichever is longer.

3. WHAT IS NOT COVERED

The remedies provided for in this Limited Warranty are available only within Canada. This Limited Warranty does not cover any defect, malfunction, failure or damage caused by or resulting from any of the following: (a) removal, installation, re-installation, maintenance, or service of the Product that was not authorized by us; (b) accident, re, ood, power interruption, power surges, incorrect line voltage or supply or electrical current, fuses, house wiring, circuit breakers, connectors not supplied by us, unusual electrical or electromechanical stress, acts of God, or acts of nature; (c) misuse, abuse, neglect, mishandling, misapplication, alteration or modication of the Product or any part of the Product; (d) use of the Product in conjunction with products, equipment, utilities, services, parts, supplies, accessories, applications, external wiring, connectors, or ancillary or peripheral equipment not supplied or authorized by us; (e) uses for which the Product was not intended. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 75 2022-04-28 10:55:43Warranty English76 Further, this Limited Warranty does not cover: (i) any Product or part from which the serial number has been removed or on which the serial number has been made illegible. Removing the serial number on any Product or rendering it illegible on any Product will immediately void the Limited Warranty for that Product; (ii) any damage whatsoever that occurs during shipment of the Product once the Product has been accepted by the Purchaser; (iii) any damage whatsoever resulting from any failure to follow operating, maintenance or environmental instructions contained in any instruction booklet or owner’s manual available in connection with the Product; (iv) service fees for travel to islands and remote areas, which include but are not limited to, ferries, toll roads, or other travel expenses; (v) replacement of house fuses, fuse boxes, or resetting of circuit breakers; (vi) liability or responsibility for damage to surrounding property including cabinetry, oors, ceilings and other structures or objects; (vii) the cost of service calls for instructions, for the correction of installation errors, for customer adjustments that are explained in the Product owner’s manual, or where the Product operates according to the Product’s specications. There may be a service charge for service calls made for issues not covered under this Limited Warranty; (viii) breakage, discoloration or damage to glass, metal surfaces, plastic components, trim, paint, or other cosmetic nish caused by improper usage, care, abuse, or neglect; (ix) except as noted above, consumable parts such as lters and light bulbs are not covered and are the responsibility of the Purchaser; (x) commercial, business, or rental use, or any application other than residential consumer use; (xi) colour variation due to differences in painted parts, kitchen lighting, product placement, and other factors; We do not warrant or guarantee uninterrupted or error-free operation of the Product. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 76 2022-04-28 10:55:43English 77

4. WHAT ARE THE LIMITATIONS ON IN-HOME WARRANTY SERVICE?

In-home service is subject to availability, and it is not available in all areas of Canada. In-home service will only be provided if the Product is unobstructed and easily accessible from oor level to service personnel. If repair cannot be completed during in-home service or if in-home service is not available in your area, you may be directed to deliver the Product to a Dacor Authorized Service Center for warranty service. The cost of transportation of the Product to and from a Dacor Authorized Service Centre shall be paid by the Purchaser unless we elect to provide that transportation at our discretion. To receive in-home service, the Purchaser must rst contact Dacor Customer Care for problem determination and service procedures. All in-home warranty repairs must be performed by a Dacor Authorized Service Center. Valid proof of purchase must be presented to us at the time that service is requested and before warranty services are rendered. When in-home service is not available, the Purchaser must return the Product to a Dacor Authorized Service Center for analysis. Assistance on where to deliver the Product can be obtained by contacting our Customer Service center. The cost of transporting the Product to or from the Authorized Service Center must be paid by the Purchaser.

RESPECT TO THE PRODUCT

If your Dacor product fails to function within one year of the original date of purchase due to a defect in material or workmanship, Dacor will furnish a new part, F.O.B. factory to replace the defective part. All delivery, installation, labor costs, and other service fees are the responsibility of the purchaser. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 78 2022-04-28 10:55:44English 79 Regulatory Notice FCC Notice FCC CAUTION: Any changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Contains Transmitter Module FCC ID: A3LCCAR210R This device complies with Part 15 of FCC Rules. Operation is Subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received including interference that cause undesired operation. For products available in the US and Canadian markets, only channels 1~11 are available. You cannot select other channels. FCC STATEMENT: This equipment has been tested and found to comply within the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and receiver

• Connect the equipment to an outlet that is on a different circuit than the receiver.

• Consult the dealer or an experienced radio/TV technician for help. FCC RADIATION EXPOSURE STATEMENT: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated so there is at least 8 inches (20 cm) between the radiator and your body. This device and it’s antennas must not be co-located or operated in conjunction with any other antenna or transmitter except in accordance with FCC multi-transmitter product procedures. Dacor_T-TYPE_RF7000AC_DA68-04278M-00_EN.indd 79 2022-04-28 10:55:44Regulatory Notice English80 IC Notice Contains Transmitter Module IC: 649E-CCAR210R The term "IC" before the radio certication number only signies that Industry Canada technical specications were met. Operation is subject to the following two conditions : (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme á la norme NMB-003 du Canada. For products available in the US and Canadian markets, only channels 1~11 are available. You cannot select other channels. IC RADIATION EXPOSURE STATEMENT: This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated so there is at least 8 inches (20 cm) between the radiator and your body. This device and it’s antennas must not be co-located or operated in conjunction with any other antenna or transmitter except in accordance with FCC multi-transmitter product procedures.

SAVE THESE INSTRUCTIONS
