VRT 82821 DV - Vacuum Cleaner BEKO - Free user manual and instructions

USER MANUAL VRT 82821 DV BEKO

24h NEWPlease read this manual first! Dear Customer, Thank you for selecting a Beko product. We hope that you get the best results from your appliance which has been manufactured with high quality and state-of-the-art technology. For this reason, please read this user manual and all other provided documents carefully before using the appliance and keep it as a reference for future use. If you hand over the appliance to someone else, give the user manual as well. Follow the instructions by paying attention to all the information and warnings in the user manual. Meanings of the symbols Following symbols are used in various sections of this manual:

Warnngs for dangerous stuatons concernng the safety of lfe and property. Protecton class for electrc shock.

Techncal data Rated nput power : 180W (VRT82821BV) 100W (VRT82821DV, VRX 221 DR) Input : 100-240V~ 50/60Hz 0.6A (max) Output : 26.0V 0.6A Chargng tme : 3-4 hours Runnng tme max. power VRT82821DV : 22 mn. VRT82821BV : 12 mn. VRX 221 DR : 22 mn. Runnng tme mn. power to up to: 40 mn. Techncal and desgn modfcatons reserved. The values whch are declared n the markngs affxed on your applance or the other prnted documents suppled wth t represent the values whch were obtaned n the laboratores pursuant to the pertnent standards. These values may vary accordng to the usage of the applance and ambent condtons.RECYCLED &RECYCLABLEPAPERParameter of External Power Supply Manufacturer :

MASS POWER ELECTRONIC LIMITED

Model Identifier : S018-1B260060HE Input Voltage : 100-240V~ Input Frequency : 50/60Hz Input Current : 0.6A Output Voltage : 26.0Vd.c. Output Current : 0.6A Output Power : 15.6W Average active efficiency : 87.36% Efficiency at low load(10%) : 77.73% No-load power consumption : 0.08WCordless Stick Vacuum Cleaner / User Manual 9 / 14 EN 9 / EN This section contains safety instructions that will help protect from risk of personal injury or property damage. Failure to follow these instructions invalidates the granted warranty.

• Ths applance comples wth nternatonal safety standards.

• Ths applance can be used by chldren aged from 8 years and above and persons wth reduced physcal, sensory or mental capabltes or lack of experence and knowledge f they have been gven supervson or nstructon concernng use of the applance n a safe way and understand the hazards nvolved. Chldren shall not play wth the applance. Cleanng and user mantenance shall not be made by chldren wthout supervson.

• If the adapter or the applance tself s damaged, do not use t. Contact an authorsed servce.

• Your mans power supply should comply wth the nformaton suppled on the ratng plate of the applance.

• Do not use the applance wth an extenson cable.

• Prevent damage to the power cable by not squeezng, bendng, or rubbng t on sharp edges.

• Do not touch the applance or ts plug when t s plugged f your hands are damp or wet.

• Do not pull the power cable when unpluggng the applance.

• Do not vacuum flammable materals and when vacuumng cgarette ash, make sure that t has cooled down.

• Do not vacuum water or other lquds.

• Protect the applance from ran, humdty and heat sources.

• Never use the applance n or near places where combustble or nflammable ambence or places are present.

• Unplug the applance before cleanng and mantenance.

• Do not mmerse the applance or ts power cable n water for cleanng.

• Do not attempt to dsmantle the applance. 1 Important safety and environmental instructions10 / 14 EN Cordless Stick Vacuum Cleaner / User Manual 10 / EN

• Use the original parts or parts recommended by the manufacturer only.

• Do not clean the particles such as cement, plaster and compressed paper in order to prevent the filter from being clogged and the motor being damaged.

• Use the appliance only with the adapter supplied with.

• Do not use the appliance without filters; otherwise it can get damaged.

• If you keep the packaging materials, store them out of the reach of children.

• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety

• Children should be supervised to ensure that they do not play with the appliance

• The appliance is only to be used with the power supply unit provided with the appliance. 1 Important safety and environmental instructions

• The adapter must be removed from the socket-outlet and the battery pack must be removed from the appliance before cleaning or maintaining the appliance

• If the adapter is damaged, it must be replaced by the manufacturer or its agent or similarly qualified person in order to avoid hazard.

• Keep fingers, hair and loose clothing from moving parts and openings whilst using the vacuum cleaner

• The battery must be removed from the appliance before it is scrapped;

• The appliance must be disconnected from the supply mains when removing the battery;

• Please dispose of used batteries according to local laws and regulations.

• This appliance contains batteries that are only replaceable by skilled persons.

For the purposes of recharging the battery, only use the detachable supply unit S018- 1B260060HE provided with this appliance.

• Please remove and insert the batteries according to UM.Cordless Stick Vacuum Cleaner / User Manual 11 / 14 EN 11 / EN

• Rechargeable batteries are to be removed from the appliance before being charged;

• Different types of batteries or new and used batteries are not to be mixed.

• Batteries are to be inserted with the correct polarity.

• Exhausted batteries are to be removed from the appliance and safely disposed of.

• If the appliance is to be stored unused for a long period, the batteries should be removed.

• The supply terminals are not to be short-circuited.

• Only use with ZB1852 or ZB1852- 01 battery. 1 Important safety and environmental instructions12 / EN Cordless Stick Vacuum Cleaner / User Manual 2 Part assemblng

2.1 Elbow (12) and flexible hose

(15) The elbow and flexible hose are extension tools, one end is inserted into the suction port , the other end is connected with the accessories, which can clean corners or narrow spaces

2.2 Crevice (13), 2in1 Brush (8)

and dust brush (16) Push the round part of the accessory into the suction part until it clicks. The hairbrush of the 2in1 accessory can be removed.

2.3 Mini turbo brush (14)

Push the end of the Mini-brush into the suction part until it clicks. Remove it by pulling the buttons.Cordless Stick Vacuum Cleaner / User Manual 13 / EN

4.1 Cleaning and care

Switch off and unplug the appliance ,before cleaning it.

WARNING: Never use gasoline, solvent, abrasive cleaning agents, metal objects or hard brushes to clean the appliance.

• In order to ensure the performance of the product, we recommend you clean regularly, and replace one after 3-6 months. (Depending on usage) WARNING: Long-term no use, please keep the battery intact, stored in a cool dry place, and let the battery in the semi-state of charge. Not full or empty. Please enclose the battery with non-conductive material to avoid the metal touching the battery directly, causing the battery to be damaged.3.1 Charging IndicatorWorkng ChargngFully chargedLower powerPersstent lght blueBlnkng lght bluePersstent lght blue 2 mnutes and then gong out.Blnkng red lght3.2 Charging dock (9)While charging the battery on the charging dock the charge indicator flashes blue.

• When you receive this product, please use the charger provided by our company to recharge the battery for 3 hours (no need to charge it full). • Do not place the battery on the charging base for a very long time. If it is still charging beyond the normal charging time, stop it immediately. Otherwise, the battery may cause heating, deformation or burning hazard. • When the battery is not in use for a long time, we recommend you fully charge the battery (usually 4.5 hours). The charging period should be every 3 months for the products not in use. 3 Use 4 Informaton14 / EN Cordless Stick Vacuum Cleaner / User Manual

4.3 Compliance with the WEEE

Directive and disposal of the waste product This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waste electrical and electronic equipment (WEEE). This symbol indicates that this product shall not be disposed with other household wastes at the end of its service life. Used device must be returned to offical collection point for recycling of electrical and electronic devices. To find these collection systems please contact to your local authorities or retailer where the product was puchased. Each household performs important role in recovering and recycling of old appliance. Appropriate disposal of used appliance helps prevent potential negative consequences for the environment and human health.

4.4 Compliance with RoHS

Directive The product you have purchased complies with EU RoHS Directive (2011/65/EU). It does not contain harmful and prohibited materials specified in the Directive.

4.5 Package information

Packaging materials of the product are manufactured from recyclable materials in accordance with our National Environment Regulations. Do not dispose of the packaging materials together with the domestic or other wastes. Take them to the packaging material collection points designated by the local authorities.

4.6 Information on waste

batteries This symbol on rechargeable batteries/ batteries or on the packaging indicates that the rechargeable battery/battery may not be disposed of with regular house hold rubbish. For certain recharge able batteries/batteries, this symbol may be supplemented by a chemical symbol. Symbols for mercury (Hg) or lead (Pb) are provided if the rechargeable batter ies/batteries contain more than 0,0005 % mercury or more than 0,004 % lead. Rechargeable batteries/batteries, including those which do not contain heavy metal, may not be dis- posed of with household waste. Always dispose of used batteries in accordance with local environ- mental regulations. Make enquiries about the ap- plicable disposal regulations where you live.

• If you do not intend to use the appliance for a long time, store it carefully.

• Pull the appliance’s plug out.

• Keep the appliance out of the reach of children.

• During handling and transportation, carry the appliance in its original packaging. The packaging of the appliance protects it against physical damages.

• Do not place heavy loads on the appliance or on the packaging. The appliance may get damaged.
