USER MANUAL FK321.6GBDF AMICA

INSTALLATION AND OPERATING CONDITIONS OF THE APPLIANCE

DE46 Yourapplianceisexceptionallyeasytouseandextremelyefcient.Beforebeingpackaged andleavingthemanufacturer,theappliancewasthoroughlycheckedwithregardtosafetyand functionality. Beforeusingtheappliance,pleasecarefullyreadtheseOperatingInstructions DEARCUSTOMER! THANK YOU FOR PURCHASING AN AMICA APPLIANCE The appliance is intended for household use only. The manufacturer reserves the right to introduce changes which do not affect the operation of the appliance.

Figures in this user manual are for illustra- tive purposes only. Full appliance ttings are listed in a relevant section. EN47

GUIDELINES CONCERNING THE SAFETY OF USE

Some provisions in this user manual are unied for re- frigerating products of different types (for a refrigerator, refrigerator-freezer or freezer) The Manufacturer shall not be held liable for damage arising from the failure to observe the instructions con- tained in this manual. Keep this manual for future re- ference, or to pass it over to the next user. This appliance is not intended for use by persons (inc- luding children) with limited physical or mental capabili- ties and persons who lack experience or familiarity with the appliance. Do not allow una tte nde d children to use the applian- ce. Do not allow them to play with the appliance. They must not climb inside the drawers and swing on the do- ors. The appliance operates properly at the ambient tem- perature (see product che). Do not use it in the cellar, unheated summer cottage during autumn and winter. When placing, moving, lifting the appliance, do not hold the door han- dles, do not pull the condenser at the rear part of the refrigerator and do not touch the compressor unit. When transporting, moving or positioning the fridge- -freezer do not tilt it by more than 40° from the vertical position. Should such a situation occur, the appliance should be switched on after minimum 2 hours from its re-placement in the right position (g.2). Pull the plug out from the mains socket before each ma- intenance activity. Do not pull on the cord, but hold the body of the plug instead. The “cracking” sound, which the appliance may emit is caused by the expansion and contraction of parts as a result of temperature variations. For safety reasons do not repair the appliance yourself. Repairs car- ried out by persons who do not have the required qualications may result in serious danger for the user of the appliance. EN48

GUIDELINES CONCERNING THE SAFETY OF USE

Air the room in which the appliance is placed for a few minutes (the size of the room for a product containing isobuthane/R600a must be at least 4m

) to avoid da- mage to the cooling system. Do not refreeze partly thawed products. Do not store beverages in bottles and cans, especially carbonated be- verages, in the freezer chamber. The cans and the bottles may explode. Do not put frozen products, taken out directly from the freezer (lollies, ice cubes, etc.) into your mouth, their low temperature may cause severe frost-bite. Make sure you do not damage the cooling system, by puncturing the refrigerant pipes in the evaporator or breaking the pipes. The refrige- rant is ammable. If the refrigerant makes contact with the eyes, rinse them with clean water and call for medical assistance imme- diately. If the power wire gets broken, it should be replaced with a new one in a specialist repair shop. This appliance is intended for food storage, do not use it for other purposes. When performing activities, such as cleaning, mainte- nance or moving, the appliance must be completely di- sconnected from power supply (by pulling the plug out from the socket) This appliance can be used by children aged 8 years and older or by persons with physical, mental or sen- sory handicaps, or by those who are inexperienced or unfamiliar with the appliance, provided they are super- vised or have been instructed how to safely use the ap- pliance and are familiar with risks associated with the use of the appliance. Ensure that children do not play with the appliance. Cleaning and maintenance of the appliance should not be performed by children unless they are 8 years or older and are supervised by a com- petent person. EN49

GUIDELINES CONCERNING THE SAFETY OF USE

Anti-bacteria System (varies depending on the model. Its presence is indicated by the label inside the applian- ce chamber) - The Antibacteria System protects foods and products inside the- refrigerator from bacteria and mould which may cause unpleasant smells and shorten storage time. The Antibacteria System prolongs the fre- shness of food. The special material used to construct the fridge liner prevents bacterial, microorganism and mould growth. In order to obtain more space in the freezer, you can remove the drawers and place the food directly on the shelves. This has no effect on the product mechanical properties and cooling performance. Declared freezer capacity was calculated with the drawers removed. EN50 INSTALLATION AND OPERATING CONDITIONS OF THE APPLIANCE

• Only free- standing appliances ** According to the model Installationbeforeusingtheap- plianceforthersttime ● Take the product out of the package, re- move the scotch tape protecting the door and the equipment. Any remaining adhesive stains may be removed with a mild washing agent. ● Do not throw away the polystyrene ele- ments of the packaging. If it is necessary to transport the fridge-freezer, pack it in the polystyrene elements and lm as well as protect ing it with scotch tape ● Clean the interior surface of the fridge- freezer and the elements of the equip- ment with a washing agent dissolved in lukewarm water, then wipe it dry. ● Place the fridge-freezer on an even, at and stable surface, in dry, aired and shaded room, far from the heat sources such as: oven, hob, central heating ra- diators, central heating pipes, hot water installation, etc. ● On the exterior surface of the product may be a protective foil, this foils should be removed. ● Make sure the appliance is placed in a horizontal position by screwing in the 2 adju- stable front legs (g. 3) ● To ensure that the door opens freely, the distance between the side of the applian- ce (on door hinges side) and the wall is shown on gure 5.* ● Ensure adequate ventilation of the room and free air circulation from all sides of the appliance (g. 6).* Minimum distancesfrom the heat sources - from the electric gas and other ovens - 30 mm, - from oil or coal red ovens - 300 mm, - from built-in ovens - 50 mm If there is no possibility of ensuring the above- mentioned distances, provide an appropriate insulation board. ● The rear wall of the refrigerator, in parti- cular, the condenser and other elements of the cooling system must not contact other elements, which may damage them, (e.g. central heating pipes and the water supply pipes). ● It is forbidden to readjust or modify any parts of the unit. It is crucial not to damage the capillary tube visible in the compressor recess. The tube may not be bent, straightened or wound. ● If the capillary tube is damaged by the user the guarantee will be void (g. 8). ● In some models the handle is put into the appliance, You should screw it with Your own screwdriver, Mainsconnection ● Prior to connection, it is recommended to set the temperature control knob to an „OFF” or other position that disconnects the appliance from the power supply (See page with the control description). ● This appliance should be connected to AC 220-240V 50Hz supply socket. The socket must be tted properly, and must be supplied with an earthing conduit and a 10A fuse. ● It is a legal requirement that the applian- ce is properly earthed. The manufacturer will not be held liable for any damage or injury which may result from the failure to full this requirement. ● Do not use adapters, multiple sockets and two-wire extension leads. If it is necessary to use the extension lead, it must be equipped with a protection ring and a single socket and must have a VDE/GS safety certicate. ● If an extension lead is used (with a protection ring and safety certicate), its socket must be located at a safe distan- ce, away from the sinks, and must not be in a place where it could be ooded by water or waste water. ● See the type plate at the lower part of the internal wall of the appliance for detailed specications**. Disconnectingthemains ● Make sure the appliance can be easily disconnected from the mains, either by pulling the plug out of the mains socket, or by switching the two-pole switch off (g. 9). EN51

1. Clean the parts of the refrigerator with lukewarm

water containing a little neutral detergent and with clear water, and wipe them dry. Notes: Electric parts of the refrigerator can only be wiped by dry cloth.

2. Turn on electricity. The compressor begin to

rature in the refrigerator decreased obviously, it shows that the refrigerator system works well. When the refrigerator operates for a period of time, the temperature controller will automatically set the temperature within limits it opens. The display is located in the middle of the refrige- rator door. Please refer to the below gure for the layout. introduction of the buttons 1 Fridge: to set the refrigerator temperature 2 Freezer: to set the freezer temperature 3 Function: to choose functions of fast cooling, fast freezing, SmartECO and vacation 4 OK: to enter or to quit the existing function Function setting Appliance connected to power at the rst time When the appliance is connected to power at the rst time, the display will be lit for 2 seconds before going normal and the appliance runs with SmartECO function. Display control When the refrigerator door is closed and there is no button operation in 3 minutes, the display light goes off. When the display light is off, open the refrigerator door or click any button to light it up. Temperature setting

1) Click the “refrigerator” or “freezer” button and

when it ickers in the symbol, temperatures can be set; each time when the button is clicked, the temperature changes accordingly (the display shows the temperature accordingly). (Temperatu- res cannot be set under functions of fast cooling, fast freezing, SmartECO and vacation,)

2) Under temperature setting, if there is no button

operation in 5 seconds, the button stops ickering and the set temperature comes into effect. 3)Temperature cycle Refrigerator: 2

SmartECO Under SmartECO, it is 4

C in the refrigerator and

C in the freezer. Temperatures cannot be changed and you can click the temperature zone button to check the temperature.

1) To enter SmartECO

Click “option” until it ickers and then click “OK” to enter this function.

Under SmartECO, click “option” until it goes to SmartECO, click “OK” to quit this function and the light goes off. Temperatures of each chamber go back to the value before SmartECO function. Controlpanel(Fig.10). Fast cooling Under fast cooling, it is 2

C in the refrigerator and the refrigerator temperature cannot be changed. 1)To enter fast cooling Click “option” until it ickers in “fast cooling” and then click “OK” to enter this function.

2) To quit fast cooling

Under fast cooling, click “option” until it goes to “fast cooling” and then click “OK” to quit this function. The light in fast cooling goes off and the refrigera- tor temperature goes back to the value before fast cooling. Fast freezing Under fast freezing, refrigerator temperature can be set but not for the freezer temperature.

1) To enter fast freezing

Click “option” until it ickers in “fast freezing” and then click “OK” to enter this function.

2) To quit fast cooling

Under fast freezing, click “option” until it goes to “fast freezing” and then click “OK” to quit this function. The light in fast freezing goes off and the freezer temperature goes back to the value before fast freezing. When fast freezing time is up (26 hours), it quits automatically. When it goes to SmartECO, fast freezing stops. Vacation Under vacation, it is 14

C in the refrigerator and the temperatures in this chamber cannot be changed.

1) To enter vacation

Click “option” until it ickers in “fast freezing” and then click “OK” to enter this function.

2) To quite vacation

Under vacation, click “option” until it goes to “vaca- tion” and then click “OK” to quit this function. The light in vacation goes off and the refrigera- tor temperature goes back to the value before vacation. Vacation quits under functions of SmartECO and fast cooling. Power off memory With this design, the refrigerator can automatically keep all the setting in case of power off. When the unit is plugged in again, the refrigerator will run with the setting before power off. Power-On Delay To prevent harm to the refrigerator in case of sudden power cut and power on, the unit does not start immediately if the power off time is less than 5 minutes. Freezer over-temperature alarm (only in case of power on) When the freezer temperature is higher than 10

at the rst time connected to power, the symbol light of the freezer chamber goes on and the num- ber representing temperature ickers. Press any button or wait for 5 seconds, ickering stops and it goes back to the temperature that was set. Refrigerator door opening alarm When the refrigerator is open over 3 minutes, the buzzer will buzz. Close the door or press any but- ton to stop the alarm, but for the latter, the alarm will go off again after 3 minutes. Sensor fault alarm When it shows “E0”, “E1”, “E2” or other abnormal symbols, it means sensor faults and the refrigera- tor needs repair. EN52

OPERATION AND FUNCTIONS

Storageoffoodinthefridge-freezer Observethefollowingrecommen-dationsto ensurethefoodremainsfresh. ● The products should be placed on plates, in containers or packed in food wrap. Di- stribute them evenly l over the shelves. ● If the food contacts the rear wall, it may cause frosting or wetting of the products. ● Do not put dishes with hot food t into the fridge ● Products which absorb avours easily such as butter, milk, white cheese and products with in- tense avour, such as sh, smoked meat, hard cheese must be placed on shelves, packed in food wrap or in tightly sealed containers. ● The storage of vegetables containing signicant quantities of water will cause the deposition of condensation on the vegetable containers, it does not impact on the proper functioning of the fridge. ● Before putting the vegetables into the fridge, dry them well. ● Excessive moisture shortens the shelf life of ve- getables, especially the leafed vegeta- bles. ● Do not wash the vegetables before storing in the refrigerator. Washing removes the natural pro- tection, therefore it is better to wash the vegeta- bles directly before con- sumption. ● It is recommended to place the products in fre- ezer drawers 1, 2, 3* up to natural loading capa- city (Fig. 11a / 11b).**

● Stacking of products on the freezer shelves is acceptable.* ● It is acceptable to place products beyond the natural loading capacity by 20-30 mm.** ● In order to increase the loading capacity of the freezer chamber and allow the stacking of pro- ducts on the freezer evaporator wire shelves up to maximum height it is possi- ble to remove dra- wers 1 and 2.* Freezingfood** ● Practically all the food products, except for ve- getables consumed raw, such as lettuce can be frozen. ● Only food products of the highest quality, divided into small portions for single use, should be fro- zen. ● Products should be packed in materials that are odourless, resistant to air and moisture pene- tration, and not susceptible to fat. Plastic bags, polyethylene and aluminium sheets are the best wrapping materials. ● The packaging should be tight and should stick to the frozen products. Do not use glass containers. ● Keep fresh and warm foodstuff at am- bient temperature away from the products, which have already been frozen. ● We advise you not to place more of fresh food at a time to the freezer per day (see table witch technical specication). ● In order to maintain optimum quality of the frozen food, reorganise the food that is in the middle of the freezer, so that it does not touch the products that are not yet frozen. ● It is recommended that you move the already frozen products to one side and place the fresh products that are to be frozen on the opposite side, as close to the rear and side walls as po- ssible. ● To freezing products, use space marked (*/***). ● Bearinmindthatthetemperatureinthefre- ezerisaffectedbyseveralfactors,including theambienttemperatureandthequantityof foodproductsinthechamber,thefrequency ofopeningthedoor,theamountoffrostinthe freezer,andthethermostatsetting. ● Ifyoucannotopenthefreezerdoorimmedia- telyafterclosingit,allow1-2minutesforthe negativepressuretocom-pensate, andtry againtoopenthedoor. The storage time for frozen products depends on their quality before freezing when fresh, and on the storage temperature. The following storage periods are recommended when the temperature of -18°C or lower is maintained:: Products Months Beef 6-8 Veal 3-6 Giblets 1-2 Pork 3-6 Poultry 6-8 Eggs 3-6 Fish 3-6 Vegetables 10-12 Fruit 10-12 Do not store frozen food in rapid cooling cham- ber. Ice cubes can be prepared and stored in this chamber.***

• Applicable to appliances with a freezer com- partment at the bottom of the appliance. ** Applicable to appliances with a freezer com- partment (*/***) *** Not applicable to appliances with a freezer compartment marked (*/***) EN53

USING THE REFRIGERATOR EFFICIENTLY

Practicaleverydaytips ● Do not place fridges or freezers next to radiators, heaters, stoves or in direct sunlight. ● Make sure that air vents are not covered up and clean the dust off them once or twice a year. ● Select the right temperature: 6 to 8°C in your refrigerator and -18°C in your freezer is sufcient. ● When on holiday, turn up the temperature in your fridge. ● Only open your fridge or freezer when necessary. It helps if you know what food each contains and where it is located. Return food to the fridge or freezer as soon as possible after you have used it so that it does not warm up too much. ● Wipe the inside of your fridge regularly with a cloth soaked in a mild detergent. Appliances which are not self-defrosting will require regular defrosting. Do not allow frost layers thicker than 10 mm to form. ● Keep the seal around the door clean, otherwise it will not shut properly. Always replace broken seals. Understandingthestars

• Temperature is at least -6°C; sufcient to store frozen food for about a week. Drawers or com- partments marked with one star used to be a feature of (mostly) cheaper fridges. ** Food can be stored at -12°C or below for 1-2 weeks without losing its taste. Not suitable for freezing food. *** This rating is mainly used to store foods at -18°C or below. Can also be used to freeze up to 1 kilogram of fresh food. **** This appliance is suitable for storing foods at -18°C or below and freezing larger quantities of fresh foods. Storagezonesintherefrigerator ● Due to the natural circulation of the air in the appliance, there are different temperature zones in the refrigerator chamber. ● The coldest area is directly above the vegetables drawers. Use this area for all delicate and highly perishable food e.g. - Fish, meat, poultry - Sausage products, ready meals - Dishes or baked goods containing eggs or cream - Fresh dough, cake mixtures - Pre-packed vegetable and other fresh food with a label stating it should be kept at a temperature of approx 4oC. ● The warmest area is in the top section of the door. Use this for storing butter and cheese. Foodthatshouldnotbestoredinarefrigerator ● Not all food is suitable for storing in the refrige- rator, particularly: - Fruit and vegetables which are sensitive to cold, such as bananas, avocado, papaya, pas- sion fruit, aubergines, peppers, tomatoes and cucumbers. - Fruit which is not yet ripe - Potatoes Exampleofstoringthefood-seegure12. EN54 DEFROSTING,WASHINGANDMAINTENANCE Never clean the product’s casing or plastic parts using solvents or strong, abrasive detergents (e.g. washing powders or creams)! Use mild liquid de- tergents and soft cloths only. Do not use sponges. Defrostingthefridge*** ● Frost settles on the rear wall of the fridge chamber. It is removed automatically. During the defrosting, the condensate, which contains contaminants may clog the opening in the through. Should it occur, carefully unclog the opening with the cleaning plug (fig. 13). ● The appliance operates in cycles: it refrigerates (then the frost settles on the rear wall), and defrosts (water flows down the rear wall) Disconnecttheappliancefromthemains beforecleaningby removing the plug fromthemainssocketorswitchingoff thefuse.Preventwaterfrompenetrating thecontrolpanelorthelight. ● Do not use defrosting aerosols. They may cause the formation of an explosive mixture, or contain solvents which may damage the plastic compo- nents of the appliance and even be harmful to health. ● Make sure the water used for cleaning does not flow into the evaporation container through the discharge opening. ● The whole appliance, except for the door gasket must be cleaned with a mild cleaning detergent. The door gasket should be cleaned with water and wiped dry. ● Wash all the accessories (vegetable containers, door shelves, glass shelves, etc.). Defrostingthefreezer** ● It is recommended to combine defrosting the appliance with washing it. ● Excessive accumulation of ice on the freezing areas impairs the appliance’s freezing capacity and increases the energy consumption. ● Defrost the appliance at least once or twice a year. In case of a higher ice build-up, defrosting must be carried out more frequently. ● If there is food in the freezer, set the knob to the max. position about 4 hours before the planned defrosting. This will ensure the possibility of storing the food at the ambient temperature for a longer time. ● After taking the food out of the freezer, put it in a container, wrap it with several layers of paper, a blanket and store it at a cool place. ● The defrosting operation should last as short as possible. Long storage of food at the ambient temperature shortens their shelf life. Inordertodefrostthefreezerchamber,you musttakethefollowingsteps:** ● Switch of the appliance using the control panel and pull the plug out from the socket.. ● Open the door and remove the food from the freezer. ** Applicable to appliances with a freezer com- partment (*/***) Not applicable to appliances with a Frost-free System. *** Applicable to appliances with a refrigerator compartment Not applicable to appliances with a Frost-free System. **** Applicable to appliances with a Frost-free System. ● Depending on the model, pull out the drainage tube located in the bottom of the freezer com- partment and place a suitable vessel underne- ath. ● Leave the door open, this will speed up the de- frost process. Additionally, a pot with hot water (not boiling) may be placed inside the freezer compartment. ● Wash the interior of the freezer and wipe it dry. ● Switch on the appliance as per the relevant point in the manual. Automaticfridgedefrosting**** The fridge chamber has been equipped with an automatic defrosting function. However, frost may settle on the rear wall of the fridge chamber. This happens usually, when large quantities of fresh food products are stored in the fridge. Automaticfridgedefrosting**** The freezer chamber has been equipped with an automatic defrosting function (no-frost). The food is frozen in the cooled circulation air, and the moisture from the freezer chamber is discharged outside. As a result, no ice and frost is produced in the freezer and the products do not freeze on each other. Washingthefridgeandfreezerchambers manually**** It is recommended to wash the fridge and freezer chambers at least once a year. This prevents the formation of bacteria and bad odours. Switch off the appliance, using button (1), remove the food from the chambers and wash them using water with a mild detergent. Then, wipe the chambers dry with a cloth. Takingoutandputtingintheshelves Slide the shelf out, then slide it in as much as po- ssible so that its clamp could t the guide groove (g. 15). Takingoutandputtinginthedoorshelf Lift the door shelf, remove it and put it back from the top into its required position (g. 16). Youmustnotputanelectricheater, aheatingfanorahairdryerintothe freezerbyanymeans. EN55 TROUBLE-SHOOTING Problems Possiblecauses Remedies The appliance does not work The electric circuit is disrupted - check whether the plug is properly inserted into the socket - check whether the power cable of the appliance is not damaged - check whether there is voltage in the socket, by plugging another appliance, e.g. a night lamp - check whether the appliance is switched on by setting the thermostat to a position above 0. The lighting inside the chamber does not work The bulb is loose or fused (only appliances with bulb lightning type) - t the bulb correctly or replace it (see section above “Replacing the interior light bulb) Temperature inside the appliance is not low enough or too high Incorrect setting of the adjustment knob - reset the knob to a higher position The ambient temperature is higher or lower than the climate range from table with technical specication - the appliance is adapted to operation in the clima- te range from table with technical specication. The appliance is located in a sunlit place or near heat sources - move the appliance to another place. Observe the guidelines contained in the manual Too much warm food loaded at a time - wait 72 hours until the food becomes cool (fre- ezes) and the required temperature is reached inside the chamber Internal air circulation obstructed - place the food and containers in such a way that they do not touch the rear wall of the fridge The air circulation at the back of the ap- pliance is obstructed - move the appliance min. 30 mm away from the wall The door of the frid- ge/freezer is opened too often and/or remains open for too long - reduce the frequency of opening the door and/or shorten the time when door remains open The door does not close completely - place the food and containers so that they would not interfere with door closed The compressor is switched on too rarely - check whether the ambient temperature is not lower than climate class Door gasket inserted incorrectly - press the gasket in The appliance works continuously Incorrect setting of the adjustment knob - reset the knob to a lower position See. ”Temperature inside the appliance is not low enough for description of other possible causes See. ”Temperature inside the appliance is not low enough for description of other possible remedies Water collects in the lower part of the appliance The water discharge opening is clogged (depending on the model) - clean the discharge opening (see the operating manual – chapter entitled ”Defrosting the fridge”) Internal air circulation obstructed - place the food and containers in such a way as that they do not touch the rear wall of the fridge The appliance generates unusual noise Incorrect levelling of the appliance - level the appliance properly The appliance is touching furniture and/or other objects - place the appliance at a location that ensures proper clearances around it Certain sounds can be heard during normal use of the refrigerator, which do not affect its correct operation. Sounds,whichcanbeeasilyprevented: ● noise caused by the appliance which is not level - adjust the position with the adjustable turn-in front feet. Alterna- tively, place pads made of soft material under the rear rollers, especially when the appliance is placed on tiles. ● touching the adjacent piece of furniture - move the refrigerator away. ● creaking of the drawers or shelves - take out and put back the drawer or shelf. ● sounds of clinking bottles - move bottles apart. Sounds heard during normal use are mainly due to operation of the thermostat, compressor (switching on) and cooling system (thermal expansion and contraction of the radiator caused by ow of the cooling agent). EN56 ENVIRONMENTAL PROTECTION Ozonelayerprotection The refrigerants and foaming agents, which are 100% free of FCKW and FKW have been used for manufacturing our product. Therefore we are helping to protect the ozone layer and prevent the increase of greenhouse effects. Also, the innovative technology and environmental- ly friendly insulation help in reducing energy consumption. Recyclingofthepackaging Our packaging are made of environmentally friendly mate- rials, which can be reused: ● The external packaging is made of cardbo- ard/foil ● The FCKW free shape of foamed polystyre- ne (PS) ● Polyethylene (PE) foils and bags ELIMINATION/DISPOSALOFTHEEQU- IPMENT If the appliance is no longer in use, cut the connecting cable off the used equipment before its scrapping. Also, remove the appliance lock or render it useless so that the appliance presents no danger to children while being stored for di- sposal. This appliance is marked with a symbol of the crossed out waste container in conformance with the European Directi- ve 2002/96/EC. Such marking informs that the equipment may not be kept together with other waste coming from the house- hold after the period of its use. The user is obliged to dispose of the appliance at the waste collection point. The local waste collection points, shops and communal units form an appropriate system enabling the disposal of the equipment. Handling the used electrical and electro- nic equipment properly contributes to the avoidance of consequences harmful to the human health and natural environment, resulting from the presence of hazardous substances and improper storage and processing of such equipment. CLIMATE RANGE Climaterange Permissibleambient temperature SN from +10°C to +32°C N from +16°C to +32°C ST from +16°C to +38°C T from +16°C to +43°C The information about the climate range of the appliance is provided on the rated plate. It indicates at which ambient temperature (that is, room temperature, in which the appliance is working) the operation of the appliance is optimal (proper). Manufacturer’sDeclaration The manufacturer hereby declares that this product meets the requirements of the following European directives: ● Low Voltage Directive 2006/95/EC, ● Electromagnetic Compatibility (EMC) Directive 2004/108/EC, ● ErP Directive 2009/125/EC and has thus been marked with the symbol and been issued with a declaration of compliance made available to market regulators. EN57

WARRANTY AND AFTER-SALE SERVICES

Warranty Warranty service as stated on the warranty card The manufacturer shall not be held liable for any damage caused by improper use of the product. CHANGING THE DIRECTION OF THE DOOR OPENING Disassemble the refrigerator/freezer door

1. Use a tool to remove the screw off the hinge cover, and then remove the latter. Insert the communi-

cation line to the hole on the cabinet top (20.1)

2. Use a tool to remove the 4 screws off the upper hinge cover and then remove the latter. Pry up the

door bush and small end cap cover on the door (20.2)

3. Insert the door bush and door communication line into the hole on the door and then put on the

small end cap cover (20.3)

4. Use a tool to remove the 2 screws as shows in the below gure to remove the hole cover on the

cabinet top and get the cabinet communication line out of the hole.Pry up the small end cap cover on the door and get out the door bush and door communication line (20.4)

5. Insert the door bush into the round hole on the door and then put on the small end cap cover (20.5)

9. Remove the adjustable front feet under the lower hinge; use a tool to remove the 4 screws from the

lower hinge and then disassemble the lower hinge (20.9)

10. Door disassembly is nished (20.10)

Assemble the door, lower hinge accessories to the corresponding positions of the other side.

11. Use a tool to get the door bush out as shown in the below gure and assemble it to the correspond-

ing position of the other side (20.11)

12. Use a tool to remove the screws off the stopper ass as shown in the below gure and then assem-

ble them to the other side of the door (20.12)

13. Use a tool to remove the axle and two stoppers on the lower hinge and then assemble them to the

position as shown in the below gure (20.13) Assemble the refrigerator door and freezer door to the opposite side.

14. Remove the adjustable front foot as shown below by hand and then assemble the lower hinge to the

other side of the cabinet and x the screws by using a tool (20.14)

15. Assemble the shorter adjustable front foot to the lower hinge side and adjust the height of the foot to

make the refrigerator stay in level (20.15)

16. Put on the freezer door and turn the middle hinge by 180

and then assemble it to the other side of the cabinet; use a tool to screw up the 3 screws to x the middle hinge (20.16)

17. Put on the refrigerator door and assemble the upper hinge to the other side of the cabinet; use a

tool to screw up the 4 screws to x the upper hinge. After that, connect the door communication line and the cabinet communication line and then put on the upper hinge cover and x it using a screw.

18. Assemble the hole cover to the other side of the cabinet and use a tool to screw up the hole cover

19. Door disassembly is nished here. Figure of door opening from the right (20.18)

20. Figure of door opening from the left (20.19)

1 Light 2 Cooling room shelves 3 Vegetable and fruit crisper cover 4 Vegetable and fruit crisper 5 Freezing drawers 6 Removable foot 7 Cooling room door 8 Door balcony 9 Freezing room door 10 Lighting switch FK321.6GBDF Glass shelf 3 Shelf over the vegetable container 1 Vegetable container 1 Large door shelf 1 Medium door shelf 3 Egg tray 1 Pusher 1 Type of lighting LED Drawer in freezer compartment 3 EN ES
