Surround HS60 - Headphones CORSAIR - Free user manual and instructions

Product Type	Gaming headset with virtual 7.1 surround sound
Brand	Corsair
Model	Surround HS60
Connectivity	3.5mm jack (stereo mode), USB (surround 7.1 mode)
Compatibility	PC, Mac, PlayStation 4, Xbox One, Nintendo Switch, mobile devices
Surround sound	Virtual 7.1 via included USB adapter
Microphone	Unidirectional, flexible, adjustable
Earcup type	Plush with memory foam
Headband	Adjustable
Customization software	Corsair Utility Engine (CUE) - equalizer, microphone volume, surround activation
Weight	Approximately 350 g
Dimensions	Approximately 200 x 180 x 90 mm
Power	Via USB for surround mode, otherwise passive via jack
Cable length	2 m (detachable jack cable) + integrated USB cable
Frequency response	20 Hz - 20 kHz
Impedance	32 ohms
Sensitivity	111 dB (+/-3 dB)
Care and cleaning	Clean with a soft, dry cloth. Do not use chemicals.
Safety	Avoid prolonged listening at high volume to protect hearing.
Spare parts / Repairability	Not provided by the manufacturer. Consult authorized resellers.
General information	Manual available online. Compliant with European directive 2012/19/EU (WEEE).

Frequently Asked Questions - Surround HS60 CORSAIR

How to enable 7.1 surround sound on the Corsair HS60?

Plug the provided USB adapter into a high-power port (USB 2.0 or higher). Then, use the Corsair Utility Engine (CUE) software to enable Virtual 7.1 Surround mode.

Does the headset work on Xbox One without an adapter?

Yes, in stereo mode via the controller's 3.5mm jack. For surround sound, a separately sold Microsoft adapter is required.

How to adjust the HS60 microphone?

Bend the flexible microphone boom so it points directly at your mouth, ideally about 3 cm from the left corner of your lips. Use the CUE software to adjust the microphone input volume.

Where to download the Corsair Utility Engine (CUE) software?

Download CUE from the official Corsair website: corsair.com/support/downloads. The software is compatible with Windows 7, 8, and 10.

What to do if surround mode does not activate?

Make sure the USB adapter is connected to a high-power port (USB 2.0 or higher). Also check that the CUE software is installed and that 7.1 Surround mode is enabled in the settings.

Is the headset compatible with Nintendo Switch?

Yes, in stereo mode via the console's 3.5mm jack. 7.1 surround sound is not supported on Switch.

How to clean the HS60 earcups?

Use a soft, dry cloth to clean the plush earcups. Avoid chemicals or water. For deep cleaning, consult the manufacturer's manual.

Can I use the headset without CUE software?

Yes, the headset works in basic stereo mode without software. However, CUE is required to enable 7.1 surround sound, customize the equalizer, and adjust the microphone.

How to recycle the Corsair HS60 headset?

In accordance with European directive 2012/19/EU, do not dispose of the headset with household waste. Drop it off at a public collection point for electrical and electronic equipment.

Is the headset compatible with mobile devices?

Yes, via the 3.5mm jack. The microphone and earphones will work, but 7.1 surround sound is only available on PC with the USB adapter.

USER MANUAL Surround HS60 CORSAIR

2017 CORSAIR COMPONENTS, Inc. All rights reserved. CORSAIR and the sails logo are registered trademarks

In the United States and/or other countries. All other trademarks are the property of their respective owners. Product may vary slightly from those pictured 49.00168 AB

QUICK START GUIDE
GUIDE DE DEMARRAGE RAPIDE
SCHNELLSTARTANLEITUNG
GUIA DE INICIO RAPIDO
GUIA RAPIDA DEL USUARIO
KPATKOE PYKOBODCTBO

HS60

SURROUND

STEREO GAMING HEADSET WITH 7.1 SURROUND SOUND

ENGLISH 1

FRANCAIS. 9

DEUTsCH 17

PORTUGUES 25

ESPANOL 33

PYCCKN 41

GETTING STARTED

CORSAIR UTILITY ENGINE

3

ENLL

HS60 SURROUND is a multi-platform headset that operates in two audio modes: Stereo and 7.1 surround sound. In stereo mode, you can connect the 3.5mm jack into any PC, Mac, PlayStation 4, XBOX One*, Nintendo Switch or mobile device. The included 7.1 surround sound USB adapter enables virtual 7.1 surround sound on PC.

Remember that powering the 7.1 surround sound USB adapter requires a high power (USB 2.0 or better) port. Some USB ports on older keyboards and monitors do not support high-power devices.

Place the headset on your head and adjust the headband for a comfortable fit. The plush memory foam ear pads enable the CORSAIR HS60 SURROUND headset to fit comfortably so you can play for hours without fatigue.

*May require Microsoft adapter sold separately

Go to corsair.com/support/downloads to download the CORSAIR Utility Engine ('CUE') Software.

Using CUE software will enable the full feature set of the HS60 SURROUND headset.

Install the software on a PC running Windows 7, 8, or 10
After installation is complete, reboot your PC, and launch CUE

You can use it to:

• Select and customize audio equalizer (EQ) settings.
• Adjust microphone input volume.
• Set 7.1 surround sound on or off.

The software's built-in documentation explains how to use the HS60 SURROUND headset's features in greater detail.

4

ENGLISH

5

GENERAL TIPS ADJUSTMENT

For the best audio performance:

Download the CORSAIR Utility Engine software from.
corsair.com/support/downloads.
- Don't be afraid to use the software equalizer to adjust the audio quality to your liking. EQ presets have been provided for popular gaming and media types.

Prolonged listening at high volumes may adversely affect your hearing. Take breaks between sessions and always begin with the volume at the lowest possible level before increasing.

As with any audio product, reduce the volume before trying it with an audio source the first time.

You can adjust the volume with:

• Once an audio source is playing, set the volume to a comfortable level.

• The volume controller on the headset at the bottom corner of your left earcup.

• The standard Windows audio controller can also be used to adjust volume.

6

HS170N3

7

MICROPHONE ADJUSTMENT

Your new HS60 SURROUND headset features a high performance "unidirectional" microphone designed to reject noise other than your voice, but it must be pointed directly at your mouth to function correctly.

• Bend the flexible microphone boom to best fit near to the left corner of your mouth.
  We've found that about a 30 degree bend is a good place to start, but feel free to increase or decrease this if your mic is too loud or too soft.

Enjoy your CORSAIR HS60 SURROUND headset! If you have any questions or comments, see the back panel of this guide for contact information.

MISE EN ROUTE

Note on environmental protection

After the implementation of the European Directive 2012/9/EU in the national legal system, the following apolies:

Electrical and electronic devices may not be disposed of with domestic waste.

Consumers are obligated by law to return electrical and electronic devices at the end of their service lives to the public collecting points set up for this purpose of point of sale. Details to this are defined by the national law of the state, but not by the manufacturer or the owner. The manufacturer or the package indicates that a product is subject to these regulations. By recycling, reselling the materials or other forms of utilizing old devices, you are making an important contribution to protecting our environment.

The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user from accessing the system.

Exposure of the USB adapter to electrical shock may result in temporary mating of the microphone. If this occurs, remove and reconnect the USB adapter to reset.

FCC STATEMENT

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation, if this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help

This device must not be co-located or operating in conjunction with any other antenna or transmitter.

Operation is subject to the following two conditions:
1. this device may not cause harmful interference, and
2. this device must accept any interference received, including interference that may cause undesired operation.

EMAIL

supoortgorsair.com

WEB

corair.com

BLOG

corsair.com/bio

FORUM

forum.corsair.com

FACEBOOK

Facebook.com/Corser

TWITTER

Twitter.com/Corssair

YOUTUBE

youtbe.com/Corso

2017 CORSAIR COMPONENTS, Inc.

All rights reserved. CORSAIR and the sails logo are registered trademarks in the United States and/or other countries. All other trademarks are the property of their respective owners. Product may vary slightly from those pictured.

49-001619 AB
