Product type	Countertop oven
Brand	ARIETE
Model	BOn Cuisine 380 977
Power supply	Mains, 220-240 V ~ 50/60 Hz
Maximum temperature	250 °C
Timer	Yes, with automatic shut-off
Cooking functions	Convection, upper heat, lower heat, rotisserie, ventilation, upper heating plates, spit
Controls	Rotary thermostat, function selector, rotary timer, push buttons for plates
Indicator light	Yes, operation light
Number of cooking levels	3
Included accessories	Grid, drip tray, spit for rotisserie, two forks, crumb tray, extraction fork
Cleaning	External surface with damp sponge, interior with damp sponge after cooling, removable crumb tray, grid and drip tray dishwasher safe
Safety	Automatic shut-off after timer, hot door, do not immerse, keep out of reach of children
Use	Domestic
Compliance	Directives 2006/95/EC and EMC 2004/108/EC, Regulation (EC) No 1935/2004

Frequently Asked Questions - BOn Cuisine 380 977 ARIETE

How to clean the interior of the oven?

After complete cooling, clean the internal walls with a damp sponge and a little mild soap. Avoid abrasive or corrosive products for aluminum. Remove the crumb tray and wash separately.

How to use the rotisserie?

Thread the roast onto the spit centering it, secure with the forks. Insert the spit into the right cavity of the oven and press the left end onto the support. Select the rotisserie function, set temperature and timer.

What to do if the oven does not heat?

Check that the plug is connected and the voltage matches. Make sure the function selector and thermostat are set. If the indicator does not light, contact after-sales service.

Can I use aluminum foil in the oven?

It is not recommended to cover the internal walls with aluminum foil as this can damage the thermostat. For food, you can use aluminum foil, but avoid contact with the heating elements.

How to set the timer?

Turn the timer knob (N) clockwise to set the desired cooking time. The oven will stop automatically at the end of the programmed time. Turn the knob back to '0' for manual stop.

What accessories are included?

The oven comes with a grid, a drip tray, a spit for rotisserie with two forks, a crumb tray and an extraction fork.

Can I wash the accessories in the dishwasher?

Yes, the drip tray, grid, crumb tray and spit can be washed in the dishwasher, preferably on the top rack.

What temperature for roasting a chicken?

For a chicken of about 1 kg, preheat the oven to 200-250°C and cook for 50-60 minutes using the rotisserie function. Use the thermostat to set the temperature.

The oven emits smoke during first use, is this normal?

Yes, it's normal. Protective substances on metal parts may produce smoke and an odor. Run an empty cycle for 15 minutes at maximum temperature with the door open in a ventilated room.

How to change the interior oven light?

This model is not equipped with an interior light. If you need a light, contact an authorized after-sales service for more information.

USER MANUAL BOn Cuisine 380 977 ARIETE

Illustration of a modern microwave oven with two top ovens and control knobs (no text or symbols)

bon cuisine

199 202 250

NUMERO UNICO

-Ariete

De' Longhi Appliances Srl

Labeled diagram of a microwave oven with parts numbered A through Q, showing internal components and exterior view.

Fig. 1

Interior view of a microwave oven with a hand inserting a plug into the tray (no text or symbols visible)

Fig. 2

Illustration of a hand using a tool to clean or install a tray inside an oven (no text or symbols visible)

Fig. 3

Illustration of a hand inserting a tray into an oven with a handle (no text or symbols visible)

Fig. 4

Close-up of a refrigerator with open door and keyboard (no visible text or symbols)

Fig. 5

AVVERTENZE IMPORTANTI

LEGGERE QUESTE ISTRUZIONI PRIMA DELL'USO.

The necessary precautions must be taken when using electrical appliances, and these include the following:

Make sure that the voltage on the appliance rating plate corresponds to that of the 1. mains electricity.

Never leave the appliance unattended when connected to the power supply; 2. unplug it after every use.

Never place the appliance on or close to sources of heat.3.

Always place the appliance on a flat, level surface during use.4.

Place the oven on a work top or kitchen cabinet capable of withstanding a 5. temperature of at least 90^ C and leave some room above it. Under no circumstances should it be slotted in or inserted into a unit.

Never leave the appliance exposed to the elements (rain, sun, etc....).6.

Make sure that the power cord does not come into contact with hot surfaces.7.

This appliance can be used by children aged from 8 years and above and persons 8. with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and maintenance can be made by children aged from 8 years and under surveillance.

Keep the appliance and the power cord out of reach of children under 8 years of 9. age.

NEVER PLACE THE APPLIANCE BODY, PLUG OR POWER CORD IN WATER 10. OR OTHER LIQUIDS; ALWAYS WIPE CLEAN WITH A DAMP CLOTH.

ALWAYS UNPLUG THE POWER CORD FROM THE ELECTRICITY MAINS 11.

BEFORE FITTING OR REMOVING SINGLE ATTACHMENTS OR BEFORE CLEANING THE APPLIANCE.

1. Always make sure that your hands are thoroughly dry before using or adjusting the switches on the appliance, or before touching the power plug or power connections.

2. Remove all internal accessories, then wash and dry with care.

3. Do not transport the appliance while it is operating.

4. Do not cover the inside parts of the oven with aluminium foil as this could seriously damage thermostat operation.

During operation, the metal parts and glass become hot: only touch the 16. door handle at this time.

Do not place anything on the door when it is open.17.

Do not place dish cloths or plates on the appliance.18.

The appliance shall be placed against a wall when use. 19.

Do not allow acid substances (lemon juice, vinegar, etc.) to remain on 20. the appliance. Acidic as lemon juice, tomato sauce, vinegar or similar, if leaved for long time, may harm the enamel, making it opaque.

To unplug the appliance, grip the plug and remove it directly from the power 21. socket. Never pull the power cord to unplug the appliance.

Never use the appliance if the power cord or plug are damaged or if the appli-22. ance itself is faulty; in this case, take it to your nearest Authorised Assistance Centre.

To prevent any risks, if the power cord is damaged, it must be replaced by the 23. manufacturer, its Technical Assistance Service or a similarly qualified person.

This appliance is designed for HOME USE ONLY and may not be used for com-24. mercial or industrial purposes.

This appliance conforms to the directives 2006/95/EC and EMC 2004/108/EC, 25. and to the regulations (EC) No. 1935/2004 of 27/10/2004 regarding material in contact with foods.

Any changes to this product that have not been expressly authorised by the 26. manufacturer may lead to the user's guarantee being rendered null and void.

In the event that you decide to dispose of the appliance, we advise you to make 27. it inoperative by cutting off the power cord. We also recommend that any parts that could be dangerous be rendered harmless, especially for children, who may play with the appliance or its parts.

Packaging must never be left within the reach of children since it is potentially 28. dangerous.

The appliance is not intended to be operated by means of an external timer or 29. separate remote-control system.

1. To dispose of product correctly according to European Directive 2009/96/CE, please refer to and read the provided leaflet enclosed with the product.

DO NOT THROW AWAY THESE INSTRUCTIONS

DESCRIPTION OF THE APPLIANCE (Fig. 1)

A Fork to remove drip pan
B Fork to remove the brochette
C Grill
D Drip pan
E Rotisserie brochette
F Cooking levels
G Cooking plates
H Appliance body
I Thermostat dial
L Function select dial
M On indicator light
N On dial and timer
O Cooking plate buttons
P Heating elements
Q Handle
R Crumb tray

USING FOR THE FIRST TIME

Carry out an "empty" cooking cycle so as to remove any smell and smoke from the protective coatings applied to metal parts:

• switch on the oven by turning the dial to the symbol ☐; set the temperature to the maximum and the timer to 15 minutes;
• leave the appliance to operate with the door open in a well-aired environment.

During this operation, it is usual for smoke to come off metal parts and side openings. After this operation, ventilate the room.

INSTRUCTIONS FOR USE

• Prepare the foods for cooking by placing them on the grill (C) or inside the drip pan (D).
• Plug the appliance into the mains power and use the function select dial (L) to select the type of cooking required:

top cooking and rotisserie;

bottom cooking (with fan);

cooking at full power (top and bottom at the same time), fan and rotisserie;

• Turn the dial of the thermostat (I) and set the required cooking temperature.
• Place the grill (C) or the drip pan (D) with the previously prepared foods inside the oven at the cooking level (F) required.
  When cooking foods on the grill (C), also insert the drip pan (D) at a lower level (F) than the grill (C) so as to collect any cooking fat. We recommend pouring two glasses of water in the drip pan (D) to prevent smoke, unpleasant odours and build up.
• Turn the dial (N) to set timer according to required cooking time. At this stage, the oven starts cooking and the indicator light (M) switches on.
  When the oven is on, according to the type of cooking selected, the fan starts up automatically. Hot ventilated air guarantees an even temperature distribution and permits a uniform cooking on several levels without mixing up smells.
• The oven will stop automatically either when the set cooking time is up or when the dial (L) is returned to "0". In both cases, the indicator light (N) switches off.

- Unplug the appliance from the mains power, open the door and to avoid the risk of burning yourself, remove the grill (C) or the drip pan (D) with special oven gloves for the grill or the special fork (A), provided, for the pan (Fig. 2).

IMPORTANT:

Place foods at a minimum distance of 2 cm from the top heating element.

Watch over the recipe while it is cooking.

COOKING WITH ROTISSERIE

• Slip one of the forks onto the rotisserie (E) (two tines facing inwards) and screw it into place. Tie the roast (meat, chicken, etc.) with string and slide it onto the fork take care to centre the meat well, then slide in the second fork, also with the tip facing inwards. If necessary, unscrew the first fork to centre the roast on the rotisserie and then lock the two forks in position.
• Remove the grill (C) from the oven and place the drip pan (D) on a level (F) lower than the position of the rotisserie (E).
• Insert the pointed end of the rotisserie (E) into the hole in the right-hand side, fixing it to the motor axle. Rest the opposite end of the rotisserie in the support on the left-hand side (Fig. 3).
• Plug the appliance into the power mains and use the function select dial (L), select the type of cooking required:

top rotisserie cooking;

full power rotisserie cooking (top and bottom at the same time, with fan).

• Turn the thermostat dial (I) and set the required cooking temperature.
• Turn the dial (N) to set timer according to required cooking time. At this stage, the oven starts cooking and the indicator light (M) switches on. When the oven is on, according to the type of cooking selected, the fan starts up automatically. Hot ventilated air guarantees an even temperature distribution and permits a uniform cooking on several levels without mixing up smells.
• The oven will stop automatically either when the set cooking time is up or when the dial (L) is returned to "0". In both cases, the indicator light (N) switches off.
• Unplug the appliance from the power means, open the door all the way and use the fork (B) to lift the rotisserie out of the support side on the left and then lift out the other end of the motor axle (Fig. 4).

IMPORTANT:

Watch over the recipe while it is cooking.

COOKING WITH TOP PLATES

• Plug in appliance and select cooking mode with top plates (●●) by means of the function selection dial (L).
• Select the required cooking plate by pressing the related starting button (O) to "I", and then put food to be cooked on it, placed into an appropriate pot. The button goes on to signal operating start.
• After cooking, re-position the related plate button (O) to "0" and disconnect the plug from the socket.

CLEANING

• Frequent cleaning prevents the formation of smoke and unpleasant odours during cooking.
• By using proper kitchen gloves, remove the crumb tray (R) and proceed with cleaning. Place it back into the appliance making sure it is properly positioned in its seat (Picture 5).
• The drip tray (D), grill (C), crumb tray (R) and rotisserie (E) can be washed in warm, soapy water, or in the top rack of the dishwasher.
• Always wipe the outside clean with a damp sponge.
  Do not use abrasive products that can damage the paintwork.
• Never use products that might corrode aluminium (spray detergents) to clean the inside surfaces and never scrape the sides with sharp or pointed objects. Wipe with a damp sponge at the end of each use, when the oven has completely cooled.
• When there are grease spots or smoke exhalations, we recommend removing grease with a sponge soaked in hot soapy water.

IMPORTANT:

All enamelled parts need to be washed with soapy water or other non-abrasive products.

Dry with a soft cloth. Acidic substances such as lemon juice, tomato purée, vinegar or similar can damage the enamel, making it lose shine.

Recipes/quantities Degrees Times Funct.

Meat roasts (1 Kg) 200°-250° 50-60 min.			↔; ✉	☎
Roast fish (1 Kg) 190°-210° 30-40 min.				☎
Baked vegetables (500 g)	190°-210° 30-40 min.			☎
Brochettes, sausage, chopped meats (500 g)	190°-210° 30-45 min.			☎
Wrapped meat, vegetables and fish (500 g)	190°-210° 30-45 min.			☎
Meat, vegetable, fish gratin (500 g)	230°	20-30 min.		↔
Oven-baked pasta (1 Kg)	200°	20-30 min.		☎
Bread, pizza and focaccia (500 g)	230°-250° 20-35 min.			☎
Cakes, pastries (500 g)	170°-180° 25-40 min.			☎
Biscuits, small pastries (200 g)	170°	10-15 min.		☎
