Product Type	Wireless Gyroscopic Mouse (Air Mouse)
Brand	Gyration
Model	Air Mouse Go Plus
Dimensions (approx.)	100 x 60 x 30 mm
Weight (approx.)	80 g
Power	Rechargeable lithium-ion battery
Charging	Via charging base and USB cable, 8 hours
Connectivity	USB 2.4 GHz receiver
Range (estimated)	10 m
Buttons	Left, right, scroll wheel, 3 programmable, air control trigger
Key Features	Air control by wrist movement, double-click to lock air mode, gesture recognition
Software	MotionTools (download at gyration.com/motiontools)
System Compatibility	Windows, Mac (via MotionTools)
Warranty	2 years limited
Compliance	FCC, CE, Industry Canada, Class 1 Laser
Care and Cleaning	Clean with a soft, dry cloth; do not use abrasive products
Safety	Do not expose to moisture or extreme temperatures; use only the provided charging base
Spare Parts and Repairability	Contact Gyration customer service or an authorized reseller
General Information	Class 1 laser optical product safe for eyes under normal conditions

Frequently Asked Questions - Air Mouse Go Plus Gyration

How to set up the Air Mouse Go Plus for the first time?

Remove the plastic film between the battery and the mouse, then charge the mouse for 8 hours using the charging base. Insert the USB receiver into a port on your computer, press the connection button on the receiver, then press the one on the mouse. The computer will detect the Air Mouse automatically.

How does air control work?

Press and hold the trigger located under your index finger, then move your wrist to move the cursor. Release the trigger to stop. Double-click the trigger to lock air mode for hands-free use.

What to do if the mouse does not connect?

Check that the battery is charged. Reinsert the USB receiver into another port. Press the connection button on the receiver again, then press the one on the mouse. Reset if necessary by removing and reinserting the battery.

How to charge the Air Mouse?

Place the mouse on the provided charging base and connect the USB cable to a free port on your computer or a power adapter. The LED indicator blinks during charging. Allow 8 hours for a full charge.

Can I use the Air Mouse without the USB receiver?

No, the Air Mouse Go Plus requires the supplied USB 2.4 GHz receiver to work with your computer. The receiver must be connected to an active USB port.

How to download MotionTools software?

Go to www.gyration.com/motiontools and download the latest version for Windows or Mac. This software allows you to customize the programmable buttons and enable gesture recognition.

What gestures are recognized by MotionTools?

MotionTools recognizes gestures such as swipe, circle, up-and-down movement, etc. You can assign them to actions like opening an app, controlling media playback, or navigating between windows.

How to clean the Air Mouse Go Plus?

Use a soft, dry cloth to wipe the surface. Do not use chemicals, abrasives, or liquids. Avoid getting moisture into the openings.

What to do if the cursor jumps or does not respond properly?

Make sure you are within 10 meters of the receiver. Check that the battery is sufficiently charged. Avoid reflective surfaces that could interfere with the sensor. Reset the mouse by removing and reinserting the battery.

Is the Air Mouse compatible with Mac computers?

Yes, the Air Mouse works on Mac with MotionTools software. The USB receiver is recognized as a standard mouse. MotionTools allows you to enjoy all advanced features.

USER MANUAL Air Mouse Go Plus Gyration

Lithium-ion Battery
In-Air Activation Trigger
Mouse Connect Button
2.4 GHz USB Receiver
USB Receiver Connect Button

Getting Started

1 Remove Insulator tab.

Press the release button on the bottom of the mouse and remove battery pack. Remove and discard the plastic insulator lab. Replace battery.

2 Plug one end of the included USB charging cable into the desktop charger and the other end into an available USB port. Place the mouse on the charging cradle and charge for 8 hours. The blue LED will flash while charging.
3 Insert the USB receiver into an available USB port on your computer.

4 Press the connect button on the USB receiver.

5 Press the connect button on the bottom of the mouse.

6 If the product includes a keyboard, turn the keyboard over and insert the 2 AAA batteries. Repeat step 4 then press the connect button on the back of the keyboard.

The computer will automatically detect and configure the Air Mouse.
8 Visit www.gyration.com/Motiontools to download the MotionTools software (Mac and PC) and enjoy gesture recognition for your favorite applications.

In-Air Operation

9 Hold the mouse using a comfortable handshake position. Use your index finger to access the in-air activation trigger and your thumb to access the top mouse buttons.

Top Buttons

10 Press and hold the in-air activation trigger and move the cursor by flexing only your wrist while keeping your arm and body stationary.

11 Click and hold the in-air activation trigger then move the cursor over a target and release the trigger before clicking. This parks the cursor over the target and allows you to click more accurately.

12 Double-clicking the in-air activation trigger puts the Air Mouse in motion mode so you can move the cursor without holding the trigger.

Gyration - www.gyration.com

Regulatory Information

Notice to Users:

This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If the equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that which the receiver is connected.
• Consult the dealer or an experienced radio/TC technician for help.

The user is cautioned that changes and modifications made to the equipment without the approval of manufacturer could void the user's authority to operate this equipment.

FCC Statement:

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

CE

This equipment has been tested and found to comply with the limits of the European Council Directive on the approximation of the law of the member states relating to electromagnetic compatibility (89/336/EEC) according to EN 55022 Class B.

Industry Canada Equipment Notice

Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

Warranty Information

LIMITED TWO YEAR WARRANTY

We warrant to the original purchaser that this product (hardware or software) shall be free from defects in material and workmanship for a period of two years from the date of purchase ("warranty period"). Proof of purchase in the form of a legible sales receipt indicating that the product is within the warranty period must be presented for warranty service. If this product is determined to be defective during the warranty period, we will either repair or replace the product with a current equivalent, at our option.

For further information contact:

Gyration

www.gyration.com

North America: 1888 340-0033

This repair/replacement is our sole obligation under this warranty. We will not be responsible for any incidental or consequential damages or for any loss arising in connection with the use or inability to use this product. Some states/provinces do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. This warranty excludes defects or damage due to misuse, abuse, or neglect. This warranty gives you specific legal rights, and you may also have other rights, which vary from state to state/province to province.

Class 1 Laser Product

This optical device complies with International Standard IEC 60825-1 (also known as EN 60825-1:2001) Class 1 Laser Product Invisible and also complies with 21 CFR 1040 Laser Notice 50. Low risk to eyes, no risk to skin.

Class 1 products are defined to be safe under all conditions including optical instruments.

Caution: Use of controls or adjustments or performance of procedures other than those herein specified may result in hazardous radiation exposure.

Gyration - www.gyration.com

Gyration - www.gyration.com

Gyration - www.gyration.com

Gyration - www.gyration.com

Kennisgevingen

www.gyration.com North America: 1888340-0033
