Product type	Ceiling fan
Brand	Kalorik
Model	KA DV 1
Supply voltage	230 V
Power	55 W
Frequency	50 Hz
Number of speeds	3 (fast, medium, slow)
Rotation direction reversal	Yes (summer/winter)
Integrated lighting	Yes
Compatible bulb type	E27 (max 60 W per bulb)
Number of blades	4 or 5 (depending on installation)
Minimum installation height	2.3 m (recommended 2 to 3 m)
Hook load capacity	70 kg
Net weight	Approximately 6 kg
Installation	With rod or directly on ceiling
Use	Indoor only
Maintenance	Cleaning with a soft cloth; check fastenings twice a year
Repairability	Entrust to a qualified service

Frequently Asked Questions - KA DV 1 KALORIK

How to install the ceiling fan?

Two methods are possible: mounting with a rod (for high ceilings) or direct mounting (low ceiling). First fix the mounting plate to the ceiling, assemble the blades onto their holders, then connect the wires according to colors (blue/neutral, brown/phase, yellow-green/ground). Hang the device on the hook, fix the cover and screw in the bulbs (max 60W).

How to change the blade rotation direction?

Use the direction switch located on the side of the switch block. Turn off the fan, wait for the blades to stop completely, then slide the switch. Summer direction (counterclockwise) creates a cooling breeze; winter direction (clockwise) stirs warm air down.

How to clean the fan?

Always unplug the device before cleaning. Use a soft cloth to wipe the blades and decorative parts. Never use water or liquid on the motor. The shaft is lubricated for life, do not add oil. Check and tighten fastenings twice a year.

What if the fan vibrates abnormally?

First check that all screws and blades are properly fastened. Run the device for 10 minutes. If vibrations persist, ensure the blades are equidistant and the distance from center to each tip is identical. Tighten screws. If the problem continues, contact technical service.

What types of bulbs to use?

Use E27 base bulbs with a maximum power of 60 W each. Do not exceed this limit to avoid risk of overheating or fire.

Can I use a speed controller (dimmer) with this fan?

No, the use of an electrical attenuator (dimmer) is prohibited. This could cause a fire or electric shock. Use only the provided pull chain to change speeds.

What is the minimum installation height?

The fan must be installed at least 2 meters from the floor, ideally between 2 and 3 meters. This distance ensures optimal air circulation and prevents accidental contact with the blades.

How to connect the electrical wires?

Before any connection, turn off the power at the circuit breaker. Connect the fan wires to the junction block on the mounting plate: blue to blue (neutral), brown to brown (phase), yellow/green to ground. The red wire of the lighting connects to the brown wire. Tighten the screws well.

What if the fan does not work?

Check that the power supply is active and the circuit has not tripped. Ensure the pull chain is in the on position. If nothing happens, unplug the device and check connections at the junction block. If the problem persists, contact a qualified service.

How to maintain the fan in the long term?

At least twice a year, disassemble and check all parts (blades, supports, screws). Clean with a soft cloth. Never disassemble the motor block. If a part is loose, tighten it. At end of life, dispose of the device at an electronics waste collection point (WEEE directive).

USER MANUAL KA DV 1 KALORIK

INSTALLATION #1: MONTAGE AVEC LA TIGE
