Product type	Blender
Brand	Braun
Model	IdentityCollection JB 5160
Maximum capacity	1.6 liters
Bowl material	Glass
Blade material	Stainless steel
Power supply	220-240 V, 50-60 Hz
Automatic programs	Ice crushing, Soup and puree, Smoothie
Pulse function	Yes, wheel activation
Cleaning of removable parts	Dishwasher safe
Cleaning the motor base	Damp cloth, do not immerse
Safety	Operates only if the bowl is correctly positioned
Included accessories	Measuring cup, lid with seal, bowl, blade with locking ring
Cord storage	Yes, under the motor base
Maximum hot soup capacity	1.3 liters
Maximum milk capacity	0.8 liters
Repairability	Spare parts available from Braun after-sales service

Frequently Asked Questions - IdentityCollection JB 5160 BRAUN

How to use the Soup and puree program?

Turn the wheel counterclockwise to the soup icon. The light ring flashes. Press the Start button to start the program; it stops automatically. To stop it earlier, press Start again or turn the wheel to the O position.

Can the bowl go in the dishwasher?

Yes, all removable parts (bowl, lid, seal, measuring cup, blade with locking ring) are dishwasher safe. Remove the seal from the lid for effective cleaning.

Can I blend hot ingredients?

Let hot liquids cool before pouring into the bowl. The maximum capacity for hot soup is 1.3 liters. Caution: hot liquids may be expelled due to sudden steam formation.

What to do if the blender does not start?

Check that the bowl is correctly positioned on the motor base and the lid is properly closed. Ensure the wheel is not in the O (off) position. Plug the appliance into a working power outlet.

How to clean the motor base?

Never immerse the motor base in water. Clean it with a damp cloth. Unplug the appliance before cleaning.

Can I use the blender without liquid?

No, do not use it empty. The bowl must contain solid or liquid ingredients to avoid damaging the appliance.

What is the maximum capacity for hot soup?

The maximum capacity for hot soup is 1.3 liters. For milk, it is 0.8 liters.

How to change the blade?

Make sure the bowl is empty. Unscrew the locking ring (f) by turning counterclockwise. Handle the blade carefully as it is very sharp. Reassemble in reverse order.

Can children use the appliance?

This appliance can be used by persons with reduced capabilities or without experience if they are supervised or have received instructions. Do not let children play with it. Cleaning and maintenance should not be performed by children without supervision.

Where to find spare parts?

Contact an authorized Braun Service Center or visit the Braun website. At the end of its life, do not dispose of the appliance with household waste; take it to an appropriate collection point.

USER MANUAL IdentityCollection JB 5160 BRAUN

Deutsch 4
English 7
Français 10
Español 13
Português 16
Italiano 19
Nederlands 22
Dansk 25
Norsk 27
Svenska 30
Suomi 32
Polski 34
Český 37
Slovenský 40
Magyar 43
Hrvatski 46
Slovenski 49
Türkçe 52
Română (MD) 54
Ελληνικά 57
Казакша60
Русский 63
Українська 66

De'Longhi Braun Household GmbH

			+		15...20°C
		7	1 7	- 1		- 11		1 7	-	- 11		1 7	-							—
		2	0 4	0-9		0-12		-1 23		30		0	6		6
		1	1,0	1			2 [5SAK]	3		1	0		1,		1,		1		31

Deutsch

Our products are engineered to meet the highest standards of quality, functionality and design. We hope you thoroughly enjoy the new Braun appliance.

Before use

Please read the user instructions carefully and completely before using the appliance

Caution

• The blades are very sharp! To avoid injuries, please handle blades with utmost care.
- This appliance can be used by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and if they understand the hazards involved.
- Children shall not play with the appliance.
- This appliance shall not be used by children.
- Children shall be kept away from the appliance and its mains cord.
- Cleaning and user maintenance shall not be made by children without supervision.
- Always unplug or switch off the appliance when it is left unattended and before assembling, disassembling, cleaning and storing.
- If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
- Before plugging into a socket, check whether your voltage corresponds with the voltage printed on the bottom of the appliance.
- Be careful if hot liquid is poured into the food processor or blender as it can be ejected out of the appliance due to a sudden steaming.

• This appliance is designed for household use only and for processing normal household quantities.
• Do not use any part in the microwave.
• Do not grab into the jug while the lid is open – risk of injury by the knife.
• The appliance works only if the jug is correctly assembled on the power base.
• Before switching on, make sure the jug is properly assembled and in place on the power base with the lid (incl. measuring cup).
• Do not use the device without any load in the jug.
• Allow hot liquids to cool off before pouring it into the jug.
• During first usages under heavier load, the appliance can emit some smell. This is a normal occurrence and does not mean any technical defect.

Description

a Measuring cup

b Lid

c Lid gasket

d Jug

e Blade gasket

f Blade unit with fastener ring

g Power base

h Start button

i Rotary switch

j Cord storage

Max. processing capacity: 1.6 litres

Prior to use

• Clean all parts before using the jug blender for the first time (see paragraph «Cleaning»).
• Uncoil amount of cord needed from cord storage at the bottom of the power base and connect to an outlet.

Jug assembly

• Carefully place the blade into the fastener ring.
• Position the blade gasket onto the rim of the blade unit.
• Screw the jug securely clockwise into the fastener ring until limit is contacted.

Attaching the jug

• Make sure that the rotary switch is in the «O» position.
• Place the jug on the power base and push it down until it is securely locked into place.
• Before removing the jug from the power base always turn the rotary switch to the «O» position and unplug the power base after use.

How to use

• Put the food to be processed into the jug.
• Place the lid firmly on the jug. Insert measuring cup firmly into the lid opening.
• Turn the power base on.

Rotary switch

To switch on the appliance turn the rotary switch clockwise; the light shines permanently. Alternatively turn it anti-clockwise to use the programs; the light is flashing when the programs are activated.

Start button

Press the start button to start or stop a program.

O Off

Pulse = instant burst of operating

Ice crushing Program

1. Turn rotary switch anti-clockwise to Ⓟ. Light ring starts fl ashing.
2. Press «start» button as long as motor should run.

Ice crushing Program:

1. Turn rotary switch anti-clockwise to the ice crystal icon ✉. Light ring starts fl ashing.
2. Press «start» button; program starts to run and ends automatically.
3. To stop earlier press «start» button again or turn rotary switch to «O» position.

1. Turn rotary switch anti-clockwise to 📋. Light ring starts flashing.
2. Press «start» button; program starts to run and ends automatically.
3. To stop earlier press «start» button again or turn rotary switch to «O» position.

Further application: The program is as well perfectly suitable for processing different kinds of baby food.

Smoothie Program:

1. Turn motor switch anti-clockwise to 📋. Light ring starts fl ashing.

2. Press «start» button; program starts to run and ends automatically.

3. To stop earlier press «start» button again or turn rotary switch to «O» position.

Recipe example:

Raw vegetable soup

Cut 750 g carrots into cubes and fill them into the jug. Add 750 ml water, seasoning and herbs.

Mix for 5 seconds at maximum speed.

For best results

• When puréeing with solid ingredients, feed small portions into the jug gradually rather than adding a large quantity at one time.
• When mixing solid ingredients, cut them up into small pieces (2–3 cm).
• Always start by mixing solid ingredients with a small amount of liquid. Then gradually add more liquid through the opening in the lid.
• When preparing mayonnaise, oil can be added through the drip hole in the measuring cup.
• Use the pulse mode when mixing solid or highly viscous ingredients to avoid the blade becoming stagnant.
• Always operate the unit with your hand positioned on the top.
• Maximum capacity 1.3 l for hot soup and 0.8 l for milk.
• For preparing small amounts of foodstuff use a low speed level.

Cleaning

Power base

Do not immerse the power base in water.

Wipe clean with a damp cloth only.

Easy cleaning/rinsing of assembled jug

After emptying the jug, fi ll it with water. Place it on the power base and turn the rotary switch to the «P» setting several times.

Empty the jug and rinse clean.

Thoroughly cleaning the disassembled jug

Make sure the jug is empty before you unscrew the fastener ring (f). Handle the blade with caution.

All detachable parts are dishwasher-safe.

For an efficient cleaning of the lid, remove the lid gasket (c).

Subject to change without notice.

Please do not dispose of the product in the household waste at the end of its useful life. Disposal can take place at a Braun Service Centre or at appropriate collection points provided in your country.

UK Only

Guarantee Information

All Braun Household products carry a minimum guarantee period of two years. The rights and benefits under this guarantee are additional to your statutory rights which are not affected.

Please keep your receipt as this will form the basis of your guarantee.

In the unlikely event of a breakdown you have access to professional help from our team simply by calling:

02392 392333

For service in the Republic of Ireland please call:

012475471

Braun Household undertakes within the specified period to repair or replace any part of the appliance, free of charge (with the exception of any glass or porcelain-ware incorporated in the product) found to be defective provided that;

• We are promptly informed of the defect.
- The product is used and maintained in accordance with the User Instructions.
- The appliance has not been altered in any way or subjected to misuse or repair by a person other than an authorised service agent for Braun Household.
- No rights are given under this guarantee to a person acquiring the appliance second hand or for commercial or communal use.
- Any repaired or replaced appliance will be guaranteed on these terms for the unexpired portion of the guarantee.
- The need for repair has not been caused by insufficient aftercare or cleaning: or damage caused by the chemical or electrochemical effects of water.

Under no circumstances shall the application of this guarantee give rise to the complete replacement of the appliance or entitle the consumer to damages.

Braun Household, New Lane, Havant, Hampshire PO9 2NH

www.braunhousehold.co.uk

Français

Pulse = Impulsion instantanée

Country of origin: China

Year of manufacture

To determine the year of manufacture, refer to the 5-digit production code located near the type plate. The first digit of the production code refers to the last digit of the year of manufacture. The next 2 digits refer to the calendar week in the year of manufacture. And the last 2 digits show the print date automatically calculated since 1992.

Example : 30421 - The product was manufactured in week 4 of 2013.
