USER MANUAL MV3 Premium Kärcher

MV 3 www.kaercher.com/register-and-win59651040 11/13 MV 3 MV 3 Premium MV 3 P MV 3 P Premium

For vacuuming up moisture or wet- ness pay attention to the correct floor nozzle insert and connect the corresponding accessories. 몇 Caution: Immediately switch the appli- ance off or pull the power plug if foam forms or liquids escape! Do not use a filter bag! Note: If the container is full, a float closes the suction opening, and the ap- pliance works at a higher speed. Switch off the appliance immediately, and empty the container. Illustration Adapt the adapter to the connection diameter of the electric tool using a knife if necessary. Connect the adapter to the handle of the suction hose and connect it to the electric tool connection. Connect the mains plug of the elec- tric power tool to the vacuum clean- er. Illustration Switch the vacuum cleaner to Posi- tion II and start working. Note: As soon as the electric tool is switched on, the suction turbine starts with a 0.5 second delay. If the electric tool is switched off, the suction turbine continues to run for approx. 5 seconds in order to vacuum up the remaining dirt in the suction hose. Cleaning hard to reach locations or, where vacuuming is not possible, like leaves from a gravel bed. Illustration Connect the suction hose to the blower connection, this will activate the blower function. Turn off the appliance. Illustration Hook the floor nozzle into the park- ing position. Turn off the appliance and discon- nect the mains plug. Illustration Remove the appliance head and empty the reservoir. Illustration Stow away the mains cable and ac- cessory at the machine. Store the appliance in a dry room. Wet vacuum cleaning Working with electrical power tools Blowing function Interrupting operation Finish operation Empty the container Storing the appliance 17EN Downloaded from www.vandenborre.be– 11 Danger Turn off the appliance and re- move the mains plug prior to any care and maintenance work. Repair works may only be per- formed by the authorised cus- tomer service. 몇 Warning Do not use abrasives, glass or universal cleaners! Never im- merse the appliance in water. Clean the appliance and accessory parts made of plastic with a com- mercial plastic cleaner. If required, rinse the container and accessories with water properly and dry them before reuse. Illustration Only clean the cartridge filter under running water; do not wipe or brush. Let it dry completely prior to instal- lation. If the cleaning power of the appliance deteriorates please check the follow- ing: Accessories, suction hose or suc- tion tubes are clogged, please re- move the obstruction using a stick. Illustration Filter bag is full, install new filter bag. Illustration Cartridge filter is dirty, knock off dirt from cartridge filter and clean under running water if necessary. Replace damaged cartridge filter. The Specifications are listed on page

IV. The following is an explanation of
