Product Type	Modular PC Power Supply
Brand	Corsair
Model	TX750W / TX650W (Modular Power Supply series)
Form Factor	ATX12V v2.2, backward compatible with ATX12V 2.01
Dimensions (L × H × D)	TX750W: 150 × 86 × 160 mm; TX650W: 150 × 86 × 150 mm
Weight	Approximately 2.5 kg
AC Input	90-264 VAC, 5-10 A, 47-63 Hz
Total Power	650 W (TX650W) or 750 W (TX750W)
Efficiency	Greater than 80% at 20%, 50%, and 100% load
Fan	140 mm (TX750W) or 120 mm (TX650W), dual ball bearing, ultra quiet, thermal control
Protections	Overvoltage, overcurrent, overload, undervoltage, short circuit
Main Connectors	1× ATX 24-pin (detachable 4-pin), 1× EPS12V 8-pin (detachable 4-pin)
PCI-E Connectors	TX750W: 4× 6+2-pin; TX650W: 2× 6+2-pin
SATA Connectors	2 cables with 4 SATA connectors each
Peripheral Connectors	2 cables with 4 Molex connectors + 1 FDD connector
Cable Length	ATX and EPS: 610 mm; PCI-E: 610 mm; SATA: 864 mm; Peripherals: 1016 mm
Warranty	5 years
Standards	CE, FCC, C-TICK, UL, CSA, TUV, CB
Maintenance	Clean the exterior with a soft dry cloth. Do not open the casing.
Safety Instructions	Unplug before any intervention. Do not insert objects into the vents. Indoor use only.

Frequently Asked Questions - Modular Power Supply CORSAIR

What are the advantages of the Corsair TX power supply?

Corsair TX power supplies offer greater than 80% efficiency, a silent dual ball bearing fan, a single +12V rail for maximum compatibility, and a 5-year warranty.

How to install the power supply in a new system?

Follow steps A in the manual: install the power supply in the case, connect the ATX, EPS12V, PCI-E, SATA and peripheral connectors according to your configuration, then plug in the AC power cord and set the switch to I.

Can I use this power supply on a 20-pin motherboard?

Yes, the 24-pin ATX connector has a detachable 4-pin section. You can disconnect these 4 pins and connect the 20-pin connector to the motherboard.

What to do if the power supply does not start?

Check that the switch is on I, that the power cord is properly plugged in, and that all connectors are firmly seated. If the problem persists, contact Corsair support.

Are the cables modular?

No, the cables are fixed (non-modular) on TX models. All necessary cables are provided and cannot be removed.

What is the maximum power on the +12V rail?

For the TX650W, the +12V rail supplies up to 52A (624W). For the TX750W, it supplies up to 60A (720W).

Is the power supply protected against overvoltages?

Yes, it includes protections against overcurrent, overvoltage, overload, undervoltage, and short circuits.

How to maintain the power supply?

Unplug the power supply and clean the exterior with a dry cloth. Never open the casing as high voltages are present inside.

What is the warranty period?

The warranty is 60 months (5 years) from the delivery date. It covers hardware and manufacturing defects.

Can I replace a damaged cable?

The cables are fixed and not individually replaceable. If a cable is damaged, contact Corsair support for repair or replacement under warranty.

USER MANUAL Modular Power Supply CORSAIR

Close-up of a honeycomb structure with hexagonal cells, no text or symbols visible

User's Manual

Congratulations on the purchase of your new Corsair TX650W/TX750W Power Supply!

This User Agreement (the "Agreement") is a legal agreement between you ("You"), and Corsair Memory. You are agreeing to be bound by the terms of this agreement, as defined below, by using the Corsair TX650W/TX750W power supply ("Product"). If you have any questions or concerns about the terms of this agreement, please contact us at http://www.corsairmemory.com/company/contacts.aspx. If, prior to using the Product, you decide you are unwilling to agree to the terms of this agreement, promptly return the Product and the accompanying items (including written materials and binders or other containers) for Corsair Memory or the Corsair Memory authorized distributor from whom you obtained the Product and accompanying items. If you have already paid for the Product, provide us with your proof of purchase and we will refund the fees you have paid for these items to you.

Limited Warranty And Limitation of Liability

The Product is guaranteed for sixty (60) months from the date of delivery to the end-user against defects in materials or workmanship. During this period, the Product will be repaired or have parts replaced, at our discretion, provided that: (I) the Product is returned to the agen from whom it was purchased with shipping prepaid; (II) the Product has been purchased by the end-user and not used for hire purposes; (III) the Product has not been misused, handled carelessly, or other than in accordance with any instructions provided with respect to its use; (IV) the Product has not been damaged due to acts of nature, such as lighting, fire, flood, or earthquake; (V) the warranty stickers have not been removed or tampered with.

Corsair Memory's warranty on the Product is to the first end user or consumer only, in accordance with the Corsair Memory's Limited Warranty. All warranties, express or implied, including without limitation the implied warranties of merchantability and fitness for a particular purpose, shall be limited to the duration of the guarantee above. The repair, replacement, or refund as provided under this express limited warranty is the exclusive re of the consumer, and is provided in lieu of all other warranties, express or implied. In no shall Corsair Memory be liable, whether in contract or tort (including negligence) for damage in excess of the purchase price of the product, or accessory, or for any indirect, incident special or consequential damages of any kind, or loss of revenue or profits, loss of business loss of information or data, software or applications or other financial loss arising out of connection with the ability or inability to use the products or accessories to the full extent these damages may be disclaimed by law.

Corsair Memory's total liability, whether for breach of contract, warranty, tort (including negligence), indemnification or otherwise, is limited to the price of the Product sold under these terms with respect to which losses or damages are claimed. In no event will Corsair Memory be liable for any loss of use, loss of time, inconvenience, commercial loss, lost p or savings or other indirect, incidental, special or consequential damages to the full extent may be disclaimed by law. The limitations, exclusions and disclaimers in these terms shall survive a fundamental breach or breach or the failure of the essential purpose of these t or of any remedy contained herein. No action will be brought for any breach of these t more than one year after the accrual of such cause of action. For the purpose of this paragraph, "Corsair Memory" includes its affiliates and its and their respective directors, officers, employees and agents, each of whom shall be considered as a trust beneficiary.

Introduction

Enthusiasts looking for the optimal in price performance PSU technology will find the Corsair TX650W/TX750W series of PSUs will meet even the most demanding of required specifications. The Corsair TX650W/TX750W power supplies are engineered using advanced technology and components typically found with high performance power supplies. With design features such as a dedicated, single +12V rail, the TX series offers the maximum compatibility with the latest system components. Energy efficient circuitry capable of delivering greater than 80% efficiency ratings across 20%, 50%, and 100% load conditions make the TX family of PSUs ideal for the value/quality conscious enthusiast. With a large 140mm (120mm on TX650W) diameter temperature-controlled fan that is ultra quiet, yet still more than sufficient to cool the internals of the system, reliability and stability are no longer worries for the gamer, overclocker or enthusiast and high-end system builder. Each Corsair TX power supply is backed with an industry-leading 5-year warranty and 24/7 on-demand customer service.

Corsair Advantages

The TX650W/TX750W is packed with latest technology and features:

• Supports the latest ATX12V v2.2 standard and is backwards compatible with ATX12V 2.01 systems.
• Ultra-quiet 120mm (140mm on TX750W) double ball-bearing fan delivers excellent airflow at an exceptionally low noise level by varying the RPM in response to temperature.
• 80%+ energy efficiency at 20%, 50% and 100% load condition for less heat generation and lower energy bill.
• 99% Active Power Factor Correction provides clean and reliable power to your system.
• Universal AC input 90\~264V automatically scans and detects the correct voltage. No more hassle of flipping that tiny red switch!
• Dedicated single +12V rail offers maximum compatibility with latest components.
  • Over Current/Voltage/Power Protection, Under Voltage Protection, and Short Circuit Protection provide maximum safety to your critical system components.
• High quality Japanese capacitors provide uncompromised performance and reliability.
• Extra long fully-sleeved cables support full tower size chassis.
• TX650W Dimension: 5.9"(W) x 3.4"(H) X 5.5"(L); 150mm(W) x 86mm(H) x 150mm(L)
• TX750W Dimension: 5.9"(W) x 3.4"(H) X 6.3"(L); 150mm(W) x 86mm(H) x 160mm(L)
  • MTBF: 100,000 Hours
• 5 year warranty and lifetime access to Corsair's legendary technical support and customer service

Model	CMPSU-650TX		CMPSU-750TX
AC Input Rating	90-264VAC		90-264VAC
Input Current	5-10A		5-10A
Frequency	47Hz~63Hz		47Hz~63Hz
DC Output	Max Load	Max Output	Max Load	Max Output
+3.3V	24A	170W	30A	180W
+5V	30A		28A
+12V	52A	624W	60A	720W
-12V	0.8A	9.6W	0.8A	9.6W
+5VSB	3A	15W	3A	15W
Total Power	650W		750W

Package Contents

• Corsair TX650W/TX750W Power Supply unit
- User Manual
- AC Power cord
- Cable ties
- Mounting screws
- Corsair case badge

Corsair Cable Configuration

- 1 x 610mm (24") 24-pin ATX power connector cable.

Note: The ATX power connector has a detachable 4-pin mechanism in order to support either a 24-pin or a 20-pin socket on the motherboard.

- 1 x 610mm (24") 8-pin EPS12V connector cable.

Note: The EPS12V power connector has a detachable 4-pin mechanism in order to support either an 8-pin socket or a 4-pin "P4/12V" socket on the motherboard.

• For TX650W: 2 x 610mm (24") 6+2-pin PCI-E connector cable.
• For TX750W: 4 x 610mm (24") 6+2-pin PCI-E connector cable.
• 2 x 864mm (34") SATA connector cable with four SATA connector heads.
• 2 x 1016mm (40") 4-pin peripheral power connector cable with four connector heads and one small 4-pin for floppy drive.

Installation

Before proceeding with installation, please read through this manual in its entirety.

Step A: Building a brand new system:

(If you are replacing your existing power supply, please go to step B.)

1 Please make sure the TX650W/TX750W is not connected with an AC power cord

2 Follow the directions in your chassis manual and install the TX650W/TX750W with the screws provided.

3 The main 24-pin power cable attached on the TX650W/TX750W has a detachable 4-pin mechanism in order to support either a 24-pin or a 20-pin socket on the motherboard.

a If your motherboard has a 24-pin socket, you may connect the 24-pin main power cable from the TX650W/TX750W directly to your motherboard.

b If your motherboard has a 20-pin socket, you must detach the 4-pin cable from the 24-pin connector, and then plug the 20-pin cable onto your motherboard without connecting the 4-pin connector.

4 The TX650W/TX750W has an 8-pin +12V; also know as "EPS12V" cable.

a If your motherboard has an 8-pin +12V socket, connect the 8-pin cable directly to your motherboard.

b If your motherboard has a 4-pin socket, detach the 4-pin from the 8-pin cable and then plug the correct 4-pin directly to your motherboard.

WARNING: The detachable 4-pin from the 24-pin main connector is not a "P4" or "+12V" connector. Serious damage can be caused if you use it in place of "P4" or "+12V" con

5 The TX650W/TX750W includes 2 Peripheral cables, 4 PCI-Express cables (2 on TX650W), and 2 SATA cables.

a Connect Peripheral cable to hard disk power socket (repeat if necessary).

b Connect Peripheral cable to CD-ROM/DVD-ROM drive's power socket (repeat if necessary).

c Connect SATA cable to SATA Hard drive's power socket (repeat if necessary).

d Connect PCI-E cable to power socket of your PCI-Express video card if required (repeat if necessary).

e Connect Peripheral cable for any peripheral requiring a small 4-pin connector (repeat if necessary).

f Please make sure all the cables are tightly connected.

6 Connect the AC power cord to the TX650W/TX750W and turn on the TX650W/TX750W by pushing the switch to "I" position.

Congratulations! You have completed installation of the TX650 W/ TX750 W power supply and your system is ready to go!

Step B: Replacing your existing power supply

1 Disconnect the AC power cord from your wall outlet or UPS and from the existing power supply.
2 Disconnect all the power cables from your video card, motherboard and all the other peripherals.
3 Follow the direction in your chassis manual and uninstall your existing power supply.
4 Go to Step A.

Safety and Agency Approvals

CE EN55022:1998/A1:2000/A2:2003 CLASS B EN 61000-3-2:2000,

EN 61000-3-3:1995/A1:2001 EN55024:1998/A1:2001/A2:2003

FCC FCC Part 15 & Part 2 (CISPR 22 CLASS B)

C-TICK AS/NZS CISPR 22:2002 CLASS B

UL UL 60950-1

CSA CSA C22.2 NO. 60950-1

TUV EN 60950-1

CB IEC 60950-1

WARNING

■Due to high voltages inside the power supply, under no circumstances should the power supply cover be removed. Warranty is voided once the cover is removed.

■ Please operate the power supply in a safe and dry environment.

■Do not insert any objects into the open ventilation or fan grill area of the power supp

■The 24-pin main power connector has a detachable 4-pin connector. This 4-pin connector is not a P4 or ATX 12V connector. Please DO NOT force this cable in the P4 or AT socket on the motherboard.

■For indoor use only.

FCC FCC Comma 15 e Comma 2 (CISPR 22 CLASSE B)

C-TICK AS/NZS CISPR 22:2002 CLASSE B

UL UL 60950-1

CSA CSA C22.2 NO. 60950-1

TUV EN 60950-1

CB IEC 60950-1

AVVERTENZE

- TX750W 尺寸：5.9" (W) x 3.4" (H) X 6.3" (L)；150mm (W) x 86mm (H) x 160mm (L)

- MTBF: 100,000小时
