USER MANUAL PS42B430P2W SAMSUNG

Contact SAMSUNG WORLD-WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Country Customer Care Centre Web Site AUSTRIA www.samsung.com/be (Dutch) www.samsung.com/be_fr (French)

800 - SAMSUNG (800-726786)

• www.samsung.com/cz CZECH REPUBLIC Plasma TV user manual imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register Model Serial No. BN68-02353A-01 BN68-02353A-Eng.indb 1 2009-06-30 9:17:14 User Instructions „„ Screen Image retention Do not display a still image (such as on a video game or when hooking up a PC to this PDP) on the plasma monitor panel for more than 2 hours as it can cause screen image retention. This image retention is also known as “screen burn”. To avoid such image retention, reduce the degree of brightness and contrast of the screen when displaying a still image. „„ Height The PDP can normally operate only under 2000m in height. It might abnormally function at a place over 2000m in height so do not install and operate there. „„ Heat on the top of the PDP TV The top side of the product may be hot after long period of use as heat dissipates from the panel through the vent hole in the upper part of the product. This is normal and does not indicate any defect or operation failure of the product. However, children should be prevented from touching the upper part of the product. „„ The product is making a ‘cracking’ noise. A ‘cracking’ noise may occur when the product contracts or expands due to a change of surrounding environment such as temperature or humidity. This is normal and not a defect of the unit. „„ Cell Defects The PDP uses a panel consisting of 2,360,000(HD-level) to 6,221,000(FHD-level) pixels which require sophisticated technology to produce. However, there may be few bright or dark pixels on the screen. These pixels will have no impact on the performance of the product. „„ Avoid operating the TV at temperatures below 5°C(41°F) „„ A still image displayed too long may cause permanent damage to the PDP Panel. Watching the PDP TV in 4:3 format for a long period of time may leave traces of borders displayed on the left, right and centre of the screen caused by the difference of light emission on the screen. Playing a DVD or a game console may cause similar effect to the screen. Damages caused by the above effect are not covered by the Warranty. „„ Afterimage on the Screen. Displaying still images from Video games and PC for longer than a certain period of time may produce partial afterimages. To prevent this effect, reduce the ‘brightness’ and ‘contrast’ when displaying still images. „„ Warranty -- Warranty does not cover any damage caused by image retention. -- Burn-in is not covered by the warranty. „„ Installation Be sure to contact an authorized service centre, when installing your set in a location with heavy dust, high or low temperatures, high humidity, chemical substance and where it operates continually such as the airport, the train station etc. Failure to do so may cause a serious damage to your set. Functionalities related to Digital TV(DVB) are only available in countries/areas where DVB-T (MPEG2 and MPEG4 AVC) digital terrestrial signals are broadcasted or where you have access to a compatible DVB-C(MPEG2 and MPEG4 AAC) cable-TV service. Please check with your local dealer the possibility to receive DVB-T or DVB-C signal. DVB-T is the DVB European consortium standard for the broadcast transmission of digital terrestrial television and DVB-C is that for the broadcast transmission of digital TV over cable. However, some differentiated features like EPG (Electric Program Guide), VOD (Video on Demand) and so on, are not included in this specification. So, they cannot be supported at this moment. Although this TV set meets the latest DVB-T and DVB-C standards[August,2008], the compatibility with future DVB-T digital terrestrial and DVB-C digital cable broadcasts cannot be guaranteed. Some cable-TV providers may charge an additional fee for such a service and you may be required to agree to terms and conditions of their business. Some Digital TV functions might be unavailable in some countries or regions and DVB-C might not work correctly with all providers. For more information, please contact your local Samsung customer care centre. Contact SAMSUNG WORLDWIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. (See back cover for more informations.) NN Figures and illustrations in this User Manual are provided for reference only and may differ from actual product appearance. Product design and specifications may be changed without notice in order to enhance product performance. © 2009 Samsung Electronics Co., Ltd. All rights reserved. English - 2 BN68-02353A-Eng.indb 2 2009-06-30 9:17:14 English Contents Connecting and Preparing Your TV Function Description Recommendations for Use ■■ Teletext Feature p. 28
• ■■ Wall Mount Kit Specifications (VESA) p. 29
• ■■ Preparing before installing Wall- Mount on the wall p. 30
• ■■ Securing the TV to the Wall p. 30
• ■■ Troubleshooting p. 31
• ■■ Securing the Installation Space p. 31
• ■■ Specifications p. 32
• Picture Control ■■ Changing the Picture Settings One-Touch Button TOOLS English - 3 BN68-02353A-Eng.indb 3 2009-06-30 9:17:14 Connecting and Preparing Your TV Checking Parts Owner’s Instructions Remote Control/ AAA Batteries (2ea) Power Cord Cloth-Clean Screws (4ea) Cover-Bottom Holder-Ring (4ea) (Refer to page 30) Ferrite Core for Power Cord (1ea) Warranty Card/ Safety Guide Manual (Not available in all locations) NN The ferrite core is used to shield the cable from interference. When connecting a cable, open the ferrite core and clip it around the cable near the plug. Using the Stand-Base NN Two or more people should carry the PDP. Never lay the PDP on the floor because of possible damage to the screen. Always keep the PDP upright. NN The PDP can rotate 20 degrees in right and left directions. -20° ~ 20° How to assemble the Stand-Base (depending on the model) Using the 4 screws for securing the stand base and the monitor, firmly attach the monitor to the stand base. (The exterior of the set may be different than the picture.) In case of installing your TV on the wall, close the cover (1) on the stand-base connection part using two screws for hiding. Warning Firmly secure the stand to the TV before moving it, as the stand may fall and could cause serious injury. NN Two or more people should carry the TV. Never lay the TV on the floor because of possible damage to the screen. Always store the TV upright. English - 4 BN68-02353A-Eng.indb 4 2009-06-30 9:17:17 Viewing the Control Panel Front Panel buttons NN The product colour and shape may vary depending on the model. 1 SOURCE Toggles between all the available input sources (TV, Ext., AV, Component, HDMI1, HDMI2/DVI). p. 17

Press to change channels. In the on-screen menu, use the buttons as you would use the ▲ and ▼ buttons on the remote control. 5 POWER INDICATOR Lights up when the power is on.

NN In the on-screen menu, use this button as you would use the ENTER Touch each button to operate. button on the remote control. 2 MENU Press to see an on-screen menu of your TV’s features. 3 + Press to increase or decrease the volume. In the on-screen menu, use the + – buttons as you would use the ◄ and ► buttons on the remote control. (POWER) Press to turn the TV on and off.

7 REMOTE CONTROL SENSOR

Aim the remote control towards this spot on the TV. 8 SPEAKERS

English - 5 BN68-02353A-Eng.indb 5 2009-06-30 9:17:18 Viewing the Connection Panel TV Rear Panel

Cable Television Network

NN The product colour and shape may vary depending on the model. NN Whenever you connect an audio or video system to your set, ensure that all elements are switched off. NN When connecting an external device, match the colour of the connection terminal to the cable. 1 POWER IN Connect the supplied power cord. 2 SERVICE 1, 2 Connector for service. 3 COMPONENT IN Audio (AUDIO L/R) and video (Y/PB/PR) inputs for Component. 4 EXT (RGB) Inputs or outputs for external devices, such as VCR, DVD, video game device or video disc players. Input/Output Specification Connector EXT Video Input Audio(L/R) RGB

Output Video + Audio(L/R) Only TV or DTV output is available. 5 DIGITAL AUDIO OUT (OPTICAL) Connect to a Digital Audio Component. 6 AUDIO OUT(AUDIO R/L) Connect RCA audio signals from the TV to an external source, such as Audio equipment. 7 HDMI IN 1, 2 (DVI) No additional Audio connection is needed for an HDMI to HDMI connection. -- When using an HDMI/DVI cable connection, you must use the HDMI IN 2 (DVI) jack. NN What is HDMI? -- High Definition Multimedia interface allows the transmission of high definition digital video data and multiple channels of digital audio. -- The HDMI/DVI terminal supports DVI connection to an extended device with the appropriate cable (not supplied). The difference between HDMI and DVI is that the HDMI device is smaller in size, has the HDCP (High Bandwidth Digital Copy Protection) coding feature installed, and supports multi - channel digital audio.

DVI AUDIO IN

DVI audio outputs for external devices. 8 ANT IN 75Ω Coaxial connector for Air/Cable Network. Input/Output Specification 480i 480p 576i 576p 720p HDMI/DVI 50Hz

English - 6 BN68-02353A-Eng.indb 6 2009-06-30 9:17:19 TV Side Panel

NN The product colour and shape may vary depending on the model. 1 COMMON INTERFACE Slot Insert CI (Common Interface) card into the slot. (refer to page 23) -- When not inserting CI CARD in some channels, Scramble Signal is displayed on the screen. -- The pairing information containing a telephone number, CI CARD ID, Host ID, and other information will be displayed in about 2~3 minutes. If an error message is displayed, please contact your service provider. -- When the channel information configuration has finished, the message Updating Completed is displayed, indicating that the channel list is now updated. NN Insert the CI-Card in the direction marked on it. NN CAM is not supported in some countries and regions,check with your authorized dealer. 2 AV IN (VIDEO, AUDIO L/R) Video and audio inputs for external devices, such as a camcorder or VCR. English - 7 BN68-02353A-Eng.indb 7 2009-06-30 9:17:20 Remote Control You can use the remote control up to a distance of about 23 feet from the TV. NN The performance of the remote control may be affected by bright light. 1 POWER button (turns the TV on and off) 2 Selects the TV mode directly. 3 Number buttons for direct channel access 4 Press to switch to your Favourite channels. 5 Temporary sound switch-off

Volume increase Volume decrease Available source selection Use to see information on the current broadcast Use to quickly select frequently used functions. Control the cursor in the menu Used to display Channel Lists on the screen Use these buttons in the Channel list, etc. Previous channel Teletext Functions [ZW 2 Exit from the teletext display (depending on the model) 7 Teletext mode selection (LIST/FLOF) 8 Teletext reveal 9 Teletext size ! Teletext store @ Fastext topic selection # Teletext display/mix both teletext information and the normal broadcast $ Teletext sub page :Teletext next page % P :Teletext previous page ^ Teletext index

• Teletext hold ( Teletext cancel Next channel Previous channel ^ Displays the main on-screen menu

& Electronic Program Guide (EPG) display

• Returns to the previous menu ( Exit the on-screen menu ) Turn the audio description function on or off. a Digital subtitle display English - 8 BN68-02353A-Eng.indb 8 2009-06-30 9:17:21 Installing Batteries in the Remote Control

Lift the cover at the back of the remote control upward as shown in the figure. Install two AAA size batteries. NN Make sure to match the ‘+’ and ‘–’ ends of the batteries with the diagram inside the compartment.

Close the cover. NN Remove the batteries and store them in a cool, dry place if you won’t be using the remote control for a long time. NN If the remote control doesn’t work, check the following

1. Is the TV power on?

2. Are the plus and minus ends of the batteries reversed?

3. Are the batteries drained?

4. Is there a power outage or is the power cord unplugged?

5. Is there a special fluorescent light or neon sign nearby?

Switching On and Off The mains lead is attached to the rear of your set.

Plug the mains lead into an appropriate socket. NN The standby indicator lights up on your set.

Press the POWERP button on your set. NN You also can press the POWERP button or the TV button on the remote control to turn the TV on. The programme that you were watching last is reselected automatically. Press the numeric button (0~9) or channel up / down (< / >) button on the remote control or < CH > button on your set. NN When you switch the set on for the very first time, you will be asked to choose language in which the menus are to be displayed.

4. To switch your set off, press the POWERP button again.

Placing Your Television in Standby Mode Your set can be placed in standby mode in order to reduce the power consumption. The standby mode can be useful when you wish to interrupt viewing temporarily (during a meal, for example).

Press the POWERP button on the remote control. NN The screen is turned off and a red standby indicator appears on your set.

To switch your set back on, simply press the POWERP, numeric buttons (0~9), TV button or channel up / down (< / >) button again. NN Do not leave your set in standby mode for long periods of time (when you are away on holiday, for example). It is best to unplug the set from the mains and aerial. English - 9 BN68-02353A-Eng.indb 9 2009-06-30 9:17:21 Viewing the Menus

With the power on, press the MENU button. The main menu appears on the screen. The menu’s left side has icons: Picture, Sound, Channel, Setup, Input, Support. Press the ▲ or ▼ button to select one of the icons. Then press the ENTERE button to access the icon’s sub-menu. Press the EXIT button to exit. Picture NN The on-screen menus disappear from the screen after about one minute. [ZW Mode : Standard Cell Light

Contrast : 95 Brightness : 45 Sharpness : 50 Colour : 50 Tint (G/R) : G50/R50 Using the TOOLS Button You can use the TOOLS button to select your frequently used functions quickly and easily. The Tools menu changes depending on which external input mode you are viewing.

[ZW Press the TOOLS button. The Tools menu will appear. Press the ▲ or ▼ button to select a menu, then press the ENTERE button. Press the ▲ / ▼ / ◄ / ► / ENTERE buttons to display, change, or use the selected items. For a more detailed description of each function, refer to the corresponding page.

Tools Picture Mode, see page 17 Sound Mode, see page 20 Sleep Timer, see page 24 Energy Saving, see page 23 Add to Favourite (or Delete from Favourite), see page 15 Picture Mode

Add to Favourite U Move E Enter e Exit Viewing the Display The display identifies the current channel and the status of certain audio-video settings. OO Press the INFO button to viewing the information. Press the INFO button on the remote control. The TV will display the channel, the type of sound, and the status of certain picture and sound settings.

• • ▲, ▼: You can view other channel’s information. If you want to move to the currently selected channel, press ENTERE button.
• • ◄, ►: You can view the desired program’s information at the current channel. NN Press the INFO button once more or wait approximately 10 seconds and the display disappears automatically. abc1 DTV Air

18:11 Thu 6 Jan Life On Venus Avenue Unclassified No Detaild Information Plug & Play Feature When the TV is initially powered on, basic settings proceed automatically and subsequently. NN The Screen Saver is activated if there is no remote control key input for longer than 1 minute while Plug & Play is running. NN The Screen Saver is activated if there is no operating signal for longer than 15 minutes.

Press the POWER button on the remote control. You can set the menu language. menu is automatically displayed. Select the appropriate language by pressing the ▲ or ▼ button. Press the ENTERE button to confirm your choice. Press the ◄ or ► button to select Store Demo or Home Use, then the ENTERE button. Plug & Play You can set the menu language. Menu Language

NN We recommend setting the TV to Home Use mode for the best picture in your home environment. NN Store Demo mode is only intended for use in retail environments. NN If the unit is accidentally set to Store Demo mode and you want to return to Home Use (Standard): Press the Volume button on

the TV. When the volume OSD is displayed, press and hold the MENU button on the TV for 5 seconds. Press the ENTERE button. Select the appropriate country by pressing the ▲ or ▼ button. Press the ENTERE button to confirm your choice. Press the ▲ or ▼ button to memorize the channels of the selected connection, then press the ENTERE button.

• • Air: Air antenna signal.
• • Cable: Cable antenna signal. Press the ▲ or ▼ button to select the channel source to memorize. Press the ENTERE button to select Start.

• • Digital & Analogue: Digital and Analogue channels.
• • Digital: Digital channels.
• • Analogue: Analogue channels. NN For more detailed description of selecting Cable mode,, refer to page 12. NN The channel search will start and end automatically. NN Press the ENTERE button at any time to interrupt the memorization process. NN After all the available channels are stored, the message Set the Clock Mode. is displayed.

6. Press the ENTERE button. Press the ▲ or ▼ button to select Auto, then Press the ENTERE button.

NN If you select Manual, Set current date and time is displayed. (refer to page 24) NN If you have received a digital signal, the time will be set automatically. If not, see page 24 to set the clock.

7. The brief instruction on How to get the best performance from your new HDTV. is displayed. Press the ENTERE button.

NN This menu is available HD Connection Guide in the Support menu.

8. The message Enjoy your TV. is displayed. When you have finished, press the ENTERE button.

If you want to reset this feature...

NN The Plug & Play feature is only available in the TV mode. Setup Press the MENU button to display the menu. Press the ▲ or ▼ button to select Setup, then press the ENTERE button.

2. Press the ENTERE button again to select Plug & Play.

3. Enter your 4 digit PIN number. The default PIN number of a new TV set is

‘0-0-0-0’. NN If you want to change PIN number, refer to 22 page.

Time Broadcast Security General English - 11 BN68-02353A-Eng.indb 11 2009-06-30 9:17:22 Channel Control Storing Channels ❑❑ Country „„ Analogue Channel: You can change the country for analogue channels. NN The PIN number input screen appears. Enter your 4 digit PIN number. Channel „„ Digital Channel: You can change the country for digital channels. Country

Scans for all channels with active broadcast stations (and availability depends on your country) and stores them in the TV's memory. You can memorize the channels of the selected connection.

• • Air: Air antenna signal.
• • Cable: Cable antenna signal. NN When selecting Cable,
• • Search Mode: Displays the search mode. (Quick) -- Network ID: Displays the network identification code. -- Frequency: Displays the frequency for the channel. -- Modulation: Displays available modulation values. -- Symbol Rate: Displays available symbol rates.
• • Search Mode: Displays the search mode. (Full, Network) -- Frequency (Start ~ Stop) : Displays the frequency for the channel. -- Modulation: Displays available modulation values. -- Symbol Rate : Displays available symbol rates. You can memorize the Channel source
• • Digital & Analogue: Digital and Analogue channels.
• • Digital: Digital channels.
• • Analogue: Analogue channels. NN If you want to stop Auto Store, press the ENTERE button. NN The Stop Auto Store? message will be displayed. NN Select Yes by pressing the ◄ or ► button, then press the ENTERE button. NN If a channel is locked using the Child Lock function, the PIN input window appears. Continued... English - 12 BN68-02353A-Eng.indb 12 2009-06-30 9:17:22 Scans for a channel manually and stores it in the TV’s memory. „„ Digital Channel (DTV) Manual store for digital channels. NN Digital Channel is only available in DTV mode.

• • Channel: Set the Channel number using the ▲, ▼ or number (0~9) buttons.
• • Frequency: Set the frequency using the number buttons.
• • Bandwidth: Set the bandwidth using the ▲, ▼ or number (0~9) buttons. NN When it has finished, channels are updated in the channel list. „„ Analogue Channel Manual store for analogue channel.
• • Programme (Programme number to be assigned to a channel): Sets the programme number using the ▲, ▼ or number (0~9) buttons.
• • Colour System → Auto / PAL / SECAM / NTSC4.43: Sets the colour system value using the ▲ or ▼ button.
• • Sound System → BG / L / I / DK: Sets the sound system value using the ▲ or ▼ button.
• • Channel (When you know the number of the channel to be stored): Press the ▲ or ▼ button to select C (Air channel) or S (Cable channel). Press the ► button, then press the ▲, ▼ or number (0~9) buttons to select the required number. NN You can also select the channel number directly by pressing the number (0~9) buttons. NN If there is abnormal sound or no sound, reselect the sound standard required.

• • Search (When you do not know the channel numbers): Press the ▲ or ▼ button to start the search. The tuner scans the frequency range until the first channel or the channel that you selected is received on the screen.
• • Store (When you store the channel and associated programme number): Set to OK by pressing the ENTERE button. NN Channel mode -- C (Air channel mode): You can select a channel by entering the assigned number to each air broadcasting station in this mode. -- S (Cable channel mode): You can select a channel by entering the assigned number for each cable channel in this mode. ❑❑ Cable Search Options (Cable) You can add directly the channel search range in the network search mode.(Depending on the each country)
• • Frequency (Start ~ Stop): Displays the frequency for the channel.
• • Modulation: Displays available modulation values.
• • Symbol Rate: Displays available symbol rates. NN Set the Frequency (Start~Stop) and Symbol Rate using the number (0~9) buttons. The EPG (Electronic Programme Guide) information is provided by the broadcasters. Programme entries may appear blank or out of date as a result of the information broadcast on a given channel. The display will dynamically update as soon as new information becomes available. „„ Now & Next Guide: For the six channels indicated in the left-hand column, displays the Current programme and the Next programme information. „„ Full Guide: Displays the programme information as time ordered One hour segments. One hours of programme information is displayed which may be scrolled forwards or backwards in time. Continued... English - 13 BN68-02353A-Eng.indb 13 2009-06-30 9:17:22 ❑❑ Default Guide „„ Now/Next / Full Guide: You can decide whether to display either the Now/Next or Now & Next Guide Channel the Full Guide when the GUIDE button on the remote control is pressed. Full Guide Default Guide : Now/Next

Channel List Channel Mode : Added Ch. Fine Tune OO You can also display the guide menu simply by pressing the GUIDE button. Using the Now & Next Guide / Full Guide Now & Next Guide DTV Cable 900 f tn Freshmen On Campus 2:00 - 2:30 No Detailed Information

▼ 903 Now Next Freshmen O.. Street Hypn.. No Information Mint Extra Loaded No Information Fresh 40 with Dynamite MC Kisstory No Information The Distillery Smash Hits! Sunday Watch Information Page Full Guide Exit f tn ITV Play Kerrang! Kiss oneword Smash Hits! DTV Cable 900 f tn Freshmen On Campus 2:00 - 2:30 No Detailed Information

▼ 903 Today f tn ITV Play Kerrang! Kiss oneword Smash Hits! Watch 2:00 - 3:00 Freshmen O.. Street Hypn.. Mint Extra Loaded Fresh 40 with Dynamite MC The Distillery Smash Hits! Sunday Information 2:10 Tue 1 Jun Now/Next Exit Select a programme by pressing the ▲/▼/◄/► button. If the next progrmme is selected, it is scheduled with the clock icon displayed. If the ENTERE button is pressed again, press the ▲/▼/◄/► button to select Cancel Schedules, the scheduling is canceled with the clock icon gone. For details about scheduling programmes, refer to the section. Toggle between the Now/Next or Full Guide. Full Guide: Scroll backwards quickly (-24 hours). Full Guide: Scroll forwards quickly (+24 hours). BLUE Exit the guide. INFO INFO button for the detailed information. Channel Number, Running Time, Status Bar, Parental Level, Video Quality Information (HD/SD), Sound Modes, Subtitle or Teletext, languages of Subtitle or Teletext and brief summary of the highlighted programme are included on the detailed information. “…” will be appeared if the summary is long. ❑❑ Channel List For the detailed procedures on using the Channel List, refer to the descriptions on pages 15~16. ❑❑ Channel Mode When the P </> button is pressed, Channels will be switched within the selected channel list. „„ Added Ch.: Channels will be switched within the memorized channel list. „„ Favourite Ch.: Channels will be switched within the favourite channel list. ❑❑ Fine Tune (only analogue channels) If the reception is clear, you do not have to fine tune the channel, as this is done automatically during the search and store operation. If the signal is weak or distorted, you may have to fine tune the channel manually. NN Fine tuned channels that have been saved are marked with an asterisk * on the right-hand side of the channel number in the channel banner. NN If you do not store the fine-tuned channel in memory, adjustments are not saved. NN To reset the fine-tuning, select Reset by pressing the ▼ button and then press the ENTERE button. English - 14 BN68-02353A-Eng.indb 14 2009-06-30 9:17:23 [ZW Managing Channels NN Select a channel in the All Channels, Added Channels, Favourites, or Programmed

Default Guide : Now/Next Channel List Channel Mode : Added Ch. Fine Tune

screen by pressing the ▲ or ▼ buttons, and pressing the ENTERE button. Then you can watch the selected channel. All Channels: Shows all currently available channels. Added Channels: Shows all added channels. Favourites: Shows all favourite channels. Programmed: Shows all current reserved programmes. Using the Colour buttons with the Channel List -- Red (Channel Type): Toggle between your TV, Radio, Data/Other and All. -- Green (Zoom): Enlarges or shrinks a channel number. -- Yellow (Select): Selects multiple channel lists. -- T TOOLS (Tools): Displays the Delete (or Add), Add to Favourite (or Delete from Favourite), Timer Viewing, Edit Channel Name, Edit Channel Number, Sort, Lock (or Unlock), Select All (or Deselect All), or Auto Store menu. (The Options menus may differ depending on the situation.) Full Guide Channel Using this menu, you can Add / Delete or set Favourite channels and use the programme guide for digital broadcasts.

C -A 3 ♥ C -A 4 C -A 5 C -A 6 C -A 7 C -A 8 C -A All NN Channel Status Display Icons

UKTV Gold UKTV style Channel Type Zoom

An Analogue channel.

A channel selected by pressing the yellow button.

A channel set as a Favourite.

A programme currently being broadcast.

A reserved programme Tools Select OO Press the CH LIST button on the remote control to bring up the channel lists. ❑❑ Channel List Tools Menu (in All Channels / Added Channels / Favourites) NN Press the TOOLS button to use the tools menu. NN Option menu items may differ depending on the channel status. You can delete or add a channel to display the channels you want. All deleted channels will be shown on All Channels menu. A gray-coloured channel indicates the channel has been deleted. The Add menu only appears for deleted channels. You can also delete a channel to the Added Channels or Favourite menu in the same manner.

„„ Add to Favourite / Delete from Favourite You can set channels you watch frequently as favourites. All Channels „„ Add / Delete

UKTV Gold UKTV style

A 3 A 4 A 5 A 6 A 7 A 8 C -C -C -C -C -C -C -- Add to Favourite [ZW1

All Channel Type Zoom Timer Viewing Edit Channel Name Sort Lock

Select Tools You can also add the favourite channel by selecting Tools → Add to Favourite (or Delete from Favourite). NN The “♥” symbol will be displayed and the channel will be set as a favourite. NN All favourite channels will be shown on Favourite menu. OO To select the Favourite channels you have set up, press the FAV.CH button on the remote control. Continued... English - 15 BN68-02353A-Eng.indb 15 2009-06-30 9:17:23 If you reserve a programme you want to watch, the channel is automatically switched to the reserved channel in the Channel List; even when you are watching another channel. To reserve a programme set the current time first. (See page 24) NN Only memorized channels can be reserved. NN You can set the channel, date, or start time directly by pressing the number buttons on the remote control. NN Reserving a programme will be shown on Programmed menu. NN Digital Programme Guide and Viewing Reservation When a digital channel is selected, and you press the ► button, the Programme Guide for the channel appears. You can reserve a programme according to the procedures described above. „„ Edit Channel Name (only analogue channel) Channels can labeled so that their call letters appear whenever the channel is selected. NN The names of digital broadcasting channels are automatically assigned and cannot be labeled. „„ Edit Channel Number (only digital channel) You can also edit the channel number by pressing the number buttons on the remote control. „„ Sort (only analogue channel) This operation allows you to change the programme numbers of the stored channels. This operation may be necessary after using the auto store. „„ Lock / Unlock You can lock a channel so that the channel cannot be selected and viewed. This function is available only when the Child Lock is set to on. (see page 22) NN The PIN number input screen appears. Enter your 4 digit PIN number. NN The default PIN number of a new TV set is ‘0-0-0-0’. You can change the PIN, by selecting Change PIN from the menu. NN The “\” symbol will be displayed and the channel will be locked. „„ Select All / Deselect All

• • Select All: You can select all the channels in the channel list.
• • Deselect All: You can deselect all the selected channels in the channel list. NN You can perform the add / delete, add to Favourites / delete from Favourites, or lock / unlock function for multiple channels at the same time. Select the required channels and press the yellow button to set all the selected channels at the same time. NN The “c” mark appears to the left of the selected channels. NN You can only select Deselect All when there is a selected channel. „„ Auto Store NN For further details on setting up options, refer to page 12. NN If a channel is locked using the Child Lock function, the PIN input window appears. You can view, modify or delete a reservation. NN Press the TOOLS button to use the tools menu.

• • Change Info: Select to change a viewing reservation.
• • Cancel Schedules: Select to cancel a viewing reservation.
• • Information: Select to view a viewing reservation. (You can also change the reservation information.)
• • Select All / Deselect All : You can select (or deselect) all channels in the channel list. Programmed ❑❑ Channel List Tools Menu (in Programmed) All 1 / 1 / 2009 13:59

ChangeQuincy, Info M.E TV1 Cancel Schedules TV3 The Equalizer Information TV3 McMillan & Wife Select All TV3 M.Spillane’s mike Hammer Zoom Select Tools Information English - 16 BN68-02353A-Eng.indb 16 2009-06-30 9:17:24 Picture Control Changing the Picture Settings ❑❑ Mode Picture You can select the type of picture which best corresponds to your viewing requirements.

• • Dynamic: Selects a high-definition picture for bright environments.
• • Standard: Selects the optimal picture display for normal environments.
• • Movie: Selects a comfortable picture display for dark environments. TT Press the TOOLS button to display Tools menu. You can also set the picture mode by selecting Tools → Picture Mode. ❑❑ Cell Light / Contrast / Brightness / Sharpness / Colour / Tint (G/R) Mode : Standard Cell Light

Contrast : 95 Brightness : 45 Sharpness : 50 Colour : 50 Tint (G/R) : G50/R50

Your television has several setting options that allow you to control the picture quality.

• • Cell Light: Adjusts the pixel brightness.
• • Contrast: Adjusts the contrast level.
• • Brightness: Adjusts the brightness level.
• • Sharpness: Adjusts the sharpness.
• • Colour: Adjusts the colour saturation of the picture using the bar on the screen.
• • Tint (G/R): The closer to Red 100, the more saturated the red colour becomes. NN Select a picture mode to be adjusted first. The adjusted values are saved for each picture mode. NN When you make changes to Cell Light, Contrast, Brightness, Sharpness, Colour or Tint (G/R), the OSD will be adjusted accordingly. NN In Analogue TV, Ext., AV modes of the PAL system, you cannot use the Tint Function. NN Settings can be adjusted and stored for each external device you have connected to an input of the TV. NN The energy consumed during use can be significantly reduced if the level of brightness of the picture is reduced, and then this will reduce the overall running cost. ❑❑ Advanced Settings Samsung’s new TVs allow you to make even more precise picture settings than previous models. See below to adjust detailed picture settings. NN Advanced Settings is available in Standard or Movie mode. Colour : 50 Tint (G/R) : G50/R50 Advanced Settings

Picture Options You can select the black level on the screen to adjust the screen depth. Picture Reset „„ Dynamic Contrast → Off / Low / Medium / High You can adjust the screen contrast so that the optimal contrast is provided. „„ Gamma You can adjust the primary colour (Red, Green, Blue) Intensity. „„ Colour Space Colour Space is a colour matrix composed of red, green and blue colours. Select your favourite Colour Space to experience the most natural colour.

• • Auto: Automatically sets the colour range depending on the input video source.
• • Native: Sets a colour range wider than that of the input video source. „„ White Balance You can adjust the colour temperature for more natural picture colours.
• • R-Offset / G-Offset / B-Offset / R-Gain / G-Gain / B-Gain: Changing the adjustment value will refresh the adjusted screen.
• • Reset: Resets the default white balance. „„ Flesh Tone You can emphasize the pink flesh tone in the picture. NN Changing the adjustment value will refresh the adjusted screen. „„ Edge Enhancement → Off / On You can emphasize object boundaries in the picture. Continued... English - 17 BN68-02353A-Eng.indb 17 2009-06-30 9:17:24 You can select the most comfortable colour tone to your eyes. NN The adjusted values are stored according to the selected Picture mode. NN Warm1 or Warm2 is only activated when the picture mode is Movie. Picture „„ Colour Tone → Cool / Normal / Warm1 / Warm2 : G50/R50 Advanced Settings Picture Options

Picture Reset „„ Size You can select the picture size which best corresponds to your viewing requirements.

• • Auto Wide: Sets the picture in Auto Wide format.
• • 16:9: Sets the picture to the 16:9 aspect ratio.
• • Wide Zoom: Select this menu to view 4:3 aspect ratio pictures over a 16:9 aspect ratio TV by stretching the 4:3 picture vertically.
• • Zoom: Stretches the 16:9 aspect ratio picture vertical
• • 4:3: Sets the picture to the 4:3 aspect ratio.
• • Screen Fit: Displays the full native HD signal that cannot be viewed using a normal TV. NN The picture size options may vary depending on the input source. NN The items available may differ depending on the selected mode. NN Settings can be adjusted and stored for each external device you have connected to an input of the TV. NN Temporary image retention may occur when viewing a static image on the set for more than two hours. NN Wide Zoom: Press the ► button to select Position, then press the ENTERE button. Press the ▲ or ▼ button to move the screen up / down. Then press the ENTERE button. NN Zoom: Press the ► button to select Position, then press the ENTERE button. Press the ▲ or ▼ button to move the picture up and down. Then press the ENTERE button. Press the ► button to select Size, then press the ENTERE button. Press the ▲ or ▼ button to magnify or reduce the picture size in the vertical direction. Then press the ENTERE button. NN After selecting Screen Fit in HDMI (1080i / 1080p) or Component (1080i / 1080p) mode: Select Position by pressing the ◄ or ►button. Use the ▲, ▼, ◄ or ► button to move the picture. NN Reset: Press the ◄ or ► button to select Reset, then press the ENTERE button. You can initialize the setting. NN If you use the Screen Fit function with HDMI 720p input, 1 line will be cut at the top, bottom, left and right as in the overscan function. „„ Screen Mode When setting the picture size to Auto Wide in a 16:9 wide TV, you can determine the picture size you want to see the 4:3 WSS (Wide Screen Service) image or nothing. Each individual European country requires different picture size so this function is intended for users to select it.
• • 16:9: Sets the picture to the 16:9 aspect ratio.
• • Wide Zoom: Select this menu to view 4:3 aspect ratio pictures over a 16:9 aspect ratio TV by stretching the 4:3 picture vertically.
• • Zoom: Stretches the 16:9 aspect ratio picture vertically.
• • 4:3: Selects the screen mode as 4:3 NN This function is available in Auto Wide mode. NN This function is not available in, Component or HDMI mode. „„ Digital NR → Off / Low / Medium / High / Auto If the broadcast signal received by your TV is weak, you can activate the Digital Noise Reduction feature to help reduce any static and ghosting that may appear on the screen. NN When the signal is weak, select one of the other options until the best picture is displayed. You can directly select the black level on the screen to adjust the screen depth. NN This function is active only when the external input connects to HDMI (RGB signals). Continued... English - 18 BN68-02353A-Eng.indb 18 2009-06-30 9:17:24 „„ Film Mode You can optimize the picture mode for watching movies.
• • Off : Basic video image processing applied and No auto-detection for film-based programs.
• • Auto: Automatically adjusts for the best image quality between film and video programs. „„ Screen Burn Protection Configures the Screen Burn Protection Options to prevent and reduce pixel burn. When an image remains in one position too long, it may cause a permanent burn on the screen.
• • Pixel Shift: To reduce the possibility of screen burn, this unit is equipped with screen burn prevention technology. This technology enables you to set picture movement up/down (Vertical) and side to side (Horizontal). The Time setting allows you to program the time between movement of the picture in minutes.

Set Pixel Shift to On by pressing the ▲ or ▼ button, then press the ENTERE button. Select the required option by pressing the ▲ or ▼ button, then press the ENTERE button. Available options: Horizontal, Vertical, Time. Optimum condition for pixel shift Item NN The Pixel Shift value may differ depending on the monitor size (inches) and mode. NN This function is not available in the Screen Fit mode.

• • Scrolling: This function helps remove after images on the screen by moving all the pixels on the PDP according to a pattern Use this function when there are remaining after images or symbols on the screen especially when you displayed a still image on the screen for a long time.
• • Side Grey: When you watch TV with the screen ratio of 4:3, the screen is prevented from any damage by adjusting the white balance on both extreme left and right sides. -- Dark: When you set the screen ratio to 4:3, it darkens the left and right sides. -- Light: When you set the screen ratio to 4:3, it brightens the left and right sides. Advanced Settings Picture Options Picture Resets all picture settings to the default values. NN Select a picture mode to be reset. The reset is performed for each picture mode. Picture Reset

English - 19 BN68-02353A-Eng.indb 19 2009-06-30 9:17:24 Sound Control Changing the Sound Setting ❑❑ Mode → Standard / Music / Movie / Clear Voice / Custom Sound You can select the type of special sound effect to be used when watching a given broadcast. Mode : Custom

Equalizer You can also configure the sound mode by selecting Tools → Sound Mode. ❑❑ Equalizer SRS TruSurround HD : Off Audio Language

Audio Description Auto Volume : Off The sound settings can be adjusted to suit your personal preferences.

• • Mode: You can select a sound mode to suit your personal preferences.
• • Balance: Controls the balance between the right and left speakers.
• • 100Hz / 300Hz / 1KHz / 3KHz / 10KHz (Bandwidth Adjustment): To adjust the level of different bandwidth frequencies
• • Reset: Resets the equalizer settings to the default values. [ZW ❑❑ SRS TruSurround HD → Off / On SRS TruSurround HD is the combined technology of TruSurround and FOCUS, TruBass. SRS TruSurround HD is down mixing technology that makes the Surround Sound effect of virtual 5.1 channel via two speakers. This function provide not only rich deep bass at a low-pitched sound but also improve the resolution at a high-pitched sound. NN If the sound is abnormal while TV is playing music, please adjust the equalizer and SRS TruSurround HD (Off/On). TruSurround HD, SRS and the symbol are trademarks of SRS Labs, Inc. TruSurround HD technology is incorporated under license from SRS Labs, Inc. ❑❑ Audio Language (only digital channel) You can change the default value for audio languages. Displays the language information for the incoming stream. NN You can only select the language among the actual languages being broadcast. ❑❑ Audio Format → MPEG / Dolby Digital (only digital channel) When sound is emitted from both the main speaker and the audio receiver, a sound echo may occur due to the decoding speed difference between the main speaker and the audio receiver. In this case, use the TV Speaker function. NN You can only select the language among the actual languages being broadcast. Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. ❑❑ Audio Description (only digital channel) This is an auxiliary audio function that provides an additional audio track for visually challenged persons. This function handles the Audio Stream for the AD (Audio Description), when it is sent along with the Main audio from the broadcaster. Users can turn the Audio Description On or Off and control the volume. OO You can select these options simply by pressing the AD button on the remote control. „„ Audio Description → Off / On Turn the audio description function on or off. „„ Volume You can adjust the audio description volume. NN Volume is active when Audio Description is set to On. Continued... English - 20 BN68-02353A-Eng.indb 20 2009-06-30 9:17:25 ❑❑ Auto Volume → Off / On Each broadcasting station has its own signal conditions, and so it is not easy to adjust the volume every time the channel is changed. This feature lets you automatically adjust the volume of the desired channel by lowering the sound output when the modulation signal is high or by raising the sound output when the modulation signal is low. ❑❑ Speaker Select → External Speaker / TV Speaker If you want to hear the sound through separate speakers, cancel the internal amplifier. NN The – +, M MUTE buttons do not operate when the Speaker Select is set to External Speaker. NN If you select External Speaker in the Speaker Select menu, the sound settings will be limited. TV's Internal Speakers Audio Out (Optical, L / R Out) to Sound System Video No Signal Mute Mute ❑❑ Sound Reset → Reset All / Reset Sound Mode / Cancel You can restore the Sound settings to the factory defaults. Auto Volume : Off Speaker Select : TV Speaker Sound Sound Reset

Selecting the Sound Mode When you set to Dual l ll, the current sound mode is displayed on the screen. NICAM Stereo Type of broadcast On-screen indication Regular broadcast (Standard audio) Mono (Normal use) Regular + NICAM Mono NICAM Mono (Normal) NICAM-Stereo NICAM Stereo Mono (Normal) NICAM Dual-1 Regular broadcast (Standard audio) Bilingual or DUAL-I/II Dual I Stereo Stereo NICAM Dual-2 Mono (Normal) Mono (Normal use) Dual II Mono (Forced mono) NN If the stereo signal is weak and an automatic switching occurs, then switch to the mono. NN This function is only activated in stereo sound signal. It is deactivated in mono sound signal. NN This function is only available in TV mode. English - 21 BN68-02353A-Eng.indb 21 2009-06-30 9:17:25 Function Description Configuring the Setup Menu ❑❑ Menu Language Setup You can set the menu language. ❑❑ Broadcast Plug & Play Menu Language : English

Time „„ Subtitle You can activate and deactivate the subtitles. Use this menu to set the Subtitle Mode. Normal under the menu is the basic subtitle and Hard of hearing is the subtitle for a hearing-impaired person.

• • Subtitle → Off / On: Switches subtitles off or on.
• • Mode → Normal / Hard of hearing: Sets the subtitle mode.
• • Subtitle Language: Set the subtitle language. NN If the programme you are watching does not support the Hard of hearing function, Normal automatically activates even though Hard of hearing mode is selected. NN English is the default in cases where the selected language is unavailable in the broadcast. OO You can select these options simply by pressing the SUBT. button on the remote control. Broadcast Security General If the programme is broadcast with digital text, this feature is enabled. NN MHEG (Multimedia and Hypermedia Information Coding Experts Group) An International standard for data encoding systems used in multimedia and hypermedia. This is at a higher level than the MPEG system which includes data-linking hypermedia such as still images, character service, animation, graphic and video files as well as multimedia data. MHEG is user runtime interaction technology and is being applied to various fields including VOD (Video-On-Demand), ITV (Interactive TV), EC (Electronic Commerce), tele-education, tele-conferencing, digital libraries and network games. „„ Teletext Language You can set the Teletext language by selecting the language type. NN English is the default in cases where the selected language is unavailable in the broadcast. „„ Preference

• • Primary Audio Language / Secondary Audio Language / Primary Subtitle Language / Secondary Subtitle Language / Primary Teletext Language / Secondary Teletext Language Using this feature, users can select one of the languages. The language selected here is the default when the user selects a channel. If you change the language setting, the Subtitle Language, Audio Language, and the Teletext Language of the Language menu are automatically changed to the selected language. The Subtitle Language, Audio Language, and the Teletext Language of the Language menu show a list of languages supported by the current channel and the selection is highlighted. If you change this language setting, the new selection is only valid for the current channel. The changed setting does not change the setting of the Primary Subtitle Language, Primary Audio Language, or the Primary Teletext Language of the Preference menu. „„ Common Interface

• • Installing the CI Card

1. Purchase the CI CAM module by visiting your nearest dealer or by phone.

2. Insert the CI CARD into the CAM in the direction of the arrow until it fits.

3. Insert the CAM with the CI CARD installed into the common interface slot.

NN Insert the CAM in the direction of the arrow, right up to the end so that it is parallel with the slot.

4. Check if you can see a picture on a scrambled signal channel.

• • CI Menu This enables the user to select from the CAM-provided menu. Select the CI Menu based on the menu PC Card.
• • Application Info. This contains information on CAM inserted in the CI slot and displays it. The Application Info inserting is about the CI CARD. You can install the CAM anytime whether the TV is ON or OFF. NN CAM is not supported in some countries and regions,check with your authorized dealer. English - 22 BN68-02353A-Eng.indb 22 Continued... 2009-06-30 9:17:25 ❑❑ Security „„ Child Lock → Off / On This feature allows you to prevent unauthorized users, such as children, from watching unsuitable programmes by muting out video and audio. NN Before the setup screen appears, the PIN number input screen appears. Enter your 4 digit PIN number. NN The default PIN number of a new TV set is '0-0-0-0'. You can change the PIN by selecting Change PIN from the menu. NN You can lock some channels in Channel List. (refer to page 15) NN Child Lock is available only in TV mode. „„ Parental Lock This feature allows you to prevent unauthorized users, such as children, from watching unsuitable programmes by a 4-digit PIN (Personal Identification Number) code that is defined by the user. NN Before the setup screen appears, the PIN number input screen appears. Enter your 4 digit PIN number. NN The default PIN number of a new TV set is '0-0-0-0'. You can change the PIN by selecting Change PIN from the menu. NN When the parental ratings are set, the \ symbol is displayed. NN Allow All: Press to unlock all TV ratings. Block All: Press to lock all TV ratings „„ Change PIN You can change your personal ID number that is required to set up the TV. NN Before the setup screen appears, the PIN number input screen appears. Enter your 4 digit PIN number. NN The default PIN number of a new TV set is '0-0-0-0'. NN If you forget the PIN code, press the remote control buttons in the following sequence, which resets the PIN to '0-0-0-0': POWER (Off), MMUTE, 8, 2, 4, POWER (On). ❑❑ General „„ Game Mode → Off / On When connecting to a game console such as PlayStationTM or XboxTM, you can enjoy a more realistic gaming experience by selecting the game menu.
• • When the Game Mode is On -- Picture Mode is automatically changed to Standard and users cannot change the mode. -- Sound Mode is automatically changed to Custom and users cannot change the mode. Adjust the sound using the equalizer. -- The Reset in the Sound menu is activated. Reset function initializes the Equalizer settings to the factory default setting.

Game Mode is not available in regular TV mode or Game Mode set to Off. If the picture is poor when external device is connected to TV, check if Game Mode is On. If you display the TV menu in Game mode, the screen shakes slightly. The mark ( ) appears on the screen which means that Game Mode is on with the selected source. This function supports only game function. Game mode is not available in PC mode. „„ Energy Saving → Off / Low / Medium / High / Picture Off This feature adjusts the brightness of the TV in order to reduce power consumption. When watching TV at night, set the Energy Saving mode option to High to reduce eye fatigue as well as power consumption. If you select Picture Off, the screen is turned off and you can only hear the sound. Press any button to get out of Picture Off. NN In the Tools menu, Picture Off function is not supported. TT Press the TOOLS button to display Tools menu. You can also set the Energy Saving option by selecting Tools → Energy Saving. „„ Melody → Off / Low / Medium / High The TV power on / off melody sound can be adjusted. NN The Melody does not play -- When no sound is output from the TV because the MUTE button has been pressed. -- When no sound is output from the TV because the – (Volume) button has been pressed. -- When the TV is turned off by Sleep Timer function. English - 23 BN68-02353A-Eng.indb 23 2009-06-30 9:17:25 Setting the Time ❑❑ Clock Setting the clock is necessary in order to use the various timer features of the TV. NN The current time will appear every time you press the INFO button. NN If you disconnect the power cord, you have to set the clock again. Menu Language : English Time

Broadcast Security General „„ Clock Mode You can set up the current time manually or automatically.

• • Auto: Set the current time automatically using the time from the digital broadcast.
• • Manual: Set the current time to a manually specified time. „„ Clock Set You can set the current time manually. NN Set up this item when you have set Clock Mode to Manual. NN You can set the Day, Month, Year, Hour, Minute directly by pressing the number buttons on the remote control. The sleep timer automatically shuts off the TV after a preset time. NN The TV automatically switches to standby mode when the timer reaches 0. NN To cancel the Sleep Timer function, select Off. U Move E Enter R Return You can also set the sleep timer by selecting Tools → Sleep Timer. Three different on / off timer settings can be made. „„ On Time: Set the hour, minute, and Activate / Inactivate. (To activate timer with the setting you’ve chosen, set to Activate.) „„ Off Time: Set the hour, minute, and Activate / Inactivate. (To activate timer with the setting you’ve chosen, set to Activate.) „„ Volume: Set the required volume level. „„ Antenna: Select ATV or DTV. „„ Channel: Select the desired channel. „„ Repeat: Select Once, Everyday, Mon~Fri, Mon~Sat, Sat~Sun, or Manual. NN When Manual is selected, press the ► button to select the desired day of the week. Press the ENTERE button over the desired day and the “c” mark will appear. NN You must set the clock first. NN You can set the hour, minute, or channel by pressing the number buttons on the remote control. NN Auto Power Off When you set the timer On, the television will eventually turn off, if no controls are operated for 3 hours after the TV was turned on by the timer. This function is only available in timer On mode and prevents overheating, which may occur if a TV is on for too long time. English - 24 BN68-02353A-Eng.indb 24 2009-06-30 9:17:25 [ZW Source List / Edit Name ❑❑ Source List Input Use to select TV or other external input sources such as DVD players or Cable Box / Satellite receivers (Set-Top Box) connected to the TV. Use to select the input source of your choice. Source List Edit Name „„ TV, Ext., AV, Component, HDMI1, HDMI2/DVI. NN You can choose only those external devices that are connected to the TV. In the Source List, connected inputs will be highlighted and sorted to the top. Inputs that are not connected will be sorted to the bottom. NN Using the Colour buttons on the remote with the Source list -- T TOOLS (Tools): Displays the Edit Name and Information menus. OO Press the SOURCE button on the remote control to view an external signal source. TV mode can be selected by pressing the TV button, number buttons (0~9), and the P < / > button on the remote control. ❑❑ Edit Name You can name the device connected to the input jacks to make your input source selection easier. „„ VCR / DVD / Cable STB / Satellite STB / PVR STB / AV Receiver / Game / Camcorder / PC / DVI PC / DVI / TV / IPTV / NN When a PC with a resolution of PS42B430: 640x480@60Hz, PS50B430: 1280x720@60 is connected to the HDMI IN 2(DVI) port, you should set the HDMI2/DVI mode to PC in the Edit Name of the Input mode. English - 25 BN68-02353A-Eng.indb 25 2009-06-30 9:17:26 PC Display ❑❑ Setting Up Your PC Software (Based on Windows XP)

The Windows display-settings for a typical computer are shown below. The actual screens on your PC will probably be different, depending upon your particular version of Windows and your particular video card. However, even if your actual screens look different, the same basic set-up information will apply in almost all cases. (If not, contact your computer manufacturer or Samsung Dealer.) First, click on Control Panel on the Windows start menu. When the control panel window appears, click on Appearance and Themes and a display dialog-box will appear. When the control panel window appears, click on Display and a display dialog-box will appear. Navigate to the Settings tab on the display dialog-box. The correct size setting (resolution) Optimum -- PS42B430 : 1024x768 pixels -- PS50B430 : 1360x768 pixels If a verticalfrequency option exists on your display settings dialog box, the correct value is 60 or 60 Hz. Otherwise, just click OK and exit the dialog box. Both screen position and size will vary depending on the type of PC monitor and its resolution. The resolutions in the table are recommended „„ HDMI/DVI Input Mode IBM MAC Resolution Vertical Frequency (Hz) Pixel Clock Frequency (MHz) Sync Polarity (H/V) PS42B430 PS50B430 640 x 350

640 x 480 VESA DMT 800 x 600 1024 x 768 VESA CVT VESA GTF

1280 x 720 1280 x 720

NN When using an HDMI/DVI cable connection, you must use the HDMI IN 2(DVI) terminal. NN The interlace mode is not supported. NN The set might operate abnormally if a non-standard video format is selected. English - 26 BN68-02353A-Eng.indb 26 2009-06-30 9:17:26 Supported Program ❑❑ Self Diagnosis „„ Picture Test, Sound Test, Signal Information If you think you have the Picture, Sound, Signal problem, perform the test. You can check the problem state. NN If you hear no sound from the TV’s speakers, before performing the sound test, make sure Speaker Select is set to TV speaker NN The melody will be heard during the test even if Speaker Select is set to External Speaker or the sound is muted by pressing NN If the signal strength meter indicates that the signal is weak, physically adjust your antenna to increase the signal strength. Continue to adjust the antenna until you find the best position with the strongest signal. ❑❑ Software Upgrade To keep your product up-to-date with new Digital Television features then software upgrades are periodically broadcast as part of the normal Television signal. It will automatically detect these signals and display the software upgrade banner. You are given the option to install the upgrade. „„ By USB Insert a USB drive containing the firmware upgrade into TV. Please be careful to not disconnect the power or remove the USB drive while upgrades are being applied. The TV will turn off and turn on automatically after completing the firmware upgrade. Please check the firmware version after the upgrades are complete. When software is upgraded, video and audio settings you have made will return to their default (factory) settings. We recommend you write down your settings so that you can easily reset them after the upgrade. USB Drive TV Panel „„ By Channel Upgrades the software using the broadcasting signal. „„ Standby Mode Upgrade To continue software upgrade with master power on, Select On by pressing the ▲ or ▼ button. 45 minutes after entering standby mode, a manual upgrade is automatically conducted. Since the power of the unit is turned on internally, the screen may be on slightly for the product. This phenomenon may continue for more than 1 hour until the software upgrade is completed. „„ Alternative Software Replace the current software with the alternative. The brief instruction on How to get the best performance from your new HDTV is displayed. We offer the connection method for HD devices. You can know the Samsung Call center, website and information for product. NN You can move the previous or next page by pressing the ▲ or ▼ button. English - 27 BN68-02353A-Eng.indb 27 2009-06-30 9:17:26 Recommendations for Use Teletext Feature Most television stations provide written information services via Teletext. The index page of the teletext service gives you information on how to use the service. In addition, you can select various options to suit your requirements by using the remote control buttons. NN For teletext information to be displayed correctly, channel reception must be stable. Otherwise, information may be missing or some pages may not be displayed. [ZW 1 : (exit) Exit from the teletext display. 2 6 (index) Used to display the index (contents) page at any time while you are viewing teletext. 3 5 (reveal) Used to display the hidden text (answers to quiz games, for example). To display normal screen, press it again.

4 4 (size) Press to display the double-size letters in the upper half of the screen. For lower half of the screen, press it again. To display normal screen, press it once again.

5 8 (store) Used to store the teletext pages.

6 / (teletext on/mix) Press to activate teletext mode after selecting the channel providing the teletext service. Press it twice to overlap the teletext with the current broadcasting screen.

8 2 (page up) Used to display the next teletext page.

9 3 (page down) Used to display the previous teletext page. 0 0 (mode) Press to select the teletext mode (LIST/FLOF). If you press it in the LIST mode, it switches into the List save mode. In the List save mode, you can save teletext page into list using the 8(store) button. ! 9 (hold) Used to hold the display on a given page if the selected page is linked with several secondary pages which follow on automatically. To resume, press it again.

[ZW @ 7 (cancel) Used to display the broadcast when searching for a page. # Colour buttons (red/green/yellow/blue) If the FASTEXT system is used by a broadcasting company, the different topics covered on a teletext page are colour-coded and can be selected by pressing the coloured buttons. Press one of them corresponding to the required. The page is displayed with other coloured information that can be selected in the same way. To display the previous or next page, press the corresponding coloured button. NN You can change teletext pages by pressing the numeric buttons on the remote control. English - 28 BN68-02353A-Eng.indb 28 2009-06-30 9:17:26 The teletext pages are organized according to six categories: Part Contents

Selected page number.

Broadcasting channel identity.

Current page number or search indications.

Status information. FASTEXT information. NN Teletext information is often divided between several pages displayed in sequence, which can be accessed by -- Entering the page number -- Selecting a title in a list -- Selecting a coloured heading (FASTEXT system) [ZW OO Press the TV button to exit from the teletext display. Wall Mount Kit Specifications (VESA) Install your wall mount on a solid wall perpendicular to the floor. When attaching to other building materials, please contact your nearest dealer. If installed on a ceiling or slanted wall, it may fall and result in severe personal injury. Product Family LCD-TV PDP-TV

inch VESA Spec. (A * B) 19" ~22" 100 * 100 23"~29" 200 * 100 30"~40" 200 * 200 46"~55" 400 * 400 57"~70" 800 * 400 80" ~ 1400 * 800 42"~ 50" 400 * 400 58"~ 63" 600 * 400 70" ~ 800 * 400 80" ~ 1400 * 800 Standard Screw Quantity

We provided the standard dimensions for wall mount kits as shown in the table above. When purchasing our wall mount kit, a detailed installation manual and all parts necessary for assembly are provided. Do not use screws longer than the standard dimension, as they may cause damage to the inside of the TV set. For wall mounts that do not comply with the VESA standard screw specifications, the length of the screws may differ depending on their specifications. Do not use screws that do not comply with the VESA standard screw specifications. Do not use fasten the screws too strongly, this may damage the product or cause the product to fall, leading to personal injury. Samsung is not liable for these kinds of accidents. Samsung is not liable for product damage or personal injury when a non-VESA or non-specified wall mount is used or the consumer fails to follow the product installation instructions. Our 57” and 63” models do not comply with VESA Specifications. Therefore, you should use our dedicated wall mount kit for this model. Do not exceed 15 degrees tilt when mounting this TV. Do not install your Wall Mount Kit while your TV is turned on. It may result in personal injury due to electric shock. English - 29 BN68-02353A-Eng.indb 29 2009-06-30 9:17:27 Preparing before installing Wall- Mount on the wall Case A. Installing SAMSUNG Wall-Mount Case B. Installing other company’s Wall-Mount

Install Wall Mount with the torque range of 15kgf·cm or less. Make sure that parts can be damaged if the torque is out of the specified range.

2. Accessory Kit contains Holder–Ring [①] for installing other company’s Wall-Mount on Samsung TV. (Case B)

NN Screw down the hole [①] when installing wall-mount on the wall.

Securing the TV to the Wall Pulling, pushing, or climbing on the TV may cause the TV to fall. In particular, ensure your children do not hang over or destabilize the TV; doing so may cause the TV to tip over, causing serious injuries or death. Follow all safety precautions provided on the included Safety Flyer. For added stability, install the anti-fall device for safety

purposes, as follows. Wall Wall ❑❑ To avoid the TV from falling

Put the screws into the clamps and firmly fasten them onto the wall. Confirm that the screws have been firmly installed onto the wall. NN You may need additional material such as an anchor depending on the type of wall. NN Since the necessary clamps, screws, and string are not supplied, please purchase these additionally.

Remove the screws from the center back of the TV, put the screws into the clamps, and then fasten the screws onto the TV again. NN Screws may not be supplied with the product.

Connect the clamps fixed onto the TV and the clamps fixed onto the wall with a strong string and then tie the string tightly. NN Install the TV near to the wall so that it does not fall backwards. NN It is safe to connect the string so that the clamps fixed on the wall are equal to or lower than the clamps fixed on the TV. NN Untie the string before moving the TV.

Verify all connections are properly secured. Periodically check connections for any sign of fatigue for failure. If you have any doubt about the security of your connections,contact a professional installer. English - 30 BN68-02353A-Eng.indb 30 2009-06-30 9:17:28 Troubleshooting Before contacting the Samsung after-sales service, perform the following simple checks. If you cannot solve the problem using the instructions below, note the model and serial number of the television and contact your local dealer. No sound or picture

Normal picture but no sound

• • Check whether the M MUTE button has been pressed on the remote control. No picture or black and white picture

• • Adjust the colour settings.
• • Check that the broadcast system selected is correct. Sound and picture interference

• • Try to identify the electrical appliance that is affecting the television, then move it further away.
• • Plug the television into a different main socket. Blurred or snowy picture, distorted sound

• • Check the direction, location and connections of your aerial.
• • This interference often occurs due to the use of an indoor aerial. Remote control malfunctions

Replace the remote control batteries. Clean the upper edge of the remote control (transmission window). Check that the + and – ends of the batteries are inserted correctly. Check that the batteries are drained. Screen is black and power indicator light blinks steadily

On your computer check; Power, Signal Cable. Move the computer’s mouse or press any key on the keyboard. On your equipment check (STB, DVD, etc) ; Power, Signal Cable. The TV is using its power management system. Press the Source button on the panel or remote control. Turn the TV off and on. The damaged picture appears in the corner of the screen.

• • If Screen Fit is selected in some external devices, the damaged picture may appear in the corner of the screen. This symptom is caused by external devices, not TV. The "Resets all settings to the default values" message appears.

• • This appears when you press and hold the EXIT button for a while. The product settings are reset to the factory defaults. Check that the mains lead has been connected to a wall socket. Check that you have pressed the button on your set. Check the picture contrast and brightness settings. Check the volume. Check if Speaker Select is set to External Speaker. Securing the Installation Space Keep the required distances between the product and other objects (e.g. walls) to ensure proper ventilation. Failing to do so may result in fire or a problem with the product due to an increase in the internal temperature of the product. Install the product so the required distances shown in the figure are kept. NN When using a stand or wall-mount, use parts provided by Samsung Electronics only. -- If you use parts provided by another manufacturer, it may result in a problem with the product or an injury due to the product falling. -- If you use parts provided by another manufacturer, it may result in a problem with the product or fire due to an increase in the internal temperature of the product due to poor ventilation. NN The appearance may differ depending on the product. „„ When installing the product with a stand 10 cm 10 cm 10 cm „„ When installing the product with a wall-mount 10 cm 10 cm 10 cm 10 cm 10 cm 10 cm 10 cm 10 cm 10 cm 10 cm 10 cm English - 31 BN68-02353A-Eng.indb 31 2009-06-30 9:17:28 Specifications The descriptions and characteristics in this booklet are given for information purposes only and are subject to modification without notice. Model Name PS42B430 PS50B430 42 inch 50 inch 1024 x 768 @ 60 Hz 1360x768 @ 60 Hz 10 W x 2 10 W x 2 Body 1055 x 667 x 73 mm 1230 x 756 x 73 mm With stand 1055 x 729 x 316 mm 1230 x 817 x 316 mm Body 24 kg 32 kg With stand 28 kg 36 kg Screen Size (Diagonal) PC Resolution (Optimum) Sound (Output) Dimension (WxHxD) Weight Environmental Considerations Operating Temperature Operating Humidity Storage Temperature This device is a Class B digital apparatus. Design and specifications are subject to change without prior notice. For the power supply and Power Consumption, refer to the label attached to the product. When using an HDMI/DVI cable connection, you must use the HDMI IN 2(DVI) terminal. English - 32 BN68-02353A-Eng.indb 32 2009-06-30 9:17:28 © 2009 Samsung Electronics Co., Ltd. All rights reserved. Français - BN68-02353A-Fre.indb

2009-6-30 9:58:50 Life On Venus Avenue Unclassified No Detaild Information 18:00 ~ 6:00 DTV Cable 900 f tn Freshmen On Campus 2:00 - 2:30 No Detailed Information

▼ 903 f tn ITV Play Kerrang! Kiss oneword Smash Hits! Voir 2:10 Tue 1 Jun Prés. Freshmen O.. Street Hypn.. Mint Extra Loaded Fresh 40 with Dynamite MC The Distillery Smash Hits! Sunday Information DTV Cable 900 f tn Freshmen On Campus 2:00 - 2:30 No Detailed Information Quitter Today f tn ITV Play Kerrang! Kiss oneword Smash Hits! Voir 2:00 - 3:00 Freshmen O.. Street Hypn.. Mint Extra Loaded Fresh 40 with Dynamite MC The Distillery Smash Hits! Sunday Information 2:10 Tue 1 Jun UKTV Gold UKTV style C --

C -A 3 ♥ C -A 4 C -A 5 C -A 6 C -A 7 C -A 8 C -A Tous UKTV Gold UKTV style Programme normal (Audio standard) Programme normal (Audio standard) NICAM dual 2 Mono (Normal)

pouce Caract. VESA (A * B) 19" ~22" 100 * 100 23"~29" 200 * 100 30"~40" 200 * 200 46"~55" 400 * 400 57"~70" 800 * 400 80" ~ 1400 * 800 42"~ 50" 400 * 400 58"~ 63" 600 * 400 70" ~ 800 * 400 80" ~ 1400 * 800 Vis standard Quantité

50 °F to 104 °F (10 °C to 40 °C) Life On Venus Avenue Unclassified No Detaild Information 18:00 ~ 6:00 DTV Cable 900 f tn Freshmen On Campus 2:00 - 2:30 No Detailed Information

▼ 903 f tn ITV Play Kerrang! Kiss oneword Smash Hits! 2:10 Tue 1 Jun Akt. Freshmen O.. Street Hypn.. Mint Extra Loaded Fresh 40 with Dynamite MC The Distillery Smash Hits! Sunday Ansehen Information DTV Cable 900 f tn Freshmen On Campus 2:00 - 2:30 No Detailed Information

▼ 903 Today f tn ITV Play Kerrang! Kiss oneword Smash Hits! 2:00 - 3:00 Freshmen O.. Street Hypn.. Mint Extra Loaded Fresh 40 with Dynamite MC The Distillery Smash Hits! Sunday Ansehen Information UKTV Gold UKTV style C --

C -A 3 ♥ C -A 4 C -A 5 C -A 6 C -A 7 C -A 8 C -A Alle Kanaltyp Zoom Extras Wählen UKTV Gold UKTV style Kanaltyp Zoom VCR / DVD / VCR / DVD / Cable STB / Satellite STB / PVR STB / AV Receiver / Game / Camcorder / PC / DVI PC / DVI / VESA CVT VESA GTF

1280 x 720 1280 x 720

❑ Software-Update Alternative Software © 2009 Samsung Electronics Co., Ltd. All rights reserved. Nederlands - BN68-02353A-Nl.indb

2009-6-30 9:52:24 Ingang Audio (L/R)

Life On Venus Avenue Unclassified No Detaild Information 18:00 ~ 6:00 f tn ITV Play Kerrang! Kiss oneword Smash Hits! DTV Cable 900 f tn Freshmen On Campus 2:00 - 2:30 No Detailed Information

▼ 903 Today f tn ITV Play Kerrang! Kiss oneword Smash Hits! Bekijken 2:10 Tue 1 Jun UKTV Gold UKTV style

C -A 3 ♥ C -A 4 C -A 5 C -A 6 C -A 7 C -A 8 C -A Alles Type kanaal Zoom Optie Keuze UKTV Gold UKTV style Type kanaal Tweetalig of DUAL-I/II Dual I Dual II Stereo Stereo Sync Polarity (H / V) 640 x 350 640 x 480 VESA DMT ❑ Software upgrade -4 °F to 113 °F (-20 °C to 45 °C) Opslagvochtigheid You can use the TOOLS button to select your frequently used functions quickly and easily. The Strumenti menu changes depending on which external input mode you are viewing.

Life On Venus Avenue Unclassified No Detaild Information 18:00 ~ 6:00 f tn ITV Play Kerrang! Kiss oneword Smash Hits! Guarda Guida Completa 2:10 Tue 1 Jun Att. Succ. Freshmen O.. Street Hypn.. No Information Mint Extra Loaded No Information Fresh 40 with Dynamite MC Kisstory No Information The Distillery Smash Hits! Sunday Informazioni Pagina Guida Completa Esci

(ENTER) DTV Cable 900 f tn Freshmen On Campus 2:00 - 2:30 No Detailed Information

▼ 903 Today f tn ITV Play Kerrang! Kiss oneword Smash Hits! 2:00 - 3:00 Freshmen O.. Street Hypn.. Mint Extra Loaded Fresh 40 with Dynamite MC The Distillery Smash Hits! Sunday Guarda Information 2:10 Tue 1 Jun UKTV Gold UKTV style

C -A 3 ♥ C -A 4 C -A 5 C -A 6 C -A 7 C -A 8 C -A Tutto Strumenti UKTV Gold UKTV style Tipo canale Zoom ❑ Menu Channel List Option (in Programme med ) Tutto 1 / 1 / 2009 13:59

Zoom ❑ Modifica Nome VCR / DVD / VCR / DVD / Cable STB / Satellite STB / PVR STB / AV Receiver / Game / Camcorder / PC / DVI PC / Programmi supportati ❑ Auto diagnosi

Spec. VESA (A * B) 19" ~22" 100 * 100 23"~29" 200 * 100 30"~40" 200 * 200 46"~55" 400 * 400 57"~70" 800 * 400 80" ~ 1400 * 800 42"~ 50" 400 * 400 58"~ 63" 600 * 400 70" ~ 800 * 400 80" ~ 1400 * 800 Vite standard Quantità

50 °F to 104 °F (10 °C to 40 °C) -4 °F to 113 °F (-20 °C to 45 °C) YPBPR_INP USB .0 (HDMI 1.3) HDMI_IN CVBS SPDIFO AUOUTRL0 IC_OUT UART LVDS_OUT BGA400 AULR1 MSD3HCG CVBS1 AUOUTRL1 CVBS out EXT_ADDR[0:14] SPI MDATA[15:0] MADR[1:0] EXT_DATA[0:]

SIF0 CVBS0 SPDIF_OUT HP_L/R Debug IR, KEY LVDS (-Bit) 4HC405D UART MAX3E MAX HP_OUT SPDIF OUT Speaker L/R HEAD PHONE Debug WALL FUNCTION KEY A ‘cracking’ noise may occur when the product contracts or expands due to a change of surrounding environment such as temperature or humidity. This is normal and not a defect of the unit. Life On Venus Avenue Unclassified No Detaild Information 18:00 ~ 6:00 f tn ITV Play Kerrang! Kiss oneword Smash Hits! Ver Actual Freshmen O.. Street Hypn.. Mint Extra Loaded Fresh 40 with Dynamite MC The Distillery Smash Hits! Sunday Información página DTV Cable 900 f tn Freshmen On Campus 2:00 - 2:30 No Detailed Information 2:10 Tue 1 Jun f tn ITV Play Kerrang! Kiss oneword Smash Hits! 2:10 Tue 1 Jun

C -A 3 ♥ C -A 4 C -A 5 C -A 6 C -A 7 C -A 8 C -A Todos UKTV Gold UKTV style UKTV Gold UKTV style

A 3 A 4 A 5 A 6 A 7 A 8 C -C -C -C -C -C -C -- Añadir a Favoritos / Delete to Favourite Regular broadcast (Standard audio) NICAM Dual-2 Mono (Normal) Mono (Normal use) VCR / DVD / VCR / DVD / Cable STB / Satellite STB / PVR STB / AV Receiver / Game / Camcorder / PC / DVI PC / Vertical Frequency (Hz) Pixel Clock Frequency (MHz) Sync Polarity (H/V) PS42B430 PS50B430 640 x 350

640 x 480 VESA DMT 800 x 600 1024 x 768 VESA CVT VESA GTF 1280 x 720 1280 x 720

❑ Software Superior VESA Spec. (A * B) 19" ~22" 100 * 100 23"~29" 200 * 100 30"~40" 200 * 200 46"~55" 400 * 400 57"~70" 800 * 400 80" ~ 1400 * 800 42"~ 50" 400 * 400 58"~ 63" 600 * 400 70" ~ 800 * 400 80" ~ 1400 * 800 Standard Screw Quantity

Dimensiones (An x Al x P) Cuerpo principal 1056 x 660 x 74 mm 1221 x 749 x 74 mm Con soporte 1056 x 721 x 316 mm 1221 x 810 x 316 mm Cuerpo principal 24 kg 31 kg Con soporte 28 kg 35 kg Peso 50 °F to 104 °F (10 °C to 40 °C) Life On Venus Avenue Unclassified No Detaild Information 18:00 ~ 6:00 Guia completo Guia predef. : Act./Post. DTV Cable 900 f tn Freshmen On Campus 2:00 - 2:30 No Detailed Information

▼ 903 f tn ITV Play Kerrang! Kiss oneword Smash Hits! 2:10 Tue 1 Jun Act. Freshmen O.. Street Hypn.. Mint Extra Loaded Fresh 40 with Dynamite MC The Distillery Smash Hits! Sunday Ver Informação DTV Cable 900 f tn Freshmen On Campus 2:00 - 2:30 No Detailed Information Sair Today f tn ITV Play Kerrang! Kiss oneword Smash Hits! 2:10 Tue 1 Jun 2:00 - 3:00 Freshmen O.. Street Hypn.. Mint Extra Loaded Fresh 40 with Dynamite MC The Distillery Smash Hits! Sunday Ver Informação Mini guia Guia predef. Canal UKTV Gold UKTV style C --

C -A 3 ♥ C -A 4 C -A 5 C -A 6 C -A 7 C -A 8 C -A Todos Adicionar aos favoritos / Delete to Favourite UKTV Gold UKTV style Zoom Selec. Ferramentas Informação Português - 16 BN68-02353A-Por.indb

2009-6-30 10:00:40 Regular + NICAM Mono NICAM Mono (Normal) NICAM-Estéreo NICAM Estéreo Mono (Normal) 50 °F to 104 °F (10 °C to 40 °C) -4 °F to 113 °F (-20 °C to 45 °C) © 2008 2009 Samsung Co.,Co., Ltd.Ltd. All rights reserved. SamsungElectronics Electronics All rights reserved. Slovenščina - BN68-02353A-Sln.indb

2009-6-30 10:01:35 Gumbi na sprednji plošči N The product colour and shape may vary depending on the model. Vhod Video Avdio(L/R (L/D)) RGB

Add to Favourite U Move E Enter e Exit Life On Venus Avenue Unclassified No Detaild Information 18:00 ~ 6:00 Time Broadcast Security General Slovenščina - 11 BN68-02353A-Sln.indb

2009-6-30 10:01:46 Analogue Channel ❑ Cable Search Options (Cable) N S številskimi gumbi (0–9) nastavite Frequency (Start~Stop) in Symbol Rate. Now & Next Guide Channel List Channel Mode : Added Ch. Fine Tune DTV Cable 900 f tn Freshmen On Campus 2:00 - 2:30 No Detailed Information

▼ 903 2:10 Tue 1 Jun Now Freshmen O.. Street Hypn.. Mint Extra Loaded Fresh 40 with Dynamite MC The Distillery Smash Hits! Sunday Watch Information Page f tn ITV Play Kerrang! Kiss oneword Smash Hits! DTV Cable 900 f tn Freshmen On Campus 2:00 - 2:30 No Detailed Information

▼ 903 f tn ITV Play Kerrang! Kiss oneword Smash Hits! Watch 2:00 - 3:00 Freshmen O.. Street Hypn.. Mint Extra Loaded Fresh 40 with Dynamite MC The Distillery Smash Hits! Sunday Page Information 2:10 Tue 1 Jun Channel List Channel Mode : Added Ch. Fine Tune

Added Channels UKTV Gold UKTV style C --

C -A 3 ♥ C -A 4 C -A 5 C -A 6 C -A 7 C -A 8 C -A All Channel Type Zoom

Add to Favourite/Delete from Favourite Add to Favourite

All UKTV Gold UKTV style Channel Type Timer Viewing Edit Channel Name Sort Lock Zoom Select

Tools Timer Viewing ❑ Channel List Tools Menu (in Programmed) All 1 / 1 / 2009 13:59

ChangeQuincy, Info M.E TV1 Cancel Schedules TV3 The Equalizer Information TV3 McMillan & Wife Select All TV3 M.Spillane’s mike Hammer Zoom Select Tools Information Slovenščina - 16 BN68-02353A-Sln.indb

2009-6-30 10:01:48 ❑ Advanced Settings Black Tone → Off / Low / Medium / High White Balance Colour Tone → Cool / Normal / Warm1 / Warm2 : G50/R50 Advanced Settings Picture Options

Picture Reset Size Digital NR → Off / Low / Medium / High / Auto HDMI Black Level → Normal / Low Screen Burn Protection Equalizer SRS TruSurround HD : Off ❑ Equalizer Audio Language

❑ SRS TruSurround HD → Off / On Audio Description → Off Volume Source List/Edit Name ❑ Source List Input Source List Edit Name ❑ Software Upgrade Spec. VESA (A * B) 19" ~22" 100 * 100 23"~29" 200 * 100 30"~40" 200 * 200 46"~55" 400 * 400 57"~70" 800 * 400 80" ~ 1400 * 800 42"~ 50" 400 * 400 58"~ 63" 600 * 400 70" ~ 800 * 400 80" ~ 1400 * 800 Standardni vijak Količina

-4 °F to 113 °F (-20 °C to 45 °C) 0 Control the cursor in the menu Life On Venus Avenue Unclassified No Detaild Information 18:00 ~ 6:00 DTV Cable 900 f tn Freshmen On Campus 2:00 - 2:30 No Detailed Information

▼ 903 f tn ITV Play Kerrang! Kiss oneword Smash Hits! 2:10 Tue 1 Jun Şimdi Freshmen O.. Street Hypn.. Mint Extra Loaded Fresh 40 with Dynamite MC The Distillery Smash Hits! Sunday İzle Bilgi DTV Cable 900 f tn Freshmen On Campus 2:00 - 2:30 No Detailed Information

▼ 903 Today f tn ITV Play Kerrang! Kiss oneword Smash Hits! 2:00 - 3:00 Freshmen O.. Street Hypn.. Mint Extra Loaded Fresh 40 with Dynamite MC The Distillery Smash Hits! Sunday İzle Bilgi 2:10 Tue 1 Jun UKTV Gold UKTV style C --

C -A 3 ♥ C -A 4 C -A 5 C -A 6 C -A 7 C -A 8 C -A Tümü Kanal Tipi Zoom Araçlar Seçim UKTV Gold UKTV style Kanal Tipi NICAM Çift I-II NICAM Çift-2 Manufacturer: SAMSUNG ELECTRONICS CO., LTD 12th FL., Samsung Main Bldg., 250, 2-Ka Taepyung-Ro, Seoul, Korea Tel) 82-2-727-7114 BN68-02353A-Tur.indb

LVD: KTL (Korea Testing Laboratory) 222-13, Kuro-Dong, Kuro,Seoul, 152-848, Korea Tel) 82-2-860-1493 Fax) 82-2-860-1482 EMC: Samsung Electronics Co., Ltd. Suwon EMC Test Laboratory416 Maetan-3 Dong, Yeongtong-Ku, Suwon City, Gyeonggi-Do, Korea, 443-742 Tel) 81-31-200-2185, Fax) 81-31-200-2189 2009-6-30 9:48:43
