CWB 9910 X - Dishwasher BEKO - Free user manual and instructions
Find the device manual for free CWB 9910 X BEKO in PDF.
📄
Document temporarily unavailable
The manual is currently being transferred to our new server. It will be accessible again in a few hours. Thank you for your patience.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product type | Extractor hood |
| Brand | BEKO |
| Model | CWB 9910 X |
| Category | Cooker hood |
| Minimum safety distance (cooking surface) | 45 cm (for electric, gas or induction hobs) |
| Extraction connection diameter | 150 mm recommended |
| Power supply | Single phase, 220-240 V (check rating plate) |
| Electrical class | Class II (no earth connection) |
| Power | Refer to the rating plate |
| Controls | Touch controls with digital display |
| Motor speeds | 3 speeds + intensive function (10 min) |
| Lighting | Halogen lamps (replaceable) |
| Grease filters | Washable (every 2 months) or dishwasher safe |
| Charcoal filter | Non-washable, replace every 3 months max |
| Clean Air function | Automatic operation 10 min/h at 1st speed |
| Automatic shut-off timer | 15 minutes |
| Filter saturation indicator | Button flashing (grease or charcoal filter) |
| Installation version | External extraction or recirculation (optional kit) |
| Optional accessories | Decorative flues, noise reduction kit, recirculation kit |
| Maintenance | Clean surfaces with denatured alcohol or mild detergent |
| Repairability | Spare parts available (lamps, filters, motor) |
| Environmental standards | Compliant with WEEE (recycle at waste disposal centre) |
Frequently Asked Questions - CWB 9910 X BEKO
How to clean the grease filters?
Remove the filters and wash them with water and a mild liquid detergent. Rinse thoroughly with warm water and let dry. They can also be washed in the dishwasher. Clean them every 2 months at least.
When to change the charcoal filter?
The charcoal filter is neither washable nor reusable. It must be replaced every 3 months maximum, or more often with heavy use. Saturation depends on usage and cleaning of the grease filter.
How to replace the halogen lamps?
Turn off the hood and unplug it. Remove the glass by prying in the slots provided. Replace the lamps with lamps of the same type. Do not touch the lamps with bare hands.
What to do if the filter saturation indicator flashes?
If the indicator flashes at 2-second intervals, the grease filters need to be washed. If it flashes rapidly (0.5 seconds), the charcoal filters need to be replaced. After cleaning or replacement, press the A button for 5 seconds to reset the memory.
How to activate the Clean Air function?
With the hood off, press the E (or F depending on model) button for 2 seconds. The hood will automatically run for 10 minutes per hour on the first speed. To deactivate, press any button other than the lighting.
What is the minimum distance between the hood and the hob?
The minimum distance must be at least 45 cm for electric, gas or induction hobs. Respect this distance to ensure safety.
Can I use the hood in recirculation mode?
Yes, your hood can be set to recirculation mode. You will need a recirculation kit containing additional charcoal filters. Follow the assembly instructions provided with the kit.
What to do if the hood does not turn on?
First check the power supply: socket, fuse, circuit breaker. Make sure the plug is properly inserted. If the problem persists, contact a qualified electrician or after-sales service.
How to clean the exterior of the hood?
Use a cloth moistened with denatured alcohol or a non-abrasive mild liquid detergent. Avoid abrasive products that could scratch the surface. Clean regularly to prevent grease deposits.
What does the display flashing mean?
The display may flash to indicate filter saturation (see corresponding question) or to signal the intensive function (speed 3 maintained). Consult the instruction manual for details of the codes.
