FC9323 - Vacuum Cleaner PHILIPS - Free user manual and instructions
Find the device manual for free FC9323 PHILIPS in PDF.
📄
Document temporarily unavailable
The manual is currently being transferred to our new server. It will be accessible again in a few hours. Thank you for your patience.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product type | Bagless canister vacuum cleaner |
| Brand | Philips |
| Model | FC9323 |
| Color | Not specified (plastic, typically gray/black) |
| Body material | ABS plastic |
| Filter type | Permanent cylindrical filter, washable HEPA 13 Ultra Clean Air filter, motor protection filter |
| Dust container capacity | Approximately 2 liters (estimate) |
| Suction power | 5 adjustable levels via MIN/MAX buttons |
| Power supply | 230 V ~ 50 Hz (European standard) |
| Power cord length | Approximately 6 meters (estimate) |
| Operating radius | Approximately 9 meters (with hose and tube) |
| Main brush type | Tri-Active brush (depending on model) with hard floor/carpet selector |
| Included accessories | Crevice tool, small nozzle, small brush, parquet brush, combination brush, accessory holder |
| Special functions | Filter cleaning button, cleaning indicator, automatic motor stop during cleaning |
| Noise level | Not specified (approximately 75-80 dB(A)) |
| Weight | Approximately 4.5 kg (estimate) |
| Dimensions (L x W x H) | Approximately 40 x 25 x 30 cm (estimate) |
| Cylindrical filter maintenance | Clean by tapping or using dedicated button; do not wash with water |
| HEPA filter maintenance | Washable with warm water every 6 months, replace after 4 washes |
| Motor filter maintenance | Clean every 2 months, rinse with cold water |
| Safety | Do not vacuum water, liquids, hot ashes, flammable materials; check mains voltage |
| Repairability | Spare parts available through Philips service; HEPA filter reference FC8038 |
| Warranty | International warranty; registration recommended at www.philips.com |
| General information | Manual available in multiple languages; consumer assistance by country |
Frequently Asked Questions - FC9323 PHILIPS
How do I clean the cylindrical filter of my Philips FC9323 vacuum cleaner?
The cylindrical filter is cleaned by tapping. You can also use the filter cleaning button on the appliance: place the vacuum cleaner horizontally, hose attached, press the button. The indicator lights up and a beep sounds. Cleaning takes a few seconds. Never wash the filter with water.
Why is the suction power of my Philips FC9323 vacuum cleaner low?
Several possible causes: 1) The power level is too low, increase it with the MIN/MAX buttons. 2) The cylindrical filter is dirty, clean it. 3) The HEPA filter or motor filter is dirty, clean them. 4) The hose or nozzle is blocked, unplug and remove the obstruction.
How do I empty the dust container of the Philips FC9323?
Turn off and unplug the vacuum cleaner. Press the cover release button, open it. Remove the container, then take out the cylindrical filter holder. Empty the dust into a trash can. Clean the container with cold water and a little dish soap. Dry before reassembling.
The filter cleaning button indicator is blinking, what should I do?
This indicates that the cylindrical filter needs cleaning. Press the filter cleaning button to clean it automatically. If you ignore the warning, the suction power will decrease.
How do I wash the HEPA 13 Ultra Clean Air filter?
Remove the grille and filter. Rinse the pleated side under warm water holding the filter so that the water flows parallel to the pleats. Do not brush. Shake off excess water and let dry for at least 2 hours before reinstalling. The filter can be washed up to 4 times.
How do I use the Tri-Active brush for hard floors or carpets?
The Tri-Active brush has a selector that can be operated with your foot. For hard floors, press the selector: the brush strip comes out and the wheel lifts. For carpets, press again to retract the brush strip and lower the wheel.
Can I vacuum water with the Philips FC9323 vacuum cleaner?
No, absolutely not. The vacuum cleaner is designed only for dry use. Never vacuum water, liquids, hot ashes, or flammable substances. This would damage the appliance and pose a danger.
How do I rewind the power cord?
Turn off and unplug the vacuum cleaner. Press the cord rewind button on the appliance to automatically rewind the cord.
What should I do if the vacuum cleaner does not turn on and the indicators are blinking?
This means that the cylindrical filter holder is not properly inserted into the container. Open the cover, make sure the filter holder is in place and the cylindrical filter is engaged. Close and try again.
Where to find spare parts for the Philips FC9323?
Spare parts, such as the HEPA filter (reference FC8038), are available from the Philips Consumer Service in your country. Check www.philips.com or the warranty leaflet for contact details.
