ALPATEC AC 280 - AC280KT - Air-conditioner

AC 280 - AC280KT - Air-conditioner ALPATEC - Free user manual and instructions

Find the device manual for free AC 280 - AC280KT ALPATEC in PDF.

English EN ⬇ Download 💬 AI Question ❓ 10 questions ⚙️ Specs
📄

Document temporarily unavailable

The manual is currently being transferred to our new server. It will be accessible again in a few hours. Thank you for your patience.

View the manual : Français FR English EN Español ES Português PT
Pick your language and provide your email: we'll send you a specifically translated version.
Product type Evaporative air cooler
Brand ALPATEC
Model AC 280 / AC280KT
Power supply 220-240 V, 50 Hz
Fan power 46 W
Standby consumption 0.47 W
Maximum air flow 10.39 m³/min
Maximum air speed 2.97 m/s
Noise level 56 dB(A)
Service value (SV) 0.23 (m³/min)/W
Functions Ventilation, Humidification, Ionization, Oscillation
Ventilation modes Normal, Natural, Sleep
Speeds Low (L), Medium (M), High (H)
Timer 0.5 to 7.5 hours
Remote control Yes, included
Filter Washable honeycomb filter
Swivel wheels Yes, for easy mobility
Safety Thermal safety protection (automatic shut-off in case of overheating)
Maintenance Clean filters every two weeks

Frequently Asked Questions - AC 280 - AC280KT ALPATEC

How to clean the filter of my ALPATEC AC 280 air conditioner?
Unplug the appliance. Remove the front panel by unscrewing the fixing bolts. Take out the filter and the honeycomb filter. Clean them with warm water and mild detergent, rinse and let dry before reinstalling.
How to set the timer on the device?
Use the timer button on the control panel or remote control. Each press increases the time by half an hour, up to a maximum of 7.5 hours. The indicators show the set time. To deactivate, press again until all indicators turn off.
How to activate the oscillation function?
Press the oscillation button (on the device or remote control). The corresponding indicator lights up. The fan rotates left and right over an angle of 75°. To deactivate, press again.
What is the ionizer function for?
The ionizer function generates negative ions that help eliminate static electricity, odors and smoke. Activate it by pressing the ion button. The corresponding indicator lights up.
Why is my device not working?
First check that the plug is properly connected and power is supplied. Make sure you have pressed the ON/OFF switch. If nothing happens, an internal component may be defective; contact the technical support.
How to fill the water tank?
Pull the water tank about 10 cm backwards. Fill it with clean water up to the MAX level. Replace it properly. Use this function for humidification.
How to use the remote control?
The remote control works with batteries (not supplied). Point it at the device. The buttons are: ON/OFF, oscillation, mode, speed, timer, cool, humidification and ions. The range is about 5 meters.
What to do if the device makes noise?
Check that all parts are correctly assembled: filter, water tank and wheels. If the noise persists, a wheel may be broken or there may be an internal problem; contact technical support.
How to switch to natural ventilation mode?
Press the Mode button until selecting Natural mode. The corresponding indicator lights up. This mode produces a natural and irregular breeze. You can adjust the speed with the Speed button.
How to store the device after the season?
Empty and clean the water tank. Wash and dry the filters. Store the device in its original packaging, in a dry place away from dust and sunlight.
