Product type	External DVD burner/player
Brand	JVC
Model	CU-VD50E
Dimensions (W x H x D)	152 x 42 x 195 mm
Weight	Approx. 920 g (without AC adapter or cables)
Power supply	AC adapter AP-V50U: input AC 110-240 V, 50/60 Hz; output DC 5.3 V, 3.5 A
Compatible discs (read/write)	DVD-R, DVD-RW, DVD-R DL (for writing with Everio HD camcorder or PC only)
Playback formats	AVCHD, DVD-video, data discs (MPEG-2 video, JPEG still images)
Video outputs	HDMI (1080p/1080i/720p/576p/576i), component video Y/Pb/Pr, composite video
Audio outputs	RCA stereo audio (2 V), HDMI audio (PCM 2 channels)
PC interface	USB 2.0 (USB 1.1 compatible)
Main functions	Direct copy from Everio camcorder, DVD burning from PC, DVD playback, HDMI-CEC functions
Included accessories	AC adapter, power cord, USB mini A-mini B cable, audio/video cable, stand, remote control (CR2025 battery included), 1 blank DVD-R, software CD-ROM, manual
Power consumption	2.3 A (rated current)
Operating temperature	0 °C to 35 °C
Maintenance and cleaning	Wipe the exterior with a dry cloth. Clean the disc tray with a soft, dry cloth. Do not touch the lens. Clean discs with a soft cloth from the center outward.
Safety	Class 1 laser product. Do not open or repair yourself. Unplug if smoke or abnormal odor occurs. Use only the supplied adapter and cord.
Spare parts and repairability	Remote control battery: CR2025 (Panasonic, Sanyo, Sony, or Maxell). For repairs, contact an authorized JVC dealer.
General information	Warranty: consult your dealer. Compliant with European directives (CE). Dispose of in accordance with WEEE and battery regulations.

Frequently Asked Questions - CU-VD50E JVC

What types of discs can I use with this burner?

Use DVD-R, DVD-RW, or DVD-R DL (single-sided dual layer) from recommended brands: JVC, TDK, Verbatim, SONY. Do not use DVD+R, DVD+RW, or DVD-RAM. DVD-R DL discs can only be used with an Everio HD camcorder or a computer.

How do I connect the burner to a TV?

You can use an HDMI cable (for HD quality), a component video cable (Y/Pb/Pr), or a composite audio/video cable (RCA). See pages 12-13 of the manual for connection diagrams. Make sure the TV is set to the corresponding input.

Can I copy videos directly from my Everio camcorder without a computer?

Yes. Connect the burner to the Everio camcorder using the supplied USB cable. Turn on the camcorder in play mode, insert a blank disc into the burner, then follow the on-screen instructions on the camcorder to copy. The copy creates an AVCHD disc, a data disc, or a DVD-video depending on the model.

The burner does not recognize the disc, what should I do?

Check that the disc is compatible (DVD-R/RW/DL) and inserted with the label facing up. Clean the disc with a soft cloth. If the problem persists, try another recommended disc. If the indicator blinks red, wait for the burner to cool down.

How do I play an AVCHD disc on this burner?

Insert the disc, the playback browser appears after about 40 seconds. Use the remote control to select and play files. You can also use the condensed playback function (preview). To stop, press STOP, then NAVIGATION/TOP MENU to return to the browser.

The remote control does not work, what should I do?

Check that the battery (CR2025) is correctly inserted and that there is no insulating sheet. Replace the battery if necessary. The remote control does not work if the tray is open or if the burner is connected to an Everio camcorder (only the power button works then). Bring it within 5 m.

Can I use this burner as a DVD burner for my computer?

Yes. Connect the burner to the computer via USB. Install the supplied CyberLink Power2Go 5.5 Lite software (under Windows XP/Vista 32-bit). You can then burn data to DVD-R/RW/DL. Note: the software does not allow video editing; use PowerDirector for that.

What does the blinking red indicator mean?

A slow red blinking indicates a drop in internal temperature of the burner. Some functions may stop. Wait for the indicator to turn off before using the unit. If the problem persists, turn off and unplug for a few minutes.

How do I finalize a disc so it is playable on other devices?

After copying from an Everio camcorder, finalize the disc via the camcorder menu. For discs burned on PC, in Power2Go, under the 'Burner' tab, check 'Close disc' to finalize. An unfinalized disc may not play correctly on other players.

Can I use this burner with a Mac?

No, the burner and the provided software are not compatible with Macintosh. It works only under Windows (XP or Vista 32-bit).

USER MANUAL CU-VD50E JVC

La lecture commence!

PRODUIT LASER DE CLASSE 1

REPRODUCTION DES ÉTIQUETTES

ÉTIQUETTE D'AVERTISSEMENT A L'INTEREUR DE L'APPAREL

CAUTION CLASS 38 VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN, AVOID EXPOSURE TO THE BEAM.

ATTENTION RADIATIONS LASER VISELES ET INVISIBLES DE CLASSE 38 QUAND OVERT. EVITEZ TOUT EXPOSITION AU FAISCEAU.

ADVARMSEL KLASSE 38 SYNULIG OG USYNLIG LASERSTRAUING VED ABBING. UNOGA UDS/ETTELSE FOR STRAUKING.

AVATTAESSA OLET ALTIINA NAKYVALLE JA

VARDI: NAKYMATTGMALELUOKAN 3B LASERSATEXYL ALA KATSOS SATESEEN.

WARNING KCLASS 38 SYNCH OCS OSYNER LASSTRAINING NAR DENNA DEL A RPPONAD. UNOVIK ATT UTSATI DIF FOR STRALEN.

BE GEFORDEN FABEOCKING IS SICHBARTE UND UNSICHTBART LEUZHARD. 1985. THE ADOPTOMY OF ANTI-PROTEIN BINDING PROTEIN. VORHANDEK. NOTCH DEM LASERSTRAH, AUSSEZTEN!

PRECAUCTION CUANDO SE ABRE HAY RADIATION LASER DE CLASE 38 VISIBLE INVISIBLE, EVITE LA EXPOSION A LOS RAVOS LASER.

CLASS 33 VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN, A/OID EXPOSURE TO THE BEAM.

ATTENTION

RADIATIONS LASER VISIBLES ET INVISIBLES DE CLASSES 38
QUIO UOVERT. EVITZ TOUT EXPERTUON AU FAISCEAU

ADVARSEL KLASSE 38 SYNILE OG USYNIG LASERSTRAING VED ABBING. UNGA UDSUTSETTE FOR STRAUNG

VAATEAESTA QET ALTTTA NAKVJALI VA
VARO! NAKTAYA KANAN 38 LASERSTABLEA LA KATO SDATSEESEN.

VARNING KCLASS 3B SYNLIG OCH OSYNLIG LASERSTRALNING NAR DENNA

DEL AR OPPNAD. UNOVIK ATT UTSATTA DIG FOR STRALEN

BE GEOFFNETER ABDECKUNG IST SICHTBARE UND UNSICHTBARE
