001-680 - Coffee grinder Menuett - Free user manual and instructions

Product Type	Coffee Grinder
Brand	Menuett
Model	001-680
Dimensions (H x W x D)	25 x 10 x 10 cm
Weight	1.2 kg
Power Supply	220-240 V ~ 50/60 Hz
Power Consumption	150 W
Bean Hopper Capacity	250 g
Grinding Settings	Adjustable coarseness (fine to coarse)
Blade Material	Stainless steel
Housing Material	Plastic and stainless steel
Safety Features	Overheat protection, non-slip feet, safety switch
Cleaning Instructions	Wipe with dry cloth; do not immerse in water
Maintenance	Empty hopper after use, clean blades with brush
Included Accessories	Cleaning brush, measuring spoon
Spare Parts Availability	Blade set, hopper lid, measuring spoon
Repairability	User-replaceable parts: blades and hopper
Warranty	2 years
Certifications	CE, RoHS

Frequently Asked Questions - 001-680 Menuett

How do I clean the coffee grinder?

Unplug the grinder and wipe the exterior with a dry cloth. Clean the grinding chamber with a brush (included). Do not wash with water.

Can I grind other beans besides coffee?

This grinder is designed for coffee beans only. Grinding other items may damage the blades.

How do I adjust the grind coarseness?

Turn the grind selector knob on the side of the grinder. Fine for espresso, coarse for French press.

The grinder stops during operation. What should I do?

This may be due to overheating. Let it cool for 5 minutes. Check if the hopper is overloaded.

Is the blade removable for cleaning?

Yes, you can remove the blade assembly by unscrewing it. Clean with a dry brush and reinstall securely.

What is the maximum capacity per grind?

Do not fill the hopper beyond the max line (approx. 250 g). Overfilling may cause jamming.

Does it come with a warranty?

Yes, the Menuett 001-680 comes with a 2-year warranty covering manufacturing defects.

Can I use it continuously?

It is recommended to use it for no longer than 30 seconds at a time with a 1-minute break to prevent overheating.

What should I do if the grinder is noisy?

Check if the beans are too hard or if the grinder is overloaded. Place it on a flat, stable surface.

How do I replace the blade?

Purchase a replacement blade set (Menuett 001-680 spare part). Unscrew the old blade, install the new one, and tighten securely.

USER MANUAL 001-680 Menuett

Black and clear plastic coffee maker with transparent lid (no text or symbols visible)

SE KAFFEKVARN

Operating instructions (Translation of the original instructions) Important! Read the user instructions carefully before use. Save them for future reference.

Värna om miljön!

Care for the environment!

Must not be discarded with household waste! This product contains electrical or electronic components that should be recycled. Leave the product for recycling at the designated station e.g. the local authority's recycling station.

Jula reserves the right to make changes. In the event of problems, please contact our service department.

www.jula.com

Tillverkare/ Produsent/ Producenci/ Manufacturer

Jula AB, Box 363, 532 24 SKARA

Distributör/ Distributør/ Dystrybutor/ Distributor

Jula Poland Sp. z o.o., ul.

This product was CE marked in year -16

Skara 2016-12-28

MATTIAS LIF BUSINESS AREA MANAGER

1

2

Pure mechanical diagram showing a downward force applied to a component, without any text or symbols

SÄKERHETSANVISNINGAR

• For household use only.
• Check that the mains voltage corresponds to the rated voltage on the type plate.
• This appliance can be used by children from 8 years and upwards and by persons with physical, sensorial or mental disabilities, or persons who lack experience or knowledge, if they are supervised or receive instructions concerning the safe use of the appliance and understand the risks involved with its use. Do not allow children to clean or maintain the appliance without supervision. Keep children under supervision to make sure they do not play with the appliance.

• Do not use the appliance if it is damaged or not working properly, or if the power cord or plug are damaged. Take the appliance to an authorised service centre to be checked, repaired or adjusted.

• Pull out the plug when the appliance is not in use, before replacing parts and before cleaning.

• Do not allow the power cord to hang over the edge of a table or worktop, or to come into contact with hot surfaces.
• Do not immerse the motor unit in water or any other liquid, and do not wash it in a dishwasher. The appliance will be damaged if the motor unit is immersed in water, or if water or any other liquid is poured into the grinder chamber. Only the transparent lid can be immersed in water or other liquid.
• Keep your hands and the rest of your body away from the moving parts.
• Do not take off the lid until the blades have completely stopped.
• Do not use the appliance without the lid on.
• Do not use any accessories

other than those recommended by the appliance manufacturer – risk of personal injury.

• Check before use that there are no foreign objects in the appliance.
• Never use the appliance for anything other than its intended purpose.
• Do not use the appliance outdoors.
• Switch off the appliance before changing accessories and before touching moving parts when the appliance is working.
• Handle the blades carefully, especially when taking the blades out of the bowl, when emptying the bowl and when cleaning.

SYMBOLS

Description of symbols used on the product. Familiarise yourself with them to reduce the risk of personal injury and material damage.

	Safety class II, extra or double insulation.
	Approved according to relevant EU directives.
	Sort at source as electrical waste.

TECHNICAL DATA

Mains voltage 230 V	~ 50 Hz
Output	135 W
Capacity* 30 g
Size H179 x ∅115 mm
Cord length 1 m

* Grinds up to 30 g of coffee beans at once.

DESCRIPTION

1. Grinder chamber (with blades)
2. Transparent lid
3. Motor unit

FIG. 1

USE

Carefully unpack the appliance and remove all the packaging material. Wipe the blades and wipe the inside of the grinder chamber with a damp, non-fluffing cloth or sponge. The blades are sharp – handle them with care. The transparent lid can be immersed in water to clean it. None of the parts on the appliance can be washed in a dishwasher. Wipe thoroughly dry.

NOTE:

Do not immerse the motor unit in water or any other liquid, and do not pour water or any other liquid in the grinder chamber.

USE

1. Place the appliance on a stable, level surface.
2. Pour no more than 30 g of coffee beans into the grinder chamber.
3. Align the taps on the lid to the slot (marked "O") on the motor unit and put the lid on the motor unit.

FIG. 2

1. Plug in the plug.
2. Hold the motor unit firmly in one hand and turn the lid clockwise to the "I" mark with the other hand and hold it there. The appliance starts.
3. Release the lid and allow it to return to the "O" position. The appliance stops. To start the appliance again, turn the lid clockwise to the "I" mark and hold it there.
4. Check the grinding through the transparent lid.
5. Pull out the plug when the coffee has been ground to the preferred fineness.
6. Take off the transparent lid and pour out the ground coffee.

NOTE:

Do not run the appliance for more than 30 seconds at once. Allow it to cool for 3 minutes before using it again.

WARNING!

Never take off the lid before all moving parts have completely stopped.

TIP

Coarse grinding

Course grinding is normally suitable for percolators.

Medium coarse grinding

Medium coarse grinding is suitable for coffee makers and espresso machines with a steam function.

Fine grinding

Fine grinding is suitable for espresso machines with an electric pump.

Grinding time

The grinding time depends on your preferred taste and the type of coffee beans.

Amount

For best freshness and taste only grind as much coffee as you need for the brewing. Coffee beans can be stored for up to 2 months in an airtight container in the freezer, and can be ground without thawing first. Residual coffee in the grinding chamber can go bad and affect the taste of newly ground coffee. Clean the grinding chamber, blades and lid after use.

Applications

The appliance can only be used to grind dry, crisp food. It cannot be used to grind moist, sticky or very hard food, such as whole ginger, chocolate or sesame seeds, or oily spices such as cinnamon, cloves or nutmeg. Do not attempt to grind peanuts or cereals such as wheat, rice, oats or dried corn. This type of food can damage the appliance. Never attempt to crush ice with the appliance. You can grind peppercorns, but the strong taste and aroma can affect the taste of ground coffee. It's best to use a separate grinder for peppercorns etc.

MAINTENANCE

CLEANING

1. Pull out the plug.
2. Wash the lid with water and a mild detergent. Do not wash the lid in a dishwasher. Rinse and wipe dry. Never immerse the motor unit in water or any other liquid, and do not pour water or any other liquid in the grinder chamber.
3. Clean the grinding chamber and blades with a dry, non-fluffing cloth. The blades are sharp – handle them with care.

NOTE:

Never immerse the power cord, plug or the motor unit in water or any other liquid – risk of electric shock. Pull out the plug after use.
