Product Type	mLAN Audio Interface Card
Brand	YAMAHA
Model	MY8-MLAN
Connectivity	IEEE 1394 (FireWire) 6-pin, 2 front mLAN jacks, rear OPTION I/O slot connector
Audio Inputs	8 digital audio inputs (via mLAN)
Audio Outputs	8 digital audio outputs (via mLAN)
MIDI	1 MIDI input, 1 MIDI output (via mLAN)
Sampling Rate	44.1 kHz, 48 kHz
Bit Rate	S200 (IEEE 1394)
Power Consumption	2.2 W (440 mA / +5 V)
Display	mLAN 1/2 LED, ACTIVE LED, RT/ERR LED
Settings	DIP switch (SW1) for enabling audio inputs/outputs and MIDI, module number selection
Included Software	mLAN Tools (CD-ROM), mLAN Patchbay
Compatibility	AW4416 (v2.0 or later), AW2816 (v1.1 or later), 01V, and other mLAN devices
Safety Precautions	Disconnect power before installation, avoid static electricity, do not touch metal pins
Maintenance	Handle with care, avoid shocks, keep screws away from inside of devices
Environment	For indoor use, avoid humidity

Frequently Asked Questions - MY8-MLAN YAMAHA

What devices are compatible with the MY8-mLAN card?

The MY8-mLAN card is compatible with Yamaha AW4416 (v2.0 or later) and AW2816 (v1.1 or later) audio workstations, the 01V digital mixing console, and any mLAN device equipped with an IEEE 1394 port.

How to install the MY8-mLAN card?

Before installation, turn off the host device and disconnect the power cable. First set the DIP switch (SW1) according to your configuration. Install the card into the designated slot, then reconnect the power. Refer to your host device manual for details.

What do the LEDs on the card mean?

The green mLAN 1/2 LED indicates the device is a leaf node, red signals possible audio interruption. The green RT/ERR LED indicates a root node, red/orange indicates an error. The blue ACTIVE LED indicates the relay function between mLAN jacks is active.

How to configure the DIP switch (SW1)?

The DIP switch has 8 positions: position 1 enables/disables audio outputs, position 2 audio inputs, position 3 MIDI, and positions 4 to 8 set the module number (1 to 31). Set before installation; modification requires removing the card.

Can I use multiple MY8-mLAN cards in the same system?

Yes, you can use multiple cards. Ensure that each card is assigned a different module number via DIP switches 4-8 to distinguish them in the mLAN Patchbay application.

How to connect the card to a computer?

Use a standard IEEE 1394 cable (6-pin) to connect the card's mLAN jack to the computer's FireWire port. Then configure audio and MIDI connections via the provided mLAN Patchbay application.

What to do if the RT/ERR LED flashes red?

A red RT/ERR LED indicates an IEEE 1394 bus error or other error. Check connection loops, faulty devices, or bus power. Consult the error message table in the manual.

What cables are included with the card?

The box contains a 4.5-meter IEEE 1394 cable, a CD-ROM with mLAN Tools, the instruction manual, and the mLAN guide.

Does the MY8-mLAN card require external power?

No, it is powered directly by the host device slot. Its power consumption is 2.2 W (440 mA / +5 V).

What precautions should be taken to avoid damaging the card?

Avoid static electricity by touching a metal surface before handling the card. Do not touch metal pins. Always install it with power off. Protect it from shocks and humidity.

USER MANUAL MY8-MLAN YAMAHA

mLAN mLAN Interface Card

mLAN Interface Card

MY8-mLAN

Owner's manual

Bedienungsanleitung

Mode d'emploi

1.1. IMPORTANT NOTICE: DO NOT MODIFY THIS UNIT! This product, when installed as indicated in the instructions obtained in this manual, meets FCC requirements. Modifications expressly approved by Yamaha may void your authority, grant by the FCC, to use the product.
2. IMPORTANT: When connecting this product to accessories and/or another product use only high quality shielded cables. Cable/s supplied with this product MUST be used. Follow all installation instructions. Failure to follow instructions could void your FCC authorization to use this product in the USA.
3. NOTE: This product has been tested and found to comply with the requirements listed in FCC Regulations, Part 15 for Class "B" digital devices. Compliance with these requirements provides a reasonable level of assurance that your use of this product in a residential environment will not result in harmful interference with other electronic devices. This equipment generates/uses radio frequencies and, if not installed and used according to the instructions found in the users manual, may cause interference harmful to the operation of other electronic devices. Compliance with FCC

regulations does not guarantee that interference will not occur in all installations. If this product is found to be the source of interference, which can be determined by turning the unit "OFF" and "ON", please try to eliminate the problem by using one of the following measures:

Relocate either this product or the device that is being affected by the interference.

Utilize power outlets that are on different branch (circuit breaker or fuse) circuits or install AC line filter/s.

In the case of radio or TV interference, relocate/reorient the antenna. If the antenna lead-in is 300 ohm ribbon lead, change the lead-in to co-axial type cable.

If these corrective measures do not produce satisfactory results, please contact the local retailer authorized to distribute this type of product. If you can not locate the appropriate retailer, please contact Yamaha Corporation of America, Electronic Service Division, 6600 Orangethorpe Ave, Buena Park, CA90620

The above statements apply ONLY to those products distributed by Yamaha Corporation of America or its subsidiaries.

• This applies only to products distributed by YAMAHA CORPORATION OF AMERICA.

(class B)

CANADA

This Class B digital apparatus complies with Canadian ICES-003.
