| Product type | Stereo system with CD player |
| Brand | Panasonic |
| Model | SC-UX102E |
| Output power (RMS) | 150 W per channel (4 Ω), total 300 W |
| Disc player | CD, CD-R/RW (CD-DA, MP3) |
| USB support | USB 2.0 Full Speed, FAT12/16/32, up to 32 GB |
| Bluetooth | Version 2.1+EDR, Class 2, range 10 m |
| FM tuner | 30 presets, 87.50-108.00 MHz |
| DAB+ tuner (SC-UX102) | 20 presets, Band III (5A-13F) |
| Auxiliary input | Jack socket (1 system) |
| Speakers | 13 cm woofer, 5 cm tweeter, 4 Ω impedance |
| Power supply | 220-240 V, 50 Hz, power consumption 49 W |
| Standby power consumption | 0.5 W (0.6 W with Bluetooth standby enabled) |
| Equalizer | Preset and manual (Bass, Mid, Treble, Surround) |
| Sound effects | D.Bass (Level/Beat), Jukebox with crossfade |
| Timers | Sleep timer, Play timer (programmable wake-up) |
| Remote control | Included (battery supplied) |
| Antennas | Indoor FM, external DAB+ (depending on model) |
| Maintenance | Soft dry cloth; avoid alcohol, paint thinner, benzene |
| Safety | Thermal protection, USB overcurrent, Class 1 laser |
| Supplied accessories | 2 power cords, DAB antenna, ferrite cores, remote control, battery |
Frequently Asked Questions - SC-UX102E PANASONIC
How to connect a Bluetooth device?
Enable Bluetooth on your device. On the system, press the [3] button to switch to Bluetooth mode. If 'PAIRING' is not displayed, go to [PLAY MENU] > 'PAIRING'. Select 'SC-UX102' or 'SC-UX100' from your device's Bluetooth list. If a code is requested, enter 0000.
How to set the clock?
Press [SETUP], select 'CLOCK' with the [▲/▼] buttons, then press [OK]. Set the time with the [◄/►] buttons and confirm with [OK]. The clock operates on a 24-hour cycle.
How to set the play timer (wake-up)?
Make sure the clock is set. Press [SETUP], select 'TIMER ADJ'. Set the start and end times, then choose the source (CD, USB, radio). Next, in 'TIMER SET', select PLAY ON. The unit must be off for the timer to work.
What to do if the remote control does not work?
First check that the battery is correctly installed and not depleted. Make sure there are no obstacles between the remote control and the sensor (max. distance 7 m, angle 20°). If the problem persists, there may be a code conflict: press and hold the [OK] and [3] buttons for 4 seconds for 'REMOTE 1' or [OK] and [USB/CD] for 'REMOTE 2'.
How to clean the unit?
Use a soft dry cloth to wipe the unit. Never use alcohol, paint thinner, or benzene. If you use a cloth impregnated with a chemical product, first read the instructions.
How to improve radio reception?
For FM, extend the supplied antenna and place it in a position that gives the best reception. For DAB+, use the supplied DAB antenna and orient it. Keep the antenna away from computers, televisions, and other cables. If reception remains poor, consider an outdoor antenna installed by a professional.
Can I play MP3 files on a USB flash drive?
Yes, the system supports MP3 files on USB devices formatted in FAT12/16/32. Connect the USB flash drive to the front port, select the 'USB' source, and use the playback buttons. Note: the maximum supported capacity is 32 GB.
What does the error message 'F61' mean?
The code 'F61' indicates a problem with speaker connection. Check that the speaker cables are correctly connected to the corresponding color terminals and that there is no short circuit. Also disconnect any USB device, turn off the system and turn it back on.
How to reset the system?
Disconnect the power cord. While holding down the [U/I] button on the main unit, reconnect the cord. Continue holding the button until '----' is displayed, then release. All settings will return to factory defaults.
What types of discs are compatible?
The system can play audio CDs (CD-DA) as well as CD-R/RW discs containing MP3 or CD-DA files. For CD-R/RW discs, the disc must be finalized. 8 cm and 12 cm discs are accepted.
User questions about SC-UX102E PANASONIC
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
No questions yet. Be the first to ask one.
Download the instructions for your Pregnant in PDF format for free! Find your manual SC-UX102E - PANASONIC and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. SC-UX102E by PANASONIC.
USER MANUAL SC-UX102E PANASONIC
Section tuner, bornes
Dimensions (L x H x P)
181 mm x 308 mm x 165 mm
Poids
2 kg
Données générales
Alimentation
Dimensions (L x H x P)
250mm× 132mm× 227mm
Poids (SA-UX102)
1,7 kg
Poids (SA-UX100)
1,7 kg
