M450BS - Hand blender GORENJE - Free user manual and instructions

Product Type	Hand Mixer
Brand	Gorenje
Model	M450BS
Power Consumption	450 W
Voltage	220-240 V
Frequency	50/60 Hz
Speed Settings	5 speeds + Pulse (Turbo)
Attachments Included	2 beaters, 2 dough hooks, blending attachment
Material	Plastic motor unit, stainless steel beaters
Cable Length	Approx. 1.5 m
Noise Level	72 dB(A)
Weight	Approx. 1.2 kg
Dimensions (L x W x H)	Approx. 20 x 10 x 15 cm
Safety Features	Automatic shut-off, safety lock, ejector button
Cleaning	Removable attachments dishwasher safe; motor unit wipe clean
Intended Use	Mixing, beating, whipping, kneading, blending
Guarantee	2 years (subject to country)
Repairability	Service by skilled personnel only

Frequently Asked Questions - M450BS GORENJE

How do I attach the beaters or dough hooks?

Ensure the mixer is switched off and unplugged. Insert the stem of the beater into the mounting hole, push and turn until it locks. Repeat for the second beater. For dough hooks, insert the one with ears into the right opening and the one with finger ring into the left opening.

What is the maximum speed setting?

The highest speed is achieved by using the Pulse (Turbo) function. For continuous high speed, you can also turn the speed dial to the 'M' (Pulse) position.

Can I use the blender attachment for hot liquids?

The blender attachment is intended for blending cold or warm ingredients. Avoid blending very hot liquids to prevent splashing and damage.

How should I clean the mixer?

Unplug the mixer. Wash beaters, dough hooks, and blender attachment in warm soapy water or dishwasher (top rack). Wipe the motor unit with a damp cloth. Do not immerse the motor unit in water.

What does the 'FOLD' speed setting do?

The FOLD speed (setting 1) is ideal for starting bulk and dry foods such as flour, butter, or potatoes. It gently mixes without overworking.

Is it safe to leave the mixer plugged in when not in use?

No. Always unplug the mixer from the power supply when not in use, before fitting or removing parts, and before cleaning.

Can I use the mixer to knead heavy dough?

Yes, use the dough hooks for mixing and kneading dough. Do not overload the mixer; follow recommended quantities in the manual.

What should I do if the mixer stops working suddenly?

Check if it is unplugged or if the fuse has blown. If it still does not work, contact Gorenje Customer Care. Do not attempt to repair it yourself.

How do I remove the beaters?

Switch off and unplug the mixer. Press the ejector button (B) to release the beaters or dough hooks. Pull them out of the motor unit.

Can children use this mixer?

This appliance can be used by children aged 8 years and above if supervised. Children shall not play with the appliance. Cleaning and maintenance should not be done by children unless they are over 8 and supervised.

USER MANUAL M450BS GORENJE

Black gorenje blender with a glass bowl and hand mixer (no visible text or symbols)

M450WS

M450BS

Instructions for use GB

Line drawing of a bucket with lid and handle (no text or symbols)

Simple line drawing of a device with a coiled spring and upward arrow, no text or symbols present.

Illustration of a hand pouring liquid into a mixing bowl using a stand mixer (no text or symbols)

Simple line drawing of a bucket and a lever (no text or symbols)

Namen

Line drawing of a bucket pump with handle and side arm (no text or symbols)

Simple line drawing of a device with a coiled spring and upward arrow, no text or symbols present.

Illustration of a hand using a blender to lift a cup, with an arrow indicating the process (no text or symbols present)

Line drawing of a hand using a mixing bowl to press a motor (no text or symbols)

Simple line drawing of a hand holding a device with a spring attached, no text or symbols present

Simple line drawing of a bucket being lifted by a lever, no text or symbols present

Namjena

uredajima (waste electrical and electronic equipment - WEEE).

Line drawing of a bucket pump with handle and lid (no text or symbols)

Simple line drawing of a hand holding a spring with an arrow indicating upward motion (no text or symbols)

Line drawing of a hand using a mixing bowl to press another container (no text or symbols)

Simple line drawing of a hand holding a device with a coiled spring, no text or symbols present

Simple line drawing of a bucket being handled with a cloth, no text or symbols present

Namen

Line drawing of a bucket pump with lid and handle (no text or symbols)

Simple line drawing of a hand washing machine with a coiled spring (no text or symbols)

Line drawing of a hand pouring liquid into a mixing bowl using a stand mixer (no text or symbols)

Simple line drawing of a hand holding a small object with a coiled spring, no text or symbols present

Simple line drawing of a bucket and a lever mechanism (no text or symbols)

Намена

Read carefully the following operating instructions. It is suggested that you keep these instructions in a safe place for future reference.

Line drawing of a bucket pump with lid and handle (no text or symbols)

Simple line drawing of a hand holding a spring with an upward arrow, no text or symbols present

Illustration of a hand pouring liquid into a mixing bowl using a stand mixer (no text or symbols)

Simple line drawing of a hand holding a small object with a coiled spring, no text or symbols present

Line drawing of a bucket being handled with a tool, no text or symbols present

Intended use

Your hand mixer has been designed for mixing, beating, whipping and kneading. This product is intended for household use only.

Important safeguards

• Warning! When using mains-powered appliances, basic safety precautions, including the following, should always be fallowed to reduce the risk of fire, electric shock and personal injury.
• Read this entire manual carefully before using the appliance.
• The intended use is described in this manual. The use any accessory or attachment or the performance of any operation with this appliance other than those recommended in this instruction manual may present a risk of personal injury.

Retain this manual for future reference.

Using your appliance

• Do not touch moving parts.
  • Make sure that the appliance is switched off before connecting to or disconnecting from the power supply.
  • Always take care when using the appliance.
• Never pull the power supply cord to disconnect the plug from the socket. Keep the power supply cord away from heat, oil and sharp edges.
• Do not use the appliance outdoors.
  • Always protect the motor unit from water or excessive humidity.
• Operate the appliance only with dry hands.

• Never detach the beaters, dough hooks and blending attachment from the main body while the appliance is still connected to the power supply. Always disconnect the unit from power supply first.

• Never clean the beaters, dough hooks or blending attachment under running water while they are still connected to the main body.

• Take care that the beaters, dough hooks and blending attachment do not touch the power cable while operating the unit.
• If the power supply cord is damaged during use, disconnect the appliance from the power supply immediately. Do not touch the power supply cord before disconnecting from the power supply.
• Disconnect the appliance from the power supply when not in use, before fitting or removing parts and before cleaning.
• All repairs of electrical appliances must only be performed by skilled personnel. Improper repairs can result in Considerable hazards for the user.
• In case of damages, the power cord must be changed only by the skilled service - personnel.
• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Children shall not play with the appliance.
• Cleaning and maintenance shall not be made by children unless they are older than 8 and supervised.
• Noise level: Lc = 72 dB(A)

This appliance is marked according to the European directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE).

This guideline is the frame of a European-wide validity of return and recycling on Waste Electrical and Electronic Equipment.

After use

• Switch off and remove the plug from the socket before leaving the appliance unattended and before changing, cleaning or inspecting any parts of the appliance.
• When not in use, the appliance should be stored in a dry place. Children should not have access to stored appliances.

Inspection and repairs

• Before use, check the appliance for damaged or defective parts. Check for breakage of parts, damage to switches and any other conditions that may affect its operation.
• Do not use the appliance if any part is damaged or defective.
• Before use, check the power supply cord for signs of damage, ageing and wear.
• Do not use the appliance if the power supply cord or mains plug is damaged or defective.
• Never attempt to remove or replace any parts other than those specified in this manual.

ASSEMBLY

Before assembly, make sure that the appliance is switched off and unplugged.

Choosing beaters, dough hooks or blending attachment

• Use beaters for mixing, beating, whipping and creaming liquids and mixtures.
• Use dough hooks for mixing and kneading dough.
• Use blending attachment for blending.

Fitting the beaters or dough kneaders

• Switch the appliance off.
• Insert the stem of beater into one of the mounting holes in the motor unit.
• Push and turn the beater until in locks into place.
• Repeat for the other beater.

Removing the beaters or dough hooks

• Switch the appliance off.
• Keep the release button depressed.
• Pull the beaters or dough hooks out of the motor unit.

USE

- To assemble, insert the end of beaters or dough hooks into the openings. (Fig1)

• Press it until they lock securely in place. (Note: It is important that you insert the dough hooks with a pair of ears into the right opening and insert the dough hook with finger ring into the left opening. (Fig 2)
• Put the ingredients into a bowl. (Fig. 3)
• Lower the beaters or dough hooks into the ingredients. (Fig. 3)
• Plug in and switch the mixer on and choose the desired speed (Fig. 4).
• If you need highest speed, please press turbo or turn the pulse position. (Fig. 5)
• After use unplug the unit first. Depress ejector knob (B) to release the beaters or dough hooks (Fig. 6).

HITROST	OPIS
1 FOLD	This is a good starting speed for bulk and dry foods such as flour, butter and potatoes.
2 BLEND	Best speed to start liquid ingredients for mixing salad dressings.
3 MIX	For mixing cakes, cookies and quick breads.
4 CREAM	For creaming butter and sugar, beating uncooked candy, desserts, etc.
5 WHIP	For beating eggs, cooked icings, whipping potatoes, whipping cream, etc.
M PULSE	Max turbo.

CLEANING AND MAINTENANCE

!!!Before cleaning and maintenance, switch the appliance off and unplug it.

• Wash the beaters, dough hooks or blending attachment in warm soapy water and dry well.
• Wipe the motor unit with a damp cloth. Do not use any abrasive or solvent-based cleaner.

Do not immerse the motor unit in water or any other liquid.

Environment

Do not throw away the appliance with the normal household waste at the end of its life, but hand it in

at an official collection point for recycling. By doing this, you help to preserve the environment.

Guarantee & service

If you need information or if you have a problem, please contact the Gorenje Customer Care Centre in your country (you find its phone number in the worldwide guarantee leaflet). If there is no Customer Care Centre in your country, go to your local Gorenje dealer or contact the Service department of Gorenje domestic appliances.

For personal use only!

GORENJE WISHES YOU A LOT OF PLEASURE WHEN USING YOUR APPLIANCE

We reserve the right to any modifications!

Line drawing of a bucket mixer with a side arm (no text or symbols)

Simple line drawing of a device with a coiled spring and upward arrow, no text or symbols present.

Illustration of a hand using a mixing bowl to brush an object, with no text or symbols present.

Illustration of a hand using a mixing bowl to press a motor (no text or symbols present)

Simple line drawing of a hand holding a device with a spring and rope (no text or symbols)

Simple line drawing of a bucket and a cloth with an arrow indicating rotation (no text or symbols)

Utilizare menită

Line drawing of a bucket pump with handle and side arm (no text or symbols)

Simple line drawing of a hand holding a spring with an upward arrow, no text or symbols present

Line drawing of a hand using a mixing bowl to press another container (no text or symbols)

Simple line drawing of a bucket with an arrow indicating direction (no text or symbols)

Odporúčané použitie

Line drawing of a bucket pump with handle and side arm (no text or symbols)

Simple line drawing of a handheld device with a coiled spring and upward arrow (no text or symbols)

Line drawing of a hand pouring liquid into a mixing bowl using a stand mixer (no text or symbols)

Line drawing of a bucket being lifted by a handbag, no text or symbols present

Javasolt használat

Line drawing of a bucket pump with handle and lid (no text or symbols)

Simple line drawing of a hand holding a spring with an upward arrow, no text or symbols present

Line drawing of a hand pouring liquid into a mixing bowl using a stand mixer (no text or symbols)

Simple line drawing of a hand holding a small object with a coiled spring, no text or symbols present

Simple line drawing of a bucket and a rope, no text or symbols present

URČENÉ POUŽITÍ

Line drawing of a bucket pump with handle and side arm (no text or symbols)

Simple line drawing of a device with a coiled spring and two circular ports, no text or symbols present.

Line drawing of a hand using a mixing bowl to lift a cup, with an arrow indicating the process (no text or symbols)

Simple line drawing of a bucket being lifted by a lever, no text or symbols present

Line drawing of a bucket pump with handle and lid (no text or symbols)

Simple line drawing of a hand mixer with a coiled spring (no text or symbols)

Line drawing of a hand pouring liquid into a mixing bowl using a stand mixer (no text or symbols)

Simple line drawing of a hand holding a device with a spring and a wavy line, no text or symbols present.

Simple line drawing of a bucket being handled with a cloth (no text or symbols)

Назначение
