MODE D'EMPLOI B6200N OKI

OKI®

B6200/6300 series

59357801

Oki, / Network Solutions

for a Global Society

PREFACE

Every effort has been made to ensure that the information in this document is complete, accurate, and up-to-date. The manufacturer assumes no responsibility for the results of errors beyond its control. The manufacturer also cannot guarantee that changes in software and equipment made by other manufacturers and referred to in this guide will not affect the applicability of the information in it. Mention of software products manufactured by other companies does not necessarily constitute endorsement by the manufacturer.

While all reasonable efforts have been made to make this document as accurate and helpful as possible, we make no warranty of any kind, expressed or implied, as to the accuracy or completeness of the information contained herein.

For latest information please see these web sites:

Oki Europe: http://www.okieurope.com

Oki Americas Inc.: http://www.okidata.com

Copyright © 2004 Oki Data Americas. All rights reserved.

Oki and Microline are registered trademarks of Oki Electric Industry Company, Ltd.

Energy Star is a trademark of the United States Environmental Protection Agency.

Hewlett-Packard, HP, and LaserJet are registered trademarks of Hewlett-Packard Company.

Microsoft, MS-DOS and Windows are registered trademarks of Microsoft Corporation.

Apple, Macintosh, Mac and Mac OS are registered trademarks of Apple Computer.

Other product names and brand names are registered trademarks or trademarks of their proprietors.

As an Energy Star Program Participant, the manufacturer has determined that this product meets the Energy Star guidelines for energy efficiency.

This product complies with the requirements of the Council Directives 89/336/EEC (EMC) and 73/23/EEC (LVD) as amended where applicable on the approximation of the laws of the member states relating to electromagnetic compatibility and low voltage.

59357801 Rev 1.1

FCC STATEMENT

Federal Communications Commission Radio Frequency Interference Statement for 120-Volt Models.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and the receiver.
- Plug the unit into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio television technician for help.

It is the responsibility of the user to obtain the required shielded cable in order to ensure compliance of this equipment with FCC regulations.

Changes or modifications not expressly approved by Oki Data may void your authority to operate this equipment.

Industry Canada (IC) Radio Interference Statements For 120-Volt Models

This Oki Data apparatus complies with the Class B limits for radio interference as specified in the IC Radio Interference Regulations.

CONTENTS

Preface....2

FCC Statement .... 3

Introduction 6

Welcome....6

Features overview....7

About this Guide....8

Conventions 8

Installation and relocation procedure ..... 9

Safety precautions....9

Handling the printer 9

Checking the package contents.... 10

Locating parts of the printer 11

Preparing a location for the printer....12

Space requirements ..... 12

Environment 12

Installing the Face Up (Rear) Tray 14

Installing the optional accessories ..... 15

Installing a Universal Tray 16

Installing the Duplex Unit....21

Installing the Offset Catch Tray 23

Installing a Network Software Kit, Hard Disk, Compact

Flash Disk, or Additional Memory 26

Preparing the printer 26

Closing the printer 27

Installing a Network Software Kit 28

Installing a Hard Disk 30

Installing a Compact Flash Disk....32

Installing Additional Memory....34

Installing the Drum-Toner Cartridge 35

Connecting an interface cable....38

Connecting the power cord....39

Loading paper 40

The Control Panel and Menu system 43

Navigating the control panel menus 44

Selecting the control panel language 45

Printing a configuration summary 46

Setting printer configurations via a Web page ..... 47

Using Online Help 47

Installing the printer driver....48

Microsoft Windows Systems 48

Install the PCL6 Emulation Driver 48

Print a Test Page 49

To Install the PostScript Driver as Well ..... 49

Install Printer Software Utilities .... 50

Activate the Duplex Unit, Internal Hard Drive and additional Options .... 50

To Load the Manuals 50

Macintosh - OS 9.1+ ....51

Install the Driver 51

Create the Desktop Printer for A Network ..... 51

Create the Desktop Printer For USB ..... 51

Activate the duplex unit and additional options ..... 52

To print a job using the optional duplex unit ..... 52

To Load the Manuals 52

Macintosh - OS X.1+....53

Install the Driver 53

Adding the Printer for USB 53

Adding the Printer for a Network 54

Activate the Duplex Unit and Additional Options .... 54

To print a Job Using the Optional Duplex Unit ..... 55

To Load the Manuals 55

Printing a test document....55

If paper jams....56

Inside Cover A 58

Inside the Paper Tray 59

Error Messages....61

Index 63

Limited Warranty:

United States and Canada....64

Oki Data Americas Service Centers 66

INTRODUCTION

WELCOME

Thank you for choosing an Oki B6200/B6300 Series printer. This is a guide to help you set up, install and operate your printer. To understand its features fully and to use the printer correctly and effectively, please read this guide before using the printer.

This guide is applicable to the B6200/B6300 Series printers in general although illustrations used are based on the B6300.

This guide assumes that you are familiar with the basics of how to operate your computer and, if required, network environment.

This User's Guide and other important user documents including the Reference Guide, are on the CD-ROM supplied with your printer.

FEATURES OVERVIEW

A brief overview of the main features of your printer is given here:

• Multiple up printing
• 2-sided printing
• Watermark printing
- Poster printing
- Booklet printing
• Transparency separation
- Favorites
• Special media printing
• Secure printing (requires the Hard Disk option)
• Proof printing (requires the Hard Disk option)
• Delayed printing (requires the Hard Disk option)
• Receiving restriction

ABOUT THIS GUIDE

CONVENTIONS

Throughout this guide, the four sides of the printer are referred to as front, rear, right and left. Standing at the front of the printer you can view the control panel and the rear of the printer is opposite the front. The right and left sides of the printer are defined as the sides to the right and left, respectively, of a person who is facing the front of the printer.

The following conventions are used throughout this guide to emphasize certain procedures or information:

NOTE

A note provides additional information to supplement the main text which may help you to use and understand the product.

CAUTION!

A caution provides additional information which, if ignored, may result in equipment malfunction or damage.

WARNING!

A warning provides additional information which, if ignored, may result in a risk of personal injury.

[ ]: Indicates items displayed on the computer and the printer control panel. Also indicates the title of printed reports/lists from the printer.

<>: Indicates items such as hard buttons and indicators on the keyboard and printer.

INSTALLATION AND RELOCATION PROCEDURE

The following sections guide you through the process of installing and setting up your printer right through to making a test print from an application. Complete the entire installation procedure to ensure a proper installation.

SAFETY PRECAUTIONS

This printer is available in either of the following power specifications: 110V and 220 – 240V. The specifications that apply to your printer depend on your configuration. To prevent fire or shock hazards, connect the power plug only to a properly rated power outlet.

HANDLING THE PRINTER

• The printer is very heavy and should always be lifted by two people. The printer with consumables weighs 20.4kg (45lb) (B6200) or 22.6kg (50lb) (B6300). Never attempt to lift the printer alone.
• To lift the printer, have two individuals facing each other from the front and rear of the printer grasp the recessed areas on each side of the printer. Do not lift the printer by grasping any area other than these recessed areas.

Line drawing of two hands holding a rectangular object, viewed from above (no text or symbols)

• When lifting the printer, maintain proper lifting posture to prevent injuries.
• Other safety information is contained in the Installation Safety or Warranty and Regulatory Information booklet supplied with this product and should be read prior to setting up the printer.

CHECKING THE PACKAGE CONTENTS

Check that all items listed below are included in the printer packaging. If any items are missing or damaged, contact your dealer.

NOTE

Retain the packaging material and box for future use if there is a possibility that the printer will be moved over long distances.

• Printer
• Drum-toner cartridge (for approximately 6,000 Letter pages at 5% coverage, i.e. 5% of the addressable print area is printed)
  • 250-sheet Paper Tray
  • Face Up (Rear) Tray (B6300 only)
  • Power cord(s)
  • Unpacking instructions and Quick Setup Guide
  • Safety and Warranty Booklet
• CD-ROM

The CD-ROM contains printer drivers, software and documentation designed to help you fully utilize your new printer. Oki has provided an interface, under MS Windows, to assist you in selecting the appropriate document or application.

NOTE

When the duplex unit is provided with your printer as a standard configuration, refer to “Installing the optional accessories” on page 15 to install the unit.

LOCATING PARTS OF THE PRINTER

The main parts of the printer and a brief description of their functions are shown below:

No.	Name	Description
1	Center output tray	Print jobs are output here with printed side facing down.
2	Control panel	Consists of the control buttons, indicators and display.For control panel details, refer to “The Control Panel and Menu system” on page 43.
3	Ventilation slots	Provide ventilation for the interior of the printer.
4	Paper level indicator	Indicates the level of the remaining paper in the 550-sheet paper tray.
5	Tray 1	Holds 150 sheets of paper.
6	Tray 2	Holds 250 sheets (B6200) or 550 sheets (B6300) of paper.
7	Power switch	Switches the printer power on and off.
8	Extension output tray	Pull this tray out to print on paper larger than Letter.
9	Duplex unit connector	For connecting the duplex unit (option).
10	Power cord connector	For connecting the power cord.
11	Parallel connector	For connecting a parallel cable.
12	Network connector	For connecting the network cable when using the printer as a network printer. (The Network Software Kit option needs to have been installed to enable networking capability.)
13	USB connector	For connecting a USB cable.
14	Serial connector	For connecting a serial cable.

PREPARING A LOCATION FOR THE PRINTER

Place the machine on a level and sturdy surface that can withstand the machine weight - 20.4 kg (45lb) (B6200) or 22.6 kg (50lb) (B6300). If tilted, the machine may fall over and cause injuries.

SPACE REQUIREMENTS

The printer has ventilation holes on the side and rear panels. Ensure that the printer is installed with a minimum clearance of 255mm (10in) from the rear vent to any wall, 200mm (8in) from the left vent to any wall, and 300mm (12in) from the right vent to any wall. A poorly ventilated machine can cause excessive internal heat and fire. The following diagram shows the minimum clearances required for normal operation, consumables replacement, and maintenance to ensure your machine operates at peak performance.

* B6200

ENVIRONMENT

Ensure that the installation location meets the following conditions:

- Do not place the printer in a hot, humid, dusty or poorly ventilated environment. Prolonged exposure to such adverse conditions can result in fire or electric shock.

- Temperature range 10 – 32 °C (50 – 89 °F), humidity range 15 – 85% (no condensation). Humidity should be 70% or below at 32 °C (89 °F), and temperature should be 28°C (82 °F) or below at 85% humidity.

NOTE

Sudden temperature fluctuations can affect print quality. Rapid heating of a cold room or moving the printer from a location with low humidity/temperature to high humidity/temperature can cause condensation inside the printer, directly interfering with image transfer. When condensation occurs, leave the printer for at least 1 hour to acclimatize to the environment before using it.

• Do not expose the printer to direct sunlight.
- Do not expose the printer to the direct draft of air-conditioning or heating.

INSTALLING THE FACE UP (REAR) TRAY

You can install the face up (rear) tray on this printer if required.

NOTE

A face up (rear) tray can be installed on the B6300 only.

1. Insert the right and left tabs of the face up (rear) tray into the holes at the back of the printer (1), and lower the tray into position (2).

1. Push up the rear output tray lever as shown in the diagram (1) and pull out the extension tray (2).

1. Affix the label provided to the back of the printer.

Line drawing of a vehicle front view with a magnified inset showing two document sheets (no text or symbols)

14 > INSTALLATION AND RELOCATION PROCEDURE

INSTALLING THE OPTIONAL ACCESSORIES

If you have purchased any optional accessories, install them before setting the drum-toner cartridge and before loading paper. If there are no optional accessories to install, proceed to the next section, “Installing the Drum-Toner Cartridge” on page 35.

WARNING!

Never open or remove machine covers that are secured with screws unless specifically instructed in this guide. A high voltage component can cause electric shock.

Do not try to alter the machine configuration, or modify any parts. An unauthorized modification can cause smoke or fire.

CAUTION!

Ensure the printer is switched off before connecting any interface cables or options. Connecting cables or options to a live machine may result in an electric shock.

NOTE

To add more optional accessories when the printer is in use, you need to change the configuration of optional accessories in the printer driver. For details, refer to the Online Help for the printer driver.

INSTALLING A UNIVERSAL TRAY

You can install up to two levels of universal tray (550-sheet) option to this printer.

This section explains how to install two trays as an example.

1. Ensure that you have all of the following items:

• Tray module and paper tray

Technical line drawing of a mechanical device with internal components (no text or symbols)

• Fasteners (four pieces)

1. Place the tray module to be installed at the bottom level on a flat surface, then pull out the paper tray.

Technical line drawing of a mechanical device casing with internal compartments and mounting holes (no text or symbols)

NOTE

Proceed to step 6 if you are installing only one tray module.

1. Lift the tray module to be installed at the top level by holding the parts as shown in the diagram.

Technical line drawing of a mechanical device with internal components and an arrow indicating direction (no text or symbols)

1. Align the front and back corners of the top and bottom tray modules, and slowly lower the top module so that the guide pins at the four corners of the bottom module fit into the holes at the base plate of the top module.

CAUTION!

The tray module must be lowered gently. Otherwise, the interior parts may be damaged.

Technical line drawing of a mechanical assembly with multiple components and mounting holes (no text or symbols)

1. Insert the fasteners provided into the two locations inside the tray module and the two locations at the back of the tray module. Insert the fasteners securely.

Technical line drawing of a mechanical assembly with two views showing internal components and alignment (no text or symbols)

1. Pull the paper trays out of the printer.

Line drawing of a hand pressing down on a printer's front panel (no text or symbols)

1. Lift up the printer by holding the recessed areas.
2. Align the corners of the printer and the tray modules, and lower the printer gently so that the guide pins at the four corners of the tray modules fit into the holes at the base plate of the printer.

CAUTION!

The printer must be lowered gently. Otherwise, interior parts of the tray modules may be damaged.

Technical line drawing of a computer tower with visible internal components and mounting brackets (no text or labels)

1. Insert the fasteners provided into the two locations inside and the two locations at the back of the printer. Insert the fasteners securely.

Technical line drawing of a mechanical assembly with an inset showing a component detail (no text or symbols)

Technical line drawing of a mechanical assembly with an inset showing a close-up of a component detail (no text or symbols)

1. Push both trays completely into the printer.

NOTE

For details on how to load paper, refer to “Loading paper” on page 40.

INSTALLING THE DUPLEX UNIT

You can install a duplex unit option on this printer. If a face up tray has been fitted, remove it by reversing the steps in “Installing the Face Up (Rear) Tray” on page 14 before installing the duplex unit and refit it when the duplex unit has been installed.

1. Remove the duplex unit cover by pushing the two tabs as shown in the diagram (1).

Next, remove the connector cap at the top right of the back of the printer (2).

1. Insert the right and left tabs at the bottom of the duplex unit into the holes at the back of the printer, and then align the top part of the duplex unit with the printer.

Ensure that the connector of the duplex unit is connected to the connector of the printer.

Technical line drawing of a printer or printer with internal components and directional arrows indicating flow (no text or symbols)

1. Tighten the screws at both ends of the bottom of the duplex unit.

Technical line drawing of a mechanical device with a close-up inset showing a component (no text or symbols)

INSTALLING THE OFFSET CATCH TRAY

You can install an offset catch tray option on this printer.

NOTE

An offset catch tray can be installed on the B6300 only.

1. Lift the second lever on the top left corner at the back of the printer (1), and open the cover (2).

NOTE

When the duplex unit is installed, lift the lever on top of the left side cover of the unit and open the unit, then open the cover as shown in the diagram.

1. Loosen the right and left thumbscrews as shown in the diagram to uninstall the top cover of the paper exit.

Diagram of a mechanical device with internal components and directional arrows indicating motion (no text or symbols)

1. Insert the right and left tabs of the offset catch tray into the holes at the top of the printer (1) and lower it slowly onto the top of the printer (2).

1. Secure the screws at both ends of the bottom of the offset catch tray.

Technical illustration of a printer with a magnified inset showing internal structure (no text or symbols)

24 > INSTALLATION AND RELOCATION PROCEDURE

1. Close the cover.
2. If you install the face up (rear) tray on the printer, affix the label provided to the back of the offset catch tray.

Line drawing of a computer monitor with an open lid and directional arrows indicating file orientation (no text or symbols)

1. Pull out the extension tray.

Line drawing of a printer's internal structure with no text or symbols

CAUTION!

Printing while the tray is folded up may cause a paper jam. Be sure to open the tray when using the printer.

1. Flip up the stopper when printing on heavy weight papers.

Technical line drawing of a mechanical assembly with a hand operating a tool (no text or symbols present)

INSTALLATION AND RELOCATION PROCEDURE > 25

INSTALLING A NETWORK SOFTWARE KIT, HARD DISK, COMPACT FLASH DISK, OR ADDITIONAL MEMORY

The same steps are required at the beginning and at the end of each installation to prepare the printer and to close it. These steps are described here.

Preparing the printer

1. Remove the screw on the right detachable cover.

Technical diagram of a computer monitor with an inset showing a cable or cable device (no text or symbols present)

1. Slide the cover towards the back of the printer (1) to release the protrusions at the bottom and pull it downwards (2).

1. Remove the two screws on top of the metal cover (1), and pull the metal cover upwards (2).

Closing the printer

1. Align and insert the protrusion at the bottom of the metal cover into the notch of the printer (1), and tighten the two screws on the top of the cover (2).

1. Align and insert the protrusions at the top of the right detachable cover into the notches of the printer (1). Fit the protrusions at the bottom of the cover into the printer (2) and slide the cover towards the front of the printer (3).

1. Tighten the screw on the right detachable cover.

INSTALLING A NETWORK SOFTWARE KIT

You can install a network software kit option on this printer. Installing this option may initialize the settings of [Network/Port] and [Allocate Memory].

CAUTION!

Never touch the connectors of the network software kit.

Never allow the network software kit to be bent or damaged.

Before handling the network software kit, touch something metal in order to discharge any electrostatic charge built up in your body.

1. Refer to "Preparing the printer" on page 26.
2. Hold the network software kit so its notch (1) is aligned with the protrusion on the slot.

1. Release the hook on the top of the slot.

Technical line drawing of a mechanical assembly with an inset showing a component being inserted (no text or symbols present)

1. Gently insert the network software kit into the slot, and press firmly at the top corner of the card then at the bottom corner.

Inserting the network software kit fully and securely into the slot will cause the hook on the top of the slot to rise.

NOTE

Be sure to insert the network software kit securely into the slot as far as it will go.

Technical line drawing of a mechanical assembly with an inset showing a close-up of a component (no text or symbols present)

1. Remove the cap from the network connector.

1. Refer to "Closing the printer" on page 27.

INSTALLING A HARD DISK

You can install a hard disk option on this printer.

NOTE

When the Compact Flash disk (option) is installed on your printer, you cannot install the hard disk. You can install only one of them.
Installing this option may initialize the settings of [Network/Port] and Allocate Memory].

CAUTION!

The hard disk is a delicate item and must be handled with care. In the event that damage does occur, it may erase important data saved on the disk. It is recommended that you back up your data regularly.

1. Refer to "Preparing the printer" on page 26.
2. Remove the screws on the right and left sides of the Compact Flash bracket (1) and remove the Compact Flash disk drive as shown in the diagram (2).

1. Remove the cable of the Compact Flash bracket from the connector on the printer.

Technical line drawing of a mechanical assembly with a magnified inset showing internal components (no text or symbols)

1. Connect the cable of the hard disk to the connector on the printer as shown in the diagram.

CAUTION!

When connecting the cable, hold the disk firmly by hand to prevent it from dropping.

Technical line drawing of a mechanical assembly with an inset showing a component detail (no text or symbols)

1. Hold the hard disk as shown in the diagram, and install it in the printer. Align the arrow on the hard disk with the arrow on the printer, and insert the bracket at the top of the disk into the install position.

Line drawing of a hand inserting a component into a device (no text or symbols visible)

1. Tighten the screws on both sides of the hard disk.

Technical line drawing of a mechanical assembly with directional arrows indicating motion (no text or symbols)

1. Refer to "Closing the printer" on page 27.

INSTALLING A COMPACT FLASH DISK

You can install a Compact Flash disk option (only available in certain regions) to this printer.

NOTE

When the hard disk (option) is installed on your printer, you cannot install the Compact Flash disk. You can install only one of them.
Installing a Compact Flash disk erases any data that resides in the Compact Flash disk.
Installing this option may initialize all the printer settings for allocating memory.

1. Refer to "Preparing the printer" on page 26.
2. Open the fastener on the Compact Flash disk drive.

Technical line drawing of an electrical enclosure with internal components (no text or symbols)

1. Locate the Compact Flash disk as shown in the diagram.

Diagram showing a computer monitor mounted on an electronic device with a magnified inset highlighting the screen (no text or symbols present)

1. Close the fastener.

Technical line drawing of a mechanical assembly with internal components (no text or symbols)

1. Refer to "Closing the printer" on page 27.

INSTALLING ADDITIONAL MEMORY

The additional memory module for this printer is 512MB.

CAUTION!

Do not touch the terminal area of the additional memory.

Do not bend or damage the additional memory.

Before handling the memory board, touch something metal in order to discharge any electrostatic charge built up in your body.

To add more memory when the printer is in use, you need to configure the memory capacity in the printer driver. For details, refer to the Online Help for the printer driver.

1. Refer to “Preparing the printer” on page 26.
2. Hold the additional memory so that the notch (1) is aligned with the protrusion on the slot.

1. Insert the additional memory at an angle (1) and push it into the printer until it clicks into position (2).

NOTE

Ensure that the additional memory is firmly inserted.

1. Refer to "Closing the printer" on page 27.

INSTALLING THE DRUM-TONER CARTRIDGE

Technical line drawing of a mechanical component or housing (no text or symbols visible)

NOTE

Your printer is supplied with a drum-toner cartridge with capacity 6,000 Letter pages at 5% coverage. Replacement drum-toner cartridges are available with capacity 10,000 pages (B6200/B6300) or 17,000 pages (B6300 only).

When handling the drum-toner cartridge, take note of the following points:

WARNING!

Never throw a drum-toner cartridge into an open flame as it can cause an explosion.

• Do not subject the drum-toner cartridge to direct sunlight or strong light.
• When installing the drum-toner cartridge, select a location not subject to strong light and try to finish the installation within 5 minutes.
• Do not touch the surface of the photosensitive drum. Do not let the drum-toner cartridge stand upside down or place it upside down as this may damage the drum.
• A drum shutter protects the photosensitive drum from light. Do not open the drum shutter.

• Although the toner is not harmful to the body, wash it off immediately with cold water if your hands or clothes are in contact with it.

• It is recommended to use up the drum-toner cartridge within one year of removing it from its packaging.

• Keep the drum-toner cartridge out of the reach of children.

• Open the cover.

Line drawing of a printer front panel with an arrow indicating the paper's edge (no text or symbols present)

NOTE

When the optional offset catch tray is installed, fold the tray first before opening the cover.

WARNING!

Do not touch any parts inside the printer.

1. Take the drum-toner cartridge out of the packaging box and shake it seven or eight times as shown in the diagram.

Diagram of hands holding a cylindrical device with rotating arrows indicating rotation (no text or symbols)

1. Place the drum-toner cartridge on a flat surface and pull out the seal horizontally.

Line drawing of a mechanical component being inserted into a housing, with arrows indicating direction (no text or symbols)

CAUTION!

When pulling out the seal, pull it out horizontally. The tape might break if it is pulled out diagonally.

After the seal has been pulled out, do not shake or bump the drum-toner cartridge.

1. Hold the drum-toner cartridge by the grip and insert it into the slot inside the printer.

Line drawing of a hand operating a firearm on a device (no text or symbols)

CAUTION!

Do not touch any parts inside the printer.

Ensure that the drum-toner cartridge is firmly located.

1. Close the cover securely.

NOTE

If the offset catch tray is folded as in Step 1, close the cover and then return the tray to its original position.

CONNECTING AN INTERFACE CABLE

Connect the interface cable to be used to the printer.

NOTE

Connect a USB cable only after the printer driver has been installed on the computer.

1. Connect the interface cable to the interface connector at the back of the printer: serial (1), USB (2), network (3), parallel (4). For a parallel cable, lift up the wire clip on both sides to secure it after it has been inserted into the connector.

1. For Parallel, USB, or Serial cables, connect the other end of the cable to the interface connector of the computer.

CONNECTING THE POWER CORD

When connecting the power cord, take heed of the information given in “Safety precautions” on page 9.

1. Ensure that the printer power switch is in the O position.

Diagram showing a door handle mechanism with an arrow pointing to the lock (no text or symbols present)

1. Connect the power cord to the power cord connector at the back of the printer. Connect the other end of the power cord to the power outlet.

Diagram of a server rack with connected power plugs and a socket, showing no text or symbols

1. Press the power switch of the printer to the <|> position. The power will be applied and the control panel will display that the printer is ready to print.

Line drawing of a microwave oven with an inset showing a close-up of the door handle (no text or symbols)

NOTE

If "Found New Hardware" displays on your screen, click Cancel.
Depending on the network environment used, it may take some minutes before the printer is ready for printing.
If the message that the printer is ready to print but is unable to retrieve an IP Address is displayed, continue operating as normal.

LOADING PAPER

This section explains how to load Letter size plain paper in portrait orientation in the paper tray.

Portrait orientation

1. Place the paper tray on a flat surface and remove the lid.

Technical line drawing of a mechanical device with an arrow indicating a component (no text or symbols present)

1. If the base plate of the paper tray is raised, push it down.

Technical line drawing of a mechanical assembly with a black arrow pointing to a component (no text or symbols present)

1. Squeeze the length guide and slide it to the desired paper size (1). Squeeze the right width guide and slide it to the desired paper size (2).

1. Load the paper with the side to be printed facing up and with all four corners aligned.

Isometric line drawing of a rectangular electronic device with a black arrow pointing to the top panel (no text or symbols)

CAUTION!

Do not place paper over the right width guide.

Do not load paper exceeding the maximum fill line or the maximum capacity allowed.

Align the right width guide with the paper width correctly. If the right width guide is not in place, the paper will not be properly fed and this may cause paper jams.

1. Close the lid of the paper tray and push the tray completely into the printer.

Technical line drawing of a mechanical assembly with a downward arrow indicating a component (no text or symbols present)

CAUTION!

The lid of the tray must be firmly closed. If not, the paper may become misaligned.

1. Depending on the types and sizes of the loaded paper, you need to configure settings on the control panel.

Change the paper type when non-plain paper such as recycled paper, heavyweight paper or transparencies is loaded.

Configure the paper size when custom size paper is loaded.

THE CONTROL PANEL AND MENU SYSTEM

For full details on the control panel and menu structure, refer to the Reference Guide.

The control panel components and their functions are described below:

No.	Name	Description
1		Press to display/close the menu screen.
2		Press to set the required menu value and use to print reports/lists.
3		When illuminated, the printer is ready to receive data from the computer.
4	LCD Display	Displays menu values, printer status and error messages.
5		When illuminated, there is a malfunction in the printer.
6		Press to enter/exit power save mode. The indicator is illuminated when the printer is in power save mode.
7		Press to cancel printing.
8		Press to enter offline status, in which the printer cannot receive data or process printing data. Press again to exit offline status and enter online status, in which the printer can receive data from the computer.
9	<▲><▼><◀><▶>buttons	Press these to move to the required menu, item and required value on the display. Also, press the <◀> button when you are carrying out secure/sampled/delayed printing or when you are checking/printing received mail manually.Note: When you are changing the candidate values by the <▲><▼> buttons, you can press and hold down the buttons to change the display continuously. Also, pressing the <▲><▼> buttons simultaneously displays the default values.

NAVIGATING THE CONTROL PANEL MENUS

Display/Close the Menu screen	button
Switch between the menu levels	button (moves one level downwards) orbutton (moves one level upwards)
Switch between menus or items in the same level	button (displays the previous menu or item) orbutton (displays the next menu or item)
Move the cursor(_) of the setting value to the right or left	button (moves to the right) orbutton (moves to the left)
Confirm setting	button

When you press the MENU button on the control panel, you enter the printer's menu system. At that point, the first line of the display contains the text [Menu], indicating that you are in the menu system. The second line of the display lists the active menu, which you can change by pressing the <▲> or <▼> button.

Using these buttons repeatedly, you can cycle through the main menus in the following order: Print Language; Report/List; Meter Reading; Admin Menu; Display Language.

By using the arrow buttons as indicated above, you can navigate through the menu system to make any required settings. For example, to set the paper type in Tray 1 to accommodate recycled paper, navigate as follows: Admin Menu, Printer Settings, Paper Type, Tray 1, Recycled then press the button to record the setting and the

button to close the menu screen.

SELECTING THE CONTROL PANEL LANGUAGE

English is the default language for all error and status messages; however, these messages are also available in many languages. Use the following procedure to change the display language.

NOTE

Refer to the section “The Control Panel and Menu system” on page 43 for a brief overview of the control panel and its menus and sub-menus.

1. Press the button to display the Menu screen.
2. Press the <▲> or <▼> button until [Display Language] is displayed, then press the <▶> button.
3. Press the <▲> or <▼> button until the required language is displayed, then press the button.
4. Press the button to complete the language setting.

PRINTING A CONFIGURATION SUMMARY

To check whether the printer is correctly installed, use the control panel to print the [System Settings List].

NOTE

If you have made a mistake when operating the control panel, press the

button to restart. For details on how to operate the control panel, refer to “The Control Panel and Menu system” on page 43.

1. Press the button to display the Menu screen.
2. Press the <▲> or <▼> button until [Report/List] is displayed, then press the <▶> button.
3. Press the <> or <> button until [System Settings] is displayed, then press the <> button.
4. Press the button. The [System Settings List] will be printed.
5. Press the button when printing has completed.

NOTE

The layout of the [System Settings List] may differ depending on the configuration and settings of the printer.
For B6300, [Rear Output Tray] is displayed in the column for Output Device even when the rear tray is not installed.
Reports/lists cannot be output to the face up (rear) tray. When the face up (rear) tray is installed, lower the face up (rear) tray output lever.

SETTING PRINTER CONFIGURATIONS VIA A WEB PAGE

If you are working in a TCP/IP-enabled environment, you can use a web browser to display the printer or job printing status and to change the settings.

Among the printer settings that are made on the control panel, settings for the system and network ports can be configured under [Printer], [Network] and Maintenance] on the web page.

NOTE

The web page facility is only available when the printer is connected to the network.
Refer to the Reference Guide when the web page does not appear after carrying out the steps 1 and 2 below.
You can also use Telnet to set the printer configuration. For details on the settings, refer to the NIC Configuration Guide.

1. Boot your computer, and start the web browser.
2. Enter the printer's IP address or URL in the address input column on the web browser and press the key.

Using Online Help

For details regarding the items that can be set in each screen, click the [Help] button to display the Online Help.

INSTALLING THE PRINTER DRIVER

To print from the computer, install the printer driver and other required software.

The installation procedure(s) you will use for your printer vary according to operating system, usage of the USB port, and network connection.

Instructions for installing drivers on Windows and Macintosh operating systems are given below. Solaris, Linux and HP-UX are dealt with in other parts of your documentation.

MICROSOFT WINDOWS SYSTEMS

NOTE

For network installation information, see the Network User Guide on the CD-ROM. Click the Documentation/Network User's Guide buttons.

INSTALL THE PCL6 EMULATION DRIVER

1. Make sure the cable is connected to your printer and PC and your printer is turned OFF.
2. Insert the driver CD supplied with your printer into your CD-ROM drive. The CD will autorun. (If it doesn't, click Start → Run → Browse. Browse to your CD-ROM drive and double-click Install.exe, click OK.)
3. The License Agreement appears. Click Next.
4. If prompted, select your language.
5. The Software Installation screen appears. Click the Printer Driver Installer button.
6. Click Local printer. Click Next.
7. Select the port you are using (USB or LPT1 Parallel). Click Next.
8. Select your printer model and PCL6 emulation type (the default setting). Click Next.
9. If prompted, type a printer name for your printer. Click Next.

10. If prompted, select "do not share this printer" Click Next.

11. Drivers are copied. Click Finish. If Connect cable screen displays. Click Finish.

12. Switch your printer ON. If the New Hardware Found Wizard displays:
13. Win 98: select “Search for the best driver for your device”, select CD-ROM drive, clear other choices. Click Next twice. Win XP and Win Me: select “Automatic Search for a better driver.” Click Next.
14. The driver installs. Click Finish.

PRINT A TEST PAGE

1. From the taskbar, click Start→Settings→Printers (& Faxes).
2. Right-click the printer icon, then click Properties.
3. Click the Print Test Page button.

TO INSTALL THE POSTSCRIPT DRIVER AS WELL

1. With the Software Installation screen open, click the Printer Driver Installer button.
2. Click Local printer. Click Next.
3. Select the LPT1 port. Click Next. USB Users: select the LPT1 port temporarily.
4. Select your printer model and PS emulation. Click Next.
5. Follow the on-screen instructions. Click Finish. USB Users:
6. From the taskbar, click Start → Settings → Printers (& Faxes).
7. Right click the PS printer icon, then click Properties.
8. Click on the Details/Ports tab.
9. Select the USB port in the "Print to the following port" drop-down list.
10. Click Apply, OK. Close the Printers dialog box.

INSTALL PRINTER SOFTWARE UTILITIES

With the Software Installation screen open, click the Software Utilities button. Select and install the utilities you want following the on-screen instructions.

To access the utility program from your desktop, click

Start → Programs → OkiData.

ACTIVATE THE DUPLEX UNIT, INTERNAL HARD DRIVE AND ADDITIONAL OPTIONS

If your printer has an optional duplex unit, internal hard drive, compact flash disk, additional memory, universal paper tray, or face-up rear tray and offset catch tray (B6300 only) installed, you must enter the driver and activate them.

1. From the taskbar, click Start → Settings → Printers.
2. Right click the printer icon, then click Properties.
3. Select the Options/Device Settings tab.
4. Select the installed option.
5. Change setting to AVAILABLE.
6. Click Apply, OK.

NOTE

If you are installing both the PCL6 and PostScript drivers, you must activate the installed options in both drivers. For more information, see the Reference Guide contained on the CD-ROM supplied with your printer.

TO LOAD THE MANUALS

Note: In order to open the on-line manual, you must have Acrobat Reader installed.

1. Insert the CD into your CD-ROM drive.
2. When the Software Installation screen appears, click the Documentation button. Then click the button for the manual you want to load.

MACINTOSH - OS 9.1+

INSTALL THE DRIVER

1. Turn on the printer, then turn on the computer.
2. Place the Drivers CD supplied with your printer into the CD-ROM drive.
3. Double-click the CD icon that appears on the desktop.
4. Open the MAC folder.
5. Open the PSDRV folder.
6. Open your language folder.
7. Double-click the OKI MAC Installer icon, then click Continue and accept the License agreement.
8. Select Classic Easy Install from the drop-down menu. Click Install.
9. Select your printer model. Click OK.
10. When the installation is complete, click Quit.

CREATE THE DESKTOP PRINTER FOR A NETWORK

1. Activate Chooser from the Apple menu.
2. Select the LaserWriter8 icon and highlight the printer model.
3. Click Create. The printer icon appears on the desktop.
4. Close Chooser.

CREATE THE DESKTOP PRINTER FOR USB

1. Navigate to your local hard drive → Application (Mac OS 9) → Utilities.
2. Double-click the Desktop Printer Utility icon.
3. Highlight Printer (USB).
4. In the drop-down box, select LaserWriter 8. Click OK.

5. Under PostScript Printer Description (PPD) file, click Change.

6. Make sure the Printer Descriptions folder is selected in the drop-down box.

7. Highlight your printer model, click Select.
8. Under USB Printer Selection, click Change.
9. Highlight your printer model, click OK.
10. Click Create. The printer icon appears on the desktop.
11. Click Save.

ACTIVATE THE DUPLEX UNIT AND ADDITIONAL OPTIONS

1. Highlight the printer created on the desktop.
2. Select Printer from the desktop menu.
3. Click the Change drop-down menu.
4. Select each option. Click the To drop-down menu and select Installed. Click OK.

TO PRINT A JOB USING THE OPTIONAL DUPLEX UNIT

1. Select File from the desktop menu.
2. Click Print Desktop from the drop-down menu.
3. Select Layout.
4. Check Print on Both Sides. Click Print.

TO LOAD THE MANUALS

Note: In order to open the on-line manual, you must have Acrobat Reader installed.

1. Insert the CD into your CD-ROM drive.
2. From the CD contents folder, either open the file directly or drag the Manual folder to copy them to the desktop.

MACINTOSH - OS X.1+

INSTALL THE DRIVER

Note: Be sure to switch off antivirus software before installing a printer driver.

1. Turn on the printer, then turn on the computer.
2. Place the Drivers CD supplied with the printer in the CD-ROM drive.
3. Double-click the CD icon that appears on the desktop.
4. Open the MAC folder.
5. Double-click PSDRV.
6. Double-click your language.
7. Double-click the OKI Mac Installer icon, then click Continue and accept the License agreement.
8. Select MAC OS X.1+ Driver from the drop-down menu in the left corner. Click Install.
9. Select your printer model. Click OK.
10. When the installation is complete, click Quit.

ADDING THE PRINTER FOR USB

1. Run the Print Center (Local HD → Applications → Utilities → Print Center).
2. Click Printers from the menu bar.
3. Click Add Printer.
4. Select USB from the drop down menu.
5. Highlight your printer model from the product list.
6. Under the Printer Models drop down list, select Oki.
7. Select your printer model. Click Add.
8. Close the Print Center.

ADDING THE PRINTER FOR A NETWORK

1. Run the Print Center (Local HD → Applications → Utilities → Print Center).
2. Click Printers from the menu bar.
3. Click Add Printer.
4. Select Appletalk from the drop down menu.
5. Select your printer model (see Note).
6. Click Add.

NOTE

To list printer models, enable EtherTalk in the printer control panel:

1. Press the button to display the Menu screen.
2. Press <▲> button until [Admin Menu] displays.
3. Press <▶> button until [Network/Port/Parallel] displays.
4. Press ▼ until [EtherTalk] displays.
5. Press ▶ until [Port Status/Disable] displays.
6. Press ▼ until [Enable] displays.
7. Press the button to set Enable.
8. Press the button to complete the setting.

ACTIVATE THE DUPLEX UNIT AND ADDITIONAL OPTIONS

1. In the Print Center, highlight your printer model.
2. Click Printers from the Menu bar.
3. Select Show Info.
4. Select Installable Options from the drop-down list.

5. Select your printer's installed options.

6. Click Apply Changes.

7. Close the Print Center. Your printer is available under Mac OS X.1 applications.

TO PRINT A JOB USING THE OPTIONAL DUPLEX UNIT

1. From your application, click File → Print → Copies & Pages → Duplex.
2. Check Print on Both Sides.
3. Select the binding.
4. Click Print.

TO LOAD THE MANUALS

Note: In order to open the on-line manual, you must have Acrobat Reader installed.

1. Insert the CD into your CD-ROM drive.
2. From the CD contents folder, either open the file directly or drag the Manual folder to copy them to the desktop.

PRINTING A TEST DOCUMENT

After completing the installation procedure, verify that the printer is working correctly by printing a document from an application.

IF PAPER JAMS

CAUTION!

When removing jammed paper, make sure that no pieces of torn paper are left in the machine. A piece of paper remaining in the machine can cause a fire. If a sheet of paper is wrapped around the heat roller, or when clearing a jammed paper that is difficult or impossible to see, do not try to remove it by yourself. Doing so may cause injuries or burns. Switch off the machine immediately, and contact your Oki dealer.

Guided by the message on the control panel, open the cover and remove the jammed paper. If paper is torn, check for any remaining torn pieces of paper.

CAUTION!

The fuser unit gets hot when operating. Avoid touching it.

The covers and trays are identified in the following diagram:

Cover A: When the optional offset catch tray is installed, fold the tray first before opening cover A. When a message to remove the drum-toner cartridge is displayed, refer to “Inside Cover A” on page 58.

Cover B:

NOTE

Remove the rear tray (if installed) when opening the back cover.

Open Cover B (For B6300, raise the lever as shown in the diagram and open cover B (1)). After opening cover B, hold the part marked with a *, open the cover of the fuser unit (2) and remove any jammed paper.

Cover C (Duplex Unit):

NOTE

Remove the rear tray (if installed) when opening the back cover.

Push up the lever (1) to open the duplex unit cover.

Technical line drawing of a printer internal structure showing internal components and a black arrow indicating a component (no text or symbols present)

Cover D Offset catch tray:

Technical line drawing of a printer internal structure showing internal components and a black arrow indicating a specific area (no text or symbols present)

Paper Tray: Pull out the tray and follow the procedure to remove paper. Refer to “Inside the Paper Tray” on page 59.

INSIDE COVER A

Follow the procedure below to remove any jammed paper when the control panel indicates either [Paper jam Open Cover A] or [Remove cartridge Clear jam]:

1. Open cover A, and holding the drum-toner cartridge by the grip, remove it from the printer (1).
2. Turn the roller as shown in the diagram and remove any jammed paper inside (2).

1. Return the drum-toner cartridge and Cover A to their original positions.

CAUTION!

When the optional offset catch tray is installed, close Cover A first before returning the tray to its original position.

If you continue to print with the offset catch tray folded, this may cause a paper jam. Always use the printer with the tray open.

INSIDE THE PAPER TRAY

Follow the procedure below to remove any jammed paper when the following messages are displayed intermittently: [Pull out all trays. Clear jam] and [Clear jam and close Cover A]:

Pulling out the paper trays:

1. Pull out all paper trays and remove any wrinkled paper.
2. Examine the inside of the printer and remove any jammed paper.

Line drawing of a printer with a hand inserting a button to the front panel (no text or symbols present)

After removing the paper:

1. Push the paper trays completely back into the printer.
2. Open and close Cover A to clear the error message.

Line drawing of a printer with a paper feeding into the cover (no text or symbols)

ERROR MESSAGES

If an error message is displayed at the control panel, follow the instructions to fix the error. Depending on the message content, follow the instructions in the Reference column below to fix the error.

Message content	Reference
An error code xxx-xxx is displayed.	Refer to the Reference guide for a list of error codes.
Paper jam or “Remove paper” is displayed.	Refer to “If paper jams” on page 56.
Installing and replacing the drum-toner cartridge	Refer to procedures described on the consumables packaging box or “Installing the Drum-Toner Cartridge” on page 35.
Loading and replenishing paper	Refer to “Loading paper” on page 40.

The following section explains the contents and actions required for the more complex messages. For details on messages not described here, refer to the Reference Guide.

Message	Condition/Reason/Action
Corrupt HDD File. Press SEL key	When the hard disk (option) is installed, the printer assumes that data in the hard disk is corrupted if power is cut off when the printer is in use.Press thebutton on the control panel. The hard disk will be initialized.Initializing the hard disk will delete data for registered forms, logos, secure print, and PostScript download fonts.
Corrupt Log file Press SEL key	When the hard disk (option) is installed, the printer assumes that data in the hard disk is corrupted if power is cut off when the printer is in use.Press thebutton on the control panel. The log file will be initialized.It can take 1 minute to initialize the log file. Do not switch off the power of this printer when initialisation is in progress.
Incorrect paper type ReselectSEL to print CANCEL to cancel	Paper of the type specified under [Paper Type] in the printer driver is not loaded in the trays. Press thebutton on the control panel to print on paper of another type or pressto cancel the job.
Off-line	The printer is off-line, probably because thebutton has been pressed. To cancel the off-line status, press thebutton again.
Off-lineData in memory
	The printer cannot receive any print data from the computer while it is off-line.
Ready to printDNS Update Fail	Unable to retrieve IP address from DNS.Check the settings for DNS and retrieving IP address.
Ready to printGet IP Add. Fail	Failed to retrieve IP address from DHCP server.Change the retrieving method for IP address and manually set the IP address.Refer to the Reference Guide.
Ready to printRepl. Drum/Toner	The drum/toner cartridge is almost used up. Prepare a new drum/toner cartridge. You can still print about another 100 pages even when this message is displayed.

INDEX

A

arrow buttons....44

C

Condensation Problems Occur......13

connecting interface cables ....38

Connecting power cord ....39

E

Error Messages (control panel) ......61

F

button .....44

I

Installing Additional Memory......34

Installing the Drum/Toner Cartridge...35

Installing the Optional Accessories.....15

installing the printer ....12

Installing the Printer Driver......48

L

loading paper

loading paper in paper tray 40

M

Macintosh OS X.1+ driver installation53

Macintosh OS 9.1+ driver installation 51

MENU button....44

Menu Items on the Control Panel......43

0

Online Help (Web page facility) ......47

P

paper tray....59

Printer driver installation ....48

printing reports/lists 46

S

system settings list ....46

W

Web page facility

Using Online Help......47

When Paper Jams 56

Windows systems driver installation ..48

LIMITED WARRANTY: UNITED STATES AND CANADA

Oki Data Americas, Inc. (Oki Data) warrants this printer to be free from defects in material and workmanship and will remedy any such defect according to the terms of this Limited Warranty.

Oki Data will repair (or at its option, replace) at no charge, any defective component(s) of the Printer for one (1) year from the date of purchase. This Limited Warranty extends to the original purchaser only. This Limited Warranty does not extend to consumable items.

ON-SITE REPAIR

Note: On-Site Repair is available in the United States and Canada only. On-Site Repair does not include the replacement or repair of product consumables or supplies.

Oki Data will, for a period of one (1) year from the date of original purchase, repair or replace (at Oki Data's option) on-site at the original purchaser's facility and without charge, any defective component(s) of the printer, provided that the warranty service is performed by an Oki Data authorized service provider. Oki Data reserves the right to use new and/or refurbished parts in the warranty repair process.

As a condition of this Limited Warranty, requests for On-Site Repair must include the name and phone number of a fully competent and responsible adult with the authority to consent to the entry of the servicing technician to the premises where the printer is located, and who will remain with the servicing technician while the service work is performed. Any and all dangerous conditions must be removed from the site prior to and throughout the time a service technician is present. The service technician may refrain from entering the premises or continuing to provide services at any site, if in the servicing technician's reasonable judgement the site poses a risk of physical harm or danger. If warranty services cannot be performed or completed due to any of the foregoing reasons the On-Site service option is null and void and the product must be returned to an authorized Oki Data service location for warranty repair service.

To make request or claim for service under this Limited Warranty contact your local Oki Data authorized service center or Oki Data at 1-800-OKI-DATA (1-800-654-3282).

A written receipt for the product, showing the date of purchase, dealer's name, and both the model and serial numbers of this printer must accompany any request or claim for work to be performed under this Limited Warranty.

This Limited Warranty shall not apply if the product has been damaged due to abuse, misuse, misapplication, accident, or as a result of service or modification by any other than an authorized Oki Data service center.

THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE ON THE FACE HEREOF AND DESCRIBED ABOVE. NO WARRANTIES WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, SHALL EXTEND BEYOND THE RESPECTIVE WARRANTY PERIOD DESCRIBED ABOVE. Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.

OKI DATA SHALL NOT BE RESPONSIBLE OR LIABLE FOR ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LOSS ARISING FROM THE USE OF THIS PRODUCT. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above exclusion may not apply to you.

Additional information on obtaining service under this Limited Warranty is available by contacting the Oki Data dealer from whom the product was purchased, by contacting Oki Data directly at 1-800-654-3282 (1-800-OKI-DATA) [U.S. and Canada, English only] or at 1-856-222-7496 (Spanish only), or by contacting the service location listed below.

This Limited Warranty applies to this printer. However, the procedure for obtaining service may vary outside the continental United States. Contact your Oki Data dealer for such warranty service information.

This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

OKI DATA AMERICAS SERVICE CENTERS

UNITED STATES

Oki Data Americas Inc.

2020 Bishops Gate Blvd.

Mt. Laurel, NJ 08054, USA

Tel: [phone]

Fax: [phone]

CANADA

Oki Data Americas Inc.

2735 Matheson Blvd. East, Unit 1

Mississauga, Ontario

Canada L4W 4M8

Tel: [phone]

Fax: [phone]

MEXICO

Oki Data de Mexico, S.A. de C.V.

Mariano Escobedo No. 748 - 8 Piso

Col. Anzures, e.p. 11590

México, DF

Tel: [phone]

Fax: [phone]

BRAZIL

Oki Data do Brasil, Ltda

Rua Alexandre Dumas, 2220 - 80

andar

Chácara Santo Antonio

04717-004, São Paulo, SP Brasil

Tel: +(5511) 3444-3500

Fax: +(5511) 3444-3501

Support Center: 0800-11-55-77

e-mail: [e-mail]

TECHNICAL SUPPORT

Oki Data Americas Inc.

2000 Bishops Gate Blvd.

Mt. Laurel, NJ 08054-4620, USA

Tel: 1-800-OKI-DATA

(1-800-654-3282)

Fax: [phone]

http://www.okidata.com
