R7060 - Programador de riego WOOX - Manual de uso y guía de instrucciones gratis

Tipo de producto	Programador de riego
Marca	WOOX
Modelo	R7060
Alimentación	2 pilas AA (no incluidas)
Conexión de entrada	Hembra 3/4" con junta tórica
Conexión de salida	Macho 3/4" y Quick-Click macho
Presión de agua máxima	6 bares
Caudal máximo	25 L/min
Programación	Hasta 4 riegos por día, 7 días
Duración de riego	1 min a 3 horas
Número de zonas	1 zona
Protección contra la intemperie	IP54
Material de la carcasa	ABS resistente a los rayos UV
Dimensiones	12 x 7 x 7 cm
Peso	250 g (sin pilas)
Mantenimiento	Limpiar el filtro regularmente; no usar disolventes
Seguridad	Función de parada manual; antihielo automático
Garantía	2 años

Preguntas frecuentes - R7060 WOOX

¿Cómo instalar el programador R7060?

Fije el programador a un grifo exterior usando la conexión hembra de 3/4" con junta tórica. Asegúrese de que la junta esté bien colocada para evitar fugas. Luego, enrosque la manguera de riego en la salida macho o Quick-Click.

¿Qué tipo de pilas usar?

Use dos pilas alcalinas AA 1,5V. No mezcle pilas nuevas y usadas. Cámbielas cada temporada o si la pantalla está débil.

¿Cómo programar los horarios de riego?

Presione el botón PROGRAM para acceder a los ajustes. Use las flechas para configurar la hora de inicio, la duración (1 min a 3 h) y los días de la semana. Confirme con OK.

¿Qué hacer si el programador no se enciende?

Verifique que las pilas estén correctamente insertadas (respete la polaridad). Si la pantalla sigue en blanco, reemplace las pilas. Si el problema persiste, contacte al servicio postventa.

¿Cómo limpiar el filtro?

Desenrosque la tapa del filtro ubicada en la entrada de agua. Retire el filtro y enjuáguelo con agua limpia. Vuelva a colocarlo y enrosque firmemente. Realice esta operación al menos una vez al mes.

¿Puedo usar el R7060 con un recolector de agua de lluvia?

Sí, siempre que la presión del agua sea suficiente (mínimo 0,5 bar). Si la presión es demasiado baja, el programador puede no abrirse correctamente.

¿Qué hacer en caso de fuga en las conexiones?

Verifique que las juntas tóricas estén en buen estado y bien colocadas. Apriete las conexiones manualmente sin forzar. Si la fuga persiste, reemplace las juntas.

¿El programador es resistente a las heladas?

Sí, tiene una función antihielo que cierra automáticamente la válvula en caso de temperatura cercana a 0°C. Sin embargo, se recomienda guardarlo en invierno.

¿Cuántas zonas puede manejar?

Este modelo está diseñado para una sola zona de jardín. Para varias zonas, necesitará un programador multizona o un dispositivo adicional.

¿Cómo restablecer los ajustes de fábrica?

Presione simultáneamente los botones PROGRAM y OK durante 5 segundos. La pantalla mostrará CLR y luego se restaurarán los ajustes predeterminados. Las pilas deben estar en su lugar.

MANUAL DE USUARIO R7060 WOOX

W00X

Green industrial water pump device with black fittings and a small pipe fitting (no visible text or symbols)

If necessary, you can change Male Quick-Click connector to 3/4" Male connector

English

English

English

STEP2.

Illustration of hands assembling or adjusting a mechanical component (no text or symbols visible)

STEP3.

Technical line drawing of a mechanical device with internal components, enclosed in a circular frame (no text or symbols)

English

STEP4.

Illustration of hands assembling or adjusting a mechanical component, no text or symbols present

English

STEP1.

Illustration of a hand holding a mechanical component with an arrow indicating direction (no text or symbols present)

STEP2.

Illustration of hands assembling or adjusting a mechanical component, enclosed in a circular frame (no text or symbols)

STEP3.

Technical line drawing of a mechanical device with internal components, enclosed in a circular frame (no text or symbols)

STEP4.

Illustration of hands assembling a cylindrical object with a cap, enclosed in a circular frame (no text or symbols)

STEP1.

Illustration of a hand holding a mechanical component with an arrow indicating direction (no text or symbols present)

STEP2.

Illustration of hands assembling or adjusting a mechanical component, enclosed in a circular frame (no text or symbols)

STEP3.

Technical line drawing of a mechanical device with internal components, enclosed in a circular frame (no text or symbols)

STEP4.

Illustration of hands assembling a cylindrical object with a cap, enclosed in a circular frame (no text or symbols)

STEP1.

Illustration of a hand holding a mechanical component with an arrow indicating direction (no text or symbols present)

STEP2.

Illustration of hands assembling or adjusting a mechanical component (no text or symbols visible)

STEP3.

Technical line drawing of a mechanical device with internal components, enclosed in a circular frame (no text or symbols)

STEP4.

Illustration of hands assembling a cylindrical object with a cap, enclosed in a circular frame (no text or symbols)

STEP1.

Illustration of a hand holding a mechanical component with an arrow indicating direction (no text or symbols present)

STEP2.

Illustration of hands assembling or adjusting a mechanical component, enclosed in a circular frame (no text or symbols)

STEP3.

Technical line drawing of a mechanical device with internal components, enclosed in a circular frame (no text or symbols)

STEP4.

Illustration of hands assembling a cylindrical object with a cap, enclosed in a circular frame (no text or symbols)

STEP1.

Illustration of a hand holding a mechanical component with an arrow indicating direction (no text or symbols present)

STEP2.

Illustration of hands assembling or adjusting a mechanical component, enclosed in a circular frame (no text or symbols)

STEP3.

Technical line drawing of a mechanical device with internal components, enclosed in a circular frame (no text or symbols)

STEP4.

Illustration of hands assembling a cylindrical object with a cap, enclosed in a circular frame (no text or symbols)

STEP1.

Illustration of a hand holding a mechanical component with an arrow indicating direction (no text or symbols present)

STEP2.

Illustration of hands assembling or adjusting a mechanical component, enclosed in a circular frame (no text or symbols)

STEP3.

Technical line drawing of a mechanical device with internal components, enclosed in a circular frame (no text or symbols)

STEP4.

Illustration of hands assembling or adjusting a mechanical component, no text or symbols present

STEP1.

Illustration of a hand holding a mechanical component with an arrow indicating direction (no text or symbols present)

STEP2.

Illustration of hands assembling or adjusting a mechanical component, enclosed in a circular frame (no text or symbols)

STEP3.

Technical line drawing of a mechanical device with internal components, enclosed in a circular frame (no text or symbols)

STEP4.

Illustration of hands assembling or adjusting a mechanical component, no text or symbols present

STEP1.

Illustration of a hand holding a mechanical component with an arrow indicating direction (no text or symbols present)

STEP2.

Illustration of hands assembling or adjusting a mechanical component, enclosed in a circular frame (no text or symbols)

STEP3.

Technical line drawing of a mechanical device with internal components, enclosed in a circular frame (no text or symbols)

STEP4.

Illustration of hands assembling a cylindrical object with a cap, enclosed in a circular frame (no text or symbols)

STEP1.

Illustration of a hand holding a mechanical component with an arrow indicating direction (no text or symbols present)

STEP2.

Illustration of hands assembling or adjusting a mechanical component, enclosed in a circular frame (no text or symbols)

STEP3.

Technical line drawing of a mechanical device with internal components, enclosed in a circular frame (no text or symbols)

STEP4.

Illustration of hands assembling a cylindrical object with a cap, enclosed in a circular frame (no text or symbols)

STEP1.

Illustration of a hand holding a mechanical component with an arrow indicating direction (no text or symbols present)

STEP2.

Illustration of hands assembling or adjusting a mechanical component, enclosed in a circular frame (no text or symbols)

STEP3.

Technical line drawing of a mechanical device with internal components, enclosed in a circular frame (no text or symbols)

STEP4.

Illustration of hands assembling a cylindrical object with a cap, enclosed in a circular frame (no text or symbols)

STEP1.

Illustration of a hand holding a mechanical component with an arrow indicating direction (no text or symbols present)

STEP2.

Illustration of hands assembling or adjusting a mechanical component, enclosed in a circular frame (no text or symbols)

STEP3.

Technical line drawing of a mechanical device with internal components, enclosed in a circular frame (no text or symbols)

STEP4.

Illustration of hands assembling a cylindrical object with a cap, enclosed in a circular frame (no text or symbols)

STEP1.

Illustration of a hand holding a mechanical component with an arrow indicating direction (no text or symbols present)

STEP2.

Illustration of hands assembling or adjusting a mechanical component, no text or symbols present

STEP3.

Technical line drawing of a mechanical device with internal components, enclosed in a circular frame (no text or symbols)

STEP4.

Illustration of hands assembling a cylindrical object with a cap, enclosed in a circular frame (no text or symbols)

STEP1.

Illustration of a hand holding a mechanical component with an arrow indicating direction (no text or symbols present)

STEP2.

Illustration of hands assembling or adjusting a mechanical component, enclosed in a circular frame (no text or symbols)

STEP3.

Technical line drawing of a mechanical device with internal components, enclosed in a circular frame (no text or symbols)

STEP4.

Illustration of hands assembling a cylindrical object with a cap, enclosed in a circular frame (no text or symbols)

STEP1.

Illustration of a hand holding a mechanical component with an arrow indicating direction (no text or symbols present)

STEP2.

Illustration of hands assembling or adjusting a mechanical component, enclosed in a circular frame (no text or symbols)

STEP3.

Technical line drawing of a mechanical device with internal components, enclosed in a circular frame (no text or symbols)

STEP4.

Illustration of hands assembling a cylindrical object with a cap, enclosed in a circular frame (no text or symbols)
