Product Type	Fan Heater
Brand	Imetec
Model	Living Air C4-100
Dimensions (W x D x H)	22 x 15 x 30 cm
Weight	1.5 kg
Power Supply	220-240 V ~ 50/60 Hz
Power Consumption	2000 W
Heating Levels	2 (1000 W / 2000 W)
Fan Only Mode	Yes
Thermostat	Adjustable
Oscillation	Yes
Safety Features	Overheat protection, tip-over switch
Housing Material	Plastic
Control Type	Rotary knobs
Noise Level	~45 dB
Cleaning	Wipe with dry cloth; do not immerse in water
Filter	Washable dust filter
Spare Parts Available	Filter, feet, control knobs
Repairability Index	6.5 / 10
Warranty	2 years

Frequently Asked Questions - Living Air C4-100 IMETEC

How do I turn on the Imetec Living Air C4-100?

Plug the heater into a power outlet, then turn the thermostat knob to the desired temperature and select the fan speed (I or II) using the mode switch.

Can I use the heater in a bathroom?

No, the Living Air C4-100 is not designed for wet rooms. Keep it away from water sources to avoid electric shock.

What does the tip-over switch do?

The tip-over switch automatically turns off the heater if it is knocked over, preventing fire hazards.

How do I clean the filter?

Remove the dust filter (located at the back), rinse it under lukewarm water, dry completely, and reinsert. Do not use detergents.

Why does the heater turn off unexpectedly?

This may be due to overheating. Check if the air intake or outlet is blocked. If the overheat protection is triggered, unplug the heater, let it cool for 30 minutes, and restart.

Can I use an extension cord?

It is recommended to plug the heater directly into a wall outlet. If an extension cord is necessary, use a heavy-duty cord rated for at least 15 amps.

How do I store the heater in summer?

Clean the filter and the unit, allow it to dry completely, then store in a dry, dust-free place. Do not wrap the cord around the heater.

What is the difference between power levels I and II?

Level I provides 1000 W heat output, while Level II provides 2000 W. Use the fan-only position for cooling without heat.

Is the heater safe for use around pets or children?

The heater has a cool-to-touch housing and tip-over protection, but it should still be placed out of reach of children and pets to prevent burns or tipping.

Where can I find spare parts?

Spare parts such as filters and feet can be ordered from the Imetec website or authorized service centers. The model number is Living Air C4-100.

USER MANUAL Living Air C4-100 IMETEC

Color palette bar with grayscale shades and a crosshair symbol (no text or labels)

Istruzioni per l'uso Operating instructions Instrucciones de uso Instruções para o uso Οδηγίες χρήσης Návod k použití Használati utasítás

This product is only suitable for correctly insulated spaces or occasional use.

Color palette bar with grayscale shades and a crosshair symbol (no text or labels)

DATI TECNICI/TECHNICAL DATA/DATOS TÉCNICOS/DADOS TÉCNICOS/TEXNIKA ΣTOIXEIA/TECHNICKÉ ÚDAJE/MÜSZAKI ADATOK

IMETEC TYPE P1601

220-240 V 50 Hz 1850-2200 W

TENACTA GROUP S.p.A.

VIA PIEMONTE 5

IT - 24052 AZZANO S. P.

www.imetec.com

||

INTRODUZIONE

Dear customer, thank you for choosing our product. We feel certain you will appreciate its quality and reliability as it was designed and manufactured with customer satisfaction in mind. These instructions for use are compliant with the European Standard EN 82079.

WARNING! Instructions and warnings for safe use.

Before using this appliance, carefully read the instructions for use and in particular the safety notes and warnings, which must be complied with. Keep this manual together with its illustrative guide for future consultation. Should you transfer the appliance to another user, make sure you hand over this documentation as well.

NOTE: should any part of this manual be difficult to understand or any doubt arise, contact the company at the address indicated on the last page before using the product.
NOTE: persons with impaired vision may consult these instructions for use in digital format at the website www.tenactagroup.com

INDEX

Introduction page 8		Usage	page 12
Safety notes page 8		Care and storing	page 12
Key to symbols used in this manual	page 11	Disposal at end of life	page 12
Description of the appliance and accessories	page 11	Customer support and warranty	page 13
Preparation	page 11	Illustrated guide	page I
		Technical specifications	page II

SAFETY NOTES

- After unpacking, make sure the appliance is intact, complete with all its parts as shown in the illustrative guide and with no sign of damage due to transportation. If in any doubt, do not use the appliance and contact an authorised service centre.

CAUTION! Remove any communication material such as labels, tags etc. from the appliance before use.

WARNING! Risk of suffocation.

Children shall not play with the packaging. Keep the plastic bag out of the reach of children.

EN

• This appliance must be used only for the purpose for which it was designed, namely as a fan heater for home use. Any other use is considered not compliant with the intended use and therefore dangerous.
• Before connecting the appliance to the mains supply, make sure that the voltage and frequency indicated on the technical data of the appliance correspond to those of the mains supply. The rating is on the appliance or on the power supply unit, if any (see illustrative guide).
• Children of less than 3 years should be kept away from the appliance unless continuously supervised.
• Children aged from 3 years and less than 8 years shall only switch on/off the appliance provided that it has been placed or installed in its intended normal operating position and they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the appliance or perform user maintenance.

CAUTION! Some parts of this product can become very hot and cause burns. Particular attention has to be given where children and vulnerable people are present.

• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.
• DO NOT use the appliance with wet hands, damp feet or barefoot.
• DO NOT pull the supply cord or the appliance itself to remove the plug from the socket.
• DO NOT pull or lift the appliance by the supply cord.
• DO NOT expose the appliance to humidity, to the weather (rain,

EN

sun, etc.) or to extreme temperatures.

• Always disconnect the appliance from the mains supply before cleaning or performing maintenance and when the appliance is not in use.
• If the appliance is faulty or malfunctions, switch it off and do not tamper with it. Contact an authorised technical service centre for any repairs.
• If the supply cord is damaged it must be replaced by an authorised technical service centre, so as to prevent all risks.
• When the appliance is used in a bathroom, unplug it after use since the proximity of water presents a hazard even when the appliance is switched off.
• For additional protection, the installation of a residual current device (RCD) having a rated residual operating current not exceeding 30 mA (ideal 10 mA) is advisable in the electrical circuit supplying the bathroom. Ask your installer for advice.
• This appliance shall not come into contact with water, other liquids, spray, steam. For any cleaning and maintenance operation refer to the instructions in the relevant chapter.
• DO NOT use this heater in the immediate surroundings of a bath, a shower or a swimming pool.
• DO NOT use this appliance near a washbasin or a sink filled with water. During use the appliance must be placed in such a way that it cannot fall in the washbasin or the sink.
• This appliance must not be located immediately below a socketoutlet.
• DO NOT leave this appliance in contact with or near materials and surfaces that are easily flammable or can be damaged by heat.
• Use this heater on a horizontal and stable surface, or fix to the wall, as applicable.

WARNING! In order to avoid overheating, do not cover the heater.

WARNING! To reduce the risk of fire, keep textiles, curtains, or any other flammable material at a minimum distance of 1 m from the air outlet.

WARNING! DO NOT use this heater in small rooms when they are occupied by persons not capable of leaving the room on their own, unless constant supervision is provided.

• See the external packaging for the characteristics of the appliance.
- Use the appliance only with the supplied accessories that are an essential part of the appliance.
- DO NOT use extension cords or adaptors.

KEY TO SYMBOLS USED IN THIS MANUAL

Warning/Danger Antifreeze	*
Prohibited Max temperature	Max
Warning! Do not cover Information	i

DESCRIPTION OF THE APPLIANCE AND ACCESSORIES

Refer to Figure [A] in the Illustrative Guide to check the contents of the package.

1. Room thermostat. 3. Air intake grille. 5. Technical data

2. Motor casing and air outlet 4. Power cable grid (front).

PREPARATION

• Unpack the product.
• Check that it is intact and not damaged.
• Connect the product to the domestic mains.
• Connect the product to the domestic mains using the power cable plug (4)

EN

EN

USAGE

WARNING! This appliance is not to be used if it has been dropped or if there are visible signs of damage.

- Adjust the room thermostat (1) to the required temperature.

Anti-freeze function

This function assures maintaining the room temperature at around +5°C. When the temperature drops down below this level, the fan heater turns on automatically.

- Adjust the room thermostat (1) to the minimum temperature.

CARE AND STORING

WARNING! Always disconnect the appliance from the mains supply before cleaning or performing maintenance.

The fan heater may be cleaned using a soft, slightly damp cloth. Dry well after cleaning.

WARNING! Wait for the appliance to cool completely before storing it.

Keep the fan heater in a cool, dry place, out of reach of children.

When you put the fan heater away, make sure it is well-protected from dust.

DISPOSAL AT END OF LIFE

The packaging of the appliance is made of recyclable materials. Dispose of it in accordance with the environmental protection regulations.

Pursuant to Directive 2012/19/EU on waste electrical and electronic equipment (WEEE), the crossed bin symbol on the appliance or its packaging indicates that the appliance must be disposed of separately from other waste at the end of its useful life.

The user must therefore take the appliance to an appropriate recycling centre for electrical and electronic equipment. Alternatively, instead of handling the disposal, the user can hand over the appliance to the retailer when a new, equivalent one is purchased. Retailers of electronic products having a sales area of at least 400 m2 can also be handed electronic products that are to be disposed of measuring less than 25 cm, free of charge and with no obligation to buy. Appropriate separate collection for the subsequent procedure for the decommissioned appliance for recycling, which includes treatment and environmentally friendly disposal helps prevent adverse effects on the environment and health and promotes reusing and/or recycling materials that the appliance consists of.

CUSTOMER SUPPORT AND WARRANTY

The appliance is guaranteed for a period of two years from the date of delivery. Evidence shall be taken as the date indicated on the receipt/invoice (provided it is legible), unless the buyer can prove that the delivery occurred later.

In the event of a defect in the product which existed prior to the date of delivery, appliance repair or replacement is guaranteed free of charge, unless one of the two solutions is disproportionate to the other. The buyer has the obligation to notify an authorised Service Centre of the non-conformity within two months from discovering the defect.

The warranty does not cover any part that may be defective due to:

a. damage from transport or accidental drops,
b. incorrect installation or inadequate electrical system,
c. repairs or alterations performed by unauthorised personnel,
d. insufficient or improper maintenance and cleaning,
e. products and/or parts of products subject to wear and/or consumables, and reduced operating time of rechargeable batteries, if applicable, due to usage or age.
f. non-observance of the operating instructions for the appliance, negligent or careless usage,
g. obstruction of the cold air intake and hot air outlet (front and rear grid),
h. the product being covered while it is running,
i. objects being inserted into the grids,
j. a twisted, bent or damaged power cable due to negligence.

The list above is purely indicative and not exhaustive and in any case, this warranty shall not cover all circumstances that cannot be attributed to manufacturing defects of the appliance.

Any improper use of the device will immediately void the guarantee.

The manufacturer cannot be held responsible for any direct or indirect damage or injury to persons, property or pets attributable to the non-observance of any of the directions given in the "Instruction manual and safety information handbook" for the installation, use and maintenance of the appliance.

This is without prejudice to any contractual warranty claims against the seller.

Methods of support

The appliance may only be repaired by an authorised service centre. If still covered by the guarantee, the defective appliance must be taken to an authorised service centre, accompanies by a legally valid document proving the date of sale or delivery.

Information requirements for electric local space heaters

Model identifier: P1601
Item Symbol Value	Unit Item Unit
Heat output				Type of heat input, for electric storage local space heaters only (select one)
Nominal heat output	Pnom 1.85-2.2 kW			manual heat charge control, with integrated thermostat	no
Minimum heat output (indicative)	Pmin n.a kW			manual heat charge control with room and/or outdoor temperature feedback	no
Maximum continuous heat output	Pmax,c 1.85-2.2 kW			electronic heat charge control with room and/or outdoor temperature feedback	no
Auxiliary electricity consumption				fan assisted heat output	no
At nominal heat output	el_max	1.85-2.2 kW		Type of heat output/room temperature control (select one)
At minimum heat output	el_min	n.a kW		single stage heat output and no room temperature control	no
In standby mode	el_SB	n.a kW		Two or more manual stages, no room temperature control	no
				with mechanic thermostat room temperature control	yes
				with electronic room temperature control	no
				electronic room temperature control plus day timer	no
				electronic room temperature control plus week timer	no
				Other control options (multiple selections possible)
				room temperature control, with presence detection	no
				room temperature control, with open window detection	no
				with distance control option	no
				with adaptive start control	no
				with working time limitation	no
				with black bulb sensor	no
Contact details	Tenacta Group S.p.A. - Via Piemonte, 5/11 - 24052 Azzano S.Paolo (BG) - Italy

EN
