RS-708 - Scale Redmond - Free user manual and instructions

Type	Digital bathroom / kitchen scale
Model	RS-708
Brand	Redmond
Max weight capacity	180 kg / 397 lb / 28 st
Min weight	5 kg
Division (resolution)	100 g
Precision sensors	4
Display	LED (red)
Units of measurement	kg, st, lb (selectable)
Auto-on	Yes (step-on activation)
Auto-off	Yes
Overload indicator	Yes (display message)
Low battery indicator	Yes (display message)
Power supply	1 x CR2032 battery (included)
Platform material	Tempered glass (estimated)
Dimensions	Approx. 30 x 30 x 2.5 cm
Weight of scale	Approx. 1.5 kg
Cleaning	Wipe with damp cloth, do not immerse
Safety	Do not use in humid areas or outdoors; keep away from mobile phones (min 2 m)
Included accessories	Scale, battery, manual, service booklet
Warranty	12 months
Service life	2 years (minimum)
Country of origin	China (PRC)
Manufacturer	Redmond Industrial Group LLC, USA

Frequently Asked Questions - RS-708 Redmond

How do I change the unit of measurement on the Redmond RS-708 scale?

Use the unit selector switch on the scale to choose between kg (kilograms), st (stones), and lb (pounds).

Why does the display show 'Lo' or a battery symbol?

This indicates the battery is low. Replace the CR2032 battery with a new one, observing correct polarity.

What does 'Err' or a flashing symbol mean?

If the display shows 'Err' or a similar message, the scale is overloaded (over 180 kg). Step off to reset.

How accurate is the Redmond RS-708?

The scale has a division of 100 g and uses 4 precision sensors. For best accuracy, place on a flat, hard surface and weigh without moving.

Can I use the scale on carpet?

For accurate results, place the scale on a flat, hard surface. Carpet may cause inaccurate readings.

How do I clean the scale?

Wipe the platform with a damp cloth and dry thoroughly. Do not use abrasive cleaners or immerse in water.

Why does the scale turn off automatically?

The scale has an auto shut-off feature to save battery. It turns off shortly after you step off.

What type of battery does the RS-708 use?

It uses one CR2032 lithium coin battery. A spare is included.

Is the scale waterproof?

No, the scale is not waterproof. Keep it away from water and do not immerse. Clean with a damp cloth only.

Why is the scale not turning on?

Ensure the battery is inserted correctly (polarity) and has charge. Step on the platform to activate auto-on. If still off, replace the battery.

USER MANUAL RS-708 Redmond

INSTRUCTION MANUAL

ИНСТРУКЦИЯ

|

—

|

|

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

|

|

|

|

,

广力云智慧零售收银系统

—

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

(1) AD = AC = 1

—

[Non-Text]

1

|

|

|

|

1

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

DEAR CUSTOMER!

Thank you for preferring the domestic appliance manufactured

by REDMOND. REDMOND means quality, reliability and thoughtful attitude towards our clients.

We hope that in future you will also prefer products of our company.

REDMOND scales are high-precision appliances for those who watches over for weight closely.

The electronic technology based on usage of high presicion sensores, gives confidence of maximal accuracy of measurements results. Measurements of value are deduced on bright LED display.

Product photo of a kitchen blender and blender with decorative icons (no visible text or labels)

Блесдер RHB-2905

Product photo of a white electric shaver with accessories and a small stand (no visible text or symbols)

Таоссессор RFP-3901

Product photo of kitchen appliances including blender, spatula, and whisk (no visible text or labels)

Гроцессор RFP-3903

Product line drawings of a washing machine and a handheld device (no text or symbols visible)

Product line showing a kitchen appliance with food and a hand mixer (no visible text or symbols)

Exterior view of a wall-mounted air conditioner unit (no visible text or symbols)

Industrial machine component with mechanical parts and a separate inset showing a close-up of a connector (no visible text or symbols)

Illustration of a transparent cylindrical container filled with fruit and vegetables, no text or symbols visible.

Product photo of a kitchen blender with colorful fruit inside (no visible text or symbols)

Product photo of a black and silver robotic device (no visible text or symbols)

Close-up of a metallic cylindrical electronic component (no visible text or symbols)

Two iron steamers, one white and one purple, displayed side by side (no text or symbols visible)

VTOR RI-A207

VIKOI RI-C208

Pair of electric iron machines in purple, black, and red colors (no visible text or symbols)

VI-C1 RI-C209

Exterior view of a pair of steam iron with blue and white panels (no text or symbols visible)

Vinci RI-C210

Two colorful vacuum cleaner units with coiled cable, no visible text or symbols

Пылбосс RV-303

Close-up of a black vacuum cleaner with coiled cord (no visible text or symbols)

Гылассо RV-307

Пылосос RV-308

Пь песс RV-309

Коллекция 2010-2011

Redmond Industrial Group, LLC USA
Redmond Industrial Group, LLC USA

REDMOND
Professional series

Black and white photo of a set of stainless steel kitchen utensils including a whisk, condenser, and stand (no text or symbols visible)

RHB-2904

Black and white photo of kitchen utensils including a whisk, beaker, and stand (no text or symbols visible)

SHETUED RHB-M2904

Black and white photo of a hand mixer on a stand (no text or symbols visible)

Миксер RHM-2101

Beca RS-714

Becl RS-M711

bytee6pondnica RSM-M1402

REDMOND

Kitchen scales

Кухонные весы

RS-708

INSTRUCTION MANUAL

ИНСТРУКЦИЯ

REDMOND

ENGLISH

CONTENT

Complete set

Product specification

Model arrangement

I. BEFORE OPERATING

Safety measures

Prior to the first use

II. OPERATING OF A SCALES

III. CLEANING AND MAINTENANCE

IV. BEFORE CONSULTING THE SERVICE CENTER

V. GUARANTEE

РУССКИЙ

СоДеРЖАНИе

Комплектация

Maximal weight 180 kg/397 lb/28 st

Minimal weight 5 kg

Division 100 g

Precision sensors quantity 4

LED display +

Overload indicator +

Low battery indicator +

Unit of measure selection +

Auto switch on function +

Auto shut off function +

Electronic balancing system +

COMPLETE SET

1. Scales - 1 pc.
2. Batteries 1xCR2032 - 1 pc.
3. Manual - 1 pc.
4. Service booklet - 1 pc.

The manufacturer has the right of making modifications to design, delivered set and technical data of the device in the course of improvement of the products without additional notifying of such modifications.

Pure electrical circuit lines without any symbols

While operating the appliance, follow the instructions given below. If used properly, it will serve you for many years.

■ Before connecting the appliance to electric outlet, check that the mains voltage coincides with supply voltage of the appliance. The later can be found in technical data or on the factory nameplate of the appliance.
■ The appliance is intended for domestic use only. The appliance is not intended for industrial use.
■ Never let children to use the appliance until they have been briefed and got the knowledge about the instructions of safe operation. The appliance itself and the packing materials are not allowed to be used as children's playthings.

■ It is prohibited to perform independent repairs or make modifications to the design of the appliance. All the service and repair works should be performed by authorised service-centre. Amateurish works performed can result in breaking, injuries and damage to property.
■ Use batteries of appropriate type only. Battery type can be found in technical specifications or in the nameplate available on the appliance.
■ It is prohibited to immerse the appliance in water or any liquids. This may result in damages.

Operation of the scales shall be prohibited in the following cases:

■ In premises with increased humidity, for example in a bathroom. There is a risk of failure of the appliance.
■Outdoors.

A risk exists, of malfunction due to rain and other weather conditions.

■ Mobile phone may create interference, which may lead to inaccurate results of weighing.
- Keep turned-on mobile phone at a distance of at least 2 metres from the scales or turn the mobile phone off.

ATTENTION!

It is prohibited to use an appliance in case of any malfunctions.

The manufacturer has no responsibility for any damage caused by violation of safety rules and operating instructions.

Note! Keep this instruction manual for further use.

PRIOR TO THE FIRST USE

1. Take out the appliance from the box carefully; remove all packing materials including advertising stickers.
2. Wipe the case of the appliance with moist cloth and then dry it up.
3. Check correctness of connection of the battery, for this purpose apply to «Operating of a scales».

II. OPERATING OF SCALE

1. Make sure the battery is inserted in a scales before operating.
2. Remove the lid of the battery compartment and make sure the battery is inserted correctly, with observance of polarity.

1. If the battery have not been inserted, insert it in place.

Connect the battery to the connectors, observing the polarity. Use battery only corresponding type.

NOTE! When inserting the batteries, the hands and the appliance should be dry.

1. Close the compartment lid after inserting the battery.

2. Choose the necessary measure unit using measure unit switcher:

kg -kilograms

st - stones

lb - pounds

1. Place the scale on a flat horizontal surface. This condition is obligatory – it allows to receive an exact results.

1. Scales is supplied with automatically switched on system, to switch on the scales step on scales platform.

Try not to move on scales during weighting, do not bend in sides, do not transfer the center of gravity from one foot to another etc.

1. On LED display value of your weight will be displayed.

1. Finishing weighting - step off the scale platform. Scale will switch off automatically.

NOTE!

To get an exact value of weight it is necessary to observe a number of conditions:

1. Place the scales on flat hard horizontal surface.
2. Get on platform of scales smoothly.
3. Do not transfer the centre of gravity from one foot to another.
4. Avoid sharp movements and rockings during weighing.

5. The most exact parameters of weight are reached on the second and the subsequent weighings

6. On LED display there will be a message

at in overload (over 180 kg)

1. On LED display there will be a message take the discharged battery off and place the new.

III. CLEANING AND MAINTENANCE

1. Do not use abrasive washing up liquids, metallic brushes, alcohol-containing solvents.
2. It is prohibited to immerse the appliance into water, or wash under a flush of water.
3. Clean scale platform with wet fabric, then wipe it dry.
4. Take the battery off before prolonged storage.

IV. BEFORE CONSULTING THE SERVICE CENTER

Trouble Probable cause Remedy
The appliance does not operate	The appliance does not switched onBattery is ran out.	Switch on the appliance pressing the button.Replace the battery according to the chapter «Operating of a scales».
Display indications does not correspond to true value.	Incorrect measure unit was selected.Weighing indispensable conditions were not observed.	Choose the necessary unit of weight measure using switcher.To get an exact value of weight it is necessary to observe a number of conditions:1. Place the scales on flat hard horizontal surface.2. Get on platform of scales smoothly.3. Do not transfer the centre of gravity from one foot on another.4. Avoid sharp movements and rockings during weighing.
The appliance switches off automatically.	Automatic switching off system was activated.	This is normal. The scales are turned off automatically upon completion of operation of the same.

V. GUARANTEE

The period of guarantee for the product is 12 months from the selling date.

The guarantee covers defects of material and workmanship.

Under the present guarantee, the manufacturer undertakes to repair or replace any part recognized as faulty on condition that the product is sent to the seller.

The present guarantee shall be valid only in case the product was used in compliance with this instruction, no modifications were made to it, it was not repaired or disassembled by unauthorized persons, or was not damaged due to improper handling. Also, the complete set of the product must be retained.

This guarantee does not cover natural wear of the product as well as brittle objects such as ceramic components, lamps, etc.

The guarantee shall not become effective unless the date of purchase is confirmed by the seller's signature and seal on the guarantee coupon.

Any repair under this guarantee shall not extend the period of guarantee and shall not initiate the beginning of a new guarantee.

In compliance with paragraph 2, article 5 of the Federal Law of the RF «On protection of consumers' rights», the manufacturer has established a minimum service life for this product, which is 2 years from the date of manufacture on condition that the product is used in strict compliance with this manual and technical requirements.

kg -килограмм

st - стоун

lb - фунт

Pure vertical black bar with no text or symbols

Produced by Redmond Industrial Group LLC, USA

1801 S Treasure Drive, 515, North Bay Village, Florida 33141, USA

http://www.redmond-ig.com

Made in P.R.C.
