Product Type	Portable Radio
Model	MR-332
Brand	Clas Ohlson
Dimensions (approx.)	20 x 12 x 8 cm
Weight (approx.)	0.5 kg
Power Supply	3 x AA batteries (not included) or AC adapter (not included)
Band Coverage	AM/FM
Tuning	Analog dial
Speaker	Built-in mono speaker
Headphone Jack	3.5 mm
Antenna	Built-in ferrite for AM, telescopic for FM
Volume Control	Rotary knob
On/Off	Rotary switch combined with volume
Carrying Handle	Yes, integrated
Battery Life (approx.)	Up to 30 hours with alkaline batteries
Recommended Use	Home, camping, outdoor
Cleaning	Wipe with a dry, soft cloth
Storage	Keep away from moisture and extreme temperatures
Safety	Do not open the device; refer to qualified service personnel

Frequently Asked Questions - MR-332 Clas Ohlson

How do I power the MR-332 radio?

The MR-332 can be powered by three AA batteries (not included) or an optional AC adapter (not included). Insert batteries with correct polarity.

Why is the radio not turning on?

Check if batteries are inserted correctly and have charge. If using AC adapter, ensure it is plugged in and compatible. Also, ensure the volume/power knob is turned clockwise.

How can I improve FM reception?

Extend the telescopic antenna fully and adjust its position. For best results, place the radio near a window or away from metal objects.

How do I clean the radio?

Use a soft, dry cloth to wipe the exterior. Do not use water, solvents, or abrasive cleaners. Ensure the radio is turned off and batteries removed before cleaning.

Can I use headphones?

Yes, connect standard 3.5 mm headphones to the headphone jack. This will mute the built-in speaker.

What type of batteries does the MR-332 use?

It requires three AA batteries. We recommend alkaline batteries for longer life. Do not mix old and new batteries.

How do I store the radio when not in use?

Remove the batteries to prevent leakage. Store in a cool, dry place away from direct sunlight and moisture.

Is the radio suitable for outdoor use?

Yes, it is designed as a portable radio with a carrying handle. However, protect it from rain and extreme conditions.

What is the frequency range?

The MR-332 covers AM (530-1710 kHz) and FM (88-108 MHz) bands. Tune using the analog dial.

Can I repair the radio myself?

No, the radio does not contain user-serviceable parts. Do not open the casing. Contact a qualified technician if service is needed.

USER MANUAL MR-332 Clas Ohlson

Release the battery cover (7) on the back by pushing it down and insert 2x LR03 batteries. Be careful to fit the batteries according to the markings on the bottom of the battery compartment according to the markings on the bottom of the battery compartment.

• Never mix old and new batteries.
- Do not mix alkaline, regular, and rechargeable batteries.

- If the display (5) begins to blink or if the radio shuts off, the batteries need to be changed.

Use

1. Press the ON/OFF (3) button once to turn on the radio.

2. Connect the headphones to the outlet (1) on the top.

3. Press one of the search buttons (6)

4. The frequency is adjusted up or down with the buttons according to the arrows.

5. Push any of the buttons for longer than one second to activate auto search function. The search stops when a strong signal is received. Push any of the buttons for longer than one second to activate search for a new station.

6. Adjust desired sound level with the volume control (2).

7. Set stereo or mono reception with the STEREO/MONO switch (4).

Preset setting

When your favourite radio stations have been found, they can be saved in the memory and activated with the buttons (10), up to five stations can be stored in the memory

• Set desired station with the search buttons (6). See above.
• Do the following to save a station in the memory: Push SET button. PRESET blinks in the display. Push any of the preset buttons (10) M1 – M5, the station is saved in the memory and can be activated with the same button.

Note: Save the frequency when PRESET blinks, if no station has been saved within 15 seconds reset the radio in normal mode and the station will not be saved.

Listen to your saved stations

Press the preset button (10) which the station was saved with and that station can be listened to.

Memory backup

When the batteries are low, the display starts to blink or shuts off. Shut off the radio and insert new batteries.

Note: If the batteries are taken out more than a minute the program may have to be programmed again.

Key lock

Press the LOCK (8) button to activate the key lock, a key is shown on the display when the key lock is activated. All the buttons besides ON/OFF can not be operated in locked position. Press the LOCK (8) button to activate the key lock.

Note

• The radio starts automatically when the batteries are inserted the first time.
- The cable to the headphones is used as antenna. Use the cable's entire length and not rolled up.
- The quality of the reception depends on how the headphone (antenna) cable is placed. Try different positions until the reception is good.

Specifications

Frequency range: FM 87,3 - 108,1

Antenna: The connection cable to headphones also works as antenna.

Power Output: 15mW + 15mW at 10% THD

Battery: 2x R03 (not included)

Accessories: Headphones carry on strap

Disposal

Follow local ordinances when disposing of this product. If you are unsure about how to dispose of this product contact your municipality.

Miniradio

Nr. 38-1208 Mod. MR-332

1 Hörlurs jack
2 Volymkontroll
3 På/Av
4 Mono/Stereo omkopplare
5 LCD display
6 Sökknappar (TUNE)
7 Batterilock
8 Knapplås (LOCK)
9 Spara frekvens (SET)
10 Förvalsknappar

Strömförsörjning
