| Brand | Elektro Helios |
| Model | TF822-5 |
| Product Type | Freestanding Washing Machine |
| Loading Type | Front-load |
| Capacity | 7 kg |
| Maximum Spin Speed | 1400 rpm |
| Energy Class | A+++ |
| Dimensions (H x W x D) | 85 cm x 60 cm x 55 cm |
| Weight | 65 kg |
| Power Supply | 220-240 V ~ 50 Hz |
| Number of Programs | 15 |
| Key Programs | Cotton, Synthetics, Delicates, Wool, Quick 30', Rinse & Spin |
| Additional Functions | Delay Start, Pre-wash, Extra Rinse, Child Lock |
| Noise Level (Wash/Spin) | 58 dB / 76 dB |
| Water Consumption (per cycle) | 49 L |
| Annual Energy Consumption | 185 kWh |
| Maintenance | Clean lint filter regularly; clean detergent drawer every 2 months |
| Safety Features | Overfill protection, unbalanced load detection, child lock |
| Repairability | Standard spare parts available; user replaceable drain pump filter |
| Warranty | 2 years |
Frequently Asked Questions - TF822-5 ELEKTRO HELIOS
How do I start a wash cycle on my Elektro Helios TF822-5?
Load your laundry, add detergent, select a program using the program dial, adjust any options (e.g., temperature, spin speed), then press the Start/Pause button.
What should I do if the washing machine does not drain?
Check the drain hose for kinks or blockages. Clean the drain pump filter located at the bottom front of the machine. Ensure the drain pump is not jammed.
How can I clean the detergent drawer?
Remove the drawer by pulling it out and pressing the release clip. Wash it under warm running water with a soft brush. Clean the recess with a damp cloth, then reinsert.
What does error code E01 mean on the TF822-5?
Error E01 typically indicates a door lock issue. Ensure the door is fully closed and latched. Check for obstructions. If persistent, contact service.
Can I use a quick wash cycle for heavily soiled clothes?
No, quick wash cycles (e.g., 15-30 minutes) are designed for lightly soiled items. For heavily soiled clothes, use a cottons or intensive program with pre-wash.
How to enable the child lock on my washing machine?
Press and hold the Child Lock button (usually indicated by a padlock icon) for 3 seconds until the lock symbol appears on the display. Repeat to disable.
What is the maximum load capacity for a delicate wash?
For delicates, load no more than 2 kg to avoid damaging fabrics. Always check garment labels.
How to clean the lint filter (drain pump filter)?
Open the lower flap, unscrew the filter cover, and drain any water. Remove the filter and clean it under running water. Ensure it is securely tightened before reuse.
Why is my washing machine vibrating excessively?
Check that the transport bolts have been removed. Ensure the machine is level on all feet. Adjust the feet if necessary. Also avoid overloading.
What detergent should I use for my machine?
Use a high-efficiency (HE) detergent suitable for front-load washers. Follow the dosage instructions on the detergent pack, considering water hardness.
User questions about TF822-5 ELEKTRO HELIOS
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
No questions yet. Be the first to ask one.
Download the instructions for your Washing machine in PDF format for free! Find your manual TF822-5 - ELEKTRO HELIOS and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. TF822-5 by ELEKTRO HELIOS.
USER MANUAL TF822-5 ELEKTRO HELIOS
Placering
Avloppsanslutning
Table of contents
Click a title to access it
Manual assistant
Powered by Anthropic
Waiting for your message
Product information
Brand : ELEKTRO HELIOS
Model : TF822-5
Category : Washing machine
