Product Type	Freestanding Washing Machine
Brand	Elektro Helios
Model	TK703-2
Capacity	3.6 kg (cotton), 1.8 kg (synthetics)
Dimensions (H x W x D)	85 x 60 x 50 cm (approx.)
Weight	60 kg (approx.)
Power Supply	220-240V ~ 50Hz, 10A
Power Consumption	2200 W (heating), 500 W (motor)
Spin Speed	800 rpm
Wash Programs	Cotton, Synthetics, Delicates, Quick Wash, Rinse & Spin
Water Consumption	40-80 L per cycle (depending on program)
Energy Efficiency Class	C (older model)
Noise Level (Wash/Spin)	58 dB / 72 dB (approx.)
Drum Material	Stainless Steel
Door Opening	Side opening (left hinge)
Control Type	Mechanical dial and push buttons
Display	None (indicator lights)
Features	Overflow protection, adjustable feet, child lock
Maintenance	Clean lint filter monthly; descale every 3 months
Safety	Thermal fuse, door lock during operation
Spare Parts Availability	Door seal, pump filter, belt, heating element, drain pump
Repairability Index	7/10 (common parts, easy access)
Installation	Freestanding, requires cold water connection and drain hose
Certifications	CE, GS

Frequently Asked Questions - TK703-2 ELEKTRO HELIOS

How do I clean the lint filter?

Open the filter door at the bottom front, turn the filter counterclockwise, remove lint, rinse under water, and reinstall. Do this monthly.

What is the maximum load for cotton?

The maximum load for cotton is 3.6 kg. For synthetics, it's 1.8 kg.

How do I fix a draining problem?

Check if the drain hose is kinked or clogged. Also clean the pump filter. If issue persists, inspect the pump impeller.

What do I do if the machine doesn't start?

Ensure the door is fully closed, the power cord is plugged in, and the water supply is on. Check the fuse or circuit breaker.

Can I wash delicate fabrics?

Yes, use the Delicates program with cold water and a reduced spin speed. Place small items in a laundry bag.

How often should I descale the machine?

Descaling is recommended every 3 months using a descaler or citric acid. Run a hot empty cycle.

What are the dimensions of the TK703-2?

Approximately 85 x 60 x 50 cm (height x width x depth). Always measure your space before installation.

Is the drum stainless steel?

Yes, the drum is made of stainless steel, which is durable and resistant to rust.

How do I replace the door seal?

Remove the front panel, detach the seal from the drum and door frame, install a new seal, and secure it with bands. Disconnect power before starting.

Why is the spin cycle noisy?

Check for unbalanced loads, ensure the machine is level, and verify that shipping bolts are removed. Excessive noise may indicate worn bearings.

USER MANUAL TK703-2 ELEKTRO HELIOS

TK 703-2

Bruksanvisning

Käyttöohje

s

SF

3-14

15-28

Innehåll

Fig. 1

Fig. 2

Viktiga råd

Kapacitet

Bomull

max. 3,6 kg

Syntet

max. 1,8 kg

Tvättvikt

Fig. 7

Fig. 7a

Anmärkning:

Fig. 9
