USER MANUAL VC66B Khind

Abstract grayscale graphic with white silhouettes of a globe and abstract geometric shapes (no text or symbols)

••• Vacuum Cleaner / 吸尘机 / Pembersih Vakum

Instruction Manual / 说明指示书/Buku Panduan

Please read this manual carefully before operating this product. Keep this manual handy for further reference.

This manual is also available online.

Safety Precaution Information

Safety & warning information

1. Read the instruction manual carefully and follow the instruction closely.

2. Use only the attached parts which are supplied by the manufacturer.

3. This appliance is intended for household use only, commercial use will void warranty.

4. Do not leave the appliance unattended while it is connected to the main power outlet

5. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

6. Do not pull, lift or carry the appliance by its power cord. In order to avoid damages to the cord, do not pull the cord around sharp corners and edges.

7. Always switch off the power before unplugging the unit from the socket. Do not unplug by pulling and jerking the cord with force.

8. Do not handle the plug or the appliance with wet hands.

9. Do not vacuum the followings: corrosive or inflammable liquids, lighted cigarette butts, ash or matches, sharp objects or objects which could block and get stuck in the tube.

10. Do not use the appliance on wet surfaces

11. Make sure the household voltage is the same as that indicated on the rating label of the unit.

12. Do not use appliance without the filters.

13. Kept the appliance dry to protect against electric shock.

14. Keep appliance away from ovens and stoves etc.

15. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

Children should be supervised to ensure that they do not play with the appliance.

Note:

1) This appliance must only be used for domestic use.

2) It is not suitable for industrial or commercial use.

Cleaning & Maintenance

1. Always switch off the appliance, unplug from the mains and let the appliance cools down when the appliance is not in use or before cleaning or before putting on or taking off parts.

2. It is recommended to regularly clean the Dust Container and HEPA Filter.

3. Do not clean the appliance's surface with metal sourcing pads as it may scratch the surface or cause electrical shock. Use only a damp soft cloth to clean it.

4. Do not immerse the appliance into the water or other liquids when cleaning.

5. Do not use abrasive chemicals, cleaning solvents like petrol, thinner or benzene to clean the appliance.

Parts Identifications

Main Floor Brush

1. Plastic Plated Floor Brush (VC66B)

2. High Efficient Floor Brush (VC68P)

Tube

1. Plastic Tube x2 [VC66B]

2. Retractable Aluminium Telescopic Tube (VC68P)

3. Dust Container

4. Dust Container Bottom Lid Release Lever

5. ON/OFF Power Button

B. Motor Body

1. Power Cord

Accessories

Crevice Nozzle Wall Mount Base

HEPA Filter
Filter Outer Shelf

* Pictures are for illustration purpose only.

Specifications

Model

Voltage

Power

Suction power

Noise Level

Air Flow

Dust Container Capacity

Cable Length

Filtration Type

Net Weight

Product Dimension (LxWxH)mm

VC66B

: 220-240V-50-60Hz

: 600W

: 120W; 15kPa

: 80dB

: 78m³/h

: 0.8L

: 5m

: HEP4

. 2kg

: 375×135×220mm

VC68P

220-240V\~50-60Hz

600W

120W; 15kPa

80dB

78m3h

0.8L

6.8m

HEPA

2.2kg

375×135×220mm

* Specifications are subject to change without prior notice.

How to Use

1. Remove and assemble the extension tube and main Floor Brush or crevice nozzle from the box.

a. Insert the extension tube to the vacuum body

b. Insert the main floor brush or crevice nozzle to the extension tube

1. Connect to the power supply
2. Switch on the power supply and press the ON/OFF Power Button to start operating the vacuum.
3. The Dust Container should be emptied regularly to obtain consistent best results.
4. How to empty the dust container

a. Remove the extension tube then take it out

b. Press the release button c. Empty the dust container

How to Use

1. How to clean the HEPA filter from the Filter Outer Shelf.

a. Turn the Filter Outer Shelf anti-clockwise to detach from the dust container

b. Remove the HEPA Filter from the outer shelf

c. Tap the HEPA filter against the side of the dustbin to remove excess dust

d. Use the soft brush to remove dirt from the pleats

Note:

The appliance and the filter should be cleaned regularly in order to maintain the suction power.

1. Wall Mout Base for main unit and crevice brush.

a. Nail the wall mout base on the flat surface and insert the main unit into the base.

Line drawing of a vacuum cleaner with handle and base (no text or symbols)

b. Place the crevice nozzle next to the main unit

△安全注意事项

安全和警告信息

Line drawing of a vacuum cleaner with handle and base mount (no text or symbols)

b. 将缝隙吸嘴放在主机旁边

Line drawing of a vacuum cleaner with handle and base mount (no text or symbols)
