Product type	Compact digital camera with built-in zoom
Sensor	CCD 1/2.5 inch, 6.18 megapixels (effective 6.0 M)
Lens	Focal length 6.3–18.9 mm (equivalent 38–114 mm in 35 mm), aperture f/3.3–f/4, 11 elements in 9 groups including 3 aspherical
Optical / digital zoom	3x optical / 4x digital (combined 12x)
LCD screen	2.5 inch, low-reflection TFT color, approx. 115,000 pixels, brightness adjustment
Dimensions (W × H × D)	106.5 × 54.5 × 23 mm (excluding protrusions)
Weight	140 g (body only) / 155 g (with battery and SD card)
Power supply	Rechargeable lithium-ion battery D-LI8; charger D-BC8; optional AC adapter K-AC8
Battery life (CIPA)	Approx. 240 photos (flash used for 50% of shots)
Storage	Internal memory 10.5 MB + SD memory card (up to 128 MB tested)
Sensitivity	Auto / manual: 64, 100, 200, 400, 800 ISO
Shutter speed	4 s to 1/2000 s
Shooting modes	Green, Program, 23 scene modes (including underwater, portrait, animals, fireworks, text...), video, voice recording
Video	MOV (Motion JPEG) with mono sound; resolutions 640×480 or 320×240; frame rate 30 or 15 fps
Flash	Red-eye reduction auto flash; range 0.2–3.6 m (wide) / 0.5–3.0 m (tele)
Focus	Contrast detection AF (9 points); modes: normal, macro (1 cm), hyperfocal, landscape, manual
Waterproof	Compliant with JIS class 8 (water) and class 5 (dust) – IP58; underwater shooting up to 1.5 m for 30 min
Connections	PC/AV terminal (USB + video), external power input
Main functions	Video anti-shake, voice memo before/after shooting, digital filters, creative frame composition, editing (cropping, resizing, red-eye correction)
Maintenance and cleaning	Rinse with clean water after use in salty or dusty environments; do not use solvents; replace the sealing gasket once a year
Safety	Do not disassemble, avoid temperatures >40 °C, use only specified battery D-LI8
Spare parts and repairability	Battery D-LI8, charger D-BC8, adapter K-AC8, standard SD card; recommended service every 1–2 years
Warranty	12 months against manufacturing defects (excluding battery, normal use)

Frequently Asked Questions - OPTIO W10 PENTAX

Is the camera really waterproof? Can I take it underwater?

Yes, the Optio W10 complies with IP58 (JIS class 8 for water, class 5 for dust). You can use it underwater up to 1.5 meters depth for 30 minutes. Make sure the battery/card compartment is properly locked before immersion.

What types of battery can I use?

The camera uses exclusively the rechargeable lithium-ion battery D-LI8. Never use other batteries, they could explode or damage the camera. The included charger (D-BC8) fully charges the battery in about 100 minutes.

How do I maintain the waterproofing after a trip to the sea or beach?

After use in salty or sandy environments, turn off the camera, ensure the compartment is closed, then rinse it with running water or immerse it for a few minutes in a bowl of clean water. Wipe it with a soft cloth. Never use soap, detergent, or alcohol.

Can I use the camera without an SD memory card?

Yes, the camera has internal memory of approximately 10.5 MB. Photos and videos will be saved there automatically if no SD card is inserted. However, capacity is very limited (a few high-resolution images).

How do I record a video underwater?

Select the "Underwater Movie" mode in the shooting mode palette. This mode optimizes white balance and sensitivity for underwater results. Press the shutter button to start video recording, and press it again to stop.

What should I do if the screen displays "Battery exhausted"?

This message indicates the battery is depleted. Turn off the camera, open the compartment, remove the battery and recharge it with the D-BC8 charger. If the battery discharges very quickly after full charge, it is at the end of its life and should be replaced.

How do I transfer my photos to a computer?

Connect the camera to the computer using the supplied USB cable. Ensure the USB connection mode is set to "PC" (Settings menu > USB Connection). The computer will recognize the camera as a removable drive; you can then copy the files.

Can I print directly from the camera?

Yes, if your printer is PictBridge compatible. Connect the camera to the printer via USB cable, set the USB connection mode to "PictBridge", then select the images to print from the camera menu.

How can I recover a accidentally deleted photo?

The camera has an "Image Recovery" function. Go to the playback menu, open the playback mode palette, select the recovery icon, then choose the image to recover. Note: this function is only available if no new photo has been taken since deletion.

What are the recommended optional accessories?

Official accessories include: spare D-LI8 battery, K-AC8 AC adapter kit (for extended use), higher capacity SD memory card, and AV cable for TV viewing. The D-BC8 charger can be used abroad with a suitable plug adapter.

USER MANUAL OPTIO W10 PENTAX

Silver Pentax Opt® waterproof camera with visible lens and control buttons (no text-heavy elements)

QuickTime

PictBridge

Illustration of two people relaxing on a surface with waves and a beach in the background (no text or symbols)

Illustration of a hand holding a camera with a heart-shaped photo on screen, next to a dog (no text or symbols present)

Illustration of a smiling woman holding a camera, with a digital display showing flower symbols and flowers nearby (no text or symbols present)

Line drawing of a digital camera with lens and control panel (no text or symbols)

Appareil photo Optio W10

Line drawing of a U-shaped object with a loop handle and a small rectangular block on top (no text or symbols)

Courroie O-ST20 (*)

Simple line drawing of a circular object with concentric rings (no text or symbols)

Line drawing of a cable with connectors and connectors (no text or symbols)

Câble USB I-USB7 (*)

Line drawing of a coiled cable with two connectors (no text or symbols)

Câble AV I-AVC7 (*)

Batterie lithium-ion rechargeable D-LI8 (*)

Line drawing of a Pentax device housing with ports and mounting holes (no text or symbols)

Coiled black cable with two terminal connectors (no text or symbols visible)

Black-and-white beach scene with palm trees, a distant hilltop building, and a stone bridge (no visible text or symbols)

Black-and-white beach scene with palm trees and distant buildings, no visible text or symbols

Black-and-white beach scene with vehicles and a person, no visible text or symbols

Microscopic view of cellular structures under different conditions (no text or symbols visible)

Black-and-white beach scene with palm trees and water, no visible text or symbols

Black-and-white beach scene with palm trees and distant hills, no visible text or symbols

MENU

MENU

Black-and-white beach scene with palm trees and a distant island under cloudy sky (no text or symbols)

Black-and-white beach scene with palm trees and distant buildings, no visible text or symbols

Black-and-white beach scene with palm trees and distant hills under a cloudy sky (no text or symbols visible)

Nighttime cityscape featuring illuminated skyscrapers and a prominent tower (no visible text or signage)

③ Vidéo

Black-and-white photo of two young children framed within a heart-shaped decorative border (no text or symbols)

⑥ Paysage

Black-and-white landscape photo of a river valley with towering cliffs and forested banks (no text or symbols visible)

⑦ Fleur

Black and white close-up of a sunflower with visible petals and center (no text or symbols)

⑧ Portrait

Black-and-white portrait of a woman with long hair, wearing a sleeveless top (no text or symbols visible)

Black-and-white photo of a striped fish swimming on grass (no text or symbols visible)

Black and white illustration of a stylized fish with striped pattern next to a video camera icon (no text or symbols)

Black-and-white beach scene with a small boat on the water and distant clouds (no text or symbols visible)

Black-and-white photo of a child kicking up a soccer ball on grass (no text or symbols visible)

Black and white close-up photo of a fluffy dog (no text or symbols visible)

⑮ Lumière tamisée

Black-and-white photo of three lit candles in a lit indoor setting (no text or symbols visible)

16 Enfants

Black-and-white photo of two young girls outdoors, one holding a spoon (no text or symbols visible)

⑰ SOFT Doux

Black-and-white photo of a plush toy bear holding flowers (no text or symbols visible)

18 Auto-portrait

Black-and-white photo of two smiling young women (no text or symbols visible)

⑰ Feux d'artifice

Black and white photo of a fireworks display with multiple bright spikes against a dark background (no text or symbols visible)

20 Soleil couchant

Silhouette of a dramatic sky with scattered clouds and a bright sun at the center (no text or symbols visible)

⑳ Gastronomie

Black-and-white photo of a plated dish with various dishes and garnishes on a wooden table (no visible text or symbols)

22 Texte

Over the years PENTAX distinguished itself as a leader in the photographic industry. Today PENTAX proud to manufacture a variety of cameras, lens flashes and photo ories.

23 Musée

Black-and-white photo of a framed landscape painting on a wall, featuring mountains and trees (no text or symbols visible)

24 Ton chair naturel

Black-and-white portrait of a woman with long hair (no text or symbols visible)

25 Documents

Exterior view of a two-story house under construction with exposed wooden framing (no signage or text)

Black-and-white photo of a wooden pier with a gazebo on calm water, labeled 'Mode Vert' and 'Correction IL' (no other text or symbols)

Black-and-white photo of a wooden pier with a gazebo on calm water, no visible text or symbols in the main scene.

Black-and-white beach scene with palm trees, a distant building, and a shoreline (no visible text or symbols)

Black-and-white beach scene with palm trees, a small lock icon, and camera app icons (no readable text or symbols)

Grid of grayscale image thumbnails including heart, frame, and pixelated shapes (no text or symbols)

Heart-shaped collage photo of a wolf with decorative border (no text or symbols)

Black-and-white portrait of a person with a facial expression, no visible text or symbols

Black-and-white photo of a dog resting on a wooden structure, with no visible text or symbols.

Black-and-white photo of a sleeping dog on a bench, with timestamp and window controls visible (no readable text or symbols)

Row of 12 icons including parking, flowers, animals, and buildings (no text or symbols)

Utilisation du zoom

Black-and-white landscape photo showing a riverbank with trees and a small boat, no visible text or symbols

Barre zoom

Black-and-white photo of a boat on a river with decorative foliage in the background (no visible text or symbols)

Abstract white silhouette on gray background, no text or symbols present

Image correcte

Abstract white silhouette on gray background, no text or symbols present

Image lumineuse

Abstract grayscale shape with a white wavy base and a smooth peak, no text or symbols present.

Exterior view of a modern building with a curved roof and surrounding trees (no signage or text visible)

Bouton de navigation (▲▼◀▶)

Black and white photo of a dolphin leaping out of water, with date and time stamps (no readable text or symbols)

Grid of six black-and-white beach and tourism photos including a tropical island, palm trees, city skyline, beach, and water (no text or symbols)

Grid of grayscale camera and terrain render options (no text or symbols)

Black-and-white photo of a wooden pier by the sea, no visible text or symbols

Black-and-white photo of a wooden pier with a traditional pavilion on calm water, no visible text or symbols.

Heart-shaped collage image of a wolf face, no text or symbols present

Close-up of a dog inside a heart-shaped frame, no visible text or symbols on the image itself.

Black-and-white photo of a wooden pier by the sea with a camera app interface overlay (no readable text or symbols in the scene)

Satellite image showing a clock face with a pointer and surrounding light spots (no readable text or symbols)

Black-and-white beach scene with palm trees, distant buildings, and a lake (no visible text or symbols)

Affichage du menu [✗️ Réglages]

Black-and-white beach scene with palm trees and distant hills, no visible text or symbols

Satellite image showing a bright object with a pointed arrow pointing to it, surrounded by faint circular spots (no readable text or symbols)

Batterie lithium-ion rechargeable D-LI8 (\*)

Câble USB I-USB7 (*)

Câble AV I-AVC7 (*)

Courroie

O-ST20 (*)

For customers in USA

STATEMENT OF FCC COMPLIANCE

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Changes or modifications not approved by the party responsible for compliance could void the user's authority to operate the equipment.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

* Consult the dealer or an experienced radio/TV technician for help.

For customers in Canada

This Class B digital apparatus meets all requirements of the Canadian Interference - Causing Equipment Regulations.

Declaration of Conformity

According to 47CFR, Parts 2 and 15 for

Class B Personal Computers and Peripherals

We: PENTAX Imaging Company A Division of PENTAX of America, Inc.

Located at: 600 12 ^th Street, Suite 300 Golden, Colorado 80401 U.S.A. Phone: [phone] FAX: [phone]

Declare under sole responsibility that the product identified herein complies with 47CFR Parts 2 and 15 of the FCC rules as a Class B digital device. Each product marketed is identical to the representative unit tested and found to be compliant with the standards. Records maintained continue to reflect the equipment being produced can be expected to be within the variation accepted, due to quantity production and testing on the statistical basis as required by 47CFR §2.909.

Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. The above named party is responsible for ensuring that the equipment complies with the standards of 47CFR §15.101 to §15.109.

Product Name: PENTAX Digital Still Camera

Model Number: Optio W10

Contact person: Customer Service Manager

Date and Place: February, 2006, Colorado

Bouton OK/DISPLAY 45, 47

Bouton vert Ⓞ 44, 46, 58

Bouton ▶ 44, 47
