EMK-218 - Cooker WILFA - Free user manual and instructions

Brand	Wilfa
Model	EMK-218
Product Type	Tabletop oven with grill and hotplates
Dimensions (H x W x D)	330 x 585 x 420 mm
Net Weight	17.9 kg
Oven Volume	22 liters
Power Supply	220-240 V~ (EU standard)
Lower Heater Power	650 W
Upper Heater Power	500 W
Grill Power	1000 W
Large Hotplate Power (Ø180)	1500 W
Small Hotplate Power (Ø145)	1000 W
Temperature Range	50°C - 300°C
Oven Functions	Lower heat, upper heat, both, grill
Hotplate Positions	6 settings (0-6)
Safety Features	Automatic shutdown of large hotplate when oven is used; requires 25 mm side clearance and 500 mm above
Cleaning Instructions	Unplug and cool before cleaning; wipe with damp soapy cloth; use suitable cleaner for hotplates
Warranty	5 years from purchase date for household use
Spare Parts & Support	Available at wilfa.com
Certifications	CE marked

Frequently Asked Questions - EMK-218 WILFA

What is the oven capacity of the Wilfa EMK-218?

The oven has a 22-liter capacity, suitable for moderate-sized dishes.

Can I use the large hotplate and oven at the same time?

No, the large hotplate (Ø180, 1500W) automatically switches off when the oven is in use. You can use the small hotplate independently.

How do I burn off the protective coating before first use?

Heat the hotplates at setting 3 for 8 minutes, then heat the oven at 200°C for 15 minutes, and finally run the grill for 15 minutes with the door open. Ensure good ventilation.

What are the recommended cooking times and temperatures for common foods?

For example: bread at 180-200°C for 40-60 min, pastry at 180-200°C for 20-40 min, pizza at 180-200°C for 20-25 min, chicken at 200°C to max for 60-100 min. Times may vary based on voltage and food quantity.

How should I clean the Wilfa EMK-218?

Unplug and let it cool completely. Wipe the interior and exterior with a damp cloth and mild soapy water. Clean hotplates with a suitable cleaner. Never immerse in water or use sharp tools.

What safety precautions should I take?

Keep a 25 mm gap behind and beside the appliance, and at least 500 mm above. Avoid placing near flammable materials. The sides and hotplates get hot during use. Supervise children and do not use outdoors.

Does the Wilfa EMK-218 have a timer?

No, the model does not include an automatic timer. You need to monitor cooking time manually.

What is the warranty period?

Wilfa offers a 5-year warranty from the date of purchase for private household use. It covers production defects but not misuse, unauthorized repairs, or normal wear.

Where can I find spare parts or support?

Visit wilfa.com and go to the customer service/support page for spare parts, FAQs, tips, and contact information.

Can the appliance be used with an external timer or remote control?

No, the appliance is not intended to be operated by an external timer or separate remote-control system.

USER MANUAL EMK-218 WILFA

Front view of a white kitchen toaster oven with control knobs and a blank display (no visible text or symbols)

HYBEL

MINI KITCHENER EMK-218

EN · Instruction manual

NO · Bruksanvisning

SE · Bruksanvisning

INSTRUCTIONS FOR USE – TABLETOP OVEN INSTALLATION AND SAFETY PRECAUTIONS

EN

- Before use the appliance must be checked for transportation damage, in cases of damage that might affect safety, do not use the appliance. Contact an authorized service centre.

- Only plug the appliance on a flat surface.

- The diameters of the bases of the saucepans used should not be smaller than the diameters of the hotplates.

- Place the tabletop oven on a surface with a constant temperature, but not too near a wall. See installation bellow.

- CAUTION: overheated food fats can spontaneously ignite!

- Ensure that children cannot reach or open the tabletop oven when it is hot.

- During use the sides and hotplates will become hot. Take care to avoid burns.

- Keep easily inflammable materials away from the appliance.

- Do not allow children to remain in the vicinity of a turned on or hot oven unsupervised.

- Do not use the appliance outdoors.

- The appliance must not be placed near open flames or other sources of heat.

- The tabletop oven must not be immersed in water or rinsed off under running water.

• Do not pull on the cord when unplugging. Pull on the plug itself.
• The tabletop oven must not be lifted by the handle/ oven door.
• Do not allow the cord to hang over the edge of worktops or similar.
  • Always unplug the appliance prior to cleaning it.
• Should the tabletop oven be used for purposes other than those it is intended for, the user must him or herself bear responsibility for any damage.
• Do not use the appliance if the cord is damaged. If the tabletop oven is not functioning as it should, is dropped on the floor or is damaged in any other way, it must be taken to an authorized service centre.
• Is the cable damaged, it must be replaced by authorized service personnel.
• Is there damage to the device or that it does not work, it must be serviced only by authorized personnel.

EN

- This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children unless they are older than 8 and supervised. Keep the appliance and its cord out of reach of children less than 8 years.

- Appliance is not intended to be operated by means of an external timer or separate remote-control system.

- NB! This tabletop oven is intended for normal domestic use only.

USE

The hotplates are controlled by the switches with symbols. Each hotplate has different power settings.

SWITCHES POSITION	0 1 2 3 4 5 6
∅145 Hot plate 0 115W 207W 310W	600W 875W 1000W
∅180 Hot plate 0 140W 230W 315W	855W 1140W 1500W

INSTALLATION

This tabletop oven must be placed on a surface with a constant temperature. It must have gaps of at least 25 mm behind it and to its sides so that the ventilation can work properly. There must be a gap of at least 500 mm above the hotplates. Ensure that there are no inflammable materials near the tabletop oven since the sides become hot during use. Check that the voltage on the rating plate complies with the electricity supply network's voltage.

PRIOR TO USE

Ensure that the room is well ventilated during the burning in process. The smoke that will be generated is not dangerous and will not last long, though you should avoid inhaling it directly. Allow oven door to remain open during steps 2 and 3.

1. Hotplates

Heat the hotplates at setting 3 and allow them to stay on for about 8 minutes. This process is necessary to burn away the hotplates protective layers.

EN

2. Oven

Remove the grill and baking tray. Set the oven to 200°C and allow it to stay on for about 15 minutes. This process is necessary to burn away the oven's protective layer.

3. Grill

To burn away the grill's protective layer, set the oven switch to the grill position. Turn the switch the clock to the grill symbol. Allow the grill to stay on for about 15 minutes.

	Upper and lower heating elementIn this position, the heat of the over may be adjusted to the desire heat via the termostat. When the heat of the oven reaches the desired heat, the signal lamp below the switch turns off.
	Lower heating element only
	Upper heating element only
	When using the oven, the large hotplate will automatically switch off. You cannot use the large hotplate and the oven at the same time.
	GrillKeep the door of the oven open while grilling

FOOD HEAT COOKING TIME THE POSITION OF SHELF
Bread 180-200° 40-60 min.		Middle shelf
Pastry 180-200°		20-40 min. Middle shelf
Beurek 180-220° 40-50 min.		Middle shelf
Cake 160-180°	35-45 min. Middle shelf
Cookie 170-180°	35-45 min. Middle shelf
Pizza 180-200°	20-25 min. Middle shelf
Lamb 200-MAX°	60-120 min. Middle shelf
Mutton 200-MAX°	60-120 min Middle shelf
Beef	200-MAX°	60-120 min Middle shelf
Turkey	200-MAX°	60-100 min Middle shelf
Chicken	200-MAX°	60-100 min. Middle shelf
Fish	200-MAX°	30-40 min. Middle shelf

Kindly note that, the above mentioned cooking times is obtained laboratory conditions. These cooking times can be changed according to line standby voltage, the amount of food and the pre-cooking process that before put in the mini kitchen. Your suitable heat and cooking time can be different from the above mentioned heat and cooking time.

MAINTEANCE AND CLEANING

Set the power switch to 0, pull the plug out of the power socket and allow the tabletop oven to cool down before you clean it. Wipe down the appliance inside and outside with a damp cloth, moistened with soapy water only. Clean the hot-plates with a suitable cleaner. Do not use sharp instruments for cleaning.

TECHNICAL SPECIFICATIONS

Characteristics EMK-218
Lower heater 650 W
Upper heater 500 W
Grill 1000 W
∅180 Hot plate 1500 W
∅145 Hot plate 1000 W
Termostat 50°-300°
Timer -
Dimensions 585 x 420 x 330
Net weight 17,9 kg
Gross weight 20,6 kg
Volume 22 liter

EN

GUARANTEE

Wilfa issues a 5 year guarantee on this product from the day of purchase is done. The guarantee covers production failure or defects that arise during the guarantee period. Your purchase receipt works as proof towards retailer if claiming your guarantee.

The guarantee is valid only for products that are bought and used in private households. The guarantee is not valid if the product is used commercially. The guarantee is not valid if the product is misused, used by negligence, if not following instructions given by Wilfa, if modified or if unauthorized reparation is done. The guarantee is also not valid for normal wear of the product, misuse, lack of maintenance, use of wrong electrical voltage or:

• Overloading of product
- Parts which are normally worn down

Instructions manual is also available at our website wilfa.com

EN

SUPPORT AND SPARE PARTS

For support please visit us at wilfa.com, and see our customer service/support page. Here you will find frequently asked questions, spare parts, tips and tricks and all our contact information.

RECYCLABILITY

This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where the product was purchased. They can take this product for environmentally safe recycling free of charge.

EN

BRUKSANVISNING FOR HYBELKOMFYR M/GRILL INSTALLERING OG SIKKERHETSADVARSLER

VARMETRIN 0 1 2 3 4 5 6
∅145 KOGEPLATE 0	115W	W 207W 3	10W 600W	W 875W 1	1000W
∅180 KOGEPLATE 0	140W	W 230W 3	15W 855W	W 1140W	1500W

INSTALLERING

VEDLIKEHOLDELSE OG RENG∅RING
