USER MANUAL TSA4101 Teesa

Instant water heater

TSA4101

Technical line drawing of a mechanical assembly with no visible text or symbols

Technical line drawing of a kitchen sink assembly with handle and faucet (no text or labels)

Wasserfilter:

Thank you for purchasing TEESA appliance. Read this instruction manual and keep it for future reference. Producer does not take responsibility for damages caused by inappropriate handling and use of the product.

SAFETY INSTRUCTIONS

In order to reduce the risk of injuries or damages, follow basic safety precautions applied when using any electrical device, including the following:

1. This product should be used only after it has been correctly and safely connected to constant and stable power source and water source.
2. DO NOT use this product outdoors. This device is intended for household, indoor use and water heating only.
3. DO NOT install this product in vicinity (distance should be at least 0,4 m from the main body) of heat non-resistant or flammable objects (wood, plastic, wallpaper etc.).
4. It is prohibited to leave any kind of cloth, paper towels, wiper and/or any kitchen utensil on or near the faucet at any time.
5. The instant water heating faucet must be installed vertically, other angles are forbidden. Please refer to the "Installation and connection" for correct installation.
6. To avoid circuit overload, DO NOT operate another appliance on the same socket.
7. If your power grid is weak, try not to use other, high-power electric appliances (air conditioner, microwave oven, etc.) while operating this device.
8. This device is not intended to be operated by means of an external timer or separate remote-control system.
9. This device is equipped with a grounded plug. Please ensure the wall outlet in your house is well earthed. This device must be safely grounded.
10. When you disconnect the power cord of the device, grasp and pull the plug, not the cord/cable.
11. Make sure the power cord does not touch any hot or sharp elements.
12. Fixed power cable may only be replaced in an authorized service point.
13. This appliance may be used by children who are above 8 years old and by persons with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, if they are supervised and guided by a person who is responsible for their safety in a cautious manner for all the safety precautions being understood and followed. Children should be supervised to ensure that they do not play with the appliance. Children should not perform cleaning and servicing of the device unsupervised.
14. Keep the device out of the reach of children
15. Do not use the product for purposes different from displayed in this operating manual.
16. Do not leave the appliance unattended when it's working.
17. Do not install in places with freezing temperatures. Do not switch on if there is a possibility that water is frozen either in the plumbing or faucet itself.
18. This device should never operate empty/dry or frozen because such action could result in appliance failure and/or injuries to the user.
19. If the device is not going to be used in winter and there is a risk of the water pipeline or the device freezing, it is recommended to unplug the device and empty water circuit.
20. This device is an open-outlet water heater, where the outlet must not be connected to any other tap or fitting equipment that might impede circulation.

21. Do not attempt to repair this device yourself. Only authorized and qualified personnel may repair this device. Never disassemble this device.

22. ALWAYS disconnect the product form the power mains when it is not in use or before cleaning/maintenance.

23. If the device is not working as it should, has received a sharp blow, has been dropped, damaged, left outdoors or dropped into water, do not use it.
24. It is strongly advised to unplug the device from the power supply if left unused for prolonged period of time (24 h).

* Pictures included in this user's manual are for reference only and they may differ from the actual product.

INSTALLATION AND CONNECTION

Note: The device should be installed only by qualified specialist.

1. Before installing the device, turn off the water.
2. Check the power and water supply route and based on that choose one of the following installation methods:

- If the power supply source is BELOW the sink: Make sure that the rubber gasket (6) sits tightly against the base of main body with its flat side facing down and flap aligned with main body recess. Guide the faucet's water inlet tube (5) through the hole in the sink/counter. From the bottom (thread below the sink) slide the spacer (7) and screw on a fastening nut (8),

Technical line drawing of a mechanical assembly with no visible text or symbols

- If the power source is ABOVE the sink: Slide the spacer (7) with recessed side facing upwards – on the faucet's water inlet tube (5), followed by the rubber gasket (6). Guide the faucet's water inlet tube (5) trough the hole in the sink. From bottom (below the sink) screw on a fastening nut (8).

Technical line drawing of a bathroom sink assembly with faucet and fixtures (no text or labels)

EN

NOTE: No matter the location – make sure the power source is well protected from water (splashes or leakage). If that is not the case, do not install the faucet to prevent personal or product damage.

1. Connect water source hose well to the faucet's water inlet tube. Make sure there are no leaks or tension.
2. Make sure the control handle is in closed position. Open water source, slowly move faucet's handle and spout left and right to check and identify possible leakage before usage.
   Note: Water source should be turned on before plugging into power supply to ensure that there is no water leakage on any joint.

reesa

1. Insert power cable's plug into grounded power source socket nearby. WARNING! Make sure that no electrical power cable extensions are used, there are no sharp edges rubbing against it and that it is not or could not be exposed to water. Do not modify the power cable or its plug in any way.
2. After inserting the plug into the socket rotate the handle downwards (cold water) until water flows through nozzle. Now rotate the handle upwards (hot water). The display should turn on indicating the heater is working and outlet temperature of the water should rise. Rotate the handle back to the closed position – the display should turn off.
3. Installation of the faucet is completed.

OPERATION

There are three zones of the handle: hot water zone, closed position and cold water zone:

• to increase the flow of cold water, rotate the handle downwards,
• to increase the flow of hot water, rotate the handle upwards,
• to stop the water flow, set the handle in the closed position.

NOTE: Make sure to always leave the control handle in closed position after usage.

NOTE: The temperature of hot water decreases with the intensity of its flow rate. The temperature will gradually increase and reach balance point in few seconds after turning to the hot(er) water zone. There is no consumption of electricity when handle is in cold water or closed position.

The spout can be rotated 120° according to the needs.

1. Hot water position
2. Closed position (in this position clicking sound is audible)
3. Cold water position

Fogoo

wher's manual owner's manual

OVERHEATING PROTECTION

When the water temperature reaches 110°C, the power will be instantly cut off to stop heating.

CLEANING AND MAINTENANCE

Nozzle:

When water flow becomes disrupted or low, the water nozzle needs to be descaled.

1. Unscrew the nozzle (2) counterclockwise and remove the rubber gasket (1). Do not remove any other parts from the spout.
2. Flush all parts with water.
3. Use a descaling agent (for example Teesa descaler) to descale the nozzle. Follow the instructions provided by the producer on how to descale.

Notes:

• The nozzle should be descaled according to water/usage conditions but not later than every 6 months.
  • The nozzle should be cleaned regularly.
• Pouring cold water for a few seconds after each usage of hot water can significantly reduce limestone accumulation.

Water filter:

If the flow becomes weaker after faucet has been used for a period of time, the filter net needs to be descaled.

1. Remove the water source hose, located and gently remove the filter net (2) from water inlet (1) as shown in the picture beside.
2. Use a descaling agent (for example Teesa descaler) to descale the filter net. Follow the instructions provided by the producer on how to descale.

Note: Teesa descaler (TSA0010) is available for purchase online at www.teesa.pl or www.rebelelectro.com.

You can also use another descaling agent for that purpose.

Housing:

Clean the housing with a soft, slightly wet cloth. Do not use any abrasives or chemical agents to clean this device.

TROUBLESHOOTING

Problem	Solution
The device does not heat water	Check the power connectionMake sure the water flows freely through the deviceMake sure that the filter net located in the water inlet as well as the spout nozzle are not clogged. If necessary, clean those parts
The device is leaking	Check the tightness of the connections of the water heater with the water source hose. If necessary, install seals at the connection point
The outlet water temperature is too hot or the outlet water volume is too low	Check if the water pressure is too low, increase the water flow if necessaryMake sure that the filter net located in the water inlet as well as the spout nozzle are not clogged. If necessary, clean those parts

SPECIFICATION

MAIN FEATURES

Installation on the counter or sink

LED display with temperature display Spout angle adjustment up to 120°

Hot and cold water control handle

Overheating protection (110°C)

TECHNICAL DATA

Output (Δt=25°C): 1,9 l/min
Output (Δt=35°C): 1.4 l/min
Recommended cable section: 3 x 1,5 mm ^2
Water connection: G ½"
Working pressure: 0,04 - 0,6 MPa

Spout length: 192 mm

Material:

Heating element: stainless steel 304

Housing: ABS

IP rating: IPX4

Protection class: I

Rated current: 14.5 A

Rated power: 3500 W

Power supply: 220 - 240 V\~, 50/60 Hz

PHYSICAL PARAMETERS

Weight: 910 g

Dimensions: 192 x 99 x 229 mm

Power cable length: 1 m

English

Correct Disposal of This Product

(Waste Electrical & Electronic Equipment)

[Applicable in the European Union and other European countries with separate collection systems] This marking shown on the product or its literature. Indicates that it should not be disposed with other household wastes at the end of its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources. Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take this item for environmentally safe recycling. Business users should contact their supplier and check the terms and conditions of the purchase contract. This product should not be mixed with other commercial wastes for disposal.

Made in China for Lechpol Electronics Leszek Sp.k., ul. Garwolińska 1, 08-400 Miętne.
